ZK2GT12Remote Controller

RF Module / Receiver User Manual GIYOUNG ELECTRONICS 3F #319, The O valley B/D, 555-9, Hogye-Dong, Dongan-Gu, Anyang-Si, Gyenggi-Do, Korea www.gigyong.com Introduction and Key Features Thank you for purchasing the GIYOUNG product. The GIYOUNG transmitter module and receiver based upon DSSS (direct sequence spread spectrum) This product uses 2.4GHz bandwidth in ISM band Not only this product can be used for air but also surface. (For example, you can use the 3PK for surface by the transmitter module for FF9 for air.) (The receiver is possible to use not to distinguish air from surface in the GIYOUNG products.) This product prides fast binding speed and accuracy via 2-ways communication between the transmitter and receiver when you set ID. The buzzer notifies to make link via 2-ways communication whenever switch on because the transmitter module has the buzzer. (After link, it operates 1 way communication to allow for stability and reaction rate.) This product can link an empty channel at power on the transmitter while other products are used in 2.4GHz in ISM band because of the RSSI (Received Signal Strength Indication) function. This product is realized real-time data processing for fast binding speed demanded to RC, and the reaction rate is outstanding because the real speed that the PPM signal from the transmitter is processed by digital is within 5ms. This product is stable not to communicate the receiver which is not set ID, because each transmitter RF module is allocated individual’s ID. There are the many advantages due to the RF module include antenna (antenna type). A: It is very strong to impact or falling B: It is very convenient when the handle of transmitter is installed a stand. C: It is tidy due to unnecessary an antenna cable and no fear of a damaged cable. It boasts one step ahead of technology by adopted the high efficiency and gain antenna via various field tests Caution and Safety for Using Please read the safety instructions before using this product. Do not disassemble which may cause product failure. Please install of RF module and receiver with controller after switch off. After installing the RF module into the controller, please turn on the switch for the throttle lever of controller on a stop position first and then please turn on the switch for the receiver. After stopping the engine or the motor, please turn off the receiver first, and then switch off the controller. Please make sure to test between the RF module and receiver before operating the product. Please check each channel to operate well. Please do not start to control if it malfunctioned. Do not disassemble or replace other antenna with this product for replacement of antenna. Do not cover the antenna with conductive mass or metallic painted cover, the radio wave of radiation cannot be work for sending-receiving. Do not use, assemble other products from other companies for GIYOUNG products. Do not operate one transmitter with many receivers at the same time. Please turn off the switch the receiver that you do not use for your safety when switch on the transmitter module. The guarantee does not cover customer damage by assembling with other products from other companies. The competent wireless installation is possible radio interference, thus it cannot service the related safety of life. The competent wireless installation is possible radio interference during operation. Guarantee 1. This product guarantees for a period of 12 month after the date of purchase. If any defect due to faulty materials and workmanship occurs within guarantee period, we will repair product at our expense. 2. You will be charged to repair even though the guarantee period, as follows. - If a defect is due to damage caused by incorrect use. - If alterations or repairs have been carried out by persons not authorized by GIYOUNG Electronics. - If a defect is due to damage caused by moving or falling during operation. - If a defect is due to damage caused by natural disasters. - The guarantee does not cover a need to change the consumable product parts. - It does not fill in the date of purchasing, the customer name and the store`s name on the guarantee card. - When you modify the guarantee card arbitrarily. 3. According to company policy, we will repair or exchange for the defective products only. 4. If you need service or information or if you have a problem, please contact the local dealer of purchasing with the guarantee card filled in the below table. RF module Model Number Receiver The date of purchasing Warranty period Purchasing information The place of The price of purchasing purchasing Problem Address Customer information Name Tel. If you have any problems, please contact to the local dealer for repairing or replacement. Do not disassemble your product. GIYOUNG ELECTRONICS 3F #319, The O valley B/D, 555-9, Hogye-Dong, Dongan-Gu, Anyang-Si, Gyenggi-Do, Korea www.gigyong.com Notice for install Antenna. The most important part of an antenna is the white core wire (feeder=the cable inside skin). It is better to make the space from the metallic conductors or other cables because the feeder of antenna is very sensitive part to electric field intensity. Do not use the antenna which is cut and damaged, due to danger of short range. The feeder (The cable inside skin) is very sensitive part to length. Compatible controller The model number of GIYONG : GT-12 Futaba : T12FGH, T12ZH, T14ZH(air) The model number of GIYONG : GT-9F Futaba: FF7A,FF9,10C(air),3PK(surface) Hitec: ...(air) .....(surface) The model number of GIYONG : GT-9M SANWA:...(surface) How to use 1. Please install the transmitter module of purchasing to transmitter. (Please join the cable connector below the module, if you use the Futaba 12FG or 14ZH) IMPORTANT : Transmitter should switch the PCM mode to PPM mode. 2. Please connect receiver to the servo and battery which you use as below, after checking the polarity of them. Notice polarity (+) (-), installing battery a…

Text truncated - open the document above for the full version.

GIYOUNG Electronics Co., Ltd. RM319, The O Valley, 555-9, Hogye-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Korea Tel. 82-31-479-3757 / Fax. 82-31-479-3759 Date: June 2, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Lab Manager Jim. Kim and of SGS Testing Korea Co., Ltd and hereafter referred to as SGS Testing Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Jim. Kim of SGS Testing Korea Co., Ltd on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Testing Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; GIYOUNG Electronics Co., Ltd. RM319, The O Valley, 555-9, Hogye-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Korea Tel. 82-31-479-3757 / Fax. 82-31-479-3759 e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Yoo-Seck Jeong /Representative /GIYOUNG Electronics Co., Ltd.

GIYOUNG Electronics Co., Ltd. RM319, The O Valley, 555-9, Hogye-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Korea Tel. 82-31-479-3757 / Fax. 82-31-479-3759 If you have not received all pages, please call the direct phone number. FAX : 031-428-5859 TEL : 031-428-5886 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) and 0.459 pertaining to confidential material. We, GIYOUNG Electronics Co., Ltd. would like the following documents regarding this submission for FCC ID: ZK2GT12 to be kept confidential. 1. Schematics 2. Operating description 3. Block Diagram The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Yoo-Seck Jeong /Representative /GIYOUNG Electronics Co., Ltd.

External photos of EUT Front view of EUT Rear view of EUT Top view of EUT Bottom view of EUT Side view of EUT

FCC Label 1. FCC Label Drawing 2. FCC Label Location GIYOUNG Electronics Co., Ltd. GT-12 FCC ID : ZK2GT12 Made in Korea

Internal photos of EUT PCB top view (Main Board) PCB bottom view (Main board) Antenna view

Report Number: F690501/RF-RTL004690 Page: 2 of 27 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory)18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.kr.sgs.com/ee INDEX Table of contents 1. General information --------------------------------------------------------------------------------------3 2. Transmitter radiated spurious emissions and conducted spurious emission --------------6 3. 6 ㏈ bandwidth ------------------------------------------------------------------------------------------- 15 4. Maximum peak output power --------------------------------------------------------------------------19 5. Power Spectral Density --------------------------------------------------------------------------------- 21 6. Antenna Requirement ----------------------------------------------------------------------------------- 25 7. RF Exposure evaluation -------------------------------------------------------------------------------- 26 Report Number: F690501/RF-RTL004690 Page: 3 of 27 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory)18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.kr.sgs.com/ee 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 705, Dongchun-Dong Sooji-Gu, Yongin-Shi, Kyungki-Do, South Korea. - Wireless Div. 2FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 www.kr.sgs.com/ee Telephone : +82 +31 428 5700 FAX : +82 +31 427 2371 1.2. Details of Applicant Applicant : GIYOUNG Electronics Co., Ltd. Address : RM319, The O Valley, 555-9, Hogye-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Korea Contact Person : Yoo-Seok Jeong Phone No. : +82 +31 479 3757 Fax : +82 +31 479 3759 1.3. Description of EUT Kind of Product Remote Controller Model Name GT-12 Serial Number N / A Power Supply DC 3.3 V Frequency Range 2 405 ~ 2 480 ㎒ Modulation Technique DSSS Number of Channels 76 Antenna Type Connector type (Helical Antenna ) Antenna Gain 3.76 dBi 1.4. Declaration by the manufacturer - N/A Report Number: F690501/RF-RTL004690 Page: 4 of 27 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory)18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.kr.sgs.com/ee 1.5. Test Equipment List EQUIPMENT MANUFACTURER MODEL CAL DUE. Signal Generator Agilent E4438C Mar. 31, 2012 Signal Generator Rohde & Schwarz SMR40 Jul. 15, 2011 Spectrum Analyzer R & S FSV30 Apr. 01, 2012 Power sensor R & S NRP-Z81 Aug. 14, 2011 DC power Supply Agilent U8002A Jan. 05, 2012 Preamplifier H.P 8447F Jul. 05, 2011 Preamplifier Agilent 8449B Mar. 31, 2012 High Pass Filter Wainwright WHK3.0/18G-10SS Sep. 29, 2011 Test Receiver R & S ESU26 Feb. 21, 2012 Bilog Antenna SCHWARZBECK MESSELEKTRONIK 396 Jul. 22, 2011 Horn Antenna R & S HF 906 Oct. 08, 2011 Horn Antenna SCHWARZBECK MESSELEKTRONIK BBHA9170 Mar. 17, 2012 Anechoic Chamber SY Corporation L × W × H (9.6 m×6.4 m×6.6 m) N.C.R. Report Number: F690501/RF-RTL004690 Page: 5 of 27 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory)18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.kr.sgs.com/ee 1.6. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD:FCC Part15 subpart C Standard section Test Item Result 15.205(a) 15.209 15.247(d) Transmitter Radiated Spurious Emissions Conducted Spurious Emission Complied 15.247(a)(2) 6 ㏈ Bandwidth Complied 15.247(b)(3) Maximum Peak Output Power Complied 15.247(e) Power Spectral Density Complied 1.7. Test report revision Revision Report number Description 0 F690501/RF-RTL004690 Initial Report Number: F690501/RF-RTL004690 Page: 6 of 27 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory)18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.kr.sgs.com/ee 2. Transmitter Radiated Spurious Emissions and Conducted Spurious Emission 2.1. Test Setup 2.1.1. Transmitter Radiated Spurious Emissions The diagram below shows the test setup that is utilized to make the measurements for emission from 30 ㎒ to 1 ㎓ Emissions. The diagram below shows the test setup that is utilized to make the measurements for emission from 1 ㎓ to 24 ㎓ Emissions. Report Number: F690501/RF-RTL004690 Page: 7 of 27 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory)18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 www.kr.sgs.com/ee 2.1.2. Conducted Spurious Emission EUT Attenuator Spectrum Analyzer 2.2. Limit According to §15.247(d), in any 100 ㎑ bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 ㏈ below that in the 100 ㎑ bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement , provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter…

Text truncated - open the document above for the full version.

Test setup photo of EUT Photo of radiated spurious emission
