ZDD-FS-GM704-004 port UHF RFID Reader Module

FS-GM704 Evaluation Kit User Manual V1.00 1 FS-GM704 Module Evaluation Kit User Manual V1.0 FS-GM704 Evaluation Kit User Manual V1.00 2 1. Initial setup 1.1 Powering the Reader Plug the power cable in, with the indicator light on & reader is ready. As illustrated below: 1.2 Connecting Antenna to Reader Connect the antenna with the antenna MMCX port as illustrated below: 1.3 Connecting Data Line to Reader You can connect the reader to your PC via B type USB, as illustrated below: DC IN: 9~24V B TYPE USB MMCX RF connector FS-GM704 Evaluation Kit User Manual V1.00 3 2. Connect DEMO SW Double-click EagleDemo.exe to run the software. 2.1 Connect 2.1.1 Open the software and it will shows as below: 2.1.2. Please select USB as Connection, Choose the corresponding Serial Port and Baud Rate (default baud rate is 921600). As illustrated below: 2.1.3. Click Connect, if it is connected successfully, the FW version will display as below: FS-GM704 Evaluation Kit User Manual V1.00 4 2.1.4. Text communication with the reader: Click on Get in Firmware Version or in Reader Region, the following screen displays: 3. Run Inventory function After connecting the reader with PC, we can start go Inventory Run function. Please select ISO 18000-6C tag test as illustrated below: FS-GM704 Evaluation Kit User Manual V1.00 5 3.1 Setp1: Enable ANT 1 Check mark the ANT1. 3.2 Setp2: Setting RF Output Power RF Output Power is the strength of RF output signal from antenna port whose unit is dBm. The output power range is 0 - 33dBm. Default RF output power is 30dBm . 3.3 Setp2: Setting Inventory time & Run Setting Inventory time is mean the running time when start inventory command. Setting Inventory Run is mean the running once when start inventory command. Inventory stop if which time or run up to the setting value The default inventory time is 1000ms. The default inventory run is 0, which mean “don`t care”. 3.4 Setp3: Setting RF-link mode There is different read speed & sensitivity in different RF-link mode. To more detail, please check the RF-link profile of datasheet. FS-GM704 Evaluation Kit User Manual V1.00 6 3.5 Setp4: Run/Stop Inventory click Inventory button to Run Inventory function. click Stop button enforce to stop Inventory function. 3.6 Parameter of AUTO Stop Inventory Loop time Inventory stop when reach the setting of command count. Conti-Inventory Inventory stop when reach the setting of Inventory period. * it will no stop if tick continuous 3.7 The parameter of Running Inventory There are 13 parameters when run inventory as shown as following. Inventoried Quantity Total number of inventory tags since click Inventory. Peak Speed Read Speed of Tag for last one inventory command, unit: Tag/s Max speed MAX Read Speed of Tag for total inventory period, unit: Tag/s AVG speed AVG Read Speed of Tag for total inventory period, unit: Tag/s Command Duration Time between Inventory Command to command, unit: ms Total Inventory Duration Total inventory period when click Inventory, unit: ms. Total Tag Count Total tags when start Inventory period. Count Tag count EPC EPC data of tag. PC PC data CRC CRC data RSSI The Tag signal strength at the last inventory command. FS-GM704 Evaluation Kit User Manual V1.00 7 Carrier Frequency Carrier Frequency of tag at the last time. 4. Error Display
ANT error: Reason: 1. ANT is Disconnection to ANT port of module 2. VSWR is too large of ANT, it should be lower than 1.3 3. Reflection RF power too large, please check is there some Metal around ANT.
Receiver data time out: Reason: 1. Software CRASH 2. Interface CRASH FS-GM704 Evaluation Kit User Manual V1.00 8 15.105 statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Caution (15.19 statement) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Non-modification Statement: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Validity of using the module certification: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization for this module in combination with the host equipment is no longer considered valid and the FCC ID of the module cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a sepa…

Text truncated - open the document above for the full version.

Covered list attestation FCC application letter Kiwa Page 1 of 2 RF_755_02 15-02-2023 FAVEPC Inc 6F-11,No.28,Tai-Yuen St.,Chu-Pei City, Hsinchu County 302082, Taiwan Certification Application Attestation Statements FAVEPC Inc 6F-11,No.28,Tai-Yuen St.,Chu-Pei City, 302082 Hsinchu County, Taiwan Subject: FCC ID: ZDD-FS-GM704-00 To W hom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) [FAVEPC Inc] certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) [FAVEPC Inc] (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: July 22, 2024 City: Hsinchu County Name (2) : Pike Chang Function: Vice President Telephone number: +886-3-5525838 Email address: [email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK”

Agent letter FCC attestation statement Kiwa Page 1 of 2 RF_753, Issue 2 15-02-2023 FAVEPC Inc No.176,Taihe Rd.,Jhubei City , Hsinchu County 30267, Taiwan U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Kiwa Nederland B.V. Wilmersdorf 50 7327 AC Apeldoorn Postbus 137 7300 AC Apeldoorn Netherlands The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: FAVEPC Inc Grantee Code: ZDD Contact person name: Pike Chang Street address: 6F-11,No.28,Tai-Yuen St.,Chu-Pei City, ZIP/City/State 302082/ Hsinchu County/ Taiwan Telephone number: +886-3-5525838 Email address: [email protected] Signature: Date: February 7 th , 2024

RF_160_05 Declaration of Authorisation Date of issue 02-01-2023 FAVEPC Inc 6F-11,No.28,Tai-Yuen St.,Chu-Pei City, Hsinchu County 302082, Taiwan Declaration of Authorization We Name: FAVEPC Inc Address: 6F-11,No.28,Tai-Yuen St.,Chu-Pei City City: Hsinchu County, 302082 Country: Taiwan Declare that: Name Representative of agent: Nina Hsu (1) Agent Company name: Cerpass Technology Corporation Address: No.10, Lane 2, Lianfu Street, Luzhu Dist., City: Taoyuan City 33848 Country Taiwan, R.O.C. is authorized to apply for Certification of the following product(s): Product description: : 4 port UHF RFID Reader Module Type designation: FS-GM704 Trademark: FAVEPC Validity/ expiry date N/A on our behalf. Date: July 22, 2024 City: Hsinchu County Name: Pike Chang (2) Function: Vice President Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 02-01-2022 RF_501, Issue 10 Company Name: FAVEPC Inc Address: 6F-11,No.28,Tai-Yuen St.,Chu-Pei City, City: Hsinchu County 302082 Country: Taiwan To: Kiwa Netherlands B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: ZDD-FS-GM704-00 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Prevent competitors from viewing internal parts & circuits Date: July 22, 2024 Name and signature of applicant: Pike Chang Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should state in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Kiwa NL B.V. at least 7 days before date of actual marketing or before expiration of the STC period

RF_734_05 FCC Modular Approval Request Page 1 of 3 28-12-2022 Modular Approval Request FCC (KDB 996369 D01 & Part 15.212) FCC ID: ZDD-FS-GM704-00 Items to be covered by Single modular transmitters. Answer from applicant 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly. Yes, it is fulfilled. The modular transmitter has own shielding. Shielding is show on external photos. 2. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal. YES, Module use U14 MCU as buffer modulation / data inputs 3. The module must contain power supply regulation on the module YES, it is fulfilled. The modular transmitter have its own power supply regulation 4. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per §§ 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b). Yes. The module is the contain a unique antenna connector and be marketed and operated only with specific antenna 5.The module must demonstrate compliance in a stand-alone configuration. Yes, it is fulfilled. The modular was tested in a stand-alone configuration. Please see setup photos and test jig photo. 6.The module must be labeled with its permanently affixed FCC ID label, or use an electronic display (see KDB Publication 784748). Yes, it is fulfilled. The label is shown on transmitter modular, please see the label view. . 7.The module must comply with all specific rules applicable to the transmitter, including all the conditions provided in the integration instructions by the grantee. Yes, it is fulfilled. The operation description and user guides provide this detail. 8.The module must comply with RF exposure requirements. YES Name and surname of applicant (or authorized representative): Pike Chang Date: July 22, 2024 Signature:

CERPASS TECHNOLOGY CORP. Report No.:24070239 Cerpass Technology Corp. Issued Date : Aug. 15, 2024 Page No. : 1 of 11 Photographs of EUT FAVEPC / 4 port UHF RFID Reader Module / FS-GM704 CERPASS TECHNOLOGY CORP. Report No.:24070239 Cerpass Technology Corp. Issued Date : Aug. 15, 2024 Page No. : 2 of 11 FAVEPC / 4 port UHF RFID Reader Module / FS-GM704 CERPASS TECHNOLOGY CORP. Report No.:24070239 Cerpass Technology Corp. Issued Date : Aug. 15, 2024 Page No. : 3 of 11 FAVEPC / 4 port UHF RFID Reader Module / FS-GM704 CERPASS TECHNOLOGY CORP. Report No.:24070239 Cerpass Technology Corp. Issued Date : Aug. 15, 2024 Page No. : 9 of 11 FAVEPC / 4 port UHF RFID Reader Module / FS-GM704 Antenna (Antenna is not sold with the EUT) Brand: N/A, Model: N/A CERPASS TECHNOLOGY CORP. Report No.:24070239 Cerpass Technology Corp. Issued Date : Aug. 15, 2024 Page No. : 10 of 11 FAVEPC / 4 port UHF RFID Reader Module / FS-GM704 Antenna Cable (Antenna Cable is not sold with the EUT) Brand: N/A, Model: N/A CERPASS TECHNOLOGY CORP. Report No.:24070239 Cerpass Technology Corp. Issued Date : Aug. 15, 2024 Page No. : 11 of 11 FAVEPC / 4 port UHF RFID Reader Module / FS-GM704

Label & Location

CERPASS TECHNOLOGY CORP. Report No.:24070239-TRFCC01 Cerpass Technology Corp. Issued date : Aug. 15, 2024 T-FD-517-0 Ver 1.6 Page No. : 54 of 55 FCC ID. : ZDD-FS-GM704-00 14. Radio Frequency Exposure 14.1 Applicable Standards §1.1307(b)(3)(i)(A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. §1.1307(b)(3)(i)(c) ERP is below a threshold calculated based on the distance , R between the person and the antenna / radiating structure, where R > λ / 2 π. § 1.1307(b)(3)(i)(B). Device operates between 300 MHz and 6 GHz and the maximum time-averaged power or effective radiated power (ERP), whichever is greater, <= Pth CERPASS TECHNOLOGY CORP. Report No.:24070239-TRFCC01 Cerpass Technology Corp. Issued date : Aug. 15, 2024 T-FD-517-0 Ver 1.6 Page No. : 55 of 55 FCC ID. : ZDD-FS-GM704-00 14.2 EUT Specification Frequency band (Operating) WLAN: 2412MHz ~ 2462MHz WLAN: 5150MHz ~ 5250MHz WLAN: 5250MHz ~ 5350MHz WLAN: 5470MHz ~ 5725MHz WLAN: 5725MHz ~ 5850MHz Bluetooth: 2402MHz ~ 2480MHz 902MHz~928MHz Device category Portable (<20cm separation) Mobile (>20cm separation) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Evaluation applied Blanket 1 mW Blanket Exemption MPE-based Exemption (20公分以上) SAR-based Exemption (20公分以下) Remark: The maximum conducted output power is 29.18dBm (827.942 mW) at 927.25MHz (with 5.5dBi antenna gain.) 14.3 Result Channel Frequency (MHz) Max. Conducted output power(dBm) Max. Tune up power (dBm) Antenna Gain(dBi) Antena Cable Loss(dB) Max.Tune up e.r.p. Power (dBm) Max. Tune up e.r.p power (mW) 927.25 29.18 29.68 5.5 0.5 32.53 1790.61 No non-compliance noted. ----------THE END OF REPORT----------

CERPASS TECHNOLOGY CORP. Report No.:24070239-TRFCC01 Cerpass Technology Corp. Issued date : Aug. 15, 2024 T-FD-517-0 Ver 1.6 Page No. : 1 of 55 FCC ID. : ZDD-FS-GM704-00 FCC RADIO TEST REPORT Applicant : FAVEPC Inc Address : No.176,Taihe Rd.,Jhubei City Hsinchu County,30267 Taiwan Equipment : 4 port UHF RFID Reader Module Model No. : FS-GM704 Trade Name : FAVEPC FCC ID. : ZDD-FS-GM704-00 I HEREBY CERTIFY THAT : The sample was received on Jul. 12, 2024 and the testing was completed on Aug. 07, 2024 at Cerpass Technology Corp. The test result refers exclusively to the test presented test model / sample. Without written approval of Cerpass Technology Corp., the test report shall not be reproduced except in full. Approved by: Mark Liao / Supervisor Laboratory Accreditation: Cerpass Technology Corporation Test Laboratory CERPASS TECHNOLOGY CORP. Report No.:24070239-TRFCC01 Cerpass Technology Corp. Issued date : Aug. 15, 2024 T-FD-517-0 Ver 1.6 Page No. : 2 of 55 FCC ID. : ZDD-FS-GM704-00 CONTENTS 1. Summary of Test Procedure and Test Results ................................................................................ 5 1.1 Applicable Standards ................................................................................................................. 5 2. Test Configuration of Equipment under Test ................................................................................... 6 2.1 Feature of Equipment under Test ............................................................................................... 6 2.2 Carrier Frequency of Channes ................................................................................................... 6 2.3 Test Mode & Test Software ........................................................................................................ 7 2.4 Description of Test System ......................................................................................................... 8 2.5 General Information of Test ........................................................................................................ 9 2.6 Measurement Uncertainty ........................................................................................................ 10 3. Test Equipment and Ancillaries Used for Tests ............................................................................. 11 4. Antenna Requirements ..................................................................................................................... 13 4.1 Standard Applicable ................................................................................................................. 13 4.2 Antenna Construction and Directional Gain ............................................................................. 13 5. Test of AC Power Line Conducted Emission ................................................................................. 14 5.1 Test Limit .................................................................................................................................. 14 5.2 Test Procedures ....................................................................................................................... 14 5.3 Typical Test Setup .................................................................................................................... 15 5.4 Test Result and Data ................................................................................................................ 16 5.5 Test Photographs ..................................................................................................................... 22 6. Test of Radiated Spurious Emission............................................................................................... 23 6.1 Test Limit .................................................................................................................................. 23 6.2 Test Procedures ....................................................................................................................... 23 6.3 Typical Test Setup ................................................................................................................... 24 6.4 Test Result and Data (9kHz ~ 30MHz) .................................................................................... 25 6.5 Test Result and Data (30MHz ~ 1GHz) ................................................................................... 25 6.6 Test Result and Data (1GHz ~ 25GHz) .................................................................................... 31 6.7 Restricted Bands of Operation ................................................................................................. 37 6.8 Test Photographs (30MHz ~ 1GHz) ......................................................................................... 38 6.9 Test Photographs (1GHz ~ 25GHz) ......................................................................................... 39 7. Test of Conducted Spurious Emission ........................................................................................... 40 7.1 Test Limit .................................................................................................................................. 40 7.2 Test Procedure ......................................................................................................................... 40 7.3 Test Setup Layout .................................................................................................................... 40 7.4 Test Result and Data ................................................................................................................ 40 8. On Time, Duty Cycle and Measurement methods ......................................................................... 43 8.1 Test Limit .................................................................................................................................. 43 8.2 Test Procedure .................................…

Text truncated - open the document above for the full version.

FI-A1508-US Product Feature Ultra-thinning antenna design. it can be customized mounting hole for your mounting bracket ACP material ideal for customized antenna dimension. Dimensional drawing Description The FI-A1508-US fixed antenna provides visibility into the properties, quality and reliability required for a robust solution. The ultra-thinningand can be hidden on the device or wall, and the antenna is designed to perform exceptions in all environments indoors and outdoors. FI-A1508-US provides you with a wide frequency range and high-speed RF signal conversion and data capture is fast and accurate. Applications
Retail supply chain
Manufacturing tracking
Logistics
Cold chain management
Laundry management
Personnel tracking Electrical Specification Frequency 902~928MHz Antenna Type Patch Directivity Gain 5dBi ± 0.5 dBi Return Loss -12 dB, minimum Impedance 50Ω direction High Beam Width(-3dB) XZ ±45°, YZ±46° Polarization Circular polarization Connector type SMA Female RF Cable length RG178 10cm MechanicalSpecification Size 146 x 146 x 8.2mm Weight 600g The front material ACP Mounting Universal bracket Environmental Specification Operating temperature -20 to +85 °C Storage temperature -40 to +85 °C FI-A1508-US Radiation Pattern Return Loss FI-A1508-US Dimension

CERPASS TECHNOLOGY CORP. Report No.:24070239-TRFCC01 Cerpass Technology Corp. Issued date : Aug. 15, 2024 T-FD-517-0 Ver 1.6 Page No. : 22 of 55 FCC ID. : ZDD-FS-GM704-00 5.5 Test Photographs Front View Rear View CERPASS TECHNOLOGY CORP. Report No.:24070239-TRFCC01 Cerpass Technology Corp. Issued date : Aug. 15, 2024 T-FD-517-0 Ver 1.6 Page No. : 38 of 55 FCC ID. : ZDD-FS-GM704-00 6.8 Test Photographs (30MHz ~ 1GHz) Front View Rear View CERPASS TECHNOLOGY CORP. Report No.:24070239-TRFCC01 Cerpass Technology Corp. Issued date : Aug. 15, 2024 T-FD-517-0 Ver 1.6 Page No. : 39 of 55 FCC ID. : ZDD-FS-GM704-00 6.9 Test Photographs (1GHz ~ 25GHz) Front View Rear View
