YZZGXV3615WPI-HDIP CAMERA

GXV3615WPI_HD 方型高清摄像机 用户手册 软件版本：1.0.2.58 GXV3615WPI_HD IP Camera Series Firmware 1.0.4.8 Page 2 of 30 Grandstream Networks, Inc. 02/10/12 Safety Instructions These instructions are intended to assist users with the operation of the GXV3615WPI_HD and also to instruct on how to avoid dangerous situations or damage to the device. Warnings: Serious injury or death may be caused if any of the warnings below are neglected. Cautions: Injury or damage to the equipment may occur if any of the following caution messages are neglected. Warnings Follow these safeguards to prevent serious injury or death. Cautions Follow these precautions to prevent potential injury or material damage. Warnings: Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with DC 12V according to the IEC60950-1 standard. Please refer to the technical specifications for more details. Do not use a third-party power adapter or power cord When the device is installed on the wall or ceiling, make sure that it is firmly attached. Notice： Make sure that the power supply voltage is correct before using the camera. Do not drop the device or expose it to physical shock. Do not expose the device to temperatures outside the range of -10 o C to +60 o C when the device is in operation. Do not expose the device to damp/wet conditions or high electromagnetism radiation. To avoid heat accumulation, make sure that your operating environment has proper ventilation. Do not attempt to open, disassemble, or modify the device A few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average life time. The average life time varies from the differences between operating environments and usage history. Regular maintenance checks are recommended for all users. Please contact your dealer for more details. GXV3615WPI_HD IP Camera Series Firmware 1.0.4.8 Page 3 of 30 Grandstream Networks, Inc. 02/10/12 Contents Welcome ......................................................................................................................................................... 4 Package Contents ............................................................................................................................................ 5 Product Overview ........................................................................................................................................... 5 GXV3615WPI_HD Series Overview ..................................................................................................... 5 GXV3615WPI_HD Series Front Panel ................................................................................................... 6 GXV3615WPI_HD Series Back Panel ................................................................................................... 6 GXV3615WPI_HD Series Sample Connection Diagram ....................................................................... 6 GXV3615WPI_HD Series Key Features ................................................................................................ 7 GXV3615WPI_HD Lens Specification .................................................................................................. 8 Minimum Recommended System Requirement ..................................................................................... 9 Connect your GXV3615WPI_HD Series ............................................................................................... 9 Configuring the GXV3615WPI_HD Series via Web Browser ............................................................. 10 Access GXV3615WPI_HD Series Web Configuration Menu .............................................................. 10 Connect the Camera to DHCP server. ................................................................................................... 10 Connect to the Camera using Static IP. ................................................................................................. 11 GXV3615WPI_HD Series Home Web Page ........................................................................................ 12 GXV3615WPI_HD Series System Page ............................................................................................... 13 GXV3615WPI_HD Series Video & Audio Page .................................................................................. 14 GXV3615WPI_HD Series Networking Page – Assign an IP to GXV3615WPI_HD ........................... 15 GXV3615WPI_HD And GXV3615W_HD Wifi Page – This page is only available for GXV3615W_HD and GXV3615WPI_HD ........................................................................................ 16 GXV3615WPI_HD Series DDNS Page ............................................................................................... 16 GXV3615WPI_HD Series SIP Page ..................................................................................................... 17 GXV3615WPI_HD Series Status Page ................................................................................................. 19 GXV3615WPI_HD Series User Management Page ............................................................................. 20 GXV3615WPI_HD Series Maintenance Page ...................................................................................... 20 GXV3615WPI_HD Series SMTP Page ................................................................................................ 21 GXV3615WPI_HD Series FTP Page .................................................................................................... 22 GXV3615WPI_HD Series Motion Detection Page .............................................................................. 22 GXV3615WPI_HD Series System Log ................................................................................................ 24 FAQ .................................................................................................................................…

Text truncated - open the document above for the full version.

Grandstream Networks, Inc. Address: 5F, Bldg #1, No.2 Kefa Rd., Science & Technology Park, Shenzhen, China Phone: (86)-755-26014600 FAX : (86)-755-26014601 AGENCY AUTHORIZATION LETTER FCC ID: YZZGXV3615WPI-HD Date: April 10 th ,2014 To whom it may concern: We, the undersigned, hereby authorize ECMG to act on our behalf , as our agent ,in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to the matters. and any other lawful activity necessary to obtain such certification. Any act carried out by ECMG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date , if you have any question regarding the authorization , please don’t hesitate to contact us , thank you. Sincerely, Wei Ning /Deputy management Phone: (86)-755-26014600 FAX : (86)-755-26014601 Email: [email protected]

Grandstream Networks, Inc. Date: April 10 th ,2014 Federal communications commission Authorization and Evaluation Division FCC ID: YZZGXV3615WPI-HD Confidentiality Request Pursuant to section 0.457 and 0.459 of the commission’s rules, the applicant hereby requests confidential treatment of information accompanying this application as outline below: 1. Schematics 2. Block diagram 3. Operational description The above materials contain trade secrets and proprietary information not customarily released to the public, the public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Wei Ning /Deputy management Phone: (86)-755-26014600 FAX : (86)-755-26014601 Email: [email protected]

Grandstream Networks,Inc. FCC ID:YZZGXV3615WPI-HD IC:11964A-GXV3615 POWER OF ATTORNEY (April 10 th ,2014) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We,(Grandstream Networks,Inc.) the undersigned, hereby authorize ECMG Electronic Technical Testing Corp.(Mr.Jawen Yin, EMC Manager) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by ECMG Electronic Technical Testing Corp. (Mr.Jawen Yin,EMC Manager)on our behalf shall have the same effect as acts of our own. This authorization expires on (October 10 th ,2014). This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, (Grandstream Networks,Inc.), are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section.

External Photographs EUT Model:GXV3615WPI_HD EUT-Front View EUT-Rear View Power Adapter(Mass power)-Top View Power Adapter(UE)-Top View

Proposed FCC&IC&CE Label Format: Label Location 49.70 mm 26.30 mm IC:11964A-GXV3615

Internal Photographs EUT Model:GXV3615WPI-HD EUT-Uncovered View #1 EUT-Uncovered View #2 Main board- Top View Main board- Bottom View Lens -Top View Lens-Bottom View Wi-Fi Module&Antenna Location View Wi-Fi module-Top View Wi-Fi module-Bottom View Wi-Fi module-Removed Shield Cover View

www.ecmg-global.net EMI TEST REPORT On Model Name: IP Camera Model Number: GXV3615WPI_HD Brand Name: Grandstream Prepared for Grandstream Networks, Inc. FCC ID Number: YZZGXV3615WPI-HD According to FCC 47 CFR Part 15, Subpart B Test Report #: SHE-1404-11142 -FCC Tested by: Galanz Daomen /Engineer Company Name Reviewed by: ECMG Jawen Yin/ Senior Engineer Company Name QC Manager: ECMG Swall Zhang/QC Manager Company Name Test Report Released by: May 7 th , 2014   Swall Zhang Date Test Location Tests performed in a Certified ANSI Semi-Anechoic Chamber and Shielded Room. Test Site Location : Galanz 25 South Ronggui Rd.,Shunde, Foshan,Guangdong, China Tel : (86)-757-23612785 Fax : (86)-757-23612537 Test Facility The test facility was recognized, certified, or accredited by the following organizations:  CNAL – LAB Code: L2244 Galanz EMC Laboratory has been assessed and in compliance with CN AL/AC01:2002 accreditation criteria for testing laboratories (identic al to ISO/IEC 17025:2005 General Requirements)for the Competence of Testing Laboratories.  FCC – Registration No.: 580210 Galanz EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC was maintained in our files.  IC – Registration No.: 8801A The Laboratory is registered to perform emission tests with Industry Canada (IC), and the registration number is 8801A. Table of Contents GOVERNMENT DISCLAIMER NOTICE ___________________________________________ 2 REPRODUCTION CLAUSE ______________________________________________________ 2 OPINIONS AND INTERPRETATIONS ____________________________________________ 2 STATEMENT OF MEASUREMENT UNCERTAINTY ________________________________ 2 ADMINISTRATIVE DATA _______________________________________________________ 3 EUT DESCRIPTION _____________________________________________________________ 4 TEST SUMMARY _______________________________________________________________ 5 TEST MODE JUSTIFICATION ___________________________________________________ 6 EUT EXERCISE SOFTWARE _____________________________________________________ 6 EQUIPMENT MODIFICATION ___________________________________________________ 6 EUT SAMPLE PHOTOS _________________________________________________________ 7 TEST SYSTEM DETAILS _______________________________________________________ 14 ATTACHMENT 1 - CONDUCTED EMISSION TEST RESULTS _____________________ 17 ATTACHMENT 2 – RADIATED EMISSION MEASUREMENT ______________________ 23 FCC Test Report #: SHE-1404-11142 –FCC Prepared for Grandstream Networks, Inc. Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 1 of 37 List Attached Files Exhibit Type File Description File Name Test Report Test Report YZZGXV3615WPI-HD _Test report.pdf Operation Description Technical Description YZZGXV3615WPI-HD_operation description.pdf External Photos External Photos YZZGXV3615WPI-HD_External Photos Internal Photos Internal Photos YZZGXV3615WPI-HD_Internal Photos Block Diagram Block Diagram YZZGXV3615WPI-HD_Block Diagram.pdf Schematics Circuit Diagram YZZGXV3615WPI-HD _Schematics.pdf ID Label/Location Label and Location YZZGXV3615WPI-HD_Label & Location.pdf User Manual User Manual YZZGXV3615WPI-HD _User Manual.pdf Test set-up photos Test set-up photos YZZGXV3615WPI-HD _Test Set-up Photos FCC Test Report #: SHE-1404-11142 –FCC Prepared for Grandstream Networks, Inc. Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 2 of 37 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto.This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from ECMG Electronic Technical Testing Corp (Shenzhen). Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT).Without the permission of ECMG Electronic Technical Testing Corp (Shenzhen) Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. FCC Test Report #: SHE-1404-11142 –FCC Prepared for Grandstream Networks, Inc. Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 3 of 37 Administrative Data Test Sample : IP Camera Model Numbers : GXV3615WPI_HD Model Tested : GXV3615WPI_HD Receipt Date : April 15 th , 2014 Date Tested : April 17 th , 2014 Applicant : Grandstream Networks, Inc. Address 5F, Bldg #1, No.2 Kefa Rd., Science & Technology Park, Shenzhen, China Telephone : (86)-755-26014600 Fax : (86)-755-26014601 Manufacturer : Grandstream Networks, Inc. Address 5F, Bldg #1, No.2 Kefa Rd., Science & Technology Park, Shenzhen, China Telephone : (86)-755-26014600 Fax : (86)-755-26014601 Factory : Grandstream Networks, Inc. A…

Text truncated - open the document above for the full version.

Test Set-Up Photograph FCC Part15,Subpart B: Conducted Emission Test Set-up-Front View Conducted Emission Test Set-up-Rear View Radiated Emission Test Set-up (9KHz-30MHz) Radiated Emission Test Set-up (Below 1GHz) Radiated Emission Test Set-up (Rear View) Radiated Emission Test Set-up (Above 1GHz) FCC 15.247: Conducted Emission Test Set-up –Front View Conducted Emission Test Set-up-Rear View Radiated Emission Test Set-up (9KHz-30MHz) Radiated Emission Test Set-up (Below 1GHz) Radiated Emission Test Set-up (Rear View) Radiated Emission Test Set-up (Above 1GHz)
