1 Enjoy TV Box User Manual V1.7 Introduction Enjoy TV box is a product connected to your TV via HDMI that turn your TV to a multifunction smart TV. It is a revolutionary entertainment on your TV. It is also an Android HD Media player, a mini Android PC, an IPTV Set-top box, a home media hub & NAS and a DLNA server, a photo viewer, a game player, a music player, a huge size screen e-book/ e-magazine/ e-newspaper reader, it provides a very powerful smart TV experience Features ARM Cortex™-A9 CPU, frequency is 800MHz~1GHz Embedded high-performance Open GL 3D GPU Mali-400 High Capability 1G DDR3 ROM Build in 802.11b/g/n Wi-Fi Module and 100M Rj45 Ethernet port HDMI 1.3 Digital Audio & Video Output Support SATA HDD Mass Storage IR remote control Support USB mouse and keyboard operation Support Free-to-air Digital TV Tuner (Depends on different model of Enjoy TV Box) Support flash player 10.2 hardware acceleration Support up to Full HD 1080P video decoding. High Connectivity for File Sharing Support Google play store Support Google Chrome browser Multi User Interface (optional) Video format support: DAT/MPEG/MPE/MPG/M2V/ISO/TS/VOB/AVI/MKV/MP4/MOV/3GP/3GPP/FLC/AVI/WMA/ TS/M2TS/M3TS/M4TS/M5TS/MTS/M4V/FLV/3G2. Audio format support: MP3/WMA/WAV/OGG/OGA/FLAC/ALAC/APE/AAC/M4A/AC-3/DTS/RM. Remote control There are several remote controllers for option. 2 Start Up 1 Plug in power adapter, and connect Enjoy TV Box to TV via HDMI cable. 2 There are two screens appear while starting, first screen is robotic logo, second is android text logo. 3 3 Standard launcher preview 4 Settings Settings provide individual preference setting functions. 1. Wi-Fi It will scan ambient Wi-Fi networks automatically while click “ ON” in Wi-Fi setting. Choose one encrypted Wi-Fi network to connect 5 2. Ethernet Click “ ON” in Ethernet setting, it will connect to network automatically. 3. Data usage Show data usage information. 4. More It includes VPN, Portable hotspot and Proxy settings. 6 Enable Portable hotspot Configure Wi-Fi hotspot. Choose different security way to share your network. Please note you need to disconnect Wi-Fi and connect Ethernet while using hotspot function. Wi-Fi and hotspot connection can’t be existed at the same time. 7 5. Sound If you enable Touch sound, you will hear the sound while move remote control. 6. Display Set wallpaper, output mode, display position and font size. 8 Output mode The default resolution Is 720P Display position Use direction and Enter/Ok buttons on remote control to adjust display position when the screen is not display as full screen on your TV. 9 Font size Change the font size of OSD. 7. Storage Shows the storage used of the OS and SD card. 10 8. Apps List all apps on different status. 9. Accounts & sync Click” ON” to enable accounts & sync. 11 10. Security Enable unknown sources, it will allow you to install non-market apps. 11. Language & input Change OSD language and input method. The default input method is android standard keyboard. If you are using our IR remote control, enter into “Default” option and switch to remote controller input method. 12 12. Factory reset Choose factory reset, it will erase all user data of the box. 13. Data & Time Set the time of the box. 13 14. Developer options If you are an engineer of android OS, and want to do some debugging on our box by ADB Enable USD debugging, you will get ADB function by Ethernet or Wi-Fi. 15. About Media Box. You will find firmware version under build number. 14 Movie player . Play videos in SD card, USB disk and USB / SATA HDD Click button to change video mode, subtitle, audio track, and get video information and so on. Browser 15 Visit any website around the world. Read news, view online videos. Click Menu button on the upper right corner or press F1 button on keyboard while running browser, enter into setting->advanced, and you can set browser type, the default is desktop mode. Network (SAMBA function) When you open network app at the first time, it will scan all shared folders in local area network. Scanned shared folders 16 Choose one of them, you will see a green icon appeared on the right. Click the second button to confirm the choice. Then, click and open the folder to browse videos, music, pictures and documents inside it. 17 Upgrade Upgrade the firmware from external storage device, no matter SD card, USB disk or HDD. Just need to copy the update.img file into the storage device. Upgrade online function has not been opened for M1 4.0. This manual is suitable for ATV series products. 18 FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help FCC Radiation Exposure Statement The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in con…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Shenzhen Geniatech INC., LTD ______________________________________________________ 2014.6.09 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ Shenzhen Geniatech INC., LTD _____hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: Enjoy TV Model name: ATV120SD ，ATV120B,ATV130,ATV181,ATV160,ATV100,PTV2000 FCC ID: ZJU0013181 We affirm that between SIEMIC and ____ Shenzhen Geniatech INC., LTD ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature ： Client’s name / title ： Mike Wu Manager Contact information / address ：Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Shenzhen Geniatech INC., LTD ______________________________________________________ 2014.6.09 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ZJU0013181 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Mike Wu / Manager Contact information / address: Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China

Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1 Issue Date: June 09, 2014 Page: 57 of 70 www.siemic.com.cn Annex B. EUT AND TEST SETUP PHOTOGRAPHS Annex B.i. Photograph 1: EUT External Photo Whole Package - Top View Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1 Issue Date: June 09, 2014 Page: 58 of 70 www.siemic.com.cn EUT - Front View EUT - Rear View Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1 Issue Date: June 09, 2014 Page: 59 of 70 www.siemic.com.cn EUT - Top View EUT - Bottom View Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1 Issue Date: June 09, 2014 Page: 60 of 70 www.siemic.com.cn EUT - Left View EUT - Right View

Enjoy TV Model: ATV120SD Rating: DC5, 2A FCC ID: ZJU0013181 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Shenzhen Geniatech INC., LTD

FCC Label Location

Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1 Issue Date: June 09, 2014 Page: 61 of 70 www.siemic.com.cn Annex B.ii. Photograph 2: EUT Internal Photo Cover Off - Top View 1 EUT PCB - Top View WIFI Antenna Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1 Issue Date: June 09, 2014 Page: 62 of 70 www.siemic.com.cn EUT PCB - Bottom View Uncover Without Shielding - Top View

Shenzhen Geniatech INC., LTD Enjoy TV Main Model: ATV120SD Serial Model: See P5 June 09, 2014 Report No.: 14020408-FCC-H1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Amos Xia Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Exposure Evaluation Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC 2.1091: 2013 Report No: 14020408-FCC-H1 Issue Date: June 09, 2014 Page: 2 of 8 www.siemic.com Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: RF Exposure Evaluation Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC 2.1091: 2013 Report No: 14020408-FCC-H1 Issue Date: June 09, 2014 Page: 3 of 8 www.siemic.com This page has been left blank intentionally. Title: RF Exposure Evaluation Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC 2.1091: 2013 Report No: 14020408-FCC-H1 Issue Date: June 09, 2014 Page: 4 of 8 www.siemic.com CONTENTS 1. EXECUTIVE SUMMARY & EUT INFORMATION ........................................................................................... 5 2. TECHNICAL DETAILS .......................................................................................................................................... 6 3. MAXIMUM PERMISSIBLE EXPOSURE (MPE) .................................................................................................. 7 FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ................................................................................... 7 Title: RF Exposure Evaluation Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC 2.1091: 2013 Report No: 14020408-FCC-H1 Issue Date: June 09, 2014 Page: 5 of 8 www.siemic.com 1. EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the Shenzhen Geniatech INC., LTD, Enjoy TV and model: ATV120SDagainst the current Stipulated Standards. The Enjoy TV has demonstrated compliance with the FCC 2.1091: 2013. EUT Information EUT Description : Enjoy TV Main Model : ATV120SD Serial Model ATV120B, ATV130, ATV181, ATV160, ATV100, PTV2000 Antenna Gain : WIFI Antenna: 2dBi Input Power : Adapter: Model: FJ-SW0501500U Input: AC 100-240V 50/60Hz 0.35A Output: DC 5V 1500mA Maximum Conducted Peak Power to Antenna : 802.11b:15.71dBm 802.11g:20.28dBm 802.11n:18.43 dBm Classification Per Stipulated Test Standard : FCC 2.1091: 2013 Note: in this report, we choice the ATV120SD to test, and all these models are identical in interior structure, electrical circuits and component, except model name and enclosure color for marketing requirement. Title: RF Exposure Evaluation Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC 2.1091: 2013 Report No: 14020408-FCC-H1 Issue Date: June 09, 2014 Page: 6 of 8 www.siemic.com 8 2. TECHNICAL DETAILS Purpose Compliance testing of Enjoy TV with stipulated standard Applicant / Client Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Manufacturer Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Laboratory performing the tests SIEMIC (Nanjing-China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel: +86(25)86730128/86730129 Fax: +86(25)86730127 Email: [email protected] Test report reference number 14020408-FCC-H1 Date EUT received May 12, 2014 Standard applied FCC 2.1091: 2013 Dates of test May 24 to June 09, 2014 No of Units #1 Equipment Category Spread Spectrum System/Device Trade Name N/A RF Operating Frequency (ies) WIFI: 802.11b/g/n: 2412-2462 MHz Number of Channels 802.11b/g /n: 11CH Modulation CCK/OFDM Port SD Card Port, HDMI Port, USB Port, Power Port, Infrared Ray Port FCC ID ZJU0013181 Title: RF Exposure Evaluation Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC 2.1091: 2013 Report No: 14020408-FCC-H1 Issue Date: June 09, 2014 Page: 7 of 8 www.siemic.com 3. MAXIMUM PERMISSIBLE EXPOSURE (MPE) FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Test Data Predication of MPE limit at a given…

Text truncated - open the document above for the full version.

Shenzhen Geniatech INC., LTD Enjoy TV Main Model: ATV120SD Serial Model: See P5 June 09, 2014 Report No.: 14020408-FCC-R1-V1 (This report supersedes none) Modifications made to the product : None This Test Report is Issued Under the Authority of: Amos Xia Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1-V1 Issue Date: June 09, 2014 Page: 2 of 71 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1-V1 Issue Date: June 09, 2014 Page: 3 of 71 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1-V1 Issue Date: June 09, 2014 Page: 4 of 71 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS ......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS .................................................................. 9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................ 53 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 58 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 66 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................ 70 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 71 Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1-V1 Issue Date: June 09, 2014 Page: 5 of 71 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the Shenzhen Geniatech INC., LTD, Enjoy TV and model: ATV120SD against the current Stipulated Standards. The Enjoy TV has demonstrated compliance with the FCC Part 15.247: 2013, ANSI C63.4: 2009. EUT Information EUT Description Enjoy TV Main Model ATV120SD Serial Model ATV120B, ATV130, ATV181, ATV160, ATV100, PTV2000 Antenna Gain WIFI: 2 dBi Input Power Adapter: Model: FJ-SW0501500U Input: AC 100-240V 50/60Hz 0.35A Output: DC 5V 1500mA Classification Per Stipulated Test Standard FCC Part 15.247: 2013, ANSI C63.4: 2009 Note: in this report, we choice the ATV120SD to test, and all these models are identical in interior structure, electrical circuits and component, except model name and enclosure color for marketing requirement. Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1-V1 Issue Date: June 09, 2014 Page: 6 of 71 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of Enjoy TV with stipulated standard Applicant / Client Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Manufacturer Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Laboratory performing the tests SIEMIC (Nanjing-China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel: +86(25)86730128/86730129 Fax: +86(25)86730127 Email: [email protected] Test report reference number 14020408-FCC-R1-V1 Date EUT received May 12, 2014 Standard applied FCC Part 15.247: 2013, ANSI C63.4: 2009 Dates of test (from – to) May 24 to June 09, 2014 No of Units : #1 Equipment Category : Spread Spectrum System/Device Trade Name : N/A RF Operating Frequency (ies) 802.11b/g/n: 2412-2462 MHz Number of Channels 802.11b/g/n: 11CH Modulation 802.11b/g/n: CCK/OFDM Port SD Card Port, HDMI Port, USB Port, Power Port, Infrared Ray Port FCC ID : ZJU0013181 Title: RF Test Report for Enjoy TV Main Model: ATV120SD Serial Model: See P5 To: FCC Part 15.247: 2013, ANSI C63.4: 2009 Report No.: 14020408-FCC-R1-V1 Issue Date…
