YZZGVC3200Full HD Video Conferencing System

GrandstreamNetworks,Inc. GVC3200VideoConferencingSystemforAndroid TM UserGuide FirmwareVersion1.0.0.XGVC3200UserGuidePage 1 of 86 GVC3200UserGuide Index CHANGELOG.........................................................................................................8 FIRMWAREVERSION1.0.0.X..........................................................................................................................8 WELCOME................................................................................................................9 PRODUCTOVERVIEW........................................................................................11 FEATUREHIGHTLIGHTS................................................................................................................................11 SAFETYCOMPLIANCES.................................................................................................................................13 WARRANTY........................................................................................................................................................13 INSTALLINGGVC3200........................................................................................14 EQUIPMENTPACKAGECONTENT..............................................................................................................14 CONNECTINGGVC3200.................................................................................................................................14 GETTINGTOKNOWGVC3200.........................................................................19 REMOTECONTROL.........................................................................................................................................19 USINGTHEREMOTECONTROL..........................................................................................................21 PAIRINGANDCONNECTINGTHEREMOTECONTROL.................................................................22 USINGMOUSE&KEYBOARD.......................................................................................................................22 OLEDSCREEN..................................................................................................................................................23 USINGTHELEDINDICATOR.........................................................................................................................23 STATUSICONS.................................................................................................................................................23 USINGTHEONSCREENKEYBOARD.........................................................................................................24 ENGLISHKEYBOARD.............................................................................................................................24 NUMBERSANDSYMBOLS....................................................................................................................25 HOMESCREEN.................................................................................................................................................25 CONNECTINGTONETWORKANDDEVICES..............................................27 ETHERNET.........................................................................................................................................................27 WI-FI.....................................................................................................................................................................27 TURNINGWI-FIONOROFF..................................................................................................................28 BLUETOOTH......................................................................................................................................................28 TURNINGBLUETOOTHONOROFF...................................................................................................28 PAIRINGGXV3200WITHABLUETOOTHDEVICE...........................................................................28 CONNECTINGTOABLUETOOTHDEVICE........................................................................................29 USINGBLUETOOTHREMOTECONTROL.........................................................................................29 FirmwareVersion1.0.0.XGVC3200UserGuidePage 2 of 86 TRANSFERFILESWITHBLUETOOTH................................................................................................30 USINGBLUETOOTHHEADSET............................................................................................................30 VPNSETTINGS.................................................................................................................................................30 VLANSETTINGS...............................................................................................................................................32 LLDPSETTINGS...............................................................................................................................................32 802.1XMODE.....................................................................................................................................................33 CAMERA.................................................................................................................34 PRESET..............................................................................................................................................................34 ADD/EDITPRESET...................................................................................................................................34 DELETEPRESET......................................................................................................................................35 APPLYPRESET.......................................................................................................................…

Text truncated - open the document above for the full version.

FirmwareVersion1.0.0.XGVC3200UserGuidePage 40 of 86 MAKINGPHONECALLS ACCOUNT TheGVC3200supportsupto9-wayvideoconference,pleaseregistertheaccounttotheserverbefore makingcalls.Thefollowingfigureshowstheaccountsaresuccessfullyregistered(accounticonisgreen). ThisdisplaysontheleftsideofthetopstatusbarinyourLCDdisplaydevice. Figure19GVC3200SIPAccount DIALSCREEN Oncetheaccountissuccessfullyregistered,userscoulduseoneofthefollowing3waystobringupdial screentostartmakingcalls.  PresstheDIALiconinthelowerrightcorneroftheremotecontrol. OntheLCDdisplaydevice,clickonicononhomescreen. OntheLCDdisplaydevice,clickonApplicationsandselecttobringupdialscreen. Enterdigitsinthedial-upbox,ifthedigitsorthelettersforthedigitmatchescontactsandcallhistory,a dropdownlistofnumberswillbedisplayed.Forexample,entering5(JKL),6(MNO),4(GHI)and6(MNO) willdisplay5646orjohnifcontact“john”exists.Thematchingcharacterswillbehighlightedinred. FirmwareVersion1.0.0.XGVC3200UserGuidePage 41 of 86 Figure20GVC3200CallScreen Presstheredshortcutkeyontheremotecontroltobringupcallmodesettingscreen,setcallmodeto Call,PagingorIPcall; PresstheyellowshortcutkeytosetcalltypetoAudioorVideo; PresstheblueshortcutkeytoswitchtoBlueJeansorSIPCall.  Clickon"Cancel"icononscreenorpresskeyontheremotecontroltocancelthecall. DIALINGANUMBERDIRECTLY 1.Openthedialscreen. 2.Usetheremotecontrolkeyboardtoenterdigits,orclicktheinputboxtoenterusingthepop-outsoft keyboard; 3.Pressontheremotecontroltodialout,ormovethecursortotheiconondialscreenand clickittodialout. -------------------------------------------------------------------------------------------------------------------------------------------- Note: 1.Bydefault,theGVC3200allowsuserstopress#keyasSENDkey.Thisbehaviorcanbedisabledvia option"Use#asDialKey"underwebGUI. 2.Whenenteringinitialsorfullspellingsofanamethatexistsinthecontact,thiscontactwillshowinthe dropdownlist.Forexample,iftheuserinputsAmybypressingthecorrespondingdigits“2”(ABC),“6” (MNO),“9”(WXYZ)ontheremotecontrol,Amy'snameandnumberwillbedisplayedinthelistifit existsinthecontact.Userscanthenselectittodialout. -------------------------------------------------------------------------------------------------------------------------------------------- REDIAL Userscandialoutthelastdialednumberifthereisdialedcalllog.Accessthedialscreenandthenpress "#"keyorontheremotecontroltodialout. DIALINGANUMBERVIACONTACT FollowthestepsbelowtodialanumberviaContacts. 1.OntheLCDdisplaydevice,accessContactsbytappingononhomescreen; 2.Navigateandselectinthecontactsentriesusingtheremotecontrolnavigationkeys; 3.Pressontheremotecontroltodialout. FirmwareVersion1.0.0.XGVC3200UserGuidePage 42 of 86 DIALINGANUMBERVIACALLHISTORY 1.OntheLCDdisplaydevice,accessApplicationsonhomescreenandaccesscallhistorybyselecting icon; 2.TheLCDwilldisplayallcallhistorytypes.Navigateinthecallhistorylistbyselectingthecallhistory category.Selectthecallhistoryentryyouwouldliketodialout; 3.Pressontheremotecontroltodialout. DIRECTIPCALL DirectIPCallallowsGVC3200andanotherVoIPdevicetotalktoeachotherinanad-hocfashionwithout aSIPproxy.VoIPcallscanbemadebetweenthesetwoif: BothGVC3200andVoIPphonehavepublicIPaddresses Or  BothGVC3200andVoIPphoneareonthesameLAN/VPNusingprivateorpublicIPaddresses Or  BothdevicescanbeconnectedthrougharouterusingpublicorprivateIPaddresses(withnecessary portforwardingorDMZ). TomakeadirectIPcall,pleasefollowthestepsbelow: 1.AccessthedialscreenonGVC3200; 2.Presstheredshortcutkeyontheremotecontroltobringupcallmodesettingscreen,setthemode to"IPCall"; 3.InputthetargetIPaddress.Forexample,ifthetargetIPaddressis192.168.124.123andtheportis 5062,inputthefollowing: 192*168*124*123#5062 The*keyrepresentsthedot(.)andthe#keyrepresentsthecolon(:). 4.Presstheyellowshortcutkeyontheremotecontroltoselect"AudioCall"or"VideoCall"; 5.Pressontheremotecontroltodialout. PAGING/INTERCOM Beforeplacingpaging/intercom,pleasemakesurethecalleehaspaging/intercomenabledsoitcan automaticallyanswerthepaging/intercomcall.Tomakepaging/intercomcall: 1.AccessthedialscreenonGVC3200; 2.Presstheredshortcutkeyontheremotecontroltobringupcallmodesettingscreen,setthemode to"Paging/Intercom"; 3.Enterthenumbertodial; 4.Presstheyellowshortcutkeyontheremotecontroltoselect"AudioCall"or"VideoCall"; FirmwareVersion1.0.0.XGVC3200UserGuidePage 43 of 86 5.Press ontheremotecontrol todialout. ANSWERINGACALL SINGLEINCOMINGCALL Whenthedeviceisinidleandthereisanincomingvideocall,thedevicewillshowthecallscreenas below.Select“VideoAnswer”toanswerthecallwithbothvideoandaudio,“AudioAnswer”toanswerthe callwithaudioonly,or"End"torejectthecallusingtheremotecontrolnavigationkeys. MULTIPLECALLS/CALLWAITING Whenthereisanincomingcallduringanactivecall,userswillhearacallwaitingtonewiththeLCD displayingthecallernameandIDfortheincomingcall. Figure21GVC3200MultipleIncomingCalls Similartosingleincomingcall,userscouldselect“Audio”toanswerwithaudioonly,“Video”toanswer withvideoandaudio,or“End”torejectthecallusingremotecontrolnavigationkeys. -------------------------------------------------------------------------------------------------------------------------------------------- Note: Bydefault,answeringacallduringanactivecallwillautomaticallyaddthispartyintotheconference.To answerthecallseparatelywithoutestablishingtheconference,userscouldloginwebUI->Settings->Call Settingstoselect“DisableConference”. -------------------------------------------------------------------------------------------------------------------------------------------- SWITCHINGLINESDUINGCALL WhentherearemultiplecallsontheGVC3200,therecouldbeonlyonelineintalkingstatuswhilethe otherswillbeputonhold.TheuserscanusetheLeft/Rightbuttonsontheremotecontroltoswitch betweenthecall.Unholdthecallafterselectingthelineandthentheuserscantalkusingthisline. -------------------------------------------------------------------------------------------------------------------------------------------- Note: Bydefault,answeringacallduringanactivecallwillautomaticallyaddthispartyintotheconferenc…

Text truncated - open the document above for the full version.

DATE :2015-5-18 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Mr. Jawen Yin/EMC Engineer from ECMG &Address: Room 305-306,3F,Building A,No.30 Hangkong Road(East),Sanwei Village, xi'xiang Town, Bao'an District,Shenzhen,China. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Grandstream Networks, Inc. & Address: 5F, Bldg #1, No.2 Kefa Rd.,Science & Technology Park,Shenzhen,China. Dated this 18 Day of May 20 15 Agency agreement expiration date: November 18,2015 By: Ning Wei Signature Printed Title: Deputy Management On behalf of : Grandstream Networks, Inc. Telephone: (86)-755- 26014600

Grandstream – Restricted – Confidential Cover Letter Date: 2015-06-30 We have declared below featured for device identified as FCC ID: YZZGVC3200 (1) DFS Device Master， Client with Radar detection capability， Client without radar detection capability N/A (2) Active / Passive Scanning , ad-hoc mode access point capability. Frequency Band(MHz) Scanning Plan Ad- hoc Mode Capability Access point Capability WiFi Direct Group Owner WiFi Direct Group Client 2412 – 2462 Passive No No No Yes 5745 – 5825 Passive No No No Yes 5180 – 5240 Passive No No No Yes 5260 – 5320 Passive No No No Yes 5500 – 5700 Passive No No No Yes (3)Country code selection ability - Yes, NO If yes, pls explain how it implemented : (pls also help to provide detail of each country selection) (4)Transmission in 5600MHz is notched - Yes, NO (5)Meet Part 15.202 requirement - Yes, NO, *A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices *A master device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. Grandstream – Restricted – Confidential （6）For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an install. Apply, No apply, (if apply , pls help to provide explanation on it was implement, and how software was controlled) （7）We declare that the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad-hoc peer-to- peer modes. Sincerely yours Ning Wei Company Name: Grandstream Networks, Inc Address: No.2, Kefa Road, high-Tech park, Nanshan District, Shenzhen, China TEL: (86)-755-26014600 FAX: (86)-755-26014601 Email: [email protected]

External Photographs (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo

FCCIDYZZGVC3200 1622 MadeinChina VC 1 20141217 Jjsong XBCai 282-00531-00A-01 FCC Label 14.12.17 14.12.17 mm m m mm LABEL LOCATION

Internal Photographs (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (10) EUT Photo (11) EUT Photo (12) EUT Photo (13) EUT Photo (14) EUT Photo (15) EUT Photo (16) EUT Photo (17) EUT Photo (18) EUT Photo (19) EUT Photo (20) EUT Photo (21) EUT Photo (22) EUT Photo (23) EUT Photo (24) EUT Photo (25) EUT Photo (26) EUT Photo (27) EUT Photo (28) EUT Photo (29) EUT Photo (30) EUT Photo (31) EUT Photo (32) EUT Photo (33) EUT Photo (34) EUT Photo (35) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 1505RSU01907 Phone: +86-512-66308358 Report Version: V01 Fax: +86-512-66308368 Issue Date: 06-09-2015 Web: www.mrt-cert.com FCC ID: YZZGVC3200 Page Number: 1 of 6 RF Exposure Evaluation Declaration FCC ID: YZZGVC3200 APPLICANT: Grandstream Networks, Inc. Application Type: Certification Product: Full HD Video Conferencing System Model No.: GVC3200 Brand Name: Grandstream FCC Classification: Digital Transmission System (DTS) Test Date: May 29 ~ June 07, 2015 Reviewed By : ( Robin Wu ) Approved By : ( Marlin Chen ) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1505RSU01907 FCC ID: YZZGVC3200 Page Number: 2 of 6 Revision History Report No. Version Description Issue Date 1505RSU01907 Rev. 01 Initial report 06-09-2015 Report No.: 1505RSU01907 FCC ID: YZZGVC3200 Page Number: 3 of 6 1. RF Exposure Evaluation 1.1. Limits SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The equation and threshold in Note 1 must be applied to determine SAR test exclusion. MHz 5 10 15 20 25 mm 150 39 77 116 155 194 SAR Test Exclusion Threshold (mW) 300 27 55 82 110 137 450 22 45 67 89 112 835 16 33 49 66 82 900 16 32 47 63 79 1500 12 24 37 49 61 1900 11 22 33 44 54 2450 10 19 29 38 48 3600 8 16 24 32 40 5200 7 13 20 26 33 5400 6 13 19 26 32 5800 6 12 19 25 31 MHz 30 35 40 45 50 mm 150 232 271 310 349 387 SAR Test Exclusion Threshold (mW) 300 164 192 219 246 274 450 134 157 179 201 224 835 98 115 131 148 164 900 95 111 126 142 158 1500 73 86 98 110 122 1900 65 76 87 98 109 2450 57 67 77 86 96 3600 47 55 63 71 79 5200 39 46 53 59 66 5400 39 45 52 58 65 5800 37 44 50 56 62 Note: The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation Report No.: 1505RSU01907 FCC ID: YZZGVC3200 Page Number: 4 of 6 distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°C and 78% RH. Report No.: 1505RSU01907 FCC ID: YZZGVC3200 Page Number: 5 of 6 1.3. Test Result of RF Exposure Evaluation Product Full HD Video Conferencing System Test Item RF Exposure Evaluation Antenna Gain: The maximum Gain measured in fully anechoic chamber is 2.12dBi for 2.4GHz & 1.14dBi for 5GHz in logarithm scale. For 2.4GHz Wi-Fi ISM Band: Test Mode Frequency Band (MHz) Maximum Average Output Power (dBm) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) 802.11b 2412 ~ 2462 17.32 0.0175 1 802.11g 2412 ~ 2462 16.24 0.0136 1 802.11n-HT20 2412 ~ 2462 15.17 0.0107 1 For 5GHz Wi-Fi UNII Band: For 2.4GHz Bluetooth Band: Test Mode Frequency Band (MHz) Maximum Average Output Power (dBm) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) V3.0 + HS 2402 ~ 2480 1.06 0.0004 1 BLE 2402 ~ 2480 6.39 0.0014 1 Test Mode Frequency Band (MHz) Maximum Average Output Power (dBm) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) 802.11a 5180 ~ 5240 13.02 0.0052 1 5260 ~ 5320 13.04 0.0052 1 5500 ~ 5700 14.12 0.0067 1 5725 ~ 5825 13.14 0.0053 1 802.11n-HT20 5180 ~ 5240 11.54 0.0037 1 5260 ~ 5320 11.56 0.0037 1 5500 ~ 5700 13.03 0.0052 1 5725 ~ 5825 12.58 0.0047 1 Report No.: 1505RSU01907 FCC ID: YZZGVC3200 Page Number: 6 of 6 CONCULISON: Therefore, the Max Power Density at R (20 cm) = 0.0067mW/cm 2 < 1mW/cm 2 . So the EUT complies with the requirement. The End

MRT Technology (Suzhou) Co., Ltd Report No.: 1505RSU01903 Phone: +86-512-66308358 Report Version: V02 Fax: +86-512-66308368 Issue Date: 06-29-2015 Web: www.mrt-cert.com FCC ID: YZZGVC3200 Page Number: 1 of 96 FCC ID: YZZGVC3200 APPLICANT: Grandstream Networks, Inc. Application Type: Certification Product: Full HD Video Conferencing System Model No.: GVC3200 Brand Name： Grandstream FCC Classification: FCC Part 15 Spread Spectrum Transmitter(DSS) FCC Rule Part(s): Part 15.247 Test Procedure(s): ANSI C63.10-2009, DA 00-705 Test Date: May. 29 ~ Jun. 07, 2015 MEASUREMENT REPORT FCC PART 15.247 BT v3.0 + HS Reviewed By : ( Robin Wu ) Approved By : ( Marlin Chen ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2009 and DA 00-705. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 2 of 96 Revision History Report No. Version Description Issue Date 1505RSU01903 Rev. 01 Initial report 06-09-2015 1505RSU01903 Rev. 02 Corrected the test plot of 20dBc 06-29-2015 Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 3 of 96 CONTENTS Description Page 1. INTRODUCTION ........................................................................................................................ 7 1.1. Scope .............................................................................................................................. 7 1.2. MRT Test Location .......................................................................................................... 7 2. PRODUCT INFORMATION ........................................................................................................ 8 2.1. Equipment Description .................................................................................................... 8 2.2. Working Frequencies ...................................................................................................... 9 2.3. Pseudorandom Frequency Hopping Sequence ............................................................ 10 2.4. Device Capabilities ........................................................................................................ 10 2.5. Test Configuration ......................................................................................................... 10 2.6. Test Software ................................................................................................................ 10 2.7. EMI Suppression Device(s)/Modifications ..................................................................... 10 2.8. Labeling Requirements ................................................................................................. 11 3. DESCRIPTION OF TEST ......................................................................................................... 12 3.1. Evaluation Procedure .................................................................................................... 12 3.2. AC Line Conducted Emissions ...................................................................................... 12 3.3. Radiated Emissions ....................................................................................................... 13 4. ANTENNA REQUIREMENTS .................................................................................................. 14 5. TEST EQUIPMENT CALIBRATION DATE .............................................................................. 15 6. MEASUREMENT UNCERTAINTY ........................................................................................... 16 7. TEST RESULT ......................................................................................................................... 17 7.1. Summary ....................................................................................................................... 17 7.2. 20dB Bandwidth Measurement ..................................................................................... 18 7.2.1. Test Limit ................................................................................................................... 18 7.2.2. Test Procedure used ................................................................................................. 18 7.2.3. Test Setting ................................................................................................................ 18 7.2.4. Test Setup ................................................................................................................. 19 7.2.5. Test Result ................................................................................................................. 20 7.3. Output Power Measurement ......................................................................................... 23 7.3.1. Test Limit ................................................................................................................... 23 7.3.2. Test Procedure Used ................................................................................................. 23 7.3.3. Test Setting ................................................................................................................ 23 7.3.4. Test Setup ................................................................................................................. 24 7.3.5. Test Result ................................................................................................................. 25 Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 4 of 96 7.4. Carrier Frequency Separation Measurement ................................................................ 28 7.4.1. Test Limit ............................…

Text truncated - open the document above for the full version.

Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 46 of 96 7.8.4. Test Setup Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 47 of 96 7.8.5. Test Result Test Mode Channel No. Frequency (MHz) Limit (MHz) Result DH5 00 2402 20dBc Pass DH5 39 2441 20dBc Pass DH5 78 2480 20dBc Pass 2DH5 00 2402 20dBc Pass 2DH5 39 2441 20dBc Pass 2DH5 78 2480 20dBc Pass 3DH5 00 2402 20dBc Pass 3DH5 39 2441 20dBc Pass 3DH5 78 2480 20dBc Pass DH5 Conducted Spurious Emissions Channel 00 (2402MHz) Channel 39 (2441MHz) Channel 78 (2480MHz) Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 48 of 96 2DH5 Conducted Spurious Emissions Channel 00 (2402MHz) Channel 39 (2441MHz) Channel 78 (2480MHz) Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 49 of 96 3DH5 Conducted Spurious Emissions Channel 00 (2402MHz) Channel 39 (2441MHz) Channel 78 (2480MHz) Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 50 of 96 7.9. Radiated Spurious Emission Measurement 7.9.1. Test Limit All out of band emissions appearing in a restricted band as specified in Section 15.205 of the Title 47 CFR must not exceed the limits shown in Table per Section 15.209. FCC Part 15 Subpart C Paragraph 15.209 Frequency [MHz] Field Strength [V/m] Measured Distance [Meters] 0.009 - 0.490 2400/F (kHz) 300 0.490 - 1.705 24000/F (kHz) 30 1.705 – 30 30 30 30 – 88 100 3 88 – 216 150 3 216 – 960 200 3 Above 960 500 3 7.9.2. Test Procedure Used ANSI C63.10-2009 - Section 7.10.1 & Section 7.10.2 7.9.3. Test Setting Peak Field Strength Measurements 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = as specified in Table 1 3. VBW = 3 * RBW 4. Detector = peak 5. Sweep time = auto couple 6. Trace mode = max hold 7. Trace was allowed to stabilize Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 51 of 96 Table 1 - RBW as a function of frequency Frequency RBW 9 ~ 150 kHz 200 ~ 300 Hz 0.15 ~ 30 MHz 9 ~ 10 kHz 30 ~ 1000 MHz 100 ~ 120 kHz > 1000 MHz 1 MHz Average Field Strength Measurements 1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest 2. RBW = 1MHz 3. VBW ≥ 1/T 4. De As an alternative, the instrument may be set to linear detector mode. Ensure that video filtering is applied in linear voltage domain (rather than in a log or dB domain). Some instruments require linear display mode in order to accomplish this. Others have a setting for Average-VBW Type, which can be set to “Voltage” regardless of the display mode 5. Detector = Peak 6. Sweep time = auto 7. Trace mode = max hold 8. Allow max hold to run for at least 50 times (1/duty cycle) traces Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page Number: 52 of 96 7.9.4. Test Setup 9kHz ~ 30MHz Test Setup: 30MHz ~ 1GHz Test Setup: Report No.: 1505RSU01903 FCC ID: YZZGVC3200 Page …
