ZJPBC06LBSC2074Bluetooth Speaker

Bluetooth Speaker User Manual Model: BC06L Please keep this manual well for future use and this company will not notify you about any updated versions. 1 Table of Contents 2 Introduction This product is a kind of Bluetooth sound system supporting stereo music, hands-free for answering calls, equipped with digital signal processing technology, echo and noise removal feature. It is applied to the different circumstances like office and house, etc., and it may be connected to most other equipment and mobile phones supporting Bluetooth feature by means of wireless for hi-quality hands-free calls and play the stereo music from other equipment and mobile phones. Precautions First thanks for buying the digital sound system produced by this company! Please read the User’s Instructions before using it properly. The contents stated herein may be modified from time to time for better service as the product properties and functions are changed and this company will not notify you otherwise. For the sound performances of the product, never use it in too cold, too hot, too dusty or humid places, especially: 1. Moist or underwater places 2. Near the heater or hi-temperature service 3. Solarization 4. Places apt to fall 5. Never disassemble the combination audio Otherwise, it may invalidate the warranty. Warning: 1. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. 2. Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. 3 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 4 Definitions of Keypads and Jacks There are 7 keys and 4 jacks defined as below: Front View 1、 MIC：MIC 2、 ：Press it shortly to power ON/ OFF. 3、 ：Press to activate the speakerphone function. 4、 ：Press and hold to begin connecting a Bluetooth device. Press to play or pause. 5、 ：Click for previous music in Bluetooth Model 6、：Click for next music in Bluetooth Model 7、 ： Volume down. 8、 ： Volume up 5 Black View 1、DC input jack: DC 5V input source jack 2、AUX IN ：3. 5mm jack to connect the input jack of external sound source; 3、SAMSUNG/iPad：The switches between Samsung with iPad; 4、USB（2.1A）Port 5、USB（0.5A）Port LED INDICATOR LAMP: LED (Red): The red power indicator LED will keep ON in standby status; LED (Green): The green LED indicator lamp will keep ON in startup status; LED (Blue): The blue LED indicator lamp will flicker during the Bluetooth connecting and pairing and then will keep ON after it; 6 HANDS-FREE MICROPHONE MIC: It’s designed to locate in the left of key as a small hole; Note: The user is recommended to keep at least 5m from the product to keep the normal service quality! Start Up Press “” key shortly after power-on to startup, 1. During the first use, the blue LED lamp will flicker to access to PAIR mode. 2. In case of once PAIR was succeeded, the blue LED lamp will turn on and flicker once every one second to access to SEARCH mode, the Bluetooth will connect the equipment and mobile phone used last time automatically. 3. Access to SEARCH mode: The Bluetooth will connect the equipment and mobile phone used last time automatically, and the product will come into the CONNECTION mode when it connects successfully within 10 seconds and will come into the standby mode if not. Bluetooth Pair Mode Users can enter into this status from two states: 1. Press “PAIR/ ” for more than 3 seconds in SEARCH mode or standby mode. 2. During startup for the first time use, 1). Put the mobile phone within 3 meters; 2). Press “PAIR/ ” key for more than 3 seconds, the blue lamp will flicker to enter into PAIR status; 3). Activate the Bluetooth functions of Bluetooth mobile phone so that the mobile phone starts to search for the Bluetooth device; please refer to the user’s manual of mobile phone; 4). Select “BC06L” from the device having already been searched by the cell phone; 5). In case of some kinds of cell phones, users have to key in the identification code “0000” and press ENTER key to match the product and mobile phone and after success, the green /the blue LED lamps will keep ON. 6). Press RETURN key of mobile phone to exit from the mobile phone menu and make sure that the distance between the hands-free and mobile phone is within 10 meters and free from any obstacle, users can answer calls and play music at this moment. 7 Standby Mode The blue LED lamp will flicker slowly and the blue lamp will flicker once every 5 seconds; while in the standby mode, it will accept to connect to all equipment once paired, 8 at most in records. In Bluetooth music play mode, users can Shortly press or press “ ” or “” key for a longer time to adjust the volume. Shortly press “PAIR/ ” key to play/ pause the music play. Users use Hands-fr…

Text truncated - open the document above for the full version.

1 Photographs - EUT Constructional Details Test model No.: BC06L

图纸编号 2012.12.24 业务审核 资材审核 工程审核 主机贴纸 BC06L BC06L 尺寸：59.7*29.7mm 材质：80克铜版纸背胶过哑膜 颜色： 底色 100%黑 文字 30%黑 Bluetooth Speaker Model No.: BC06L Input: DC 5V 3A FCC ID ZJPBC06LBSC2074 Made In China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)this device may not cause harmful interference, and (2) this device must accept any interference received,interference that may cause undesired operation.

1 Photographs - EUT Constructional Details Test model No.: BC06L

SGS-CSTC Standards Technical Services Ltd. No. 1 Workshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM121200697601 Page: 1 of 75 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page FCC REPORT Application No: SZEM1212006976RF Applicant: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Manufacturer: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Factory: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Product Name: Bluetooth Speaker Model No.(EUT): BC06L FCC ID: ZJPBC06LBSC2074 Standards: 47 CFR Part 15, Subpart C (2011) Date of Receipt: 2012-12-27 Date of Test: 2013-01-06 to 2013-01-15 Date of Issue: 2013-02-01 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM121200697601 Page: 2 of 75 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 (2009) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2009) PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10 (2009) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (b) ANSI C63.10 (2009) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2009) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS Band Edge (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM121200697601 Page: 3 of 75 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the l…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test model No.: BC06L) 1.1 Conducted Emission 1.2 Radiated Emission
