ZKQ-ONEWCDMA Tracker

1 WCDMA Tracker Prime One User Manual Revision: 1.00 Document TitlePrime One User manual Version1.00 Finale Date2015-05-21 StatusReleased Document Control IDTRACKER Prime One 2 Contents 1 Introduction......................................................................................................................................3 2 Product Overview............................................................................................................................ 3 2.1 Appearance............................................................................................................................3 2.2 Buttons/Micro USB Interface Description........................................................................... 3 2.3 LED Description................................................................................................................... 4 3 Getting Started................................................................................................................................. 5 3.1 Parts List................................................................................................................................5 3.2 Battery Charging...................................................................................................................5 3.3 Prime One Data Cable.......................................................................................................... 6 3.4 Power on/Power off.............................................................................................................. 6 4 Trouble shooting and Safety info.....................................................................................................7 4.1 Trouble shooting................................................................................................................... 7 4.2 Safety info.............................................................................................................................7 3 1 Introduction Prime One is a powerful GPS locator which is designed for vehicle, pets and assets tracking. With superior receiving sensitivity, fast WCDMAfrequencies 850/1900 and GSM frequencies 850/900/1800/1900. Its location can be real time or schedule tracked by backend server or specified terminals. Based on the embedded wireless tracking protocol, Prime One can communicate with the backend server through WCDMA or GSM/GPRS network, and transfer reports of emergency, Geo-fencing, device status and scheduled GPS position etc... Service provider is easy to setup their tracking platform based on the functional wireless tracking protocol. 2 Product Overview 2.1 Appearance Figure 1-1 2.2 Buttons/Micro USB Interface Description Button /Micro USB Interface Description KEY/interfaceDescription Power KeyPower on Prime One Power off Prime One (If power key is enabled) 4 Function KeyGeo-Fence mode Long press the key to enable/disable Geo-Fence ID0 Geo-Fence in current position mode Long press the key to enable/disable Geo-Fence ID0. If enable Geo-Fence ID0, using the current position as the centre of Geo-Fence 0. SOS mode (default) Long press the key to active SOS alarm Micro USB interface Connect a 5V DC adapter can power on Prime One and charge the internal battery Connect a 3.7V Li-ion or Li-Polymer battery can power on Prime One Backend server developer or administrator can use the data cable to configure Prime One Reset KeyClick the key will turn off internal VBAT when OS is abnormal, and then press Power Key to restart Prime One. Note: Reset key is invalid when external battery is used. 2.3 LED Description Figure 1-2 There are four LED lights in Prime One device, the description as following. LightEventState GPS LEDGPS fixedFast flash GPS has been turned offDark WCDMA LED Power on and normalSlow flash Power offDark WIFI LEDWIFI onSlow flash WIFI offDark Power LED Power on and normalDark 5 Fully chargedSolid In chargingSlow flash 3 Getting Started 3.1 Parts List NamePictureRemark Prime One Locater The WCDMA/GPS locator. AC-DC Power Adapter It is used to charge the internal battery of Prime One. Prime One Data and charger Cable It the USB data cable which can be used for firmware upgrading and configuration. It also includes the charger interface on the Prime One. 3.2 Battery Charging The following items are suggestion for battery charge, please pay more attention. Please connect AC-DC power adapter with Prime One device. Insert the AC-DC power adapter into the power socket. During the charging process, the Power LED lightwill solid. When the battery is fully charged, the Power LED lightwill be Ever-light. You can also charge the battery using USB cable which connects Prime One device with the PC. 6 Charging will last about 5 hours. Note: If the Prime One device is firstly used, please make sure the battery is fully charged, which will make the life of battery much longer. 3.3 Prime One Data Cable Prime One Data Cable is a cable with a Micro USB connector. The USB data cable is used for data download, which will be used for firmware update or configuration and can be used for charging at the same time. Figure 2-1 3.4 Power on/Power off Figure 2-2 Power on: Press the Power key at least 3 seconds and release it to power on Prime One device. Note that, the Power LED lightwill fast flash. Power off: Press the power key about 3 seconds; Power LED light will fast flash and then turn off, which indicates that Prime One device has been powered off. Note: the user can not power off Prime One if the power key is disabled by 7 protocol. 4 Trouble shooting and Safety info 4.1 Trouble shooting 4.2 Safety info The following items are suggestion for safety use, please pay more attention.  Please do not disassemble the device by yourself.  Please do not put the device on the overheating or too humid place, avoid exposure to direct sunlight. Too high temperature will damage the device or even cause the battery explosion.  Please do not use…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date FromTo Initial Release (obsolete)1.01.0Nov-14-2006 Revised wording (obsolete)1.02.0Sept–25-2007 Updated company template (obsolete)2.03.0Jan-31-2012 Updated letter information (obsolete)3.04.0May-23-2014 Added FCC ID field (current)4.05.0Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Micron Electronics LLC. 2015/06/02 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, __Micron Electronics LLC.___hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): (Product description, model name) WCDMA Tracker，Prime one FCC ID :ZKQ-ONE Sincerely, Client’s signature Client’s name / title：Ping Cheng/Director Contact information / address1001 Yamato Road, Suite 400, Boca Raton, FL 33431, USA

SCS-F19: Confidentiality Request LetterPage 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date FromTo Initial Release (obsolete)1.01.0Nov-14-2006 Adding CFR 2.459 (obsolete)1.02.0August – 11 - 2008 Updated company template & Added text box (obsolete) 2.03.0Jan-31-2012 Added IC confidentiality letter form (current)3.04.0March-26-2015 SCS-F19: Confidentiality Request LetterPage 2 of 2 Rev 4.0 Micron Electronics LLC. 2015/06/02 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject:Permanent Confidentiality Request forFCC ID: ZKQ-ONE We hereby request confidential treatment of information accompanying this application as outlined below: -e. g.BlockDiagram - e.g. Schematics - e.g. Operational Description -e. g. Tune up Procedure -e.g.PartList The above materials contain trade secrets and proprietary information not customarilyreleased to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title：Ping Cheng/Director Contact information / address1001 Yamato Road, Suite 400, Boca Raton, FL 33431, USA

Test Report 15050015-FCC-E Page 18 of 27 Annex B. EUT And Test Setup Photographs Annex B.i. Photograph: EUT External Photo Whole Package - Top View EUT - Front View EUT - Rear View Test Report 15050015-FCC-E Page 19 of 27 EUT - Top View EUT - Bottom View EUT - Left View EUT - Right View

Label location: In the middle of the rear housing Prime one of (24 * 24mm concave) Label location

Test Report 15050015-FCC-E Page 20 of 27 Annex B.ii. Photograph: EUT Internal Photo Cover Off - Top View 1 Battery - Top View Battery - Bottom View Test Report 15050015-FCC-E Page 21 of 27 Mainborad With Shielding - Front View Mainborad Without Shielding - Front View Mainborad With Shielding - rear View Mainborad Without Shielding - rear View WIFI/BT/BLE - Antenna View GSM/PCS/UMTS-FDD Antenna View

RF EXPOSURE REPORT Report No.: 15050015-FCC-H Supersede Report No.: N/A Applicant Micron Electronics LLC. Product Name WCDMA Tracker Model No. Prime one Serial No. N/A Test Standard FCC 2.1093 Test Date May 07 to June 04, 2015 Issue Date June 04, 2015 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification Wiky.Jam Test Engineer Chris You Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report 15050015-FCC-H Page 2 of 10 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report 15050015-FCC-H Page 3 of 10 This page has been left blank intentionally. Test Report 15050015-FCC-H Page 4 of 10 CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. FCC §2.1093 - RADIOFREQUENCY RADIATION EXPOSURE EVALUATION: PORTABLE DEVICES. 8 5.1 RF EXPOSURE .......................................................................................................................................................... 8 5.2 TEST RESULT ........................................................................................................................................................... 9 Test Report 15050015-FCC-H Page 5 of 10 1. Report Revision History Report No. Report Version Description Issue Date 15050015-FCC-H NONE Original June 04, 2015 2. Customer information Applicant Name Micron Electronics LLC. Applicant Add 1001 Yamato Road, Suite 400, Boca Raton, FL 33431, USA Manufacturer Micron Electronics LLC. Manufacturer Add 1001 Yamato Road, Suite 400, Boca Raton, FL 33431, USA 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Radiated Emission Program-To Shenzhen v2.0 Test Report 15050015-FCC-H Page 6 of 10 4. Equipment under Test (EUT) Information Description of EUT: WCDMA Tracker Main Model: Prime one Serial Model: N/A Date EUT received: May 06, 2015 Test Date(s): May 07 to June 04, 2015 Antenna Gain: GSM850:0 dBi PCS1900: 1.8 dBi UMTS-FDD Band V: 0dBi UMTS-FDD Band II: 1.8dBi Bluetooth: -1dBi WIFI:-1dBi Type of Modulation: GSM / GPRS: GMSK EGPRS: GMSK, 8PSK UMTS-FDD: QPSK, 16QAM 802.11b/g/n: DSSS, OFDM Bluetooth: GFSK, π /4DQPSK, 8DPSK RF Operating Frequency (ies): GSM850 TX: 824.2 ~ 848.8 MHz; RX: 869.2 ~ 893.8 MHz PCS1900 TX: 1850.2 ~ 1909.8 MHz; RX: 1930.2 ~ 1989.8 MHz UMTS-FDD Band V TX: 826.4 ~ 846.6 MHz; RX: 871.4 ~ 891.6 MHz UMTS-FDD Band II TX:1852.4 ~ 1907.6 MHz; RX: 1932.4 ~ 1987.6 MHz WIFI:802.11b/g/n(20M): 2412-2472 MHz WIFI:802.11n(40M): 2422-2462 MHz Bluetooth: 2402-2480 MHz Number of Channels: GSM 850: 124CH PCS1900: 299CH UMTS-FDD Band V : 102CH UMTS-FDD Band II : 277CH Test Report 15050015-FCC-H Page 7 of 10 WIFI :802.11b/g/n(20M): 13CH WIFI :802.11n(40M): 9CH Bluetooth: 79CH Port: USB Port Input Power: Battery: Spec: 3.7V 850mAh Charger Max Voltage:4.35V Input DC5V(USB Port) Trade Name : Prime GPRS/EGPRS Multi-slot class 8/10/12 FCC ID: ZKQ-ONE Test Report 15050015-FCC-H Page 8 of 10 DFP/ 5. FCC §2.1093 - Radiofrequency radiation exposure evaluation: portable devices. 5.1 RF Exposure Standard Requirement: According to §15.247 (i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’ s guidelines. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. result = P= Maximum turn-up power in mW F= Channel frequency in GHz D= Minimum test separation distance in mm Test Report 15050015-FCC-H Page 9 of 10 5.2 Test Result Bluetooth Mode: Modulation CH Freq (MHz) Conducted Power (dBm) Tune Up Power (dBm) Max Tune Up Power (dBm) Max Tune Up Power (mW) ResultLimit GFSK Low 240…

Text truncated - open the document above for the full version.

RF TEST REPORT Report No.: 15050015-FCC-R3 Supersede Report No.: N/A Applicant Micron Electronics LLC. Product Name WCDMA Tracker Model No. Prime one Serial No. N/A Test Standard FCC Part 15.247: 2014, ANSI C63.10: 2013 Test Date May 07 to June 04, 2015 Issue Date June 04, 2015 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification Wiky.Jam Test Engineer Chris You Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report No. 15050015-FCC-R3 Page 2 of 50 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report No. 15050015-FCC-R3 Page 3 of 50 This page has been left blank intentionally. Test Report No. 15050015-FCC-R3 Page 4 of 50 CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. TEST SUMMARY .................................................................................................................................................... 8 6. MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ..................................................................... 9 6.1 ANTENNA REQUIREMENT ..................................................................................................................................... 9 6.2 DTS (6 DB&20 DB) CHANNEL BANDWIDTH ..................................................................................................... 10 6.3 MAXIMUM OUTPUT POWER ............................................................................................................................... 16 6.4 POWER SPECTRAL DENSITY ............................................................................................................................. 20 6.5 BAND-EDGE & UNWANTED EMISSIONS INTO NON-RESTRICTED FREQUENCY BANDS .................. 24 6.6 AC POWER LINE CONDUCTED EMISSIONS ................................................................................................... 30 6.7 RADIATED SPURIOUS EMISSIONS ................................................................................................................... 34 ANNEX A. TEST INSTRUMENT ................................................................................................................................. 39 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 40 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 45 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PARTLIST .................................................. 49 ANNEX E. DECLARATION OF SIMILARITY ............................................................................................................ 50 Test Report No. 15050015-FCC-R3 Page 5 of 50 1. Report Revision History Report No. Report Version Description Issue Date 15050015-FCC-R3 NONE Original June 04, 2015 2. Customer information Applicant Name Micron Electronics LLC. Applicant Add 1001 Yamato Road, Suite 400, Boca Raton, FL 33431, USA Manufacturer Micron Electronics LLC. Manufacturer Add 1001 Yamato Road, Suite 400, Boca Raton, FL 33431, USA 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Radiated Emission Program-To Shenzhen v2.0 Test Report No. 15050015-FCC-R3 Page 6 of 50 4. Equipment under Test (EUT) Information Description of EUT: WCDMA Tracker Main Model: Prime one Serial Model: N/A Date EUT received: May 06, 2015 Test Date(s): May 07 to June 04, 2015 Equipment Category： DTS Antenna Gain: GSM850:0 dBi PCS1900: 1.8 dBi UMTS-FDD Band V: 0dBi UMTS-FDD Band II: 1.8dBi Bluetooth: -1dBi WIFI:-1dBi Type of Modulation: GSM / GPRS: GMSK EGPRS: GMSK, 8PSK UMTS-FDD: QPSK, 16QAM 802.11b/g/n: DSSS, OFDM Bluetooth: GFSK, π /4DQPSK, 8DPSK RF Operating Frequency (ies): GSM850 TX: 824.2 ~ 848.8 MHz; RX: 869.2 ~ 893.8 MHz PCS1900 TX: 1850.2 ~ 1909.8 MHz; RX: 1930.2 ~ 1989.8 MHz UMTS-FDD …

Text truncated - open the document above for the full version.

Test Report No. 15050015-FCC-R3 Page 44 of 50 Annex B.iii. Photograph: Test Setup Photo Conducted Emissions Test Setup Front View Conducted Emissions Test Setup Side View Radiated Spurious Emissions Test Setup Below 1GHz Radiated Spurious Emissions Test Setup Above 1GHz
