Z8D-QM29020Sit Down Quilting Machine Regulator Adapter or Base

Handi Quilter HQ Sew Sweet™ Stitch Regulator User Manual Important Information Regulatory Information Réglementations Radio Frequency Interference RF Technical Specifications Laser Safety Information General Safety Considerations Informations générales en matiére de sécurité Environmental Considerations Recycling Information Waste Electrical and Electronic Equipment (WEEE) Directive Important Battery Information General Precautions Special Precautions Battery Disposal Consignes concernant les batteries Batteries Directive Health Warning Avertissement de la Santé Product Description Stitch Regulator Components Pre-installation Instructions Verification of compatibility Battery Charging Installation Instructions Features Tips and Techniques Important Information Regulatory Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This Class B digital apparatus complies with Part 15 of the U.S. Federal Communications Commission (FCC) rules, Canadian ICES-003 and RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The term “IC:” before the certification/registration number only signifies that the Industry Canada technical specifications were met. Réglementations Cet appareil numérique de la classe B est conforme aux norms NMB-003 et CNR-210 du Canada. Son fonctionnement est assujetti aux deux conditions suivantes: (1) Cet appareil ne puet pas provoquer d’interférences nuisibiles et (2) cet appareil doit accepter toute interference recue, y compris les interferences pouvant entraîner un fonctionnement non desire. L’expression «IC:» avant le numéro d’homologation/enregistrement signefie seulement que les specifications techniques édictées par Industrie Canada ont été respectées. Radio Frequency Interference This product uses the unlicensed Industrial, Medical and Scientific (ISM) radio band, which begins at 2.400 GHz and extends to 2.483 GHz. Many commonly used products also share this band, including WiFi (wireless) network routers and cordless telephones. Correct and consistent operation of this product may be affected by these conflicting devices. RF Technical Specifications RF Output Power: < 92 dbμV/m at 3m Radio Band: 2.400 GHz to less than 2.483 GHz. Radio Channels: 34 channels, auto selection. Laser Safety Information CLASS 1 Laser Product The HQ Sew Sweet™ Motion Detector contains an invisible laser device that complies with stringent safety requirements. The product meets the U.S. DHHS and IEC 60825-1 laser safety standard requirements for and is classified as a Class 1 laser product. Under this classification, Class 1 denotes lasers whose radiation does not pose a hazard under normal or single fault conditions. There is no risk to eyes including use of an optical instrument. There is no risk to skin. General Safety Considerations Warning To protect against risk of fire, bodily injury, electrical shock or damage to the product: • Do not immerse any part of this product in water or other liquid. • Do not spray liquid on this product or allow excess liquid to drip inside. • Do not use this product if it has sustained damage, such as a damaged cord or plug. • Clean only with a damp cloth. Use water and a light detergent such as dishwashing detergent if needed. Informations générales en matiére de sécurité AVERTISSEMENT Pour protéger contre tout les risques de feu, blessures corporelles, chocs électrique ou risque d’endommager ce produit. • Ne pas immerger aucune partie de ce produit dans l’eau ou tout autre liquide. • Ne jamais vaporiser cette machine ou permettre un excès de liquide de tomber goûte à goûte a l’intérieur. • Ne jamais utiliser la machine si elle a été endommagée, tel que corde électrique ou prise de courant avarié. • S’il est nécessaire de nettoyer la machine, un torchon humide avec un détergent léger (tel qu’un détergent vaisselle) suffirais. Environmental Considerations Recycling Information Handi Quilter recommends that customers dispose of their used electronic products in an environmentally sound manner. Potential methods include reuse of parts or whole products and recycling of products, components and/or materials. Waste Electrical and Electronic Equipment (WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. For information on how to recycle this product in your country, contact your Handi Quilter Dealer. Important Battery Information Caution – Do not attempt to replace the battery. Your warranty is void if you attempt to do so. Contact Handi Quilter or an authorized Handi Quilter representative for battery replacement. General Precautions • Keep batteries out of the reach of children. • If a battery leaks, remove the battery and recycle…

Text truncated - open the document above for the full version.

www.HandiQuilter.com 1-877-697-8458 FCC ID: Z8D-QM29020 AA Handi Quilter SDSR Adapter IC ID: 10008A-QM29020 N4292 SAA101265EA 5V 1.0A Model: QM29020

EMC Report for Handi Quilter on the Model: SDSR Wireless Accessory Base Page 1 of 48 TEST REPORT Report Number: 100521432DEN-004_Base Project Number: G100521432 Report Issue Date: 11/30/2011 Product Designation: SDSR Wireless Accessory Base Standards: FCC 47 CFR Part 15.249 IC RSS 210: Issue 8:2010 IC RSS-GEN Issue 3:2010 Tested by: Client: Intertek Testing Services NA, Inc. 1795 Dogwood St. Suite 200 Louisville, CO 80027 Handi Quilter LLC 445 N 700 W North Salt Lake, UT 84054 Report prepared by Report reviewed by Michael Kanda EMC Team Leader Michael Spataro Engineering Team Leader This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Report Number: 100521432DEN-004 Base Issued:11/30/2011 EMC Report for Handi Quilter on the Model: SDSR Wireless Accessory Base Page 2 of 48 TABLE OF CONTENTS 1 Introduction and Conclusion .............................................................................................................. 3 2 Test Summary ...................................................................................................................................... 3 3 Description of Equipment Under Test ............................................................................................... 5 4 System setup including cable interconnection details, support equipment and simplified block diagram ........................................................................................................................................................ 7 5 Radiated Emissions – Fundamental Power & Harmonics of the Fundamental ............................. 9 6 Radiated Emissions – Unintentional and Spurious of the Transmitter ........................................ 16 7 Band Edge Measurements – Unintentional and Spurious of the Transmitter ............................. 26 8 Unintentional Radiated Emissions - Receiver................................................................................. 31 9 Occupied Bandwidth (OBW) ............................................................................................................. 35 10 AC Mains Conducted Emissions .................................................................................................. 38 11 Measurement Uncertainty.............................................................................................................. 45 12 Duty Cycle Correction Factor........................................................................................................ 46 Appendix A: Modifications required - None ........................................................................................... 47 13 Revision History ............................................................................................................................. 48 Intertek Report Number: 100521432DEN-004 Base Issued:11/30/2011 EMC Report for Handi Quilter on the Model: SDSR Wireless Accessory Base Page 3 of 48 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 3.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. 2 Test Summary Section Test full name Test date Result 5 Radiated Emissions – Field Strength of the Fundamental & Harmonics of the Fundamental – FCC 15.249(a)/15.205/209 (Covers RSS-210 A8.4(4) & A8.5) 10/24/2011 Pass 6 Radiated Emissions – Unintentional and Spurious of the Transmitter - FCC 15.209/15.249(a)/15.205 (Covers RSS-210 A8.5, & RSS-GEN 7.2.2/5) 10/26/2011 Pass 7 Radiated Emissions – Unintentional and Spurious – Band Edge FCC 15.209/15.249(a)/15.205 (Covers RSS-210 A8.5, & RSS-GEN 7.2.2/5) 10/27/2011 Pass 8 Radiated Emissions – Unintentional – Receiver FCC 5.209/15.249(a)/15.205 (Covers RSS-GEN Section 6) 11/15/2011 Pass 9 Occupied Bandwidth – RSS-GEN, Section 4.6.1 11/10/2011 Pass 10 AC Conducted Emissions – FCC 15.207 (Covers RSS-GEN Section 7.2.4) 10/27/2011 Pass Notes: None Intertek Report Number: 100521432DEN-004 Base Issued:11/30/2011 EMC Report for Handi Quilter on the Model: SDSR Wireless Accessory Base Page 4 of 48 2.1 Test Facility Intertek Denver’s testing facilities are located at 1795 Dogwood St. Suite 200 Louisville, CO 80027. The testing facility is ISO17025:2005 accredited by A2LA, our lab code is 2506.02, our VCCI registration numbers are. R-1643, C-1752 and T-1558, our FCC designation no. US1121 and our IC lab no. 2042N. Testing contained in this test report may not be covered under the laboratories scope of accreditation. A note will be placed in the specific test section for testing not coved under the laboratories scope. Genera…
