QUICK START GUIDE Kids Bluetooth ® Speaker & FM Radio HS-BTSP229 Little Ears www.hipstr eet.com L ittleEars A C B Getting started What’s in the box: Thank you for your purchase of this Hipstr eet ® Little Ears Kids Bluetooth ® speaker & radio. This manual is designed to help you easily set up and begin using your new speaker right away. Please read this manually car efully and be sure to ret ain it for future ref er ence. We hope this high quality product offer s you endless hours of entertainment. Pl ease visit our website at www.hipstr eet.com f or any questions or additional information you may need. 1 x Little Ears Kids Bluetooth ® Speaker & Radio A B B C 1 x Charging Cable 1 x AUX Cable 1 x User Manual 01 Getting started Getting to know your speaker: Easy-to-Use Controls Button Functions: Indicator light of the built-in lithium battery DC 5V Input ON/OFF Switch 3.5mm AUX Port 02 Volume DialBack Button Indicator Lights Foward Button MEM + Light (Selects saved radio stations) (Turns the flashlight ON or OFF. Press and hold to flicker the flashlight) Power Button Function Button Play/Pause Flashlight (Press & hold to activate pairing in Bluetooth function) (Press & hold to auto tune in Radio function) Getting started Indicat or Lights: Blue on the front: Will flash during Bluetooth ® pairing; after sucessful connection, it will remain ON. Green on the front: Will remain ON in Radio function. It will flash during the automatic radio station search. Red on the front: Will remain ON in standby mode. Red on the back: Will remain ON during battery charging (when speaker is either ON or OFF). After the battery is fully charged, the light will turn OFF. Charging the speaker: This speaker has an internal, non-removable, rechargeable battery. Do not attempt to remove the battery from the device as you may damage the device and void the warranty. Use the supplied charging cable to connect speaker to power source for charging. The Red indicat or light on the back of the unit will remain on until battery is fully charged. This will take about 3.5 hours. The battery will last about 4 hours on a full charge. Bluetooth ® Mode: St artup: Slide ON/OFF switch to the “ON” position, and then press t o turn the speaker ON. Press again to turn it off in standby mode. 03 04 To switch function (Bluetooth ® , AUX, Radio), press FUNC. Pairing the speaker: Playback via Bluetooth ® : After successful pairing, you can play the music on your device through the speaker . The buttons on the speaker can be use to control your device for music playback. Pr ess t o play or pause. Pr ess t o skip next track, and t o go back previous track. Turn the Volume Dial clockwise to increase the volume, and counter clockwise to decrease. Radio Mode: St artup: Slide ON/OFF switch to the “ON” position, and then press t o turn the speaker ON. Press again to turn it off in standby mode. 1. Make sure the speaker is ON and ready to pair. If the blue light is not fl ashing, press and hold t o enable pairing. 2. Activat e the Bluetooth ® f eature on your phone or Bluetooth ® compatible device, and set it to search for devices. 3. Select “HS-BTSP229” from the list of found devices to pair. 4. If the pairing is successful, you will see “c onnected” under the speaker name, and the Blue light on the front of the speaker will remain ON. Repeat steps 1 through 3 if pairing is not successful. Please ref er to the user guide for instructions to activat e the Bluetooth ® functionality on your mobile phone or device if necessary. light is not fl ashing, press and hold t o enable pairing.light is not fl ashing, press and hold t o enable pairing.light is not fl ashing, press and hold t o enable pairing. Pr ess t o play or pause.Pr ess t o play or pause.Pr ess t o play or pause. 05 The speaker will automatically enter Bluetooth ® mode when switched ON. Pr ess FUNC t o switch to Radio mode. In Radio mode, the blue light is OFF and green is ON. Radio Tuning: Pr ess t o tune up and t o tune down. Pr ess and hold t o perform auto search for radio stations and save them in memory. The green light will fl ash until auto search is complet ed. Pr ess MEM+ t o select saved radio station. AUX Mode: Connect your audio device to the speaker with the supplied 3.5mm AUX cable. The speaker will automatically switch over to AUX function, and you can listen to the music on your device. Pr ess and hold t o perform auto search for radio stations and Pr ess and hold t o perform auto search for radio stations and Pr ess and hold t o perform auto search for radio stations and 06 Specification 1. Bluetooth ® specifications: Bluetooth ® V3.0+EDR 2. Output power: Output Level 2, maximum connection distance of 10 meter s 3. Maximum output power: L: 2W R: 2W 4. Working frequency range: 2.402GHz - 2.480GHz 5. Profiles supported: A2DP, AVRCP, GAVDP and AVDTP 6. Speaker impedance: 4 (Ohm) 7. Product dimensions: 258× 101×170 (mm) (L x W x H) 8. Product unit Weight: Approximatel y 850g Speaker does not respond (no power): Make sure unit is complet el y charged and switched ON. Check that all connections are correctly and properly plugged in. Make sure your device is properly paired with the speaker . The product design and specifications are subject to change without prior notice. Troubleshooting No sound: Make sure volume is up. Check that all connections are correct and properly plugged in. Make sure your device is properly paired with the speaker . Increase the volume on your device. Sound is garbled: Make sure the speaker is fully charged. Turn down the volume on your device and the speaker . Keep both devices within close distance. Trouble pairing device with the speaker: Confirm that your device is Bluetooth ® c ompatible. Power cycl e the speaker and your device, then try pairing again. Need assistance? Please contact us! For troubleshooting and support, please visit our website at www.hipstr eet.com and check our Support section to view Frequently Asked Questions (FAQ’ s), …
