Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: Z5CRC-200 Product: Wireless Rear View Mirror with Back Up Camera Model No.: RC-200 Additional Model: N/A Trade Mark: AutoXS Report No.: TCT150527E008 Issued Date: Jun. 25, 2015 Issued for: SUPRA Foto Elektronik Vertriebs GmbH Denisstrasse 28a 67663 Kaiserslautern Germany Issued By: Shenzhen Tongce Testing Lab. 1F, Leinuo Watch Building, Fuyong Town, Baoan Dist, Shenzhen, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT150527E008 Page 2 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. Genera Information .................................................................................. 6 4.1. Test Environment and Mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations .................................................................. 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ..................................................... 8 6.1. Antenna Requirement ........................................................................................... 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Radiated Emission Measurement ........................................................................ 9 6.4. 20dB Occupied Bandwidth ................................................................................. 16 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT150527E008 Page 3 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Wireless Rear View Mirror with Back Up Camera Model No.: RC-200 Additional Model: N/A Applicant: SUPRA Foto Elektronik Vertriebs GmbH Address: Denisstrasse 28a 67663 Kaiserslautern Germany Manufacturer: Shenzhen Anlud Science And Technology Development Co.,Ltd. Address: Building A, Bole Industrial Zone, Bantian Avenue, Longgang District, Shenzhen City, Guangdong Province, P.R. China Date of Test: May 28 – Jun. 24, 2015 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Jun. 24, 2015 Leon Chen Reviewed By: Date: Jun. 25, 2015 Joe Zhou Approved By: Date: Jun. 25, 2015 Tomsin Report No.: TCT150527E008 Page 4 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203 PASS AC Power Line Conducted Emission §15.207 N/A Field Strength of Fundamental §15.249 (a) PASS Spurious Emissions §15.249 (a) (d)/ §15.209 PASS Band Edge §15.249 (d)/ §15.205 PASS 20dB Occupied Bandwidth §15.215 (c) PASS Note: 1. Pass: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT150527E008 Page 5 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product Name: Wireless Rear View Mirror with Back Up Camera Model : RC-200 Additional Model: N/A Trade Mark: AutoXS Operation Frequency: 2468MHz Modulation Type: FM Antenna Type: Internal Antenna Antenna Gain: 1dBi Power Supply: DC10~24V Report No.: TCT150527E008 Page 6 of 17 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 4. Genera Information 4.1. Test Environment and Mode Operating Environment: Temperature: 25.0 C Humidity: 54 % RH Atmospheric Pressure: 1010 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel and modulations The sample was placed 0.8m above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. 4.2. Description of Support Units The EUT has been tested as an independent u…

Text truncated - open the document above for the full version.

Page 1 of 1 Appendix A: Photographs of Test Setup Radiated Emission
