1 AndroidBox ENJOYTVQUALCOREBOX ATV582 User’sGuide ThankyouforpurchasingthisGeniatechproduct. .Beforeusingit,besuretoreadtheprecautionscontainedinthisUser’sGuide. .KeeptheUser’sGuideinasafeplaceforfuturereference. .Forthemostup-to-dateinformationaboutthisproduct,visitofficialwebsiteat http://www.geniatech.com 2 Contents 1.SafetyInformation,P3-4 1.1Warning,P3 1.2Precautions,P3 1.3HandlingCautions,P4 2.Introduction,P5-7 2.1PackageContents,P5 2.2ProductFeatures,P5 2.3PanelIntroduction,P6 2.4RemoteController,P6 2.5SetupConnection,P7 2.6DisplaywhenPowerUp,P7 3.Settings,P8-18 3.1WiFi,P8 3.2Ethernet,P10 3.3DateUsage,P10 3.4More...,P11 3.5Sound,P12 3.6Display,P12 3.7Storage,P13 3.8Apps,P13 3.9Permissions,P14 3.10Location,P14 3.11Security,P15 3.12Language&input,P15 3.13Backup&reset,P16 3.14Addanaccount,P16 3.15Accessibility,P17 3.16Developeroptions,P17 3.17Aboutdevice , P18 4.AppsInstall&Uninstall,P19 5.FirmwareUpdate,P20 6.TroubleShooting/FAQ,P21 7.Repairs,P22 8.Specification,P23 9.TrademarkNotice,P24 3 1.SafetyInformation Readandunderstandallinstructionsbeforeusingthisproduct.Ifdamageiscaused byfailuretofollowtheinstructions,thewarrantydoesnotapply. 1.1Warning Toreducetheriskofelectricshock,DONOTremovethecover(orback). DONOTattempttorepairtheproduct,thiscouldleadtotheriskofinjury,damage totheproduct. Toreducetheriskoffireorelectricshock,keepthisproductawayfromexposed directsunlight,nakedflamesorheat,largeamountsofmoisture,dust,andsand. FCCNote(forU.S.A) ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB digitaldevice,pursuanttoPart15oftheFCCrules.Theselimitsaredesignedto providereasonableprotectionagainstharmfulinterferenceinaresidential installation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergy and,ifnotinstalledandusedinaccordancewiththeinstructions,maycause harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby turningtheequipmentoffandon. Theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe followingmeasures. -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. - - 1.2Precautions ImportantSafetyInstructions Readtheseoperatinginstructionscarefullybeforeusingtheunit.Followallthe safetyinstructionslistedbelow. Keeptheseoperatinginstructionshandyforfuturereference. 1.2.1Readtheseinstructions. 1.2.2Keeptheseinstructions. 1.2.3Heedallwarnings. 1.2.4Followallinstructions. 1.2.5DONOTusethisapparatusnearwater. 1.2.6DONOTcleanwithanychemicaldetergent.Cleanonlywithadrycloth. 1.2.7DONOTblockanyventilationopenings.Installinaccordancewiththe manufacturer’sinstructions. 1.2.8DONOTinstallnearanyheatsourcessuchasradiators,heatregisters,stoves, orotherapparatusthatproduceheat. 1.2.9Protectthepowercordfrombeingwalkedonorpinchedparticularlyatplugs, Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. The distance between user and products should be no less than 20cm FCCWarning 4 conveniencereceptacles,andthepointwhereitexitstheapparatus. 1.2.10Onlyuseattachments/accessoriesspecifiedbythemanufacturer. 1.2.11Useonlywiththecart,stand,tripod,bracket,ortablespecifiedbythe manufacturer,orsoldwiththeapparatus.Whenacartisused,usecautionwhen movingthecart/apparatuscombinationtoavoidinjuryfromtip-over. 1.2.12Unplugthisapparatusduringlightningstormsorwhenunusedforlong periodoftime. 1.2.13Referallservicingtoqualifiedservicepersonnel.Servicingisrequiredwhen theapparatushasbeendamagedinanyway,suchaswhenthepower-supplycordor plugisdamaged,liquidhasbeenspilledorobjectshavefallenintotheapparatus, theapparatushasbeenexposedtorainormoisture,doesnotoperatenormally,or hasbeendropped. 1.3HandlingCautions 1.3.1DONOTexposethisapparatustodrippingorsplashing.Donotputobjects filledwithliquids,suchasvasesontheapparatus. 1.3.2Toturnthisapparatusoffcompletely,youmustpullthepowerplugoutofthe wallsocket.Consequently,thepowerplugmustbeeasilyandreadilyaccessibleat alltimes. 1.3.3DONOTplugmultipleelectricdevicesintothesamewallsocket. Overloadingasocketcancauseittooverheat,resultinginafire. 1.3.4Beforeconnectingothercomponentstothisplayer,besuretoturnthemoff. 1.3.5Iftheproductmakesanabnormalnoiseorproducesaburningsmellorsmoke, turnoffthepowerswitchimmediatelyanddisconnectthepowerplugfromthewall outlet.Then,contactthenearestcustomerservicecenterfortechnicalassistance.Do notusetheproduct.Usingtheproductasitismaycauseafireoranelectricshock. 5 2.Introduction 2.1PackageContents EnjoyTVDualCore-ATV582white/Black User’sGuide HDMICable OptionalCableCVBSCable IRRemoteController(IRRC) OptionalRemoteController 2.4GwirelessRemoteController USBwire/wirelessMouse&Keyboard PowerAdapter,Input:AC100~240V,50/60Hz,Output:5V/2A 2.2ProductFeatures QuadCoreA9,1.6~2.0GHz,RAM2G,ROMbuiltin16GEMMC  PoweredbyAndroid4.4OS  Builtin802.11b/g/nWiFimodule,wirelessInternetaccess 2USBinterface,supportmobileHDD,wired/wirelessmouseandkeyboard operation  RJ4510/100MEthernetinterface  Support1080Pvideoplayback HDMIvideooutput,connecttoHDTVforHDvideoplayback Supportweather,calendar,anddesktopclockgadgets  Support2.4GwirelessmotionRemoteController  Supportmusicplayer,pictureplayerandmorefamilyentertainment SupportSDcardandGoogleChromebrowserandvirtualprivatenetwork access  AppInstallerforapplicationinstallationfromUSB/SDcard 6 2.3PanelIntroduction 2.4RemoteController Note:ButtonBattery20253Vinsertwithcorrectpolarity(+/-). 7 2.5SetupConnection PlaceATV582onaflatplatformneartheTV,andmakesurenothingblockthe remotecontrolsignal. 2.6DisplaywhenPowerUp 2.6.1Afterpowerup,theTVwillfirstshowagreenrobotduringloading.When loadingisfinished,itwillgotoHomescreen. 2.6.2HomeScreendisplay. 8 3.Settings UsingNavigation(4directions),OK,EXIT,andMenukeysofRemoteController toselecttheoptions,theoptionselectedwillbehig…

Text truncated - open the document above for the full version.

DATE : August 11, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: ZJU00141730 Product Name: Enjoy TV Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this August 11, 2014 By: Mike Wu Signature Printed Title: Manager On behalf of : Shenzhen Geniatech INC.,LTD. Telephone: 86-755-26723951

Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Statement We Hereby that The product Enjoy TV, models no. ATV582, ATV581,ATV582BD,ATV582B,ATV581B,ATV581BD,ATV1800,ATV 1800E,ATV180,ATV181,ATV520E,ATV520,STV5 are all identical in interior structure, electrical circuits and components, and just model names and the enclosure are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Company Name: Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China

Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 1 of 5 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 2 of 5 Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 3 of 5 Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 4 of 5 Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 5 of 5

Enjoy TV Model: ATV582 Rating: DC5.3V, 2A FCC ID: ZJU00141730 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Shenzhen Geniatech INC., LTD

Label location

Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 15, 2014 Page 1 of 4 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 15, 2014 Page 2 of 4 Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 15, 2014 Page 3 of 4 Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 15, 2014 Page 4 of 4

Compliance Certification Services Inc. Report No: C140801R01-RPB FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 1 / 3 RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i) and §15.407(f), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b) of this chapter. EUT Specification EUT ATV582 Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.15GHz ~ 5.25GHz WLAN: 5.25GHz ~ 5.35GHz WLAN: 5.47GHz ~ 5.725GHz WLAN: 5.725GHz ~ 5.85GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 2.412-2.462GHz 802.11b mode: 19.42dBm 802.11g mode: 15.78 dBm 802.11n HT20 MHz Channel mode: 14.48 dBm 802.11n HT40 MHz Channel mode: 14.59 dBm Antenna gain (Max) Dipole antennas for 2.4GHz Gain 2.0 dBi Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: 1. The maximum output power is 19.42dBm (87.5mW) at 2412MHz (with 2.000 numeric antenna gain.) 2. DTS device is not subject to routine RF evaluation; MPE estimate is used to justify the compliance. 3. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm2 even if the calculation indicates that the power density would be larger. 4. All two antennas are completely uncorrelated with each other. Compliance Certification Services Inc. Report No: C140801R01-RPB FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 2 / 3 TEST RESULTS No non-compliance noted. Calculation Given d GP E ×× = 30 & 3770 2 E S= Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S ×× = Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 2 2 0796.0 100/3770 1000/30 d GP d GP S × ×= × ×× = Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: Yields GPS××=000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No: C140801R01-RPB FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 3 / 3 Modulation Mode Frequency band (MHz) Max. Conducted output power(dBm) Antenna gain (dBi) Distance (cm) Power density (mW/cm2) Limit (mW/cm2) 802.11b 19.42 2.0 20 0.0276 1 802.11g 15.78 2.0 20 0.0120 1 802.11 n(20MHz) 14.48 2.0 20 0.0088 1 802.11 n(40MHz) 2412-2462 14.59 2.0 20 0.0091 1 Note: Both of the WLAN 2.4G&5.0G can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density WLAN 2.4G=0.0276 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.)

Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID:ZJU00141730 Date of Issue :August 15, 2014 Page 1 of 83 Rev. 00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C TEST REPORT For Product Name: Enjoy TV Brand Name: N/A Model No.: ATV582 Series Model: ATV581,ATV582BD,ATV582B,ATV581B,ATV581BD,ATV1800,ATV1800E, ATV180,ATV181 ˈATV520ˈATV520E,STV5 FCC ID: ZJU00141730 Test Report Number: C140801R01-RPW Issued for Shenzhen Geniatech INC., LTD 8th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Issued by Compliance Certification Services Inc. Kun shan Laboratory No.10 Weiye Rd., Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China TEL: 86-512-57355888 FAX: 86-512-57370818 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID:ZJU00141730 Date of Issue :August 15, 2014 Page 2 of 83 Rev. 00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Report NO. Effect Page Contents 00 August 15, 2014 N/A ALL N/A Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID:ZJU00141730 Date of Issue :August 15, 2014 Page 3 of 83 Rev. 00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1.TEST RESULT CERTIFICATION............................................................................ 4 2.EUT DESCRIPTION.................................................................................................... 5 3.TEST METHODOLOGY ............................................................................................ 6 3.1. EUT CONFIGURATION............................................................................................................ 6 3.2.EUT EXERCISE....................................................................................................................... 6 3.3. GENERAL TEST PROCEDURES................................................................................................. 6 3.4. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS............................................ 7 3.5. DESCRIPTION OF TEST MODES................................................................................................ 8 3.6. A NTENNADESCRIPTION....................................................................................................... 9 4.INSTRUMENT CALIBRATION ................................................................................ 9 4.1. MEASURING INSTRUMENT CALIBRATION.......................................................................... 9 5.FACILITIES AND ACCREDITATIONS ................................................................ 11 5.1. FACILITIES.......................................................................................................................... 11 5.2. EQUIPMENT......................................................................................................................... 11 5.3. LABORATORY ACCREDITATIONS AND LISTING.................................................................... 11 5.4. TABLE OF ACCREDITATIONS AND LISTINGS......................................................................... 12 6.SETUP OF EQUIPMENT UNDER TEST ............................................................... 13 6.1. SETUP CONFIGURATION OF EUT........................................................................................... 13 6.2. SUPPORT EQUIPMENT.................................................................................................. 13 4.FCC PART 15.247 REQUIREMENTS..................................................................... 14 4.1. 6 DB BANDWIDTH................................................................................................................ 14 4.2. PEAK POWER....................................................................................................................... 22 4.3. PEAK POWER SPECTRAL DENSITY........................................................................................ 30 4.4. SPURIOUS EMISSIONS ................................................................................................... 38 4.5. RADIATED EMISSIONS................................................................................................. 63 4.6. POWERLINE CONDUCTED EMISSIONS................................................................................... 81 Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID:ZJU00141730 Date of Issue :August 15, 2014 Page 4 of 83 Rev. 00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Product Name: Enjoy TV Trade Name: N/A Model Name.: ATV582 Series Model: ATV581,ATV582BD,ATV582B,ATV581B,ATV581BD,ATV1800,ATV1800E,ATV180, ATV181ˈATV520ˈATV520E,STV5 Applicant Discrepancy: Initial Device Category: Mobile Device Date of Test: August 3, 2014 to August 10, 2014 Applicant: Shenzhen Geniatech INC., LTD th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Manufacturer: Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Application Type: Certification APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance n…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 1 / 2 TEST SETUP PHOTOGRAPHS OF EUT RADIATED Compliance Certification Services Inc. Report No: C140801R01-RPW FCC ID: ZJU00141730 Date of Issue :August 12, 2014 Page 2 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. CONDUCTIED
