ZIFMSL-SFStrobe Light

STROBE W/ THUNDER User Manual GENERAL INFORMATION: This product is one of home party series. It uses a xenon tube and can flash quickly and slowly according to the settings by adjusting knob. It is constructed of approved materials and is assembled in agency-inspected facilities. Follow all instructions in the user guide, and observe all warnings carefully for your further protection. SPECIFICATIONS: Power supply: 120Vac. 60Hz Power consumption: 25W 1. Important Safety Instructions • WARNING: RISK OF INJURY, DO NOT PLACE ANY ITEM ON ITS SURFACE • DANGER: TO REDUCE THE RISK OF ELECTRIC SHOCK: ALWAYS UNPLUG THIS UNIT FROM THE ELECTRICAL OUTLET BEFORE CLEANING • Before using this appliance, read and follow all warnings and instructions in this manual, even if you are familiar with this product. • It is advisable to keep this instruction manual for future reference • To protect against electric shock, do not immerse the unit, cord or plug, in water or other liquid. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. • Children should be supervised to ensure that they do not play with the appliance. • CAUTION: Never look directly at light source when in operation, especially persons who suffer from epilepsy as it may bring on an epileptic episode. • Do not leave the unit unattended when plugged in. • Unplug from power supply when not in use, before cleaning or changing the accessories. • Ensure the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance. • Never use any accessories or parts from other manufacturers or that have not been specifically made for this product. Your guarantee will become invalid if such accessories or parts have been used. • Do not operate any appliance with a damaged cord or plug or if the appliance malfunctions or has been damaged in any way. • If the mains cord of this appliance is damaged, it must always be replaced by a service centre authorized in order to avoid hazardous situations. • To disconnect – remove the plug from the outlet. Do not pull plug out by the cord. • Do not let cord hand over edge of table or counter, or come in contact with hot surfaces. • Do not place on or near a hot gas or electric burner or in a heated oven. • The surfaces of the unit may become hot. Avoid touching them. • Please open packing and inspect for any damage which may have been caused by transportation. If damage is present, do not use. Return to the supplier for replacement or repair. • Do Not use in humid, wet or dusty environments. • For indoor use only. • If moisture, water or fog liquid gets inside the housing, immediately unplug the unit and contact an qualified service centre for advice before using it again. • DO NOT store or use the appliance in or near high temperature areas. • Do not operate the Strobe Light without the front glass panel or if the front glass panel is broken. • Allow a free air space of at least 20cm around the sides and top of the unit. • Ensure there is a minimum distance of 50cm between the front of the strobe light and any object. • Do not connect the fixture to any dimmer pack. • Do not permit installation, operation or maintenance by unqualified persons. • Allow 20 minutes to cool down after removing the power plug before handling or packing away. ONLY for domestic use. Industrial or commercial use invalidates the warranty. FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to the equipment. Such modification could void the user's authority to operate the equipment. This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment. 2. Components 1 Mounting Bracket Screw Knob 2 Strobe Light Globe and Reflector 3 Mounting Bracket 4 Strobe Flash Frequency Adjuster Knob 5 On / Off Switch 3. Operation Remove all packing materials and check that there are no foam and plastic packaging left on the unit. • Ensure the On / Off switch on the back is in the “0” Off Position. • Plug in to the mains power point and turn on. • Switch the On / Off switch to the “I” On position and the strobe will start immediately. • You can adjust the rate of flash by rotating the adjustment knob on the back of the strobe light body. • DO NOT stare into the light when in use. • DO NOT touch the glass front. 4. User Maintenance WARNING: The plug must be removed from the power socket before any maintenance. • The light globe IS NOT replaceable. • The unit must be kept by dry. • Clean exterior with a dry cloth only. Read and Save These Instructions

120V Input power step-down voltage voltage stabilization IC supply Power protector Output speaker AC Charge Negative half charging control switch thyristor frequency modulator trigger flash lamp

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Foshan Ideal Lighting & Crafts Co., Ltd. 2011-6-13 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Foshan Ideal Lighting & Crafts Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Strobe Light Model name: MSL000, SF007, SF010 FCC ID: ZIFMSL-SF We affirm that between SIEMIC and Foshan Ideal Lighting & Crafts Co., Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title: Falan Li/Manager Contact information / address E-mail: [email protected] ,Tel: (86) -757-8856-2426, Address: Dajiwei Industrial Region, Nanhai Yanbuhexi Yanbian, Foshan City, Guangdong Province, China

Foshan Ideal Lighting & Crafts Co., Ltd FCC ID: ZIFMSL-SF POWER OF ATTORNEY June 11,2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on June 10, 2012. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Foshan Ideal Lighting & Crafts Co., Ltd, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Foshan Ideal Lighting & Crafts Co., Ltd ------------------------------- Manager

2.1 EUT – Front View 2.2 EUT – Back View

FCC ID Label Sample for Model: MSL000, SF007, SF010 FCC ID : ZIFMSL-SF This device complies with Part 18 of the FCC Rules.

Page:21 of 21 WALTEK SERVICES Reference No.: WT11062628-F-E-F 7 FCC Label This device complies with Part 18 of the FCC Rules. Operation is subject to the following two conditions:(1)this device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. This device complies with Part 18 of the FCC Rules.

2.1 PCB1 – Front View 2.2 PCB1 – Back View 2.3 PCB2 – Front View 2.4 PCB2 – Back View

Circuit Description The EUT is using the storage capacitor to work. The city electricity half period charge, has nearly 2 time of city electricity peak value sufficiently (approximately 600V), uses electricity for the flashtube L flash, city electricity while for stored energy charge, also to condenser charge, when on electric capacity's voltage achieves bidirectional triggering diode DB3 the break-over voltage, the silicon-controlled rectifier ignition anode obtains the trigger voltage, but the breakover, the electric capacity obtains the trigger voltage after the ignition anode but breakover, electric capacity after the DB3 electric discharge, after B1 pressure-rise, triggering flashtube electric discharge flash, silicon-controlled rectifier when city electricity zero crossing shuts off, completes a time frequency to dodge the movement. and the working frequency is 45KHz. Later will carry on process fore-mentioned same. Thus, the frequency presses certain cycle by the lamp not to stop flashes. Adjusts WI to be possible to change electric capacity's charge speed, thus changed has tri

ABCD DCBA Title Number Revision Size A4 Date: 10-Jun-2011 Sheet of File: C:\Do cu men ts and Set ti ngs \Ad mi ni strat or\ 桌面 \BACKU P~ 11 .DD B Drawn By: F R110W/100R R2120KR3120K R5100K R61M R71K R10100K R81.8K R11470K R4150K D5 1N4007 D61N4007 C1 22U/400V C2 22U/400V C32U2 C4 333 R12100K R9105 L1 +-T NL AK G QK1MC100-6 D71N4007 D8DB3 D21N4007 D31N4007D11N4007 D4 1N4007 C6 470U C8 220U C9104 C7104 C10104 R1327R R14330R R1656K VD112V VD25V1 12345678 910111213141516 U1 1234567 XP7 C5105 R15220K Operating frequency: 45KHz TextTextTextText

Page: 1 of 21 FCC TEST REPORT WALTEK SERVICES Reference No.: WT11062628-F-E-F FCC ID. : ZIFMSL-SF Applicant : Foshan Ideal Lighting & Crafts Co., Ltd Address : Dajiwei Industrial Region, Nanhai Yanbuhexi Yanbian, Foshan City, Guangdong Province, China Equipment Under Test (EUT) : Product Name : Strobe Light Model No. : MSL000, SF007, SF010 Standards : FCC Part 18 : 2009 Date of Test : June 1 ~ June 8, 2011 Date of Issue : June 11, 2011 Test Engineer : Olic huang Reviewed By : Philo zhong Test Result : PASS * Prepared By: Waltek Services (Shenzhen) Co., Ltd. 1/F, Fukangtai Building, West Baima Rd., Songgang Street, Baoan District, Shenzhen 518105, China Tel :+86-755-27553488 Fax:+86-755-27553868 * The sample detailed above has been tested to the requirements of Council Directives ANSI C63.4:2003. The test results have been reviewed against the Directives above and found to meet their essential requirements. Page:2 of 21 Foshan Ideal Lighting & Crafts Co., Ltd FCC ID: ZIFMSL-SF WALTEK SERVICES Reference No.: WT11062628-F-E-F 1 Test Summary Test Test RequirementTest Method Class / Severity Result Radiated Emission (30MHz to 1GHz) FCC PART 18 : 2009ANSI C63.4: 2003 Class B PASS Conducted Emission (450KHz to 30MHz) FCC PART 18 : 2009ANSI C63.4: 2003 Class B PASS Page:3 of 21 Foshan Ideal Lighting & Crafts Co., Ltd FCC ID: ZIFMSL-SF WALTEK SERVICES Reference No.: WT11062628-F-E-F 2 Contents 1 COVER PAGE ......................................................................................................................................................... 1 1 TEST SUMMARY .................................................................................................................................................. 2 2 CONTENTS............................................................................................................................................................. 3 3 GENERAL INFORMATION ................................................................................................................................ 4 3.1 CLIENT INFORMATION........................................................................................................................................... 4 3.2 GENERAL DESCRIPTION OF E.U.T. ........................................................................................................................ 4 3.3 DETAILS OF E.U.T................................................................................................................................................. 4 3.4 DESCRIPTION OF SUPPORT UNITS.......................................................................................................................... 4 3.5 STANDARDS APPLICABLE FOR TESTING................................................................................................................ 4 3.6 TEST FACILITY...................................................................................................................................................... 5 3.7 TEST LOCATION.................................................................................................................................................... 5 4 EQUIPMENT USED DURING TEST .................................................................................................................. 6 5 EMISSIONS TEST RESULTS .............................................................................................................................. 7 5.1 CONDUCTED EMISSION DATA...............................................................................................................................7 5.1.1 Test Equipment ........................................................................................................................................... 7 5.1.2 Test Procedure............................................................................................................................................ 7 5.1.3 Conducted Test Setup ................................................................................................................................. 7 5.1.4 EUT Operating Condition .......................................................................................................................... 8 5.1.5 Conducted Emission Limits ........................................................................................................................ 9 5.1.6 Spectrum Analyzer ...................................................................................................................................... 9 5.1.7 Conducted Emission Test Result................................................................................................................. 9 5.1.8 Measurement Data...................................................................................................................................... 9 5.1.9 Photograph –Conducted Emission Test Setup.......................................................................................... 11 5.2 RADIATION EMISSION DATA...............................................................................................................................12 5.2.1 Measurement Uncertainty......................................................................................................................... 12 5.2.2 EUT Setup ................................................................................................................................................. 13 5.2.3 Spectrum Analyzer Setup .......................................................................................................................... 13 5.2.4 Test Procedure.......................................................................................................................................... 14 5.2.5 Corrected Amplitude & Margin Calculation ............................................................................................ 14 …

Text truncated - open the document above for the full version.

2.1.1 Photograph – Radiation Emission Test Setup 2.1.2 Photograph –Conducted Emission Test Setup
