Z5GMPT-IIIMobile thermal printer

1 User Manual 2 3 4 5 6 7 8 9 10 FCC Requirement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment. This device can be expected to comply with part 15 of the FCC Rules provided it is assembled in exact accordance with the instructions provided with this kit. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. M/N: MPT-III FCC ID: Z5GMPT-III

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Xiamen PRT Technology Co., Ltd 2011-10-1 8 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _ Xiamen PRT Technology Co., Ltd hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description: mobile thermal printer, model name: MPT-II I) We affirm that between SIEMIC and __ _ Xiamen PRT Technology Co., Ltd __ , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Shuying Huang / Manager Contact information / address: 4&5F., 8# Gaoqi Nan Shi’er Road (Aide Airport Industrial Park), Xiamen, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 Xiamen PRT Technology Co., Ltd 2011-10-1 8 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: Z5GMPT-II I We hereby request confidential treatment of information accompanying this application as outlined below: -Schematics - Detailed Block diagrams - Detailed Operational/Functional Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Shuying Huang / Manager Contact information / address: 4&5F., 8# Gaoqi Nan Shi’er Road (Aide Airport Industrial Park), Xiamen, China

FCC Label information: Label

Report No. : EESZD07200006 Page 1 of 17 FCC TEST REPORT Product Name : mobile thermal printer Trade Name : PRT Model Name : MPT-III Serial Number : 08420016093、08420016092 FCC ID : Z5GMPT-III Technical Data : N/A Report Number : EESZD07200006 Date : Oct. 18, 2011 Regulations : See below Test Standards Results FCC Part 15 Subpart B: 2010 PASS Prepared for: Xiamen PRT Technology Co., Ltd 4&5F., 8# Gaoqi Nan Shi’er Road (Aide Airport Industrial Park), Xiamen, China Prepared by: CENTRE TESTING INTERNATIONAL (SHENZHEN) CORPORATION Building C, Hongwei Industrial Zone, Baoan 70 District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Check No.: 30007853 This report shall not be reproduced, except in full, without the written approval of CENTRE TESTING INTERNATIONAL (SHENZHEN) CORPORATION Report No. : EESZD07200006 Page 2 of 17 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ..........................................................................................3 2. TEST SUMMARY .........................................................................................................4 3. MEASUREMENT UNCERTAINTY ...............................................................................4 4. PRODUCT INFORMATION AND TEST SETUP ..........................................................4 5. FACILITIES AND ACCREDITATIONS .........................................................................5 6. CONDUCTED EMISSION TEST ..................................................................................6 7. RADIATED EMISSION TEST.......................................................................................9 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP............................................................13 APPENDIX 2 PHOTOGRAPHS OF EUT ..........................................................................14 (Note: N/A means not applicable) Report No. : EESZD07200006 Page 3 of 17 1. GENERAL INFORMATION Applicant: Xiamen PRT Technology Co., Ltd 4&5F., 8# Gaoqi Nan Shi’er Road (Aide Airport Industrial Park), Xiamen, China Manufacturer: Xiamen PRT Technology Co., Ltd 4&5F., 8# Gaoqi Nan Shi’er Road (Aide Airport Industrial Park), Xiamen, China Product Name: mobile thermal printer Trade Name: PRT Model Name: MPT-III Serial Number: 08420016093、08420016092 FCC ID: Z5GMPT-III Report Number: EESZD07200005 Date of Test: Jul. 20, 2011 to Oct. 18, 2011 The results of this test report are only valid for the mentioned equipment under test. The test report with all its sub-reports, e.g. tables, photographs and drawings, is copyrighted. Unauthorized utilization, especially without permission of the test laboratory, is not allowed and punishable. For copying parts of the test report, a written permission by the test laboratory is needed. The test results of this report relate only to the tested sample identified in this report. Date Oct. 18, 2011 Report No. : EESZD07200006 Page 4 of 17 2. TEST SUMMARY The EUT has been tested according to the following specifications: Standard Test Item Test FCC 15.107 Conducted Emission Yes FCC 15.109 Radiated Emission Yes 3. MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Test item Value (dB) Conducted Emission 2.7 Radiated Emission 4.4 4. PRODUCT INFORMATION AND TEST SETUP 4.1. PRODUCT INFORMATION Technical Data: 100V-240V, 50Hz/60Hz 4.2. TEST SETUP CONFIGURATION See test photographs attached in Appendix 1 for the actual connections between EUT and support equipment. 4.3. SUPPORT EQUIPMENT No. Device Type Brand Model Series No. Data Cable Power Cord 1. PC Lenovo PCG-3G1T 282170999014058N/A N/A 2. Monitor IBM 9205-AB6 VK-KZ133 Un-shielded 1.2M N/A 3. Mouse IBM M028UOL 23-468157 Un-shielded 1.2M N/A 4. Keyboard IBM 89P8300 02284699 Un-shielded 1.2M N/A Notes: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. Report No. : EESZD07200006 Page 5 of 17 5. FACILITIES AND ACCREDITATIONS 5.1. TEST FACILITY All test facilities used to collect the test data are located at Hongwei Industrial Zone, Baoan 70 District, Shenzhen, China. The site and apparatus are constructed in conformance with the requirements of ANSI C63.4, CISPR 16-1-1 and other equivalent standards. 5.2. TEST EQUIPMENT LIST Instrumentation: The following list contains equipments used at CTI for testing. The calibrations of the measuring instruments, including any accessories that may effect such calibration, are checked frequently to assure their accuracy. Adjustments are made and correction factors applied in accordance with instructions contained in the manual for the measuring instrument. Equipment used during the tests: Shielding Room No. 1 - Conducted Emission Test Equipment Manufacturer Model Serial No. Due Date Receiver R&S ESCI 100009 07/06/2012 LISN R&S ENV216 100098 07/06/2012 3M Semi-anechoic Chamber - Radiated Emission Test Equipment Manufacturer Model Serial No. Due Date 3M Chamber & Accessory Equipment ETS-LINDGRENFACT-3 3510 07/09/2012 Spectrum Analyzer Agilent E4440A MY46185649 03/29/2012 Biconilog Antenna ETS-LINGREN 3142C 00044562 07/06/2012 Multi device Controller ETS-LINGREN 2090 00057230 N/A 5.3. LABORATORY ACCREDITATIONS AND LISTINGS The measuring equipment utilized to perform the tests documented in this report has been calibrated once a year or in accordance with the manufacturer's recommendations, and is traceable under the ISO/IEC/EN 17025 to international or national standards. Equipment has been calibrated by accredited calibration laboratories. Report No. : EESZD07200006 Page 6 of 17 6. CONDUCTED EMISSION TEST 6.1. LIMITS L…
