ZEZB1230R4949.82-49.90 MHz WIRELESS REMOTE CONTROL TOY-RX

OFF • ON CAUTION-ELECTRIC TOY NOT RECOMMENDED FOR CHILDREN UNDER 8 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. INPUT: AC 100~240V 50/60Hz 0.3A OUTPUT: DC 9V 250mA ITEM NO. B1230 PLEASE NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is needed. • Consult the dealer or an experienced radio/TV technician for help. Controller 7.2V Ni-Cd Battery PackCharger 9V BatteryJackal Missile Launcher CONTENT LIST infrared control transmitter getting to know your jackal Battery Compartment Rotating Turret Launching Foam Darts Tank Track On/Off Switch Diagram #1 Diagram #2 THE INCLUDED 7.2V NI-CD BATTERY PACK IS NOT CHARGED PRIOR TO SHIPMENT AND MUST BE CHARGED BEFORE USE. To prevent damage, the contents of the package that are listed have been packed in the tray and may be out of plain sight. Please remove all contents from the tray. I N S T R U C T I O N M A N U A L IF MISSILE LAUNCHER DOES NOT RESPOND PROPERLY, PLEASE RECHARGE OR REPLACE THE 7.2V NI-CD BATTERY PACK IN THE MISSILE LAUNCHER OR REPLACE THE 9V BATTERY IN THE CONTROLLER FULL-FUNCTION 7.2V NI-CD RADIO CONTROL DART LAUNCHING VEHICLE ** NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. *IMPORTANT: WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Do not aim at eyes or face! TO AVOID INJURY: Use only darts designed for this product. Do not modify darts or dart turret. Adult supervision is required! CAUTION: IMPORTANT i g n it e- r c . c o m Manufactured & Distributed by © 2012 Bear River International, LLC Frisco, TX 75034 All Rights Reserved MADE IN CHINA LED Power Indicator Problems Reasons Solutions TROUBLE SHOOTING The battery inside the radio controller is too weak. There is a weak or low reception to the radio controls. Replace with new alkaline batteries. The batteries inside the Jackal are too weak. Foam darts do not fire. The vehicle’s tank track has an obstruction in tread or axles. The Jackal does not respond to the radio control. The radio control’s frequency is disrupted by something around the environment. Recharge or replace with new batteries inside the Jackal. Make sure the Darts are inserted correctly, push in until they click. Mechanisms may be faulty, contact customer service for assistance. Use tweezers to remove obstruction. Try playing at another location. Running Problems Firing Problems Operating Problems Other Some other equipment using the same radio wave could disrupt the radio control. Either play in another location or turn off the other equipment. If you are planning to race your vehicles with another friend, purchase vehicles with two different frequencies (49 MHz and 27 MHz) to avoid disruption. Dart LauncherDart Launcher Left Tank Track ON/OFF Switch Battery Compartment Right Tank Track Rotate Turret Left Rotate Turret Right Antenna PLEASE DO NOT RETURN TO STORE For more information please contact Customer Services: [email protected] (580)272-0022 7.2 V 600 mAh RE-CHARGEABLE Ni-Cd BATTERY, 1-9V HEAVY DUTY BATTERY AND 100~240V DIGITAL CLASS 2 CHARGER INCLUDED DO NOT MIX ALKALINE, ST ANDARD (CARBON ZINC) OR RECHARGEABLE (NICKEL CADMIUM) BATTERIES. DO NOT MIX OLD AND NEW BATTERIES. DO NOT DISPOSE OF BATTERIES IN FIRE, BA TTERIES MAY EXPLODE OR LEAK. Ni-Cd OFF • ON On/Off Diagram #8 Diagram #7 1) To turn the turret use the bottom two buttons on the top of the controller to turn the turret left and right. 2) Once the turret is angled in the desired position press the top two buttons on the top of the controller at the same time to fire the foam darts. ATTENTION PARENTS: The battery charger and battery pack need to be periodically examined for potential hazards and any potentially hazardous parts to be repaired or replaced. 1) Turn the battery cover dial away from the cover. 2) Open the top cover to reveal battery compartment. 3) Connect the battery cord to the cord from the Jackal. 4) Place the connector and the battery into the battery compartment. 5) Replace cover, and turn dial over the battery cover. 3) For one dart at a time quickly press and release both buttons together. 4) For rapid fire press buttons together and hold. Foam darts can fire to about 16ft (5 meters). 5) To refill the turret, take the foam darts and place them into the dart holes, pressing firmly until you hear a click, then dart is secure. Note that each joystick controls the corresponding side of the tank tracks. 1) To go FORWARD press both joysticks forward, to go BACKWARDS press both joyst…

Text truncated - open the document above for the full version.

FCC ID Label Location

FCC ID Label Sample for FCC ID: ZEZB1230R49 FCC ID: ZEZB1230R49 Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Bear River International LLC Model Number/Item Number: B1230 REPORT NUMBER: GKK201211080B PAGE 1 OF 10 PART 15.109 & RSS-310 ISSUE 3 Test Report Applicant Bear River International LLC Address 1011 West 400 North, Suite 110, Logan, Utah 84321, United States FCC ID Number FCC ID: ZEZB1230R49 Brand Name None Model Number/ Item Number B1230 Product Description 49.82-49.90 MHz Wireless Remote Control Toy - RX Operating Frequency 49.860 MHz Rules/Standards Part 15.109 of the FCC Rules, RSS-310 Issue 3 and RSS-Gen Issue 3 of the Industry Canada Received Date 8th November, 2012 Tested Date 9th November, 2012 Approved by Dick Chan (Director of Gakkiku) Tested by Lahm Peng (Engineer of SEM.Test) Signed by Jandy So (Manager of SEM.Test) Report Number GKK201211080B Test Results PASSED FAILED Gakkiku Technology Company Flat B, 5/F., Selwyn Factory Building, No. 404 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong Tel: (852) 8113 2281 Fax: (852) 2797 0192 Email: [email protected] Bear River International LLC Model Number/Item Number: B1230 REPORT NUMBER: GKK201211080B PAGE 2 OF 10 PART 15.109 & RSS-310 ISSUE 3 GENERAL The report is written by Gakkiku Technology Company. The tested device complies with the general approval requirements of the FCC Rules and the Industry Canada as identified in this test report. TEST LOCATION The tested device was tested at the test site of the SEM.Test Compliance Service Co., Ltd., 3/F, Jinbao Commerce Building, Xin'an Fanshen Road, Bao'an District, Shenzhen, 518101, Guangdong, China. The FCC Recognized 2.948 Listed Test Firm Registration Number is 994117. The Industry Canada IC OATS Filing Number/Assigned Code is 7673A. Bear River International LLC Model Number/Item Number: B1230 REPORT NUMBER: GKK201211080B PAGE 3 OF 10 PART 15.109 & RSS-310 ISSUE 3 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................... 4 1.2 TEST STANDARDS ....................................................................................................................................... 4 1.3 TEST METHODOLOGY ................................................................................................................................. 4 1.4 EUT EXERCISE SOFTWARE .......................................................................................................................... 5 1.5 ACCESSORIES EQUIPMENT LIST AND DETAILS ............................................................................................... 5 1.6 EUT CABLE LIST AND DETAILS .................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ......................................................................................... 6 3. PART 15.109(A) & RSS-310 ISSUE 3 §3.1 - RADIATED EMISSION ..................................... 7 3.1 MEASUREMENT UNCERTAINTY .................................................................................................................... 7 3.2 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................... 7 3.3 TEST PROCEDURE ....................................................................................................................................... 7 3.4 TEST RECEIVER SETUP ............................................................................................................................... 8 3.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ..................................................................................... 8 3.6 ENVIRONMENTAL CONDITIONS ................................................................................................................... 8 3.7 SUMMARY OF TEST RESULTS/PLOTS ........................................................................................................... 8 Bear River International LLC Model Number/Item Number: B1230 REPORT NUMBER: GKK201211080B PAGE 4 OF 10 PART 15.109 & RSS-310 ISSUE 3 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Bear River International LLC Address of applicant: 1011 West 400 North, Suite 110, Logan, Utah 84321, United States Manufacturer: Bear River International LLC Address of manufacturer: 1011 West 400 North, Suite 110, Logan, Utah 84321, United States General Description of EUT Item Description Product Description: 49.82-49.90 MHz Wireless Remote Control Toy - RX Brand Name: None Model Number/Item Number: B1230 Rated Voltage: DC 7.2V Ni-Cd Rechargeable Battery Pack Rated Current: / For more information refer to the circuit diagram form and the user’s manual. The test data is gathered from a production sample, provided by the manufacturer. 1.2 Test Standards The following report is prepared on behalf of the Bear River International LLC in accordance with Part 2 Subpart J and Part 15 Subparts B of the FCC Rules. The objective is to determine compliance with Part 15.109 of the FCC Rules and RSS-310 Issue 3 & RSS-Gen Issue 3 of the Industry Canada. Maintenance of compliance is the responsibility of the manufacturer. Any modification of the product, which results in lowering the emission/immunity, should be checked to ensure compliance has been maintained. 1.3 Test Methodology All measurements contained in this report were conducted with ANSI Standard C63.4-2009, American National Standard Institute for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. The equipment under test (EUT) was configured to measure its highest possible susceptibility against the tested phenomena. The test modes were adapted accordingly in reference to the Operating Instructions. Bear River International LLC Model Numb…
