Z89-10554001RFID READER

Insert P/N: Y1NS-0004-101 v04 draft 2 Documentation Download Information Keep this insert for future reference. Equitrac provides product documentation in PDF format. You will need Adobe ® Reader ® 5.0 or later to open, view, and print these documents. 1. Visit http://download.equitrac.com/Equitrac/hwdocs/index.html 2. For return visitors to this site, log on using your user information and select the document(s) you want to download. a. New users follow the on-screen registration instructions to create a user account. Serial # ____________________________ (Record the serial number of the unit for future reference.) FCC: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. IC: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Installation Information

PageCounter R/N: PC1CFZ00-X v04 Serial No.: PC354485 *PC1CFZ00-X* *PC354485* Volts: 5 VDC AMPS: 3 Model: PC Copy www.equitrac.com Made in U.S.A. MAC 0004B5568B5 K IC: 1818A-10554001 FCC ID: Z89-10554001

Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 2 of 12 D I R E C T O R Y - EMISSIONS Page(s) A)Documentation Test report1 - 10 Directory2 Test Regulations3 General Remarks10 Test-setups (Photos)11 - 12 B)Test data Conducted emissions150 kHz - 30 MHz5, 9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Conducted Emissions - Telecom port150 kHz - 30 MHz6, 9 Equivalent Radiated emissions1 GHz - 18 GHz7, 9 Antenna Terminal30 MHz - 1000 MHz7,9 C)Appendix A Test Equipment Calibration Information Test Data Sheets A2 A3 - A18 D)Appendix B System Under Test DescriptionB2 - B3 E) Appendix C Measurement Protocol C1 - C2 Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 3 of 12 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: 9 - EN 61000-6-3:2001 # -RSS-210 Issue 7 9 - EN 55011 : 2006 /A2:20079 - Group 19 - Group 2 9 - Class A9 - Class B # - EN 300 330-2 V1.5.1 9 - EN 55014 -1: 2001/A1:2001 A2:20029 - Household appliances and similar 9 - Portable tools 9 - Semiconductor devices # - EN 55022:2006/A1:2007# - Class A9 - Class B # -CISPR 22:2005/A1:2005# - Class A9 - Class B # - ICES-003# - Class A9 - Class B 9 - CNS 134389 - Class A9 - Class B 9 - VCCI V-3/2007.49 - Class A9 - Class B # - FCC Part 15 Subpart B# - Class A9 - Class B 9 - Certification 9 - Verification # - Declaration of Conformity # - FCC Part 15.209# - Certification Report Revision History ReleaseIssue DateComments Original09/23/2011NA Revision 109/28/2011Added additional model numbers Revision 210/12/2011(30-1,000) MHz retest with different peripherals Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 4 of 12 Environmental conditions during testing: LAB OATS Temperature: * _________: ________ Relative Humidity: ** _________: ________ * The ambient temperature during the testing was within the range of (50 o - 104 o F) unless indicted above. ** The humidity levels during the testing was within the range of (10% - 90%) relative humidity unless indicated above. Power supply system : 115 / 60 & 230 / 50 Sign Explanations: 9 - not applicable # - applicable Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 5 of 12 Emissions Test Conditions: CONDUCTED EMISSIONS ( Interference Voltage) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: 9 - Test not applicable 9 - Darby Test Site (Open Area Test Site) 9 - Darby Laboratory Test equipment used : Model NumberManufacturerDescriptionSerial Number # - 8028-50Solar50 S LISN829012, 829022 9 - 3825/2Solar50 S LISN924840 # - EMC-30Electro-MetricsEMI Receiver191 9 - 8566BHewlett-PackardSpectrum Analyzer2421A00526 9 - 85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 - 85662AHewlett Packard Analyzer Display2403A07352 9 - 8028-50Solar50 S LISN903725, 903726 9 - FCC-TLISN-T4-02Fisher Custom Com.Telecom ISN20454 9 - FCC-TLISN-T8-02Fisher Custom Com.Telecom ISN20452 Emissions Test Conditions: RADIATED EMISSIONS (Magnetic Field) The RADIATED EMISSIONS (MAGNETIC FIELD) measurements were performed at the following test location: # - Darby Test Site (Open Area Test Site) 9 - 9 - at a test distance of : 9 - 3 meters # - 10 meters 9 - Test not applicable Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 - 3148EMCOLog Periodic Antenna00044783 9 - BIA-25Electro-MetricsBiconical Antenna4283 # - 8566BHewlett-PackardSpectrum Analyzer2421A00526 # - 85662AHewlett-PackardAnalyzer Display2403A07352 # - 85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 - ALR-30MElectro-MetricsLoop Antenna824 # - 8447DHewlett PackardPreamplifier2944A06832 9 - # - EMC-30 ALA-130/A Electro-Metrics Antenna Research EMI Receiver Loop Antenna 191 106 Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 6 of 12 Emissions Test Conditions: RADIATED EMISSIONS ( Electric Field) The RADIATED EMISSIONS (ELECTRIC FIELD) measurements, in the frequency range of 30 MHz-1000 MHz, were tested in a horizontal and vertical polarization at the following test location : 9 99 9 - Test not applicable # - Darby Site (Open Area Test Site) 9 - Darby Lab 9 - at a test distance of : 9 - 3 meters # - 10 meters 9 - 30 meters Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 - HLP 3003CEMC AutomationHybrid Periodic Antenna017501 # - 8447DHewlett-PackardPreamplifier (26dB)2944A06832 # - 8566BHewlett-PackardSpectrum Analyzer2421A00526 # - 85662AHewlett-PackardAnalyzer Display2403A07352 # - 85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 - BIA 25 Electro-Metrics Biconical Antenna4283 9 - EMC-30Electro-MetricsEMI Receiver191 9 - 9 - 9 - # - # - 8568B 85650A 85662A LPA30 BIA-30 Hewlett Packard Hewlett Packard Hewlett Packard Electro-Metrics Electro-Metrics Spectrum Analyzer Quasi-Peak Adapter Analyzer Display Log Periodic Biconical Antenna 2407A03213 2043A00358 2340A05806 2280 3852 9 - 3104C EMCO Biconical Antenna 00075927 Emissions Test Conditions): CONDUCTED EMISSIONS - TELECOMMUNICATIONS PORT The INTERFERENCE POWER measurements were performed in the frequency range 0.15 MHz - 30 MHz at the following test location : 9 - Test not applicable 9 - Darby Lab 9 - Test equipment used : Model NumberManufacturerDescriptionSerial Number # - EMC-30Electro-MetricsEMI Receiver191 9 - FCC-TLISN-T8-02Fischer Custom ComT-LISN20452 # - FCC-TLISN-T4-02Fischer Custom ComT_LISN20454 9 - 9 - 9 - Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-…

Text truncated - open the document above for the full version.

Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 11 of 12 Test-setup photo(s): Conducted emission 150 kHz - 30 MHz Test Report Number 11F302C Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz
