Thin Door/Window Contact WC10-345 Operating Instructions The WC10-345 is a Thin Door/Window Contact that can be in stalled on doors, windows, and many other objects that open and close. The sensor transmits signals to the control panel when a magnet mounted near the sensor is moved away from or closer to the sensor. The sensor has an external in put that accepts N/C dry contact devices. The sensor is also equipped with a co ver tamper for additional security. Figure 1 Installation & Mounting Guidelines Use the following guidelines for internal switch usage: 1. Mount the sensor on the door frame and the ma gnet on the door. If the sensor is used on double doors, mount the sensor on the least-used door and the magnet on the most-used door. 2. If possible, locate sensors within 100 ft. (30 m) of the panel. While a transmitter may have a range of 350 ft. (106 m) or more out in the open, th e environment at the installation site can have a significant effect on transmitter range. Some times a change in sensor orientation can help overcome adverse wireless conditions. 3. Make sure the alignment arrow on the magnet point s to the alignment mark on the sensor (see Figure 1). 4. Place sensors at least 4.7 in. (12 cm) above the floor to avoid damaging them. 5. Avoid mounting sensors in areas where they wil l be exposed to moisture or where the sensor operating temperature range of 32 to 120°F (0 to 49° C) will be exceeded. 6. Use spacers (not included) to keep sensors and mag nets away from metal or metallic surfaces such as foil wallpaper. 7. Avoid mounting sensors in areas with a large q uantity of metal or electrical wiring, such as a furnace or utility room. To mount the sensor, do the following: 1. Place the base of the sensor in the desired loc ation and secure with included screws (see Figure 2). 2. When mounting the magnet, line up the arrow on t he magnet with the middle line on one side of the Figure 2 Battery Installation & Replacement If a sensor battery is low, a low battery notification will be indicated on the 2GIG or Honeywell Alarm Control Panel’s screen. When the alarm system indicates that there is a sensor wit h a low battery, replace the battery immediately. Use only the recommended replacement batteries (seeSpecification). To install or replace the battery, do the following: 1. To remove the sensor cover, use your finger to press the tab on the end of the case. This will disengage the clip holdi ng the cover to the base. 2. Place a small flathead screwdriver in the slot between the me tal clip (see Figure 3) and the battery and twist the screwdriver slightly while holding back one of the black plastic edges holding the battery. 3. Insert the replacement battery with the + sign facing out. (see Figure 3) 4. Verify programming and RF communication with the panel . (see Testing). WARNING! The polarity of the battery must be observed, as shown ( see Figure 3). Improper handling of lithium batteries may result in heat generation, explosion or fire, which may lead to personal injuries. Replace only with the same or equivalent type of battery as recommended by the manufacturer. (see Specifications) Batteries must not be recharged, disassembled or disposed of in fire . Disposal of used batteries must be made in accor- dance with the waste recovery and recycling regulations in your area. Keep away from small children. If batteries are swallowed, promptly see a doctor. California Only: This Perchlorate warning applies only to Manganese Dioxide Li thium cells sold or distributed ONLY in California, USA. Perchlorate Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate . Specifications Wireless Signal Range 350 ft., open air, with 2GIG or Honeywel l Wireless Alarm Control Panel Code Outputs Alarm; Alarm Restore; External Alarm; External Re store; Tamper; Tamper Restore; Supervisory; Low Battery Transmitter Frequency 345.000 MHz (crystal controlled) Transmitter Frequency Tolerance ± 15 kHz Transmitter Bandwidth 24 kHz Modulation Type Amplitude Shift Keying—On/Off Keying (ASK-OOK) Unique ID Codes Over one (1) million different code combinations Supervisory Interval 70 minutes Peak Field Strength Typical 36,000 uV/m at 3m External Input Sampling Current 20 uA External Input Accepts N/C dry contact devices Reed Switch Magnetic Sensitivity 10 to 20 amp turns Reed Sensitivity 0.625 in. (1.59 cm) minimum gap, 0.85 in. ( 2.16 cm) typical Magnet Type Rare earth Magnet Dimensions (LxWxH) 1.3 x 0.435 x 0.312 in. (3.3 x 1.1 x 0.79 cm) sensor (see Figure 1). Mount the magnet no more than 0 .4 in. (1 cm) away from the sensor. Be sure to secure the magnet with adhesive. To use the external input: 1. Repeat above instructions for mounting. 2. Drill hole through access hole, if needed (see Figure 2). 3. Plug two-pin connector into J1 (see Figure 3). 4. Connect wire to N/C dry contact device. Programming The following steps describe general guidelines for pro gramming (learning) the sensor into the alarm control panel memory. For more details, refer to the 2GIG or Honeywell Installation & Programming I ns t ruc t ions . 1. To remove the sensor cover, use your finger t o press the tab on the end of the case. This will disengage the clip holding the cover t o the base. 2. Set the panel to sensor learning mode. 3. Press and release the tamper switch (SW1) on t he sensor until the panel responds (see Figure 3). Sensor Dimensions (LxWxH) 2.59 x 1.03 x 0.49 in. (6.58 x 2.62 x 1.24 cm) Weight (including battery & magnet) 1.1 oz. (31.2 g) Housing Material ABS plastic Color White Operating Temperature 32° to 120°F (0° to 49°C) Relative Humidity 5-95% Non-Condensing Battery (included) Two (2) Panasonic CR2032, or equivalent Lit hium batteries Regulatory Listing(s) ETL, FCC Part 15, Industry Canada Warranty* Two (2) years Included Accessories Two (2) Phillip’s flat-head screws, one (1) two-pin connector with a 12” flying 2-wire lead, adhesive strip FCC COMPLIANCE STATEMENT* This device …
Text truncated - open the document above for the full version.
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Ningbo Sentek Electronics Co., Ltd. 2011-06-15 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _ Ningbo Sentek Electronics Co., Ltd hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Door/window contact ZE5STK-10345 We affirm that between SIEMIC and Ningbo Sentek Electronics Co., Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Peilin Jiang/ manager 448 Yingchun Road, Wangchun Industrial Zone, Ningbo City 315175 China.
Ningbo Sentek Electronics Co., Ltd. 448 Yingchun Road Wangchun Industrial Zone Ningbo City 315175 China (0086) 574-871565635 April 18, 2012 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: ZE5-STK-10345, and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block Diagrams Theory of Operation (Operation Description) These document contain detailed system and equipment description and related information about the product that Sentek considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public Since the design is a basis from which future technological products will evolve, Sentek considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. We are aware that the exhibits have been already publicly viewable since the time of grant. Sincerely, Sincerely Yours, General Manager
Ningbo Sentek Electronics Co., Ltd. 448 Yingchun Road Wangchun Industrial Zone Ningbo City 315175 China (0086) 574-871565635 April 18, 2012 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: ZE5-STK-10345, and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block Diagrams Theory of Operation (Operation Description) These document contain detailed system and equipment description and related information about the product that Sentek considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public Since the design is a basis from which future technological products will evolve, Sentek considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. We are aware that the exhibits have been already publicly viewable since the time of grant. Sincerely, Sincerely Yours, General Manager
Ke Mei Ou Laboratory Co., Ltd. Ke Mei Ou Laboratory Co., Ltd. Ke Mei Ou Laboratory Co., Ltd.
Model: WC-10-345 FCC ID:ZE5-STK-10345 1 This device complies with Part 15 of the FCC Rules .Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
Ke Mei Ou Laboratory Co., Ltd. Ke Mei Ou Laboratory Co., Ltd. Ke Mei Ou Laboratory Co., Ltd. Ke Mei Ou Laboratory Co., Ltd. Antenna
Ningbo Sentek Electronics Co., Ltd. FCC ID:ZE5-STK-10345 KMO FCC ID Report 1 Report#:KSZ2011060501J03 Ke Mei Ou Laboratory Co., Ltd. 7A, Jiaxiangge, Jiahuixincheng, No.3027, Shennan Rd., Futian, Shenzhen, Guangdong, P.R.China. Zip Code: 518033 Tel: + 86 755 83642690 Fax: + 86 755 83297077 www.kmolab.com FCC TEST REPORT Under FCC 15 Subpart C, Paragraph 15.231 Prepared For : Ningbo Sentek Electronics Co., Ltd. 448 Yingchun Road, Wangchun Industrial Zone, Ningbo City 315175 China FCC ID:ZE5-STK-10345 EUT: Door/window contact Model: WC-10-345&WC-20-345 Issue Date: June 1, 2011 Report Type: Original Report Test Engineer: Jacky Huang Review By: Apollo Liu/ Manager Test Engineer: Review By: The test report consists 26 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Ke Mei Ou Laboratory Corporation. The test result in the report only applied to the tested sample. Ningbo Sentek Electronics Co., Ltd. FCC ID:ZE5-STK-10345 KMO FCC ID Report 2 Report#:KSZ2011060501J03 TABLE OF CONTENTS 1. General Information .............................................................................................................. 3 1. 1 Notes .................................................................................................................................. 3 1. 2 Testing Laboratory ............................................................................................................. 3 1. 3 Details of Applicant ........................................................................................................... 3 1. 4 Application Details ............................................................................................................. 3 1. 5 Test Item ............................................................................................................................ 3 1. 6 Test Standards .................................................................................................................... 4 1. 7 Statement of the measurement uncertainty ........................................................................ 4 1. 8 Equipments Used during the Test ...................................................................................... 5 2. Technical Test ....................................................................................................................... 6 2. 1 Summary of Test Results ................................................................................................... 6 5. Radiated Emission ................................................................................................................. 7 6. 20dB Bandwidth ................................................................................................................. 14 7. Deactivation test .................................................................................................................. 16 8. Antenna Requirement .......................................................................................................... 19 9. External and Internal Photos of the EUT ............................................................................ 20 10.Test Setup Photos of the EUT ............................................................................................ 23 Ningbo Sentek Electronics Co., Ltd. FCC ID:ZE5-STK-10345 KMO FCC ID Report 3 Report#:KSZ2011060501J03 1. General Information 1. 1 Notes The test results of this report relate exclusively to the test item specified in 1.5. The KMO Lab does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the KMO Lab. 1. 2 Testing Laboratory Site on File with the Federal Communications Commission – United Sates Registration Number: 963441 Site Listed with Industry Canada of Ottawa, Canada Registration Number: 7353A 1. 3 Details of Applicant Name : Ningbo Sentek Electronics Co., Ltd. Address : 448 Yingchun Road, Wangchun Industrial Zone, Ningbo City 315175 China Contact : RenQian Zhu(Mr) Tel : +86-574-87155635 Fax : N/A 1. 4 Application Details Date of Receipt of Application : June 01, 2011 Date of Receipt of Test Item : June 01 , 2011 Date of Test : June 01~Oct 25, 2011 1. 5 Test Item Manufacturer : Same As Applicant Address : Same As Applicant Trade Name : Sentek Model No.(Base) : WC-10-345 Model No.(Extension) : WC-20-345 Description :WC-10-345 is same as WC-20-345 only just model name is different Additional Information Frequency : 345MHz Number of Channels : 1 Power Supply : DC 2*3.0V(by Battery) Temperature: N/A Resolution : N/A Ningbo Sentek Electronics Co., Ltd. FCC ID:ZE5-STK-10345 KMO FCC ID Report 4 Report#:KSZ2011060501J03 1. 6 Test Standards FCC 15 Subpart C, Paragraph 15.231 Note: All radiated measurements were made in all three orthogonal planes. The values reported are the maximum values. 1. 7 Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to CISPR 16 - 4 „Specification for radio disturbance and immunity measuring apparatus and methods – Part 4: Uncertainty in EMC Measurements“ and is documented in the Shenzhen Huatongwei International Inspection Co., Ltd quality system acc. to DIN EN ISO/IEC 17025. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of the device…
