ZDX-MAS100Motion Active Sensor

Motion Activated Sensor MAS 100 User Manual The Digital Door Viewer! 01- MAS100 Thank you for purchasing Motion Activated Sensor for Brinno PeepHole Viewer! Brinno MAS100 is an extension accessory for PeepHole Viewer (PHV1330), it allows PHV1330 records images when a visitor come close to your door. So even if you are not at home, you will know who came to your door. WEEE Directive & Product Disposal At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. Internal / Supplied Batteries This symbol on the battery indicates that the battery is to be collected separately. This battery is designed for separate collection at an appropriate collection point. Thank you for purchasing Brinno’s PeepHole Viewer and accessories! If you have any questions or problems setting up your Brinno PeepHole Viewer and accessories, please contact the sales staff where you purchased our product or email us at Brinno Incorporated directly [email protected] Please Visit our website www.brinno.com Package Contents Before Installation Motion Activated Sensor (MAS100) 1 Receiver (RFS100) 3 Screw 5 Holder 2 2 AA Batteries 4 1 5 234 12 1. Install 2 AA batteries on Motion Activated Sensor (MAS100). 2. Install receiver(RFS100) into extension port on PeepHole Viewer (PHV1330). MAS100 -02 Installation 03- MAS100 IndoorIndoorOutdoorOutdoor -a-b 1 33 2 1. Install Holder and tightening the screw. 2. Tear off the cover of double-sided glue. 3. Place your Motion Activated Sensor(MAS100) on our suggestion location: a. Place on ceiling above the porch and face to ground. b. Place above door, and adjust the Motion Activated Sensor angle, face to ground. D 1* A 1* D 2* D 1 : Detected distance: 5 meters D 2 : Signal received distance: 5 meters A 1 : Detected angle: 60° Note Model Detect Angle Detect Distance Receiver Distance Power Source Accessories Size Weight MAS 100 60 ̊ 3~5 meters 5 meters 2 AA batteries Holder, Recevier, 2 AA Batteries, User Manual 66(W) x 90(H) x 24(D) mm 20 g (without batteries) MAS100 -04 Finished Specifications Now, you already finished the installation, for well working we suggest you to test the detect of Motion Activated Sensor, if it works on the location you placed, then you can use screws to fix it on the wall. If it doesn't work, please try to adjust the detect angle or change to the other location. Green: Detecting Red: Battery Low LED 05- MAS100 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: ZDX-MAS100 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Federal Communication Commission Interference Statement 301-0009-00 EN-A2 7F, No.75, Zhou Zi St., Taipei City 11493, Taiwan Phone: 886-2-8751-0306 Fax: 886-2-8751-0549 E-mail: [email protected] www.brinno.com

Brinno Incorporated. 9F., No75, Zhouzi St., Taipei city 11493 Taiwan. 2011/3/30 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID : ZDX-MAS100 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application.

Brinno Incorporated. 9F., No75, Zhouzi St., Taipei city 11493 Taiwan. Power of Attorney Date: 2011/3/30 To whom it may concern: We, the undersigned Brinno Incorporated hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by (BV CPS Taoyuan) on our behalf shall have the same effects as acts of our own. This authorization is limited to the following products： FCC ID : ZDX-MAS100 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you!

Page 1 CONSTRUCTION PHOTOS OF EUT

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4

Report No.: RF110317E06 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110317E06 MODEL NO.: MAS100 FCC ID : ZDX-MAS100 RECEIVED: Mar. 17, 2011 TESTED: Mar. 29 to Apr. 18, 2011 ISSUED: May 23, 2011 APPLICANT : Brinno Incorporated. ADDRESS : 9F., No75, Zhouzi St., Taipei city 11493 Taiwan. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 28 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110317E06 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD.................................................................................3 1 CERTIFICATION.............................................................................................4 2 SUMMARY OF TEST RESULTS.....................................................................5 2.1 MEASUREMENT UNCERTAINTY..................................................................5 3 GENERAL INFORMATION.............................................................................6 3.1 GENERAL DESCRIPTION OF EUT................................................................6 3.2 DESCRIPTION OF TEST MODES..................................................................7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..................8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...............................10 3.4 DESCRIPTION OF SUPPORT UNITS...........................................................11 3.5 CONFIGURATION OF SYSTEM UNDER TEST............................................11 4 TEST PROCEDURE AND RESULT..............................................................12 4.1 RADIATED EMISSION MEASUREMENT.....................................................12 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................12 4.1.2 TEST INSTRUMENT.....................................................................................13 4.1.3 TEST PROCEDURE.....................................................................................14 4.1.4 DEVIATION FROM TEST STANDARD.........................................................14 4.1.5 TEST SETUP................................................................................................15 4.1.6 EUT OPERATING CONDITION....................................................................15 4.1.7 TEST RESULTS............................................................................................16 4.2 20dB OCCUPIED BANDWIDTH MEASUREMENT......................................20 4.2.1 LIMITS OF EMISSION BANDWIDTH MEASUREMENT...............................20 4.2.2 TEST INSTRUMENT.....................................................................................20 4.2.3 TEST PROCEDURE.....................................................................................20 4.2.4 DEVIATION FROM TEST STANDARD.........................................................21 4.2.5 TEST SETUP................................................................................................21 4.2.6 TEST RESULTS............................................................................................21 4.3 DEACTIVATION TIME...................................................................................23 4.3.1 LIMITS OF DEACTIVATION TIME MEASUREMENT...................................23 4.3.2 TEST INSTRUMENTS..................................................................................23 4.3.3 TEST PROCEDURES...................................................................................23 4.3.4 DEVIATION FROM TEST STANDARD.........................................................23 4.3.5 TEST SETUP................................................................................................24 4.3.6 TEST RESULTS............................................................................................24 5 PHOTOGRAPHS OF THE TEST CONFIGURATION....................................26 6 INFORMATION ON THE TESTING LABORATORIES..................................27 7 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB..........................................................28 Report No.: RF110317E06 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF110317E06 Original release May 23, 2011 Report No.: RF110317E06 4 Report Format Version 4.0.0 1 CERTIFICATION PRODUCT: Motion Active Sensor BRAND NAME: brinno MODEL NO: MAS100 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Brinno Incorporated. TESTED: Mar. 29 to Apr. 18, 2011 STANDARDS: FCC Part 15, Subpart C (Section 15.231) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment (model: MAS100) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: May 23, 2011 ( Carol Liao, Specialist ) APPROVED BY : , DATE: May 23, 2011 ( May Chen, Deputy Manager ) Report No.: RF110317E06 5 Report Format Version 4.0.0 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.231) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 AC Power Conducted Emission NA Power supply is 3Vdc from batteries. 15.209 15.231(b) Radiat…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
