Quick Start Guide Smart Wireless Cube Camera Quick Start Guide Smart Wireless Cube Camera Model: E96F Welcome Thank you for choosing our smart camera. Getting started is easy. 1. What’s Included Security Camera Reset Needle 3M tape Power Adapter Quick Start Guide 3. Connection Preparation Bring the camera and phone within 1 to 3 feet (30 to 100 centimeters) of the router. Router 30cm~100cm Camera Smartphone Note: Make sure smart phone is connected with your wireless router. Please note the camera is only working under 2.4G Wi-Fi, not support 5G Wi-Fi. 4. Get the APP and Account For the best experience, please download the "Tuya Smart" APP to your smartphone from App Store or Google Play, or you can also scan the QR code below, the APP icon will be displayed after installed successfully. Tuya Smart Tuya Smart Launch the app from your smartphone and click the Sign Up button. Follow the on-screen instructions. You can place your camera on a shelf or other flat surface, or you can mount it to the wall. To mount your camera to the wall: 8. Place or Mount Your Camera Connect the power to the camera by DC5V/1A Micro USB Power Adapter. 6. Connect the power to the camera You can use 3M sticker to mount the camera on the wall. You’re done! Congratulations! Your camera is set up and ready to go. All trademarks are used for reference purposes only. Thanks again for choosing our smart camera! Make life safe in your hands! Boost security mobility in your smartphone! Appendix: Camera LED Guide Model: E96F Insert the Micro SD card gently on the side edge of camera. 5. Insert the Micro SD card Use the Reset Needle to press the reset button of camera above 5 seconds, then release the button, a red LED on the front of camera will blink quickly. ollow App's instructions to complete network pairing process, the device will connect to your Wi-Fi network successfully. The blue light is on, camera is ready for viewing. 7. Set up your camera Rtguu"vjg"Tgugv"dwvvqp"hqt"cdqxg"7"ugeqpfu"vq"uvctv"Tgugv"rtqeguukpi NO. LED Status Camera Status 1 System starting up Red LED on 2 Standby for configuration Red LED blinks quickly 3 Network pairing Blue LED blinks quickly 4 Camera online Blue LED on 5 OTA upgrade Red LED blinks slowly 2. Product Details Indicator light Infrared lights Lens Base Speaker Power interface Microphone MicroSD card Reset Tgf"nkijv" dnkpmu 3M tape FCC ID: Z63-E96F FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
