ZI9-A06060GHz Millimeter-Wave System

Wireless Communications Installation and User Manual A060-Mini® Revision B Wireless Communications 1 INTRODUCTION 1 1.1 Intended users 1 1.2 Revision 1 1.3 Prior knowledge 1 1.4 Warranty 1 1.5 Copyright / Disclaimer 1 2 SYSTEM OVERVIEW 1 2.1 General description 1 2.1.1 Benefits 1 2.1.2 Applications 1 2.2 Package contents 1 2.3 System components 1 2.3.1 Terminals 1 2.3.2 Alignment bracket 1 2.3.3 Alignment tool 1 2.3.4 Ice bridge 1 2.3.5 Accessories 1 2.3.5.1 PoE+ injector (accessory) 1 2.3.5.2 Mast bracket (accessory) 1 3 SITE PLANNING 1 3.1 Terminal location 1 3.2 Line of sight 1 3.3 Link distance / Link availability 1 3.4 TERMINAL MOUNTING OPTIONS 1 3.4.1 Wall mounting 1 3.4.2 Pole mounting 1 3.5 Cabling 1 3.6 Grounding / Lightning protection 1 3.7 Co-located applications 1 4 INSTALLATION 1 4.1 Mount installation 1 4.1.1 Wall mount 1 4.1.2 Mast mount 1 4.2 Terminal installation 1 4.3 Cable installation 1 4.4 Antenna alignment 1 4.4.1 Alignment Procedure 4.4.1.1 Optical alignment 4.4.1.2 Power level alignment 4.5 Grounding 4.6 Lightning / Surge protector 4.7 Power injector 5 TERMINAL MANAGEMENT AND MONITORING FUNCTIONS 5.1 Web browser interface 5.1.1 Overview 5.1.2 Wireless 5.1.3 Network 5.1.4 System 5.1.5 Status 5.4 SNMP interface A TECHNICAL INFORMATION A.1 Troubleshooting A.1.1 Power and network connection A.1.2 Network configuration A.1.3 Duplex mismatch A.1.4 Miss-alignment A.2 Specifications A.2 Availability / Rain Zone / Link Distance A.w Map Of America A.x Map of Asia and Middle East A.y Map of Europe C CONTACTS C.1 Technical assistance C.1.2 Service center / RMA Wireless Communications Page 1 Wireless Communications 1 INTRODUCTION 1.1 Intended users This manual is intended for all installation and service personnel who are involved in the planning, installation, operation and maintenance of the A060-Mini® equipment. Although the A060-Mini® link is designed for easy installation and setup, optimum performance can be achieved by following the procedures outlined in this manual. 1.2 Revision Athena Wireless reserves the right to revise this documentation periodically without any obligation to provide notification of such revision or changes. 1.3 Prior knowledge This manual assumes that the installer has at least a basic experience and understanding of networking equipment, as well as some familiarity with its configuration and operation. The information covered in this manual should be fully understood prior to installation. 1.4 Warranty Athena Wireless warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to one year from the date of shipment to the end user. During the warranty period, and upon proof of purchase, should the product show indications of failure due to faulty workmanship and/or materials, Athena Wireless will, at its discretion, repair or replace the defective products or components without charge for either parts or labor, and to whatever extent it shall deem necessary to restore the product or components to full operating condition. Any replacement will consist of a new or remanufactured, functionally equivalent product of equal value, and will be offered solely at the discretion of Athena Wireless. This warranty shall not apply if the product is modified (e.g. warranty seal is broken), misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions. To obtain services under this warranty, contact the Athena Wireless Service Center. Products must be returned postage prepaid. It is recommended that the terminal be insured when shipped. Any products returned without either proof of purchase or with an outdated warranty will be repaired or replaced and the customer will be billed for parts and labor. All repaired or replaced products will be shipped by Athena Wireless to the corresponding return address ‘postage paid’ (USA only). If the customer specifies some other return destination beyond US borders, the customer shall bear the cost of the return shipment. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. 1.5 Copyright / Disclaimer Copyright © 2010-2011 by Athena Wireless The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system, translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without the prior written permission of Athena Wireless. Page 2 Wireless Communications 2 SYSTEM OVERVIEW 2.1 General description The A060-Mini® system operates as a data link in the unlicensed 60 GHz band between 57 GHz and 64 GHz. Measuring only 18cm x 18cm (7” x 7”), A060-Mini® delivers full duplex data at a rate of up to 1000 Mbps over a distance of up to 800m (2600 ft). The terminal’s compact size is attained by extensively integrating the active and passive components. For more detailed technical data see appendix A.2. 2.1.1 Benefits • Easy installation – The concept of the A060-Mini® link allows to the end user to install it as easy as any other network component. The single cable solution reduces the complexity of the installation. The terminal is connected to the network, monitored and supplied with power through a single outdoor rated CAT 6 Ethernet cable. A visual alignment tool together with an alignment bracket allow the user to easily install the link. Immediate operation without the need for additional configuration is granted. • Network performance – Guaranteed full duplex at 1000 Mbps along the complete range. Unlike typical WLAN equipment the user can transmit a full 1000 Mbps over the link. • License free operation – The system has been approved and can be operated in many countries. • System administration – To monitor the status and the traffic the user can access the link statistics either via the HTML user interface or…

Text truncated - open the document above for the full version.

p1140014_ FCC_15.255 Rev 2.0 Page: 1 of 20 FCC CFR47 Part 15.255 Test Report Prepared for: Athena Wireless Communications Model: A060-Mini Description: 60GHz Millimeter-Wave System To Federal Communications Commission Rule Part(s) 15.255 Date of Issue: May 23, 2011 On the behalf of the applicant: Athena Wireless Communications 12425 W. Bell Rd. Suite 110 Surprise, AZ 85378 Attention of: Terry McManus, Executive VP Ph: (623)242-7224 E-mail: [email protected] Prepared by Compliance Testing, LLC 3356 N San Marcos Pl, Suite 107 Chandler, AZ 85225-7176 (866) 311-3268 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p1140014 John Erhard Project Test Engineer p1140014_ FCC_15.255 Rev 2.0 Page: 2 of 20 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 5/23/11 J. Erhard Original Document 2.0 6/30/11 J. Erhard Additional Test Data Added p1140014_ FCC_15.255 Rev 2.0 Page: 3 of 20 Table of Contents Description Page Test Report Revision History 2 Standard Test Conditions Engineering Practices 6 Test Results Summary 7 Peak Output Power 8 In Band Emissions 10 Spurious Emissions 11 Power Density 15 A/C Powerline Conducted Emissions 16 99% Occupied Bandwidth 18 Test Equipment Utilized 20 p1140014_ FCC_15.255 Rev 2.0 Page: 4 of 20 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless noted in the table below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC OATS Reg, #933597 IC Reg. #2044A-1 Non-accredited tests contained in this report: N/A p1140014_ FCC_15.255 Rev 2.0 Page: 5 of 20 The applicant has been cautioned as to the following: 15.21 Information to Use The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) Special Accessories Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator the responsible part may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p1140014_ FCC_15.255 Rev 2.0 Page: 6 of 20 Standard Test Conditions Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing. In accordance with ANSI C63.10-2009 and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated the humidity levels were in the range of 10% to 90% relative humidity. Measurement results, unless otherwise noted, are worst-case measurements. Environmental Conditions Temperature Humidity Pressure 25.30 26.50 960.50 EUT Description Wireless point to point Gigabit Ethernet communication system EUT Operation during Tests Operating on a test chassis allowing for direct conducted measurements p1140014_ FCC_15.255 Rev 2.0 Page: 7 of 20 Test Results Summary Specification Test Name Pass, Fail, N/A Comments 15.255(e) Peak Output Power Pass 15.255(f) In band emissions Pass 15.225(c) Spurious Emissions Pass 15.207 Powerline conducted Emissions Pass RSS 210 99% Occupied Bandwidth Pass 15.203: Antenna Requirement: X The antenna is permanently attached to the EUT The antenna uses a unique coupling The EUT must be professionally installed The antenna requirement does not apply p1140014_ FCC_15.255 Rev 2.0 Page: 8 of 20 Peak Output Power Name of Test: Peak Output Power Specification: 15.255(e) Engineer: J. Erhard Test Equipment Utilized: i00029, i00394 Test date: 5/18/2011 Test Procedure The EUT was connected to a spectrum analyzer utilizing an external mixer and waveguide adapter. All cable, waveguide, and mixer losses were input in to the spectrum analyzer as a reference level offset to ensure that accurate readings were obtained. The measurement was made in a CW mode of operation as it produces an accurate peak power reading. Test Setup Peak Output Power Frequency Measured Level Limit 59.5 GHz 2.17 dBm 27 dBm 62.0 GHz 9.54 dBm 27 dBm EUT Waveguide Adapter Spectrum Analyzer p1140014_ FCC_15.255 Rev 2.0 Page: 9 of 20 Peak Power 59.5 GHz Peak Power 62.0 GHz p1140014_ FCC_15.255 Rev 2.0 Page: 10 of 20 In Band Emissions Name of Test: In Band Em…

Text truncated - open the document above for the full version.

Page 1 of 3 Test Setup Photos: Athena TCB-p1140015 FCC ID: ZI9-A060 IC: 9662A-A060 Conducted #1 Conducted #2 Page 2 of 3 Location of On Site Receiver On Site Transmitter Page 3 of 3 Receiver Details #1 Receiver Details #2
