YZU-SRCED2Remote Control Electronic Door Lock

REMOTE CONTROL ELECTRONIC DEADBOLT www.SimpliciKey.com 1 (800) 785-6595 Keep this code safe Mantén este código en un lugar seguro Place Label Here Coloca la Etiqueta Aquí Default Admin Code/Código Predeterminado de Administrador © SimpliciKey 2010, 2011 Lifetime limited finish and mechanical warranty 2-year electronic warranty Garantía limitada de por vida para el acabado y el sistema mecánico Garantía de 2 años para el sistema electrónico This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference received, including interference that may cause undesired operations Troubleshooting Tips: Resolución de problemas Question Check to make sure both wires are connected. (page 5) Asegúrese de que ambos cables estén conectados. (página 5) Check that the batteries are installed correctly. (page 6) Compruebe que las pilas están instaladas correctamente. (página 6) Check that the deadbolt is retracted and the thumbturn is vertical during installation. (page 5) Revise que el pestillo esté retraido y la perilla esté vertical. (página 5) Why doesn’t my pre-programmed keyfob get a response from the lock? ¿Por qué mi llavero pre-programado no obtiene respuesta de la cerradura? Check to make sure both wires are connected. (page 5) Asegúrese de que ambos cables estén conectados. (página 5) Check that the batteries are installed correctly. (page 6) Compruebe que las pilas están instaladas correctamente. (página 6) Why doesn’t the keypad respond when I press the buttons? ¿Por qué no responde el teclado al pulsar los botones? Why does the auto-locate feature keep giving me an error tone during installation? ¿Por qué la función de auto-localización me sigue dando un tono de error? Solution Why does the lock give an error tone when the door is closed and lock button is pressed? ¿Por qué la cerradura da un tono de error cuando se cierra la puerta y el botton de cerrar se presiona? Manually check the deadbolt to make sure it is aligned with the strike plate. (pages 4, 6) Revise manualmente el pestillo para asegurarse que esta alineado con la placa de cierre (páginas 4, 6) Changes or modications not expressly approved by SimpliciKey could void the user's authority to operate the equipment. Parts List 1 interior plate First things rst—make sure you have all of the necessary components in your SimpliciKey package. 2 remote control keyfobs 1 deadbolt lock 1 strike plate 1 reinforcement plate 1 strike box 2 keys 2 short wood screws 2 long wood screws 2 long bolts 2 strike wood screws 2 short bolts 1 interior lock 1 exterior lock 2 Código Predeterminado de Administrador 11 Para Cambiar tu Código de Administrador Ingresa tu Código Predeterminado de Administrador (ver abajo) o el Código de Administrador Válido y presiona la tecla * para activar la modalidad de Administrador. Recomendamos que anotes tu nuevo Código de Administrador aquí y guardes este manual en un lugar seguro. Nuevo Código de Administrador En este momento recibirás un tono de conrmación nal y el teclado se iluminará dos veces para informarte que el Código de Administrador ha sido cambiado. Si en cualquier momento durante la modalidad de administrador el teclado parpadea y se activa una alerta de varios tonos, has tomado demasiado tiempo y tendrás que empezar de nuevo desde el primer paso. Punto Esencial Para nalizar, ingresa una vez más el nuevo Código de Administrador de 4 a 6 dígitos y oprime la tecla *. Nuevo Código de Administrador Luego, ingresa un nuevo Código de Administrador de 4 a 6 dígitos y oprime la tecla *. Nuevo Código de Administrador Nuevo Código de Administrador A continuación, ingresa ADMIN (23646) en el teclado y oprime la tecla *. A - D - M - I - N - ADVERTENCIA: SimpliciKey advierte que ninguna cerradura por sí sola ofrece seguridad completa. Al igual que con cualquier otro dispositivo de cierre mecánico y electrónico, existe la posibilidad de que esta cerradura sea vulnerada. Les recordamos a nuestros clientes que deben seguir procedimientos apropiados de seguridad como parte del plan de protección de su hogar. Las cerraduras SimpliciKey cumplen con las especificaciones de Grado 2 de ANSI. Para incrementar la seguridad consulta a un cerrajero calificado o a un experto en seguridad. 3 1. Remove Existing Deadbolt LOCK INSTALLATION INSTRUCTIONS 2. Check Cutout Size 2 1/8” 1” 3. Install New Deadbolt First, remove the two interior screws securing the lock. Next, remove the interior and exterior lock components. Finally, take out the existing deadbolt slide assembly. Place deadbolt into door, check to see if cross-hairs are centered. To adjust the deadbolt length, twist the deadbolt slide assembly to extend and center in cutout. Make sure cross-hairs are on the lower part of the assembly. Check that the plate sits ush with the door. Secure the deadbolt plate to the door with two short wood screws. Cross-hairs 180° Stop to measure the cutouts for the lock components. If the main cutout is 2-1/8 inches in diameter, and latch cutout is 1 inch, you're ready to go. If not, you may need to use the Advanced Guide to help you adjust your door. Critical Point Mando Función de Cierre Silencioso Función Cierre Sencillo Función de Reinicio Maestro 2. Ingresa "LOCK" (ASEGURAR) y oprime * Para ACTIVAR el cierre sencillo oprime 1,* y repite Para DESACTIVAR el cierre sencillo, oprime 2,* y repite 2. Ingresa "SOUND" (SONIDO) y oprime * Para ACTIVAR los sonidos oprime 1,* y repite Para DESACTIVAR los sonidos oprime 2,* y repite Te permite cerrar con seguro sin tener que ingresar el Código de Acceso. Borra todos los códigos y configuraciones almacenadas. 1. Ingresa el Código de Administrador 1. Ingresa el Código de Administrador Enciende/apaga los sonidos del teclado Tu código de Administrador (Admin Code) se encuentra al dorso de este folleto. El Admin Code puede cambiarse siguiendo las instrucciones en la pág…

Text truncated - open the document above for the full version.

Changes or modications not expressly approved by Simplicikey could void the user's authority to operate the equipment. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

CKC Certification Services, LLC CB: US0103; NB: 0976 4933 Sierra Pines Drive Mariposa, CA 95338 Domestic Phone: 1 800-500-4EMC (4362) Domestic FAX: 1 866-779-9776 International Phone: +1 209-966-5240 International Fax: +1 858-300-5341 Looking for FCC, IC, CE or iDA approvals? CKC Certification Services provides Radio Equipment Certifications FAST! Go to http://www.ckccertification.com for more information. October 7, 2011 To Whom It May Concern: Regarding FCC submission: YZU-SRCED2; this application was originally filed on 7/19/2011 with an incorrect FCC ID. The FCC ID listed in the ID label exhibit file and the confidentiality letter exhibit were correct, however due to an administrative error on the original application form, the application was filed without the hyphen. A corrected application was obtained, and the filing corrected. No change was necessary to any previously provided exhibits. Should you have any questions or require clarification, please feel free to contact us. Thank you, Randal Clark CKC Certification Services Manager

SimpliciKey, LLC. Model: SRCED-2 Battery: 4xAA 1.5V This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference received, including interference that may cause undesired operations 1.00” 0.75” FCC ID: YZU-SRCED2 IC: 9379A-SRCED2 SimpliciKey, LLC. Model: SRCED-2 Battery: 4xAA 1.5V This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference received, including interference that may cause undesired operations FCC ID: YZU-SRCED2 IC: 9379A-SRCED2 0.45” 0.19” 0.74” SimpliciKey, LLC. Model: SRCED-FB Battery: CR2025 3V FCC ID: YZU-SRCEDFB IC: 9379A-SRCEDFB SimpliciKey, LLC. Model: SRCED-FB Battery: CR2025 3V FCC ID: YZU-SRCEDFB IC: 9379A-SRCEDFB 0.45” 0.19” 0.74” SimpliciKey, LLC. Model: SRCED-FB Battery: CR2025 3V FCC ID: YZU-SRCEDFB IC: 9379A-SRCEDFB

This report contains a total of 30 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. EWA, Inc. (Electronic Warfare Associates, Inc.) ADDENDUM TEST REPORT TO 91974‐5 Lock, SRCED‐2 Tested To The Following Standards: FCC Part 15 Subpart C Section 15.249 and RSS‐210 Issue 8 Report No.: 91974‐5A Date of issue: July 1, 2011 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long‐term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2of 30 Report No.: 91974‐5A TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C ................................................................................................................................... 7 15.249(a) Carrier & Spurious Emissions .................................................................................................................... 7 ‐20dBc Occupied Bandwidth ..................................................................................................................................... 9 Bandedge ................................................................................................................................................................. 11 15.249(d) Field Strength Of Spurious Emissions ...................................................................................................... 14 RSS‐210 ....................................................................................................................................................... 27 99 % Bandwidth ....................................................................................................................................................... 27 Supplemental Information .......................................................................................................................... 29 Measurement Uncertainty ...................................................................................................................................... 29 Emissions Test Details .............................................................................................................................................. 29 Page 3of 30 Report No.: 91974‐5A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: EWA, Inc. (Electronic Warfare Associates, Inc.) 13873 Park Center Rd. Suite 500 Herndon, VA 20171 Joyce Walker CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Jason Pizzillo Project Number: 91071 DATE OF EQUIPMENT RECEIPT: May 27, 2011 DATE(S) OF TESTING: May 27 ‐June1, 2011 Revision History Original: Testing of the Lock, SRCED‐2 to FCC Part 15 Subpart C Section 15.249 and RSS‐210 Issue 8. Addendum A: To revise the data in sequence 9 of section 15.249(d) to include the 40 dB correction factor and also correct an error in the RBW that was listed on the data sheet. No new test data was added. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4of 30 Report No.: 91974‐5A Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 1120 Fulton Place Fremont, CA 94539 Site Registration & Accreditation Information Location CB …
