Z3S-W028Remote Controller

CPEWR1101 Technical Manual 一．Electrical System Parameters 1、 Wo r k v o l t a g e：DC12V/23A 2、 Quiescent current：≦5UA 3、 Working current：≦15MA 4、 Transmitting power：≦100MW 5、 Working frequency：315MHZ 6、 Modulation mode：ASK 7、 Encode type：learning code Learning instructions： 1): Press the transmitter button ON/OFF 3 Seconds Power on，indicator light on，Press ON/OFF 3 Seconds once again or no activity 2 minutes, indicator light of. 2): Cleaner program and Learning ：Transmitter and receiver on power, Press transmitter button ON and OFF 20 Seconds then Cleaner existing program, LED turn flash to bright; Press transmitter button ON and OFF 3 Seconds in learning condition. LED turn off to on. learning program successful, then press in or out for working 3): Cleaner program and Learning must be finished within 2 minutes, If exceed 2 minutes, transmitter off work; restart Cleaner program and Learning then cleaner and learning 4): Disturbance notice: when operation under electromagnetic or radio environment, The work distance changes Federal Communication Commission Interference Statement: 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: T his equipment has been tested and found to comply with the limits Class B digital device. Pursuant to part 15 of the FCC rules. This limits are designed to a provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, The user is encouraged to try to correct the interference by one or more the following measures: -Reorient or relocate the receiving antenna -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected -Consult the dealer on an experienced radio/TV technician for help

Copyright 2006 Curtis-Straus LLC all rights reserved. Revision Nov-06 YF. Champion Power Equipment , Inc 2011-10-10 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Curtis-Straus LLC TCB One Distribution Center Circle #1 Littleton, MA 01460 Confidentiality Request FCC ID: Z3S-W028 Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Name: Joyce MA Signature： Contact: 562-204-1155

Champion Power Equipment, Inc Letter of Agency 2011-10-10 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Curtis-Straus LLC TCB One Distribution Center Circle #1 Littleton, MA 01460 We, the undersigned { Champion Power Equipment , Inc } hereby authorize {BV ADT Shanghai} to act on our behalf in all matters relating to all processes required for FCC certification of our devices. Any and all acts carried out by the above agent on our behalf shall have the same effects as acts of our own. This authorization is valid until: {2011-12-31} If you have any questions regarding this authorization, let us know please. Sincerely, Name：Joyce MA Title: President Signature

Antenna Antenna

Report No.: CPE-11OC0003VBTY 1 FCC TEST REPORT REPORT NO.: CPE-11OC0003VBTY MODEL NO.: CPEWR1101 RECEIVED: Oct. 08, 2011 ISSUED: Oct. 18, 2011 APPLICANT: Champion Power Equipment , Inc ADDRESS: 10006 Santa Fe Springs Rd, Santa Fe Springs, CA 90670 ISSUED BY: BUREAU VERITAS ADT (Shanghai) Corporation ADDRESS: 2F, Building C, No.1618, Yishan rd., 201103, Shanghai, China This test report consists of 27 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA, CNAS, or any government agency. The test results in the report only apply to the tested item. The test results in this report are traceable to the national or international standards. V 1.0.0 Report No.: CPE-11OC0003VBTY 2 Table of Contents 1 CERTIFICATION .......................................................................................... 3 2 SUMMARY OF TEST RESULTS .................................................................. 4 2.1 MEASUREMENT UNCERTAINTY............................................................... 4 3 GENERAL INFORMATION........................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 5 3.2 DESCRIPTION OF TEST MODES .............................................................. 5 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................. 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................ 7 4 EMISSION TEST.......................................................................................... 8 4.1 CONDUCTED EMISSION MEASUREMENT............................................... 8 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................ 8 4.1.2 TEST RESULTS .......................................................................................... 8 4.2 DEACTIVATION TIME ................................................................................. 9 4.2.1 LIMITS OF DEACTIVATION TIME MEASUREMENT .................................. 9 4.2.2 TEST INSTRUMENTS................................................................................. 9 4.2.3 TEST PROCEDURES ................................................................................. 9 4.2.4 DEVIATION FROM TEST STANDARD........................................................ 9 4.2.5 TEST SETUP............................................................................................... 9 4.2.6 TEST RESULTS ........................................................................................ 10 4.3 RADIATED EMISSION MEASUREMENT.................................................. 11 4.3.1 LIMITS OF RADIATED EMISSION MEASUREMENT ............................... 11 4.3.2 TEST INSTRUMENTS............................................................................... 13 4.3.3 TEST PROCEDURE.................................................................................. 14 4.3.4 DEVIATION FROM TEST STANDARD...................................................... 14 4.3.5 TEST SETUP............................................................................................. 15 4.3.6 EUT OPERATING CONDITIONS .............................................................. 15 4.3.7 TEST RESULTS ........................................................................................ 16 4.4 20DB OCCUPIED BANDWIDTH MEASUREMENT .................................. 22 4.4.1 LIMITS OF BAND EDGES MEASUREMENT ............................................ 22 4.4.2 TEST INSTRUMENTS............................................................................... 22 4.4.3 TEST PROCEDURES ............................................................................... 23 4.4.4 DEVIATION FROM TEST STANDARD...................................................... 23 4.4.5 TEST SETUP............................................................................................. 23 4.4.6 TEST RESULTS ........................................................................................ 24 5 PHOTOGRAPHS OF THE TEST CONFIGURATION................................. 25 6 PHOTOGRAPHS OF THE EUT ................................................................. 26 7 APPENDIX - INFORMATION ON THE TESTING LABORATORIES .......... 27 Report No.: CPE-11OC0003VBTY 3 1 CERTIFICATION PRODUCT: Winch remote control MODEL NO.: CPEWR1101 APPLICANT: Champion Power Equipment , Inc TESTED: Oct. 08 ~ Oct. 17, 2011 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15:2009, Subpart C (Section 15.209 and 15.231), ANSI C63.4-2003 We, BUREAU VERITAS ADT (Shanghai) Corporation, declare that the equipment above has been tested in our facility and found compliance with the requirement limits of applicable standards. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate under the standards herein specified. PREPARED BY : , DATE:Oct. 18, 2011 Yuki Tao Report Engineer TECHNICAL ACCEPTANCE : , DATE:Oct. 18, 2011 Joy Zhu Lab Manager APPROVED BY : , DATE:Oct. 18, 2011 Zhaoqian YU Director of Operations Report No.: CPE-11OC0003VBTY 4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C Standard Paragraph Test Type ResultRemarks 15.207 Conducted Emission Test N/A Please refer to 4.1.2. 15.231(a) De-activation Time PASS Meet the requirement of limit 15.209 15.231(b) Radiated Emission Test PASS Minimum passing margin is –1.51dB to 944.23MHz 15.231(c) 20dB Occupied Bandwidth Measurement PASS Meet the requirement of limit 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4: M…

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF THE TEST CONFIGURATION
