YZZGHP62XCompact Hotel Phone

GHP620 GHP621 Compact Hotel Phone Quick Installation Guide Grandstream Networks, Inc. 126 Brookline Ave, 3rd Floor Boston, MA 02215. USA T el : +1 (617) 566 - 9300 Fax: +1 (617) 249 - 1987 www.grandstream.com For Certification, Warranty and RMA information, please visit www.grandstream.com ~ 1 ~~ 2 ~ PACKAGE CONTENT: PRECAUTIONS: W ARNING: Please DO NOT power cycle the GHP620 and GHP621 during system bootup or firmware upgra de. Y ou may corrupt firmware image files and cause the unit to malfunction. 1x GHP62X Phone 1x Base Stand 1x Handset 1x Faceplate 1x RJ11(4P4C) Phone Cord 1x Quick Installa- tion Guide The GHP620 and GHP621 are not pre-confgured to support or carry emergency calls to any type of hospital, law enforcement agency, medical care unit (“Emergency Service(s)”), or any other kind of Emergency Service. You must make additional arrangements to access Emergency Services. It is your responsibility to purchase SIP-com- pliant Internet telephone service, properly configure the GHP620/ GHP621 to use that service, and peri - odically test your configuration to confirm that it works as you expect. If you do not do so, it is your responsibility to purchase traditional wireless or landline telephone services to access Emergency Services. GRANDSTREAM DOES NOT PROVIDE CONNECTIONS TO EMERGENCY SERVICES VIA THE GHP620 AND THE GHP621. NEITHER GRANDSTREAM NOR ITS OFFICERS, EMPLOYEES OR AFFILIATES MAY BE HELD LIABLE FOR ANY CLAIM, DAMAGE, OR LOSS. YOU HEREBY WAIVE ANY AND ALL SUCH CLAIMS OR CAUSES OF ACTION ARISING FROM OR RELATING TO YOUR INABILITY TO USE THE GHP620 AND GHP621 TO CONTACT EMERGENCY SERVICES, AND YOUR FAILURE TO MAKE ADDITIONAL ARRANGE- MENTS TO ACCESS EMERGENCY SERVICES IN ACCORDANCE WITH THE IMMEDIATELY PRECEDING PARAGRAPH. The GNU GPL license terms are incorporated into the device firmware and can be accessed via the Web user interface of the device at http(s)://IP/#/gpl_license. To obtain a CD with GPL source code information please submit a written request to [email protected] EN OVERVIEW: The GHP series of hotel phones feature the GHP620 and the GHP621, easy-to-use IP phones for any hotel room that can be programmed and customized based on the needs of the hotel and their guests. The GHP series features of the series include; one HD speaker on each handset, 2 SIP accounts/lines, 6 programmable keys, 10 speed dial keys, 3-way voice conferencing, full band Opus voice codec, and advanced jitter-resilience algorithm that tolerates up to 30% packet loss without impacting voice quality. The series is supported by Grandstream’s Device Management System (GDMS), which provides a centralized interface to configure, provision, manage and monitor the deployment of Grand-stream endpoints. GHP series IP phones can be installed on desktop or wall-mounted, and powered by PoE (GHP620/GHP621) and USB Type C charging. Its compact design makes it perfect for any hotel deployment. These IP Phones could also be used for deployments in settings such as hospitals, apartments, dor- mitories, and more. ~ 3 ~~ 4 ~ GHP620 & GHP621 DESCRIPTION: Wall Mount Front panel Back panel Desktop Installation 1. On the wall where the GHP620 & GHP621 will be mounted, mark two dots with 100mm distance in between vertically. 2. Using a drill, make a hole on each marked dot. Put a plastic expansion bolt and screw (not provided) into each hole. Leave enough space on the screws to mount the GHP620 & GHP621. 3. Attach the wall mount spacers to the slot for wall mount spacers on the back of the phone. 4. Mount the GHP620 & GHP621 on the screws using its “Wall Mount Slots”. Flash Volume Down Key Softkeys Redial Alphanumeric Keypad Mute Indicator Volume Up Key HoldSpeaker LAN Port Mute USB Type-C Port Wall Mount Stand Slots Message Power Handset Port Message Waiting Indicator Note: The LED for the message waiting indicator will flash in green when there is a message waiting. PHONE SETUP: Desktop Wall For installing the phone on the table with the phone stand, attach the phone stand to the bottom of the phone where there is a slot for the phone stand. INSTALLING THE FACEPLATE: 1. Remove the release paper from the back of the faceplate. 2. Stick the faceplate on the indicated area. Please refer to the illustration. ~ 5 ~ 1. Plug in the phone cord to the handset RJ11 port and then connect it to the base. 2. Connect the LAN port of the phone to the RJ45 socket of a hub/switch or a router (LAN side of the router) using the Ethernet cable. 3. Power up the phone: • For GHP620 & GHP621: A PoE switch must be used in step 2. Refer to online documents and FAQ for more detailed information: https://www.grandstream.com/our-products CONNECTING THE PHONE: To set up the phone, follow the steps below: PHONE CONFIGURATION: 1. Ensure your phone is powered up and connected to the Internet. 2. Locate the MAC address on the bottom of the device or on the package. 3. From a computer connected to the same network as the GHP62X, type in the following address using the GHP62X’s MAC address on your browser: https://<mac>.local Example: https://c074adffffff.local Note: The user can also dial **47# and the current IP address will be announced by the IVR. 4. Enter the admin username and password to access the configuration menu. (The factory default username is “admin” and the default random password can be found on the sticker at the back of the unit). For certification information, please refer to User Manuals: http://www.grandstream.com U.S. FCC Part 68 Regulatory Information This equipment complies with Part 68 of the FCC rules. Located on the equipment is a label that contains, among other information, the ACTA registration number and ringer equivalence number (REN.) If requested, this information must be provided to the telephone company. The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive REN’s on the telephone line may result in the devices not ringing in response to an incoming c…
