ZJU015N116DEnjoy TV

1 Android Box ENJOY TV QUAL CORE BOX APC380 User’s Guide Contents 1. Safety Information, P3-4 1.1 Warning, P3 1.2 Precautions, P3 1.3 Handling Cautions, P4 2. Introduction, P5-7 2.1 Package Contents, P5 2.2 Product Features, P5 2.3 Panel Introduction, P6 2 2.4 Remote Controller, P6 2.5 Setup Connection, P7 2.6 Display when Power Up, P7 3. Settings, P8-18 3.1 WiFi, P8 3.2 Ethernet, P10 3.3 Date Usage, P10 3.4 More..., P11 3.6 Sound, P12 3.6 Display, P12 3.7 Storage, P13 3.8 Apps, P13 3.9 Permissions, P14 3.10 Location, P14 3.11 Security, P15 3.12 Language & input, P15 3.13 Backup & reset, P16 3.14 Add an account, P16 3.15 Accessibility, P17 3.16 Developer options, P17 3.17 About device, P18 4. Apps Install & Uninstall, P19 5. Firmware Update, P20 6. Trouble Shooting/FAQ, P21 7. Repairs, P22 8. Specification, P23 9. Trademark Notice, P24 3 1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one or more of the following measures. - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cmbetween the radiator & your body. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. The distance between user and products should be no less than 20cm 1.2 Precautions Important Safety Instructions Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. 1.2.1 Read these instructions. 1.2.2 Keep these instructions. 1.2.3 Heed all warnings. 1.2.4 Follow all instructions. 1.2.5 DO NOT use this apparatus near water. 1.2.6 DO NOT clean with any chemical detergent. Clean only with a dry cloth. 1.2.7 DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions. 1.2.8 DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat. 1.2.9 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where it exits the apparatus. 4 1.2.10 Only use attachments/accessories specified by the manufacturer. 1.2.11 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used , use caution when moving the cart/apparatus combination to avoid injury from tip-over. 1.2.12 Unplug this apparatus during lightning storms or when unused for long period of time. 1.2.13 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 1.3 Handling Cautions 1.3.1 DO NOT expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the apparatus. 1.3.2 To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug must be easily and readily accessible at all times. 1.3.3 DO NOT plug multiple electric devices into the same wall socket. Overloading a socket can cause it to overheat, resulting in a fire. 1.3.4 Before connecting other components to this player, be sure to turn them off. 1.3.5 If the product makes an abnormal noise or produces a burning smell or smoke, turn off the power switch immediately and disconnect the power plug from the wall outlet. Then, contact the nearest customer service center for technical assistance. Do not use the product. Using the product as it is may cause a fire or an electric shock. 5 2. Introduction 2.1 Package Contents Enjoy TV Dual Core - APC380 white/Black User’s Guide HDMI Cable Optional Cable CVBS Cable IR Remote Controller (IR RC) Optional Remote Controller 2.4G wireless Remote Controller USB wire/wireless Mouse & Keyboard Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 5V/2A 2.2 Product Features  Quad Core A9, 1.6~2.0GHz, RAM 2G , ROM built in 16G EMMC  Powered by Android 4.4 OS  Built in 802.11b/g/n WiFi module, wireless Internet access  2 USB interface, support mobile HDD, wired/wireless mouse and keyboard operation  RJ45 10/100M Ethernet interface  Support 1080P video playback  HDMI video output, connect to HDTV for HD video playback  Support weather, calendar, and desktop clock gadgets  Support 2.4G wireless motion Remote Controller  Support music player, picture player and more family entertainment  Support SD card and Google Chrome browser and virtual private network access  App Installer for application installation from USB/SD card 6 2.3 Remote Controller Note: Button Battery 2025 3V insert with correct polarity (+/-). 7 2.4 Setup Connection Place APC380 on a…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 (Shenzhen Geniatech INC., LTD) (2014-12-10) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ Shenzhen Geniatech INC., LTD _____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Enjoy TV, model number: APC380,APC361,APC360EP,ATV580,ATV585,ATV360,ATV360BC,ATV360CE,ATV360CD,ATV3 60DE,ATV370,ATV485,ATV390, ATV520E,ATV520V, ATV520B) FCC ID: ZJU015N116D Sincerely, Client’s signature Client’s name / title : Mike Wu/ Manager Contact information / address: 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 (Shenzhen Geniatech INC.,LID) (2014-12-10) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ZJU015N116D We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Mike Wu/ Manager Contact information / address: 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China

Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China Statement We Hereby that The product Enjoy TV, FCC ID: ZJU015N116D, Models No.: APC380,APC361,APC360EP,ATV580,ATV585,ATV360,ATV360BC,A TV360CE,ATV360CD,ATV360DE,ATV370,ATV485,ATV390, ATV520E,ATV520V,ATV520B are all identical in interior structure, electrical circuits and components, and just model names and the enclosure are different for the marketing requirement, such as color and size Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Company Name: Shenzhen Geniatech INC., LTD 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd. Nanshan District, Shenzhen, China

Enjoy TV Model: APC380 Rating: D5V, 2A FCC ID: ZJU015N116D This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Shenzhen Geniatech INC., LTD

Label location

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 MPE TEST REPORT FCC Per 47 CFR 2.1091(b) Report Reference No......................: CTL1411252833-WM FCC ID..............................................: ZJU015N116D Compiled by ( position+printed name+signature)..: File administrators Jennifer NI Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Jacky Chen Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Dec. 09, 2014 Test Laboratory Name ...................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Applicant’s name............................: Shenzhen Geniatech INC., LTD Address.............................................: 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd., Nanshan District, Shenzhen, China Test specification: Standard ...........................................: FCC Per 47 CFR 2.1091(b) TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader’s interpretation of the reproduced material due to its placement and context. Test item description .................... : Enjoy TV FCC ID.......................................: ZJU015N116D Trade Mark .......................................: N/A Model/Type reference.......................: APC380, APC361, APC360EP, ATV580, ATV585, ATV360, ATV360BC, ATV360CE, ATV360CD, ATV360DE, ATV370, ATV485, ATV390, ATV520E, ATV520V, ATV520B Modulation .......................................: 802.11b DSSS, 802.11g/n: OFDM Work Frequency Range....................: 802.11b/g/n(20MHz): 2412~2462MHz Antenna Type ...................................: External Antenna Gain....................................: 0.5dBi Result................................................: Positive V1.0 Page 2 of 7 Report No.: CTL1411252833-WM Test Report Test Report No. : CTL1411252833-WM Dec. 09, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Enjoy TV Model /Type : APC380 Listed Modes : APC361, APC360EP, ATV580, ATV585, ATV360, ATV360BC, ATV360CE, ATV360CD, ATV360DE, ATV370, ATV485, ATV390, ATV520E, ATV520V, ATV520B Difference Description : Only the color and model's name is different Applicant : Shenzhen Geniatech INC., LTD Address : 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd., Nanshan District, Shenzhen, China Manufacturer : Shenzhen Geniatech INC., LTD Address : 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd., Nanshan District, Shenzhen, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 7 Report No.: CTL1411252833-WM Content 1. SUMMARY............................................................................. 4 1.1. EUT configuration 4 1.2. Equipment Under Test 4 1.3. Description of the test mode 4 1.4. NOTE 4 2. TEST ENVIRONMENT ............................................................... 5 2.1. Address of the test laboratory 5 2.2. Environmental conditions 5 2.3. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT..................................................... 6 V1.0 Page 4 of 7 Report No.: CTL1411252833-WM 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer o - supplied by the lab ● AC adapter Manufacturer : SHENZHEN FUJIA APPLIANCE CO., LTD Model No. : FJ-SW0502000E 1.2. Equipment Under Test Power supply system utilised Power supply voltage : „ 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC o Other (specified in blank below) 1.3. Description of the test mode IEEE 802.11b/g/n: Thirteen channels are provided to the EUT, but only eleventh channels used for USA. Channel Frequency(MHz) Channel Frequency(MHz) 1 2412 8 2447 2 2417 9 2452 3 2422 10 2457 4 2427 11 2462 5 2432 6 2437 7 2442 1.4. NOTE The EUT is an 802.11b/g/n RedPort Satellite Optimizer, The functions of the EUT listed as below: Test Standards Reference Report WLAN 802.11b/g, 802.11n FCC Part 15 Subpart C (Section15.247) CTL1411252833-WF WLAN 802.11b/g, 802.11n FCC Per 47 CFR 2.1091(b) CTL1411252833-WM The frequency bands used in this EUT are listed as follows Frequency Band(MHz) 2400-2483.5 5150-5350 5470-5725 5725-5850 802.11b √ - - - 802.11g √ - - - 802.11n(20MHz) √ - - - Modulation Mode TX Function 802.11b 1 TX 802.11g 1 TX 802.11n(20MHz) 1 TX V1.0 Page 5 of 7 Report No.: CTL1411252833-WM 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Shenzhen CTL Testing Technology Co., Ltd. Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 The sites are constructed in conformance with the requirements of ANSI C6230, ANSI C63.4 (2003) and CISPR Publication 22. 2.2. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 950-1050mbar 2.3. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment an…

Text truncated - open the document above for the full version.

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Part 15.247 Report Reference No......................: CTL1411252833-WF Compiled by ( position+printed name+signature) .: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature) .: Test Engineer Tracy Qi Approved by ( position+printed name+signature) .: Manager Tracy Qi Date of issue.....................................: Dec. 09, 2014 Test Laboratory Name...................: Shenzhen CTL Testing Technology Co., Ltd. Address ............................................: Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Applicant’s name............................: Shenzhen Geniatech INC., LTD Address ............................................: 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd., Nanshan District, Shenzhen, China Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 902–928 MHz, 2400– 2483.5 MHz, and 5725–5850 MHz. TRF Originator..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Enjoy TV FCC ID.......................................: ZJU015N116D Trade Mark ....................................... : N/A Model/Type reference ......................: APC380, APC361, APC360EP, ATV580, ATV585, ATV360, ATV360BC, ATV360CE, ATV360CD, ATV360DE, ATV370, ATV485, ATV390, ATV520E, ATV520V, ATV520B Modulation .......................................: 802.11b DSSS, 802.11g/n: OFDM Work Frequency Range ...................: 802.11b/g/n(20MHz): 2412~2462MHz Antenna Type ...................................: External Antenna Gain.................................... : 0.5dBi Result ............................................... : Positive V1.0 Page 2 of 79 Report No.: CTL1411252833-WF T E S T R E P O R T Test Report No. : CTL1411252833-WF Dec. 09, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Enjoy TV Model /Type : APC380 Listed Modes : APC361, APC360EP, ATV580, ATV585, ATV360, ATV360BC, ATV360CE, ATV360CD, ATV360DE, ATV370, ATV485, ATV390, ATV520E, ATV520V, ATV520B Difference Description : Only the color and model's name is different Applicant : Shenzhen Geniatech INC., LTD Address : 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd., Nanshan District, Shenzhen, China Manufacturer : Shenzhen Geniatech INC., LTD Address : 18th F, GDC Building, No. 9 Gaoxin Middle 3rd Rd., Nanshan District, Shenzhen, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 79 Report No.: CTL1411252833-WF Contents 1. TEST STANDARDS................................................................. 4 2. SUMMARY............................................................................ 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 6 2.5. EUT configuration 6 2.6. NOTE 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 3. TEST ENVIRONMENT ............................................................. 6 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 7 3.6. Equipments Used during the Test 8 3.7. Summary of Test Result 9 4. TEST CONDITIONS AND RESULTS.......................................... 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 13 4.3. 6dB Bandwidth Measurement 20 4.4. Maximum Peak Output Power 27 4.5. Band Edge Measurement 29 4.6. Power Spectral Density Measurement 54 4.7. Spurious RF Conducted Emission 61 4.8. Antenna Requirement 71 5. TEST SETUP PHOTOS OF THE EUT ........................................ 72 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ..................... 74 V1.0 Page 4 of 79 Report No.: CTL1411252833-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2009: American National Standard for Testing Unlicensed Wireless Devices. ANSI C63.4-2009 KDB Publication No. 558074 D01 v03r02 Guidance on Measurements for Digital Transmission Systems V1.0 Page 5 of 79 Report No.: CTL1411252833-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Nov. 25, 2014 Testing commenced on : Nov. 25, 2014 Testing concluded on : Dec. 09, 2014 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) Description of the test mode IEEE 802.11b/g/n(HT20): Thirteen channels are provided to the EUT, but only eleventh channels used for USA. Channel Frequency(MHz)ChannelFrequency(MHz) 1 241282447 2 241792452 3 2422102457 4 2427112462 5 2432 6 2437 7 2442 2.3. Short description of the Equipment under Test (EUT) Enjoy TV, support 802.11b/g/n. For more details, refer to the user’s manual of the EUT. Se…

Text truncated - open the document above for the full version.
