1 DH98 COLORED MOBILE GSM/GPRS DIGITAL PHONE USER MANUAL 2 Content 1. Safety and maintenance ........................................................ 6 1.1 Instruction ............................................................... 6 1.2 For your safety ........................................................ 6 1.3 Security Requirements ............................................ 7 1.4 Maintenance ............................................................ 8 2. Before use ............................................................................ 9 2.1 Technical parameters ............................................... 9 2.2 Description of keys ............................................... 10 2.3 Icon Description .................................................... 10 2.4 Battery ................................................................... 10 2.4.1 Installation and Removal the battery ... 11 2.4.2 Battery charging .................................. 11 2.5 Connect Network .................................................. 12 2.5.1 SIM card ................................................ 12 2.5.2 Inserting and removing SIM card .......... 12 2.5.3 Inserting and removing memory card.... 13 2.5.4 On/Off the phone ................................... 13 2.5.5 Unlock phone ........................................ 14 2.5.6 Unlock SIM card ................................... 14 2.5.7 Linked network ..................................... 14 3. Speed use guide ............................................................... 15 3.1 Characteristic functions ......................................... 15 3 3.2 Making call ............................................................ 17 3.2.1 Making Domestic calls .......................... 17 3.2.2 Calling fixed line extensions ................. 17 3.2.3 Making international calls ..................... 17 3.2.4 Dialing calls from the call log ............... 18 3.3 Emergency calls .................................................... 18 3.4 Answer a call ......................................................... 18 3.5 End a call ............................................................... 19 3.6 Call History ........................................................... 19 4. Function menu .................................................................... 19 4.1 Function menu use ................................................... 19 4.2 Phone ........................................................................ 20 4.3 Music ........................................................................ 20 4.4 Phone book ............................................................... 20 4.5 Services .................................................................... 22 4.5.1 STK* ........................................................ 22 4.5.2 Services ................................................. 22 4.5.3 Baidu Search ......................................... 25 4.6 Messages ............................................................... 25 4.6.1 SMS .......................................................... 25 4.6.2 MMS ........................................................ 27 4.6.3 Broadcast message ................................... 34 4.6.4 Email ........................................................ 35 4.7 Call history ............................................................... 35 4 4.8 Settings ..................................................................... 37 4.8.1 Dual sim settings ................................... 37 4.8.2 pen calibration ....................................... 37 4.8.3 phone settings ..................................... 37 4.8.4 Call settings ........................................... 38 4.8.5 Data account .......................................... 40 4.8.6 Music settings ........................................ 40 4.8.7 Network settings ................................. 40 4.8.8 Security settings .................................... 41 4.8.9 Restore factory settings ......................... 43 4.8.10 Connectivity ........................................ 43 4.8.11 Gsensor settings ................................ 43 4.9 Photo ..................................................................... 44 4.10 Camera ................................................................ 44 4.11 WIFI* .................................................................. 45 4.12 TV* ..................................................................... 45 4.13 User profiles ........................................................ 45 4.14 Organizer ............................................................. 47 4.14.1 Calendar .......................................... 47 4.14.2 Tasks ................................................ 47 4.14.3 Alarm ............................................... 48 4.14.4 World clock ....................................... 48 4.15 Fun&Games ........................................................ 48 4.16 File manager ........................................................ 48 5 4.17 Multimedia .......................................................... 50 4.17.1 Video player ........................................ 50 4.17.2 Video recorder ..................................... 50 4.17.3 Sound recorder .................................... 51 4.17.4 FM radio .............................................. 51 4.17.5 Slide show ........................................... 51 4.18 Ebook reader ....................................................... 52 4.19 Currency converter .............................................. 53 4.20 Stopwatch ............................................................ 53 4.21 Calcaulator .......................................................... 53 5. FAQ .................................................................................... 53 6 1. Safety and maintenance 1.1 Instruction Thanks for you to select the color GSM/GPRS numeric mobile phone. You ca…

Text truncated - open the document above for the full version.

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 07.03.2008 Datum: 00.00.00 Seite 1 von 1 PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date:2011-10-15 FCC ID: Z4W1371434380FCC Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized under the “Certification” procedure. The device is also defined as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Signature Name：David Xu Title Sales Room 1510B, Huaqiangbei Seg Plaza, Futian Area ShenzhenCity, Guangdong China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS

LABEL & LOCATION

LABEL & LOCATION

Page 1 of 55 Report No.:NTEK-2011NT0930290F2 FCC RADIO TEST REPORT Report Reference No. ............... : NTEK-2011NT0930290F2 Compiled by (+ signature) ........... Tom Zhang Approved by (+ signature) ........... Bovey Yang Applicant’s name........................... : Donghui Great Techonology Co.Ltd. Address....................................... : Room 1510B, Huaqiangbei Seg Plaza, Futian Area, Shenzhen,Guangdong Province, China Manufacture's Name...................... : Donghui Great Techonology Co.Ltd. Address....................................... : Room 1510B, Huaqiangbei Seg Plaza, Futian Area, Shenzhen,Guangdong Province, China Test specification: Standard ..................................... : FCC Part15.247 Test procedure............................... : ANSI C63.4-2003 Test item description Product name ........................ : Mobile phone FCC ID Z4W1371434380FCC Trademark ............................ : N/A Model and/or type reference : DH98 Rating(s) ................................ : DC 3.7V by battery Testing Laboratory information: Testing Laboratory Name ..... : NTEK Testing Technology Co., Ltd Address ................................ : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao ＇an District, Shenzhen P.R. China. This device described above has been tested by NTEK Testing Technology Co., Ltd, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK Testing Technology Co., Ltd, this document may be altered or revised by NTEK Testing Technology Co., Ltd, personal only, and shall be noted in the revision of the documen Testing....................................................: Date of receipt of test item ......................: 17 Oct. 2011 Date (s) of performance of tests .............: 1 Oct. 2011 ~17 Oct. 2011 Date of Issue ...........................................: 17 Oct. 2011 Test Result...............................................: Pass Page 2 of 55 Report No.:NTEK-2011NT0930290F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 8 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.1.2 TEST PROCEDURE 13 3.1.3 DEVIATION FROM TEST STANDARD 13 3.1.4 TEST SETUP 13 3.1.5 EUT OPERATING CONDITIONS 13 3.1.6 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 RADIATED EMISSION LIMITS 16 3.2.2 TEST PROCEDURE 17 3.2.3 DEVIATION FROM TEST STANDARD 17 3.2.4 TEST SETUP 18 3.2.5 EUT OPERATING CONDITIONS 19 3.2.6 TEST RESULTS (BELOW 30 MHZ) 20 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 21 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . NUMBER OF HOPPING CHANNEL 29 4.1 APPLIED PROCEDURES / LIMIT 29 4.1.1 TEST PROCEDURE 29 4.1.2 DEVIATION FROM STANDARD 29 4.1.3 TEST SETUP 29 4.1.4 EUT OPERATION CONDITIONS 29 4.1.5 TEST RESULTS 30 5 . AVERAGE TIME OF OCCUPANCY 31 5.1 APPLIED PROCEDURES / LIMIT 31 Page 3 of 55 Report No.:NTEK-2011NT0930290F2 Table of Contents Page 5.1.1 TEST PROCEDURE 31 5.1.2 DEVIATION FROM STANDARD 31 5.1.3 TEST SETUP 32 5.1.4 EUT OPERATION CONDITIONS 32 5.1.5 TEST RESULTS 33 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.1.1 TEST PROCEDURE 39 6.1.2 DEVIATION FROM STANDARD 39 6.1.3 TEST SETUP 39 6.1.4 EUT OPERATION CONDITIONS 39 6.1.5 TEST RESULTS 40 7 . BANDWIDTH TEST 43 7.1 APPLIED PROCEDURES / LIMIT 43 7.1.1 TEST PROCEDURE 43 7.1.2 DEVIATION FROM STANDARD 43 7.1.3 TEST SETUP 43 7.1.4 EUT OPERATION CONDITIONS 43 7.1.5 TEST RESULTS 44 8 . PEAK OUTPUT POWER TEST 46 8.1 APPLIED PROCEDURES / LIMIT 46 8.1.1 TEST PROCEDURE 46 8.1.2 DEVIATION FROM STANDARD 46 8.1.3 TEST SETUP 46 8.1.4 EUT OPERATION CONDITIONS 46 8.1.5 TEST RESULTS 47 9 . OUT OF BAND EMISSION 48 9.1 APPLIED PROCEDURES / LIMIT 48 9.1.1 TEST PROCEDURE 48 9.1.2 DEVIATION FROM STANDARD 48 9.1.3 TEST SETUP 49 9.1.4 EUT OPERATION CONDITIONS 49 9.1.5 TEST RESULTS 50 9.1.6 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 52 10 . EUT TEST PHOTO 54 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 4 of 55 Report No.:NTEK-2011NT0930290F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(c) Antenna conducted Spurious EmissionPASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(b)(1) Number of Hopping Frequency PASS 15.247(a)(1) Dwell Time PASS 15.205 Restricted Bands PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 5 of 55 Report No.:NTEK-2011NT0930290F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC FRN Registration Nombre:238937; IC Registration Nombre:9270A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 Radiated Emission Test ±3.17dB 3 RF power,conducted ±0.16dB 4 Spurious emissions,conducted ±0.21dB 5 All emissions,radiated(<1G) ±4.68dB 6 All emissions,radiated(>1G) ±4.89dB Page 6 of 55 Report No.:NTEK-2011NT0930290F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Mob…
