ZDB-KSSelfie Stick

Specifications: 1. Compatible with iOS/Android 2. Connection: Bluetooth 3.0 3. Battery Capacity: 50 mAh 4. Main Material: steel 5. Flex section: 7 6. Extension Length: 19-97cm 7. Holder size: 5.5-8.5cm 8. Maximum loading weight: 500g 9. Weight:130g 10.Color: black, red, pink, green, blue How to use: 1. to enter the mobile phone "Settings" - "open the Bluetooth -" click to open the Bluetooth pairing picture. 2. open the Bluetooth shutter switch, observe the mobile phone screen to see if there are any new Bluetooth device, if no new Bluetooth devices, please click the scan button on the mobile phone Bluetooth, until you see the new device pairing. 3. click on the mobile phone the paired device, display the connected Bluetooth devices. This Bluetooth pairing success. 4. if no such content, please repeat the above operation, until the pairing is successful. 5. if the operation is not successful, please charge the Bluetooth shutter charge. Shooting: Press the proper button on the shutter for iso and android phones to taking the photos. Accessories: 1 x monopod 1x phone holder 1x charging cable Bluetooth selfie stick KS10 FCC ID: ZDB-KS Specifications Selfie stick 1.monopod 2.support Android , IOS 3.Flex height:19-97CM 4. with package 7 sections 5. User Manual Monopod also fits cemara with 1/4 inch screw Adjustable ball head and thumb screw of monopod locks for multiple angle shooting with 180 degree position. Perfect combination for the users taking photo themselves with their iPhones Package content: 1 x Monopod 1xSmartphone clip 1 x micro usb charger cable Selfie StickProduct Name Selfie Stick Color black, white, blue, green, pink, orange Weight 160g Material stainless steel Monopod Leg Section 7 segments Monopod Min Length 19cm Monopod Max Length 97cm Max load capacity 500g Battery capacity 60 mAh Charging voltage 5 V DC Charging time 1 hour Standby time ≥100 hours Autodyne Frequency ≥500times Support system ≥Android3.0,IOS4.0 Main Funtion: s self-timer Wireless Mobile Phone,digital camera parameter 2015 The Source All rights reserved Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. N OTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.

Tianyu Technology Co., Ltd. No 5, 3rd Beian Road, HuangJiang Town, Dongguan China TEL: 0086-769-82182986 FAX: 0086-769-82182981 April 07, 2015 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Subject: Explanation of differences between product types FCC ID : ZDB-KS Model Number: KS30, KS10,,KS11, KS12, KS13, KS14, KS15, KS16, KS17, KS18, KS19; KS20, KS21, KS22, KS23, KS24, KS25, KS26, KS27, KS28, KS29; KS31, KS32, KS33, KS34, KS35, KS36, KS37, KS38, KS39; KS40, KS41, KS42, KS43, KS44, KS45, KS46, KS47, KS48, KS49 To Whom It May Concern: We, The Kintech Co., Ltd., hereby declare that the model : KS10, KS11, KS12, KS13, KS14, KS15, KS16, KS17, KS18, KS19, KS20, KS21, KS22, KS23, KS24, KS25, KS26, KS27, KS28, KS29, KS31, KS32, KS33, KS34, KS35, KS36, KS37, KS38, KS39, KS40, KS41, KS42, KS43, KS44, KS45, KS46, KS47, KS48, KS49 is identical with the model : KS30, except the model name and colour. Except for the different above, no other modification is performed. Sincerely, Tianyu Technology Co., Ltd. Tianyu Technology Co., Ltd. No 5, 3rd Beian Road, HuangJiang Town, Dongguan China TEL: 0086-769-82182986 FAX: 0086-769-82182981 Signature: Company Officer: Jason Li Telephone Number: 0086-769-82182986 Email: [email protected]

Tianyu Technology Co., Ltd. No 5, 3rd Beian Road, HuangJiang Town, Dongguan China TEL: 0086-769-82182986 FAX: 0086-769-82182981 Da te (03/04/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, Tianyu Technology Co., Ltd., hereby authorize TUV SUD BABT to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on April 03, 2016. Sincerely, Company Officer: Jason Li Telephone Number: 0086-769-82182986 Email: [email protected]

Tianyu Technology Co., Ltd. No 5, 3rd Beian Road, HuangJiang Town, Dongguan China TEL: 0086-769-82182986 FAX: 0086-769-82182981 Date (03/04/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID: ZDB-KS Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Tianyu Technology Co., Ltd. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Jason Li Telephone Number: 0086-769-82182986 Email: [email protected]

                           !  "      #   $

FCC ID Label Location Model: KS30 Brand Name: Kungfuren FCC ID: ZDB-KS KS10, KS11, KS12, KS13, KS14, KS15, KS16, KS17, KS18, KS19, KS20, KS21, KS22, KS23, KS24, KS25, KS26, KS27, KS28, KS29, KS31, KS32, KS33, KS34, KS35, KS36, KS37, KS38, KS39, KS40, KS41, KS42, KS43, KS44, KS45, KS46, KS47, KS48, KS49

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 Antenna

RF Exposure evaluation Product Description:Selfie Stick Model Number: KS30 FCC ID: ZDB-KS According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2441MHz 4.46dBm(2.79mW) output power] (2.79mW /5mm) .[√2.441(GHz)]= 0.87048<3.0 for 1-g SAR Then SAR evaluation is not required NOTE:The transmitteroutput power formula you can refer to Part15F (K). For the maximum power, you can refer FCC test report.

Page 1 of 44 FCC Test Report Report No.: AGC00006150301FE03 FCC ID : ZDB-KS APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Selfie Stick BRAND NAME : Kungfuren MODEL NAME : KS30, KS10, KS11, KS12, KS13, KS14, KS15, KS16, KS17, KS18, KS19, KS20, KS21, KS22, KS23, KS24, KS25, KS26, KS27, KS28, KS29, KS31, KS32, KS33, KS34, KS35, KS36, KS37, KS38, KS39, KS40, KS41, KS42, KS43, KS44, KS45, KS46, KS47, KS48, KS49 CLIENT : Tianyu Technology Co., Ltd. DATE OF ISSUE : Apr.1,2015 STANDARD(S) TEST PROCEDURE(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC00006150301FE03 Page 2 of 44 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Apr.1,2015 Valid Original Report Report No.: AGC00006150301FE03 Page 3 of 44 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ...................................................................................... 4 2. GENERAL INFORMATION .................................................................................................. 5 2.1. PRODUCT DESCRIPTION ........................................................................................................... 5 2.2. TABLE OF CARRIER FREQUENCYS .......................................................................................... 5 3. MEASUREMENT UNCERTAINTY........................................................................................ 6 4. DESCRIPTION OF TEST MODES ........................................................................................ 6 5. SYSTEM TEST CONFIGURATION ...................................................................................... 7 5.1. CONFIGURATION OF EUT SYSTEM .......................................................................................... 7 5.2. EQUIPMENT USED IN EUT SYSTEM ......................................................................................... 7 5.3. SUMMARY OF TEST RESULTS .................................................................................................. 7 6. TEST FACILITY .................................................................................................................... 8 7 ALL TEST EQUIPMENT LIST ............................................................................................... 8 8. RADIATED EMISSION ......................................................................................................... 9 8.1TEST LIMIT ..................................................................................................................................... 9 8.2. MEASUREMENT PROCEDURE ................................................................................................ 10 8.3. TEST SETUP .............................................................................................................................. 12 8.4. TEST RESULT ............................................................................................................................ 14 9. BAND EDGE EMISSION .................................................................................................... 27 9.1. MEASUREMENT PROCEDURE ................................................................................................ 27 9.2 TEST SETUP ............................................................................................................................... 27 9.3 RADIATED TEST RESULT .......................................................................................................... 28 10. FCC LINE CONDUCTED EMISSION TEST ..................................................................... 32 10.1. LIMITS OF LINE CONDUCTED EMISSION TEST ................................................................... 32 10.2. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ................................................ 32 10.3. PRELIMINARY PROCEDURE OF LINE CONDUCTED EMISSION TEST .............................. 33 10.4. FINAL PROCEDURE OF LINE CONDUCTED EMISSION TEST ............................................ 33 10.5. TEST RESULT OF LINE CONDUCTED EMISSION TEST ...................................................... 34 APPENDIX A: PHOTOGRAPHS OF TEST SETUP ............................................................... 36 APPENDIX B: PHOTOGRAPHS OF EUT .............................................................................. 38 Report No.: AGC00006150301FE03 Page 4 of 44 1. VERIFICATION OF CONFORMITY Applicant Tianyu Technology Co., Ltd. Address No 5, 3rd Beian Road, HuangJiang Town, Donguan, China Manufacturer Tianyu Technology Co., Ltd. Address No 5, 3rd Beian Road, HuangJiang Town, Donguan, China Product Designation Selfie Stick Brand Name Kungfuren Test Model KS30 Series Model KS10, KS11, KS12, KS13, KS14, KS15, KS16, KS17, KS18, KS19, KS20, KS21, KS22, KS23, KS24, KS25, KS26, KS27, KS28, KS29, KS31, KS32, KS33, KS34, KS35, KS36, KS37, KS38, KS39, KS40, KS41, KS42, KS43, KS44, KS45, KS46, KS47, KS48, KS49 Difference description All the same except for the appearance color and shape. Date of test Mar.23,2015 to Mar.24,2015 Deviation None Condition of Test Sample Normal Report Template AGCRT-US-BR/RF We hereby certify that: The above equipment was tested by Shenzhen STS Test Services Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with radiated emission limits of FCC Rules Part 15.249. Prepared By Water Zuo Apr.1,2015 Checked By Forrest Lei Apr.1,2015 Authorized By Solger Zhang Apr.1,2015 Report No.: AGC00006150301FE03 Page 5 of 44 2. GENERAL INFORMATION 2.1. PRODUCT DESCRIPTION A major technical d…

Text truncated - open the document above for the full version.

Test Setup Photos FCC LINE CONDUCTED EMISSION TEST SETUP FCC RADIATED EMISSION TEST SETUP
