ZJPBC15BTS300Bluetooth Speaker

Bluetooth Speaker User Manual Model: BC15 This picture is only provided for your reference and may be different with the actual product, so please refer to the actual product! Please keep this manual well for future use and this company will not notify you about any updated versions. 1 Table Of Contents Introduction ......................................................................................... 2 Precautions .......................................................................................... 2 Definitions of Keypads and Jacks ......................................................... 3 LED indicator lamp: .............................................................................. 4 Power on function ............................................................................... 5 Start Up ............................................................................................... 5 Bluetooth Pair Mode ........................................................................... 5 Precautions .......................................................................................... 6 Connection Mode ................................................................................ 6 Aux‐in Mode ........................................................................................ 7 Mobile phones Support ....................................................................... 7 Power Off ............................................................................................. 7 Trouble Shooting ................................................................................. 7 Product Specification ........................................................................... 9 Accessories: ....................................................................................... 10 2 Introduction This product is a kind of Bluetooth sound system supporting stereo music, hands‐free for answering calls, equipped with digital signal processing technology, echo and noise removal feature. It is applied to the different circumstances like office and house, etc., and it may be connected to most other equipment and mobile phones supporting Bluetooth feature by means of wireless for hi‐quality hands‐free calls and play the stereo music from other equipment and mobile phones. Precautions First thanks for buying the digital sound system produced by this company! Please refer the User’s Instructions before using it properly. The contents stated herein may be modified from time to time for better service as the product properties and functions are changed and this company will not notify you otherwise. For the sound performances of the product, never use it in too cold, too hot, too dusty or humid places, especially: 1. Moist or underwater places 2. Near the heater or hi‐temperature service 3. Solarization 4. Places apt to fall 5. Never disassemble the combination audio Otherwise, it may invalidate the warranty Warning: 1. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. 2. Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. 3 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐‐Consult the dealer or an experienced radio/TV technician for help. changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Definitions of Keypads and Jacks There are 5 keys, 2 jacks and one switch defined as below: 4 1. : Press it shortly to power ON/ OFF. 2. : Play / Pause 3. : Press The key for more than 3 seconds in SEARCH mode for PAIR status; 4. : Press it shortly for Volume Up and press it for a longer time to tune up the volume rapidly; 5. : Press it shortly for Volume Down and press it for a longer time to tune down the volume rapidly; 1. AUX IN: 3. 5mm jack to connect the input jack of external sound source 2. Micro USB: DV 5V power supply, with External lithium battery power supply jack ( Beside is the LED indicate light for the Battery ) 3. ◎: Built‐in battery indicate light 4. DC/BATT : Switch for changing the DC5V and with built‐in lithium battery LED indicator lamp: LED (Blue): The blue LED indicator lamp on to top of unit will flicker during the Bluetooth connecting and pairing and then will keep on lit after connected; LED (Red): The Aux in play mode,the red power indicator LED on to top of unit will keep on lit; 5 LED (Red): The Red LED indicator lamp in the back side of the unit will keep on when it is charginghe, after it is fully charged, the Red LED light will be off. Power on function (two ways are available) A. Switch the “BATT/DC” switch at the back cover of machine to “DC” and plug the DC 5V power to DC jack at the back, and then press “ ” key to power on the machine. Remarks: 1. Under any function stutus, connect the unit with DC 5V adaptor, 3.7V Nokia battery will be charged. 2. It tak…

Text truncated - open the document above for the full version.

1 Photographs - EUT Constructional Details Test Model No.: BC15

���号 ���核 工程�核 FCC贴纸 BC15 尺寸：49.8*39.9mm 材质：80G双铜背胶过哑膜 字体及LOGO颜色：白色+ 底色：黑色 Model No.:BC15 Input: DC 5V 1.5A Power Output: 3W+3W Made In China Model No.:BC15 Input: DC 5V 1.5A Power Output: 3W+3W Made In China 尺寸：27.5*15.5mm 材质：不干胶过光膜 颜色：黑底白字 粘贴位置：底部与主机贴纸居中对齐 BC15 FCC ID：ZJPBC15BTS300 BC15 FCC ID：ZJPBC15BTS300

1 Photographs - EUT Constructional Details Test Model No.: BC15

SGS-CSTC Standards Technical Services Ltd. No. 1 Workshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM130100036401 Page: 1 of 70 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page FCC REPORT Application No.: SZEM1301000364RF Applicant: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Manufacturer: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Factory: Shenzhen SKY DRAGON Audio-video Technology Co., LTD Product Name: Bluetooth Speaker Model No.(EUT): BC15 FCC ID: ZJPBC15BTS300 Standards: 47 CFR Part 15, Subpart C (2012) Date of Receipt: 2013-01-21 Date of Test: 2013-01-23 to 2013-01-30 Date of Issue: 2013-02-28 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM130100036401 Page: 2 of 70 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 (2009) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2009) PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10 (2009) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (b) ANSI C63.10 (2009) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2009) PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2009) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2009) PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS Band Edge (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2009) PASS SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM130100036401 Page: 3 of 70 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the lim…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test Model No.: BC15) 1.1 Conducted Emission 1.2 Radiated Emission 1.3 Radiated Spurious Emission
