YZZGXV3672-HDIP CAMERA

Grandstream Networks, Inc.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Nov 14, 2012
Application Purpose: Original Equipment
Date of Application: Nov 14, 2012
Equipment Note: IP CAMERA
Company: Grandstream Networks, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

GXV3672_HD/FHD User Manual www.grandstream.com Firmware Version 1.0.1.68 http://esupport.grandstream.com Grandstream Networks, Inc. GXV3672_HD/GXV3672_FHD Outdoor Day/Night IP Camera Grandstream Networks, Inc. GXV3672_HD/FHD User Manual Page 2 of 36 Firmware Version 1.0.1.68 Last Updated: 11/2012 T ABLE OF CONTENTS GXV3672_HD/FHD User Manual WELCOME.................................................................................................................................................... 4 SAFETY COMPLIANCES................................................................................................................................. 5 WARRANTY.................................................................................................................................................. 6 CONNECT YOUR GXV3672_HD/FHD......................................................................................................... 7 EQUIPMENT PACKAGE CONTENTS................................................................................................................ 7 CONNECTING THE GXV3672_HD/FHD ........................................................................................................ 7 PRODUCT OVERVIEW ................................................................................................................................ 8 GXV3672_HD/FHD FRONT AND BACK PANEL............................................................................................. 8 GXV3672_HD/FHD SAMPLE CONNECTION DIAGRAM................................................................................... 9 GXV3672_HD/FHD SPECIFICATIONS........................................................................................................ 10 INSTALLATION GUIDE ............................................................................................................................. 11 MINIMUM RECOMMENDED COMPUTER SYSTEM REQUIREMENT..................................................................... 11 CONFIGURE THE GXV3672_HD/FHD VIA WEB BROWSER.......................................................................... 11 GXV3672_HD/FHD HOME WEB PAGE...................................................................................................... 14 GXV3672_HD/FHD CONFIGURATION & LANGUAGE PAGE.......................................................................... 15 BASIC SETTINGS EXPLANATION ........................................................................................................... 16 SYSTEM SETTINGS PAGE........................................................................................................................... 16 VIDEO & AUDIO SETTING PAGE.................................................................................................................. 17 CMOS SETTINGS PAGE............................................................................................................................. 19 NETWORKING SETTING PAGE..................................................................................................................... 20 DDNS SETTINGS PAGE............................................................................................................................. 21 SIP SETTING PAGE.................................................................................................................................... 22 STATUS PAGE............................................................................................................................................ 24 ADVANCED SETTINGS EXPLANATION..................................................................................................25 USER MANAGEMENT PAGE......................................................................................................................... 25 MAINTENANCE PAGE.................................................................................................................................. 26 SMTP SETTING PAGE (EMAIL ALARM) ........................................................................................................ 27 FTP SETTINGS PAGE (UPLOAD ALARM) ...................................................................................................... 28 ALARM SERVER SETTINGS PAGE (UPLOAD ALARM TO SUPPORTED VMS OR HTTP SERVER) ........................ 29 MOTION DETECTION CONFIGURATION PAGE (SET ALARM) ........................................................................... 30 SYSLOG SETTINGS PAGE (TROUBLESHOOTING) .......................................................................................... 32 SOFTWARE UPGRADE................................................................................................................................33 SOFTWARE UPGRADE VIA TTFP, HTTP OR HTTPS.................................................................................... 33 INSTRUCTIONS FOR LOCAL FIRMWARE UPGRADE USING TFTP SERVER: ........................................................ 33 CONFIGURATION FILE DOWNLOAD.............................................................................................................. 34 RESTORE FACTORY DEFAULT SETTING.............................................................................................. 35 RESET FROM WEB INTERFACE.................................................................................................................... 35 Grandstream Networks, Inc. GXV3672_HD/FHD User Manual Page 3 of 36 Firmware Version 1.0.1.68 Last Updated: 11/2012 TABLE OF FIGURES GXV3672_HD/FHD U SER MANUAL F IGURE 1: HOME PAGE OF GXV3672_HD/FHD ........................................................................................................... 14 FIGURE 2: WEB LANGUAGE SWITCH............................................................................................................................. 15 FIGURE 3: SYSTEM SETTINGS PAGE............................................…

Text truncated - open the document above for the full version.

Block Diagram

Page 1/4 Title: Project System block Diagram Owner: DWMo Reviewers: REVISION HISTORY Version Date Changed ByChanges 1.0 2012-9-18 DWMo First release edition N/C N/C N/C N/C Over View: 1. GXV3672_HD System Block Diagram: DSP RJ45 ( PC/LAN) POE TPS23750 POWER +12V/1A ADAPTER DC-DC 2.5V DC-DC 3.3V DC-DC 1.8V DC-DC 1.2V 12V/1A 64Mbit FLASH 128*8Mbit DDR PHY 540MHz CRYS 25MHz Video JTAG+UART CRYS 24MHz GXV3672_HD System Block Diagram Page 2/4 General description GXV3672_HD comprises the following subsystems: • The DSP processor and Power management and Video engine • An external Ethernet Switch • An external DDR code execution and data • An NAND flash for code/data storage P OE supply +12V voltage Page 3/4 Title: Project System block Diagram Owner: DWMo Reviewers: REVISION HISTORY Version Date Changed ByChanges 1.0 2012-9-18 DWMo First release edition N/C N/C N/C N/C Over View: 1. GXV3672_FHD System Block Diagram: DSP RJ45 ( PC/LAN) POE TPS23750 POWER +12V/1A ADAPTER DC-DC 2.5V DC-DC 3.3V DC-DC 1.8V DC-DC 1.2V 12V/1A 64Mbit FLASH 128*8Mbit DDR PHY 680MHz CRYS 25MHz Video JTAG+UART CRYS 24MHz GXV3672_FHD System Block Diagram Page 4/4 General description GXV3672_FHD comprises the following subsystems: • The DSP processor and Power management and Video engine • An external Ethernet Switch • An external DDR code execution and data • An NAND flash for code/data storage P OE supply +12V voltage

External Photos

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Model: GXV3672_FHD EUT – Front View EUT – Rear View EUT – Bottom View Model: GXV3672_HD EUT – Front View EUT – Rear View EUT – Bottom View EUT – Adapter View EUT – Adapter Label View

ID Label/Location Info

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label Proposed FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label here

Internal Photos

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Cover off View 1 EUT – Cover off View 2 EUT – Cover off View 3 EUT – Cover off View 4 EUT – Main Board 1 Top View EUT – Main Board 1 Bottom View EUT – Main Board 2 Top View EUT – Main Board 2 Bottom View EUT – Camera Board Top View EUT – Camera Board Bottom View EUT – LED Board Top View EUT – LED Board Bottom View EUT – Thermistor Board Top View EUT – Thermistor Board Bottom View

Test Report

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and shall be marked with an asterisk “★” FCC PART 15 CLASS B TEST REPORT For Grandstream Networks, INC 5F, Bldg #1, No.2 Kefa Rd., Science & Technology Park, Shenzhen, Guangdong, China Report Type: Original Report Product Name: IP CAMERA Test Engineer: Lebron Wang Report Number: RSZ120919008-00 Report Date: 2012-11-13 Reviewed By: Sula Huang RF Engineer Test Laboratory: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn FCC ID: YZZGXV3672-HD Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ120919008-00 FCC Part 15 Class B Page 2 of 28 TABLE OF CONTENTS GENERAL INFORMATION.......................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .....................................................................................3 OBJECTIVE...................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S).............................................................................................................................3 TEST METHODOLOGY..................................................................................................................................................3 TEST FACILITY.............................................................................................................................................................3 SYSTEM TEST CONFIGURATION (FCC §15.27) ..................................................................................................5 JUSTIFICATION.............................................................................................................................................................5 EQUIPMENT MODIFICATIONS.......................................................................................................................................5 SUPPORT EQUIPMENT LIST AND DETAILS....................................................................................................................5 EXTERNAL I/O CABLE..................................................................................................................................................5 BLOCK DIAGRAM OF TEST SETUP................................................................................................................................6 SUMMARY OF TEST RESULTS...............................................................................................................................7 FCC §15.107 – AC LINE CONDUCTED EMISSIONS .............................................................................................8 APPLICABLE STANDARD..............................................................................................................................................8 EUT SETUP..................................................................................................................................................................8 EMI TEST RECEIVER SETUP.........................................................................................................................................8 TEST PROCEDURE........................................................................................................................................................9 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................................9 CORRECTED FACTOR & MARGIN CALCULATION.........................................................................................................9 TEST RESULTS SUMMARY............................................................................................................................................9 TEST DATA................................................................................................................................................................10 FCC§15.109 - RADIATED EMISSIONS ..................................................................................................................18 APPLICABLE STANDARD............................................................................................................................................18 EUT SETUP................................................................................................................................................................18 EMI TEST RECEIVER SETUP.......................................................................................................................................18 TEST PROCEDURE......................................................................................................................................................19 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................19 CORRECTED AMPLITUDE & MARGIN CALCULATION.................................................................................................19 TEST RESULTS SUMMARY..........................................................................................................................................19 TEST DATA...............................…

Text truncated - open the document above for the full version.

Test Setup Photos

EXHIBIT D - TEST SETUP PHOTOGRAPHS Model: GXV3672_FHD Conducted Emissions - Front View (Powered by adapter) Conducted Emissions - Side View (Powered by adapter) Conducted Emissions - Front View (Powered by PoE) Conducted Emissions - Side View (Powered by PoE) 30 MHz -1 GHz: Radiated Emissions - Front View (Powered by adapter) Radiated Emissions – Rear View (Powered by adapter) Radiated Emissions - Front View (Powered by PoE) Radiated Emissions – Rear View (Powered by PoE) 1-5 GHz: Radiated Emissions - Front View (Powered by adapter) Radiated Emissions – Rear View (Powered by adapter) Radiated Emissions - Front View (Powered by PoE) Radiated Emissions – Rear View (Powered by PoE) Model: GXV3672_HD Conducted Emissions - Front View (Powered by adapter) Conducted Emissions - Side View (Powered by adapter) Conducted Emissions - Front View (Powered by PoE) Conducted Emissions - Side View (Powered by PoE) 30 MHz -1 GHz: Radiated Emissions - Front View (Powered by adapter) Radiated Emissions – Rear View (Powered by adapter) Radiated Emissions - Front View (Powered by PoE) Radiated Emissions – Rear View (Powered by PoE) 1-5 GHz: Radiated Emissions - Front View (Powered by adapter) Radiated Emissions – Rear View (Powered by adapter) Radiated Emissions - Front View (Powered by PoE) Radiated Emissions – Rear View (Powered by PoE)
