ZAR-TGPBA0010260

Taiwan Green Point Enterprises Co., Ltd. Jabil Design Services Branch

ZigBee Interface Module

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 07, 2011
Application Purpose: Original Equipment
Date of Application: Mar 07, 2011
Equipment Note: ZigBee Interface Module
Frequency Range: 2405.00000000 - 2480.00000000
Company: Taiwan Green Point Enterprises Co., Ltd. Jabil Design Services Branch
Country: Taiwan

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Contact Information

Applicant

Thomas Chang(PM)

[email protected]+886-2-2799-9292Fax: +886-2-2799-3016

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchHank Chung

[email protected]886-3-593-5343

81-1, Lu Laio Keng, 9th Ling, Wu Lung Tsuen, Chiun · Hsinchu Hsien · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchNatacha Chen

[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen

[email protected]886-3-3183232Fax: 886-3-2115834

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	170.00 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. Single Modular Approval for mobile RF Exposure conditions, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter.
