ZJPBC08IME32516Bluetooth Speaker

BC08 User Manual 2 Table of Contents ● Function Overview..............................................................................3 ● Precautions..........................................................................................3 ● Know about the sound system............................................................4 Keypads and Ports..............................................................................4 Remote controller keypads.................................................................5 ● Basic Functions...................................................................................6 Startup Function..................................................................................6 Bluetooth Function..............................................................................6 AUX.......................................................................................................7 Volume Adjustment.............................................................................8 EQ Sound Effect Setup.......................................................................8 ● Specifications..........................................................................................8 ● Accessories.............................................................................................9 3 ● Function Overview: Thanks for buying our new generation of multi-functional combination audio! This combination audio is manufactured with various functions of perfect tone quality, high reliability and fashionable appearance as a masterly product. You are expected to share the excellent satisfaction launched by the digital era. This combination audio is integrated with powerful multi-functions and fashion and we have listed some of its major functions and characteristics for you to know it in a better way: * Bluetooth * AUX external input * Sound effects of FLAT, ROCK, POP, CLASS and JAZZ * Remote control ● Precautions for Use First thanks for buying the digital combination audio produced by this company! Please refer to this User’s Specification before use to use it properly. The contents stated herein may be modified from time to time for better service as the product properties and functions are changed and this company will not notify you otherwise. For the sound performances of the product, never use it in too cold, too hot, too dusty or humid places, especially: 1. Moist or underwater conditions 2. Near the heater or hi-temperature services 3. Solarization 4. Places apt to fall 5. Never disassemble the combination audio; otherwise, it may invalidate the warranty. ● Warnings: 1. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. 2. Where the mains plug or an appliance coupler is used as the disconnect device,the disconnect device shall remain readily operable. 4 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This USB interface of this product is only for charging purpose without data exchange function 5 Functions of Keypads and Ports 1. USB (1000mA): Suitable for charging jacks of iPod/iPone and other models of mobile phones 2. AUX IN: External sound source input jack (3.5mm) 3. DC IN: DC power input jack 1. : (Press it shortly for Volume up and press it for a longer time to volume down) 2. : (Press it shortly for Volume up and press it for a longer time to volume up) 3. : (Press it shortly in Bluetooth status for Pause/ Play; and press it for more than 3 seconds in Search mode for Pair key) 6 4. : (Press it shortly for startup) 5. Remote control receiver module 6. Function indicator lamp: (The blue lamp turns on for Bluetooth status and the red lamp turns on for external AUX status) Remote Control Functions: 1. : (Press it shortly for startup/Press it shortly for power-off) 2. : (Press it shortly for volume down and press it for a longer time rapidly to volume down) 3. : (Press it shortly for volume up and press it for a longer time rapidly to volume up) 4. : (Press it shortly in Bluetooth play status for Pause/ Play; press it for more than 3 seconds in Search mode for Pair) 5. : (Mute key) 6. : (Press it shortly in Bluetooth status for Previous Music; and press it shortly for in External AUX IN play status or press it for a long time for nothing) 7. : (Press it shortly in Bluetooth status for Next Music; and press it shortly for in External AUX IN play status or press it for a long time for nothing) 8. EQ: (Sound effect setup key) 9. RESET: (Press it for above 10 seconds after startup in Bluetooth status to clear the connected Bluetooth device and then the blue light will flicker rapidly) Usage of Remote Controller: 7 1. Before using the remote controller, please draw out the PVC insulating strip inside the battery cartr…

Text truncated - open the document above for the full version.

1 Photographs - EUT Constructional Details Test model No.: BC08

图纸编号 业务审核 工程审核 美工 BC08 2011.07.25 主机/FCC贴纸 BC08 331 F-P1207010-03 BC08 FCC ID：ZJPBC08IME32516 尺寸：27.5*15.5mm 材质：不干胶过光膜 颜色：黑底白字 粘贴位置：底部与主机贴纸底部对齐，与 主机贴纸相距5mm左右。 BC08 FCC ID：ZJPBC08IME32516

1 Photographs - EUT Constructional Details Test model No.: BC08

SGS-CSTC Standards Technical Services Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM121200667801 Page: 1 of 76 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 11 1 Cover page Cover pageCover page Cover page FCC REPORT Application No: SZEM1212006678RF Applicant: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Manufacturer: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Factory: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Product Name: Bluetooth Speaker Model No.(EUT): BC08 FCC ID: ZJPBC08IME32516 Standards: 47 CFR Part 15, Subpart C (2011) Date of Receipt: 2012-12-11 Date of Test: 2012-12-13 to 2012-12-18 Date of Issue: 2013-01-10 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM121200667801 Page: 2 of 76 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 (2009) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2009) PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10 (2009) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (b) ANSI C63.10 (2009) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2009) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS Band Edge (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM121200667801 Page: 3 of 76 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-documen…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test Model No.: BC08) 1.1 Conducted Emission 1.2 Radiated Emission
