ZKS-QR4000QR4000 (HxGN MineDiscover 4D-Radar)

Hexagon Geosystems Services AG Baarerstrasse 133 | CH-6300 Zug | Switzerland Certification Application Attestation Statements Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining Baarerstrasse 133 CH-6300 Zug Switzerland Subject: FCC ID: ZKS-QR4000 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date: 14.08.2024 City: CH-6300 Zug FRN Number: 0020866158 FCC ID: ZKS-QR4000 Name (2) : Daniel Hess Function: Electronics Design Engineer Telephone number: +41 71 727 34 29 Email address: [email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK”

Page 1 of 1 Document no.: 24013216 V 1.24 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Letter of Conformity Document Number: 24013216 We, TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKAN PARK, Building 10 Waltherstrasse 49-51 51069 Cologne, Germany Mail: [email protected] Tel.: +49 221-888895-0 Declare that the following product: Manufacturer : Hexagon Geosystems Services AG, Zweigstelle Mining Baarerstrasse 133 6300 Zug, Switzerland Product designation : QR4000 Product description : Transport and traffic telematics Model : QR4000 Brand name : HEXAGON Article number : 961573 Serial number : 96157301751, 96157301764, 96157301776 has been tested in our facility and found compliance with the following standards: Essential requirement Specifications / Standards Test Report Number(s) Health & Safety EN 62311:2008 EN 62368-1:2014 + AC:2015 24013197_Rev.01 24013176_Rev.01 EMC ETSI EN 301 489-1 V2.2.3 ETSI EN 301 489-51 V2.1.1 24013144_Rev.01 Radio ETSI EN 301 091-1 V2.1.1 24013196_Rev.01 Cologne, 2024-08-28 ____________________________ ____________________________ (Laboratory Manager) (Technical engineer)

Hexagon Geosystems Services AG Baarerstrasse 133 | CH-6300 Zug | Switzerland Company Name: Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining Address: Baarerstrasse 133 City: CH-6300 Zug Country: Switzerland To: Kiwa Netherlands B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: ZKS-QR4000 FRN: 0020866158 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby request non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: After a large investment has been made we seek to secure the interest of our stakeholders. Date: 13.09.2024 Name and signature of applicant: Daniel Hess Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should state in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Kiwa NL B.V. at least 7 days before date of actual marketing or before expiration of the STC period

Page 1 of 5 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Annex acc. to FCC Title 47 CFR Part 95 M relating to Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining QR4000 Annex no. 1 External Photographs Title 47 - Telecommunication Part 95 - Personal Radio Services Subpart M – The 76 – 81 GHz Band Radar Service Measurement Procedure: ANSI C63.26-2015 Page 2 of 5 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Version Applied changes Date of release 00 Initial release 2024-07-31 Page 3 of 5 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Photographs of the test equipment (EUT) – Front side of unit Page 4 of 5 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Photographs of the test equipment (EUT) – Rear side of unit Page 5 of 5 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Photograph of EUT: Connector

Page 1 of 4 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO-------------------- RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Annex acc. to FCC Title 47 CFR Part 95 M relating to Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining QR4000 Annex no. 4 Label sample Title 47 - Telecommunication Part 95 - Personal Radio Services Subpart M – The 76 – 81 GHz Band Radar Service Measurement Procedure: ANSI C63.26-2015 Page 2 of 4 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO-------------------- RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Version Applied changes Date of release 00 Initial release 2024-07-31 Page 3 of 4 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO-------------------- RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Label sample design Page 4 of 4 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO-------------------- RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-07-31 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Label location

EUT: QR4000 Date of issue: 2024-09-11 V. 1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] SAR Test exclusion documentation according to FCC § 1.1307(b)(3), RSS-102 BNetzA-CAB-13/21-08 EUT: QR4000 Date of issue: 2024-09-11 V. 1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] This SAR test exclusion document is referring to the Test report identification no.: 24013198_Rev.01_FCC Part 95 M and 24013199_Rev.01_RSS-251_Issue2. Contains the module with the Certification numbers FCC ID ZKS-QR4000 IC ID 9849A-QR4000 HVIN (Hardware Version Identification Number) Rev. A PMN (Product Marketing Name) QR4000 FVIN (Firmware Version Identification Number) 8 HMN (Host Marketing Name) QR4000 Equipment Under Test (EUT) EUT / Technology Operating Frequency [GHz] EIRP Average power. [dBm] Antenna Gain [dBi] QR4000 / FMCW RADAR 76.365 (WF0/CF0) 25.7** 17.5 76.605 (WF0/CF1) 24.5** 17.5 76.125 (WF1/CF0) 26.8** 17.5 76.845 (WF1/CF3) 23.9** 17.5 ** measurement results are taken from TÜV Nord HF Test report no. 24013198_Rev.00_FCC Part 95 M and 24013199_Rev.01_RSS-251_Issue2. EUT: QR4000 Date of issue: 2024-09-11 V. 1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] SAR test exclusion according to FCC § 1.1307(b)(3) According to FCC § 1.1307(b)(3)(i)(C) and the Table 1 in (C), the EUT is exempted from SAR evaluation. SAR test exclusion for 76 – 81 GHz RADAR devices Operating Frequency [GHz] d separation [cm] Power measured [mW] EIRP Power limit [mW] Exclusion [Yes / No] 76.400 20 371.54 6297.6 Yes 76.638 20 281.84 6297.6 Yes 76.139 20 478.63 6297.6 Yes 76.860 20 245.47 6297.6 Yes EUT: QR4000 Date of issue: 2024-09-11 V. 1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] SAR test exclusion according to RSS-102 Issue 5 Section 2.5.2 According to RSS-102 Issue 5 section 2.5.2, if the EUT operates at or above 6 GHz and the source-based, time-averaged maximum e.i.r.p of the device is equal to or less than 5 W (adjusted for tune-up tolerance), then it is exempted from SAR evaluation. SAR test exclusion for 76 – 81 GHz RADAR devices Operating Frequency [GHz] d separation [cm] Power measured [mW] EIRP Power limit [mW] Exclusion [Yes / No] 76.400 > 20 371.54 5000.0 Yes 76.638 > 20 281.84 5000.0 Yes 76.139 > 20 478.63 5000.0 Yes 76.860 > 20 245.47 5000.0 Yes EUT: QR4000 Date of issue: 2024-09-11 V. 1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] ATTESTATION: I attest that the EUT meets the exemption from the routine evaluation limits according to FCC § 1.1307(b)(3) as well as meets the exemption from the routine evaluation limits in section 2.5 “Exemption Limits for Routine Evaluation” of RSS-105 issue 5; that the Technical Brief was prepared and the information contained therein is correct; that the device evaluation was performed or supervised by me; that applicable measurement methods and evaluation methodologies have been followed; and that the device meets the SAR and/or RF field strength limits of FCC § 1.1307(b)(3) and RSS-102 issue 5. Signature Name Mr. Ralf Trepper Designation Laboratory Manager Date of issue 2024-09-11

Page 1 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Annex acc. to FCC Title 47 CFR Part 95 M relating to Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining QR4000 Annex no. 3 Test results Channel occupancy/ bandwidth Title 47 - Telecommunication Part 95 - Personal Radio Services Subpart M – The 76 – 81 GHz Band Radar Service Measurement Procedure: ANSI C63.26-2015 Page 2 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Version Applied changes Date of release 00 Initial release 2024-07-31 Page 3 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Measured 6 dB Bandwidth (Waveform 0) @ 76.365 GHz @ 76.605 GHz Page 4 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Measured 6 dB Bandwidth (Waveform 1) @ 76.125 GHz @ 76.845 GHz Page 5 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Frequency stability (Waveform 0 @ 76.365 GHz) 99% mbw +22°C 24V DC 99% mbw +22°C 7V DC 99% mbw +22°C 32V DC Page 6 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Frequency stability (Waveform 0 @ 76.605 GHz) 99% mbw +22°C 24V DC 99% mbw +22°C 7V DC 99% mbw +22°C 32V DC Page 7 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Frequency stability (Waveform 1 @ 76.125 GHz) 99% mbw +22°C 24V DC 99% mbw +22°C 7V DC 99% mbw +22°C 32V DC Page 8 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Frequency stability (Waveform 1 @ 76.845 GHz) 99% mbw +22°C 24V DC 99% mbw +22°C 7V DC 99% mbw +22°C 32V DC Page 9 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Frequency stability (Waveform 0 @ 76.365 GHz) -40°C with 24 V DC -20°C with 24V DC -10°C with 24V DC 0°C with 24V DC +10°C with 24V DC Page 10 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] +20°C with 24 V DC +30°C with 24V DC +40°C with 24V DC +50°C with 24V DC +85°C with 24V DC Page 11 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Test plots – Frequency stability (Waveform 0 @ 76.605 GHz) -40°C with 24 V DC -20°C with 24V DC -10°C with 24V DC 0°C with 24V DC +10°C with 24V DC Page 12 of 16 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO…

Text truncated - open the document above for the full version.

Page 1 of 12 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Annex acc. to FCC Title 47 CFR Part 95 M relating to Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining QR4000 Annex no. 11 Antenna Requirements Details Title 47 - Telecommunication Part 95 - Personal Radio Services Subpart M – The 76 – 81 GHz Band Radar Service Measurement Procedure: ANSI C63.26-2015 Page 2 of 12 Test report no. 24013198_Rev. 00 ---RADIO--------------------RADIO--------------------RADIO-------------------- RADIO-------------------- RADIO------------------RADIO EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M EUT: QR4000 V1.23 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Building 10, Waltherstr. 49-51, 51069 Cologne, Germany Tel.: +49 221 8888950 [email protected] Version Applied changes Date of release 00 Initial release 2024-07-31 Antenna Requirements Details Hexagon Geosystems Services AG Baarerstrasse 133 | CH-6300 Zug | Switzerland 1/1 Antenna Requirements QR4000 (DRVEGRD 152) Equipment: Radar Sensor Trademark: Hexagon Manufacturer: Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining Hexagon Geosystems Services AG Baarerstrasse 133 | CH-6300 Zug | Switzerland 1/1 Photo of the Antennas 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 DD CC BB AA ANTENNA-30_TOP.SchDoc MKL 300104 MKL ANTENNA-30 Overview 14.07.2020 smart microwave sensors GmbH * Germany In den Waashainen 1 * 38108 Braunschweig CONFIDENTIALAND PROPRIETARY The information contained in this document shall remain the sole exclusive property of smart microwave sensors GmbH and shall not be disclosed by any recipient to third parties without prior consent of smart microwave sensors GmbH in writing. RX_RFGND TX0_RF TX1_RF U_ANTENNA-30_ANT ANTENNA-30_ANT.SCHDOC MIXER_OUT RX_RF RX_ATEST_A RX_ATEST_B VCO_P VCO_N TX_ATEST TRX_CHIP_EN ADF_5901_MUXOUT TX0_RF ADF_5901_FREF V_TUNE GND AVDD_3V3 TX1_RF SPI3_CS0 SPI3_CS1 SPI3_SCLK SPI3_D0 SPI3_D1 SPI3_CS2 U_ANTENNA-30_RFC ANTENNA-30_RFC.SCHDOC GND AVDD_3V3 V_TUNE ADF_5901_FREF VCO_P VCO_N SPI4_CS0 SPI4_SCLK SPI4_D0 ADF_4159_MUXOUT PLL_CHIP_EN ADF4159_TXDATA DVDD_3V3 U_ANTENNA-30_SNT ANTENNA-30_SNT.SCHDOC AVDD_3V3 GND GND GND U_ANTENNA-30_Stack ANTENNA-30_Stack.SchDoc MP1 PCB-ANTENNA-300104 DVDD_3V3 AVDD_3V3 AVDD_1V8 DVDD_1V8 DOUT1_P DOUT1_N DOUT0_P DOUT0_N I2C3_SCL I2C3_SDA PGOOD_FE_SUPPLY SPI1_CS0 SPI1_CS1 SPI1_SCLK SPI1_D0 SPI1_D1 ADF_5901_MUXOUT ADF_4159_MUXOUT GND RX1_1_P RX1_1_N RX1_2_P RX1_2_N RX1_3_P RX1_3_N RX1_4_P RX1_4_N RX2_1_P RX2_1_N RX2_2_P RX2_2_N RX2_3_P RX2_3_N RX2_4_P RX2_4_N VCM1_12 VCM1_34 VCM2_12 VCM2_34 GPIO_PULSE_SELECT U_ANTENNA-30_TDA2P_ADC ANTENNA-30_TDA2P_ADC.SchDoc DOUT1_P DOUT1_N DOUT0_P DOUT0_N DVDD_3V3 AVDD_1V8 DVDD_1V8 I2C3_SCL I2C3_SDA AVDD_3V3 PGOOD_FE_SUPPLY SPI1_CS0 SPI1_CS1 SPI1_SCLK SPI1_D0 SPI1_D1 FE_ENABLE 3V8 GND SPI3_CS0 SPI3_CS1 SPI3_SCLK SPI3_D0 SPI3_D1 SPI3_CS2 SPI4_CS0 SPI4_SCLK SPI4_D0 ADF_4159_MUXOUT TX_ATEST RX_ATEST_A RX_ATEST_B TRX_CHIP_EN PLL_CHIP_EN ADF4159_TXDATA GPIO_PULSE_SELECT U_ANTENNA-30_TDA2P_Deserializer ANTENNA-30_TDA2P_Deserializer.SchDoc 3V8 AVDD_3V3 FE_ENABLE DVDD_3V3 PGOOD_FE_SUPPLY AVDD_1V8 DVDD_1V8 GND U_ANTENNA-30_TDA2P_Frontend_Power_Supply ANTENNA-30_TDA2P_Frontend_Power_Supply.SchDoc AVDD_3V3 DVDD_3V3 AVDD_1V8 DVDD_1V8 PGOOD_FE_SUPPLY 3V8 FE_ENABLE AVDD_3V3 DVDD_3V3 AVDD_1V8 DVDD_1V8 DOUT1_P DOUT1_N DOUT0_P DOUT0_N ADF_5901_MUXOUT SPI1_SCLK SPI1_CS0 SPI1_D0 SPI1_CS1 SPI1_D1 I2C3_SCL I2C3_SDA PGOOD_FE_SUPPLY FE_ENABLE 3V8 3V8 3V8 GND GND GND DVDD_3V3 AVDD_3V3 DVDD_1V8 AVDD_1V8 DVDD_3V3 DVDD_3V3 AVDD_3V3 AVDD_3V3 AVDD_3V3 MIXER_OUT GND AVDD_3V3 VCM1_12 VCM1_34 RX1_1_P RX1_1_N RX1_2_P RX1_2_N RX1_3_P RX1_3_N RX1_4_P RX1_4_N RX2_1_P RX2_1_N RX2_2_P RX2_2_N RX2_3_P RX2_3_N RX2_4_P RX2_4_N VCM2_12 VCM2_34 U_ANTENNA-30_TDA2P_Filter ANTENNA-30_TDA2P_Filter.SchDoc GND AVDD_3V3 AVDD_3V3 RX2_1_P RX2_1_N RX2_2_P RX2_2_N RX2_3_P RX2_3_N RX2_4_P RX2_4_N RX1_1_P RX1_1_N RX1_2_P RX1_2_N RX1_3_P RX1_3_N RX1_4_P RX1_4_N 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 DD CC BB AA DocumentName:ANTENNA-30_RFC.SCHDOC DrawnBy: MKL Revision: 300104 Engineer: MKL Title: ANTENNA-30 RF-Circuitry ModifiedDate: 14.07.2020 smart microwave sensors GmbH In den Waashainen 1 CONFIDENTIALAND PROPRIATARY The information contained in this document shall remain the sole exclusive property of smart microwave sensors GmbH and shall not be disclosed by any recipient to third parties without prior consent of smart microwave sensors GmbH in writing. 38108 Braunschweig * Germany RX_RF.CHAN_04 RX_RF.CHAN_06 ANALOG DEVICES ADF5904 RX1_O+ 32 RX1_O- 31 RX2_O+ 8 RX2_O- 9 RX3_O+ 25 RX3_O- 26 RX4_O+ 17 RX4_O- 16 RX1_RF 2 RX2_RF 6 RX3_RF 23 RX4_RF 19 DATA 12 CLK 11 LE 10 CE 13 DOUT 14 ATEST 15 LO_RF 29 U1 GND GNDGNDGND RX_SPI_LE_A TRX_SPI_DATA TRX_CE RX_LO_A GNDGND RX_RF.CHAN_08 ANALOG DEVICES ADF5904 RX1_O+ 32 RX1_O- 31 RX2_O+ 8 RX2_O- 9 RX3_O+ 25 RX3_O- 26 RX4_O+ 17 RX4_O- 16 RX1_RF 2 RX2_RF 6 RX3_RF 23 RX4_RF 19 DATA 12 CLK 11 LE 10 CE 13 DOUT 14 ATEST 15 LO_RF 29 U2 GND GNDGNDGND RX_SPI_LE_B TRX_SPI_DATA TRX_CE RX_LO_B GNDGND RX_RF.CHAN_05 RX_RF.CHAN_03 RX_LO1 Wilkinson GND GND RX_LO_A RX_LO_B GND GND 2312 100F Tantalum C44 GND GNDGNDGNDGND TX1_RF VCO_P VCO_N TRX_CE TRX_SPI_DATA TX_ATEST TX_SPI_LE V_TUNE GNDGNDGNDGND VCC_TX GNDGND ADF_5901_FREF TX_DOUT TX_MUXOUT RX_DOUT_A RX_DOUT_B RX_ATEST_A RX_ATEST_B 2312 100F Tantalum C14 GND 3V3_RX_A 3V3_RX_B L1 BLM21PG221SH1D GND MIXER_OUT.04_P MIXER_OUT.04_N MIXER_OUT.01_P MIXER_OUT.01_N MIXER_OUT.07_P MIXER_OUT.07_N MIXER_OUT.05_P MIXER_OUT.05_N MIXER_OUT.08_P MIXER_OUT.08_N MIXER_OUT.02_P MIXER_OUT.02_N MIXER_OUT.03_P MIXER_OUT.03_N MIXER_OUT.06_P MIXER_OUT.06_N 01_N 02_N 03_N 04_N 05_N 06_N 07_…

Text truncated - open the document above for the full version.

Page 1 of 88 Test report no. 24013198_Rev.01 EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-08-20 V. 1.24 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Gebäude 10, Waltherstr. 49-51, 51069 Köln, Germany Tel.: +49 221 8888950 [email protected] Test Report acc. to FCC Title 47 CFR Part 95 M relating to Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining QR4000 Title 47 - Telecommunication Part 95 - Personal Radio Services Subpart M – The 76 – 81 GHz Band Radar Service Measurement Procedure: ANSI C63.26-2015 Page 2 of 88 Test report no. 24013198_Rev.01 EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-08-20 V. 1.24 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Gebäude 10, Waltherstr. 49-51, 51069 Köln, Germany Tel.: +49 221 8888950 [email protected] MANUFACTURER Manufacturer name Hexagon Geosystems Services AG, Zweigniederlassung Hexagon Mining Manufacturer’s grantee code --- Manufacturer’s address Baarerstr. 133, 6300, Switzerland Phone +41 71 727 34 29 Fax --- Email [email protected] TESTING LABORATORY Test engineer Mr. Ralf Trepper Testing laboratory name TÜV NORD Hochfrequenztechnik GmbH & Co. KG Testing laboratory address LESKANPARK, Building 10 Waltherstr. 49-51, 51069 Cologne Germany Phone +49 221 8888950 Email [email protected] RELEVANT STANDARD Title 47 - Telecommunication Part 95 – Personal Radio Services Subpart Subpart M – 76 – 81 GHz Band Radar Service Measurement procedure ANSI C63.26-2015 EQUIPMENT UNDER TEST (EUT) Equipment category Transport and traffic telematics Trade name HEXAGON Type designation QR4000 Serial no. 96157301764 Variants --- Page 3 of 88 Test report no. 24013198_Rev.01 EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-08-20 V. 1.24 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Gebäude 10, Waltherstr. 49-51, 51069 Köln, Germany Tel.: +49 221 8888950 [email protected] Test result summary The following table summarizes the results for the tested EUT corresponding with the essential requirements. Full testing may not be required. If partial testing was performed, this shall be indicated in the relevant column (N.t. x , not tested, see clause 9) of the table below. Clause Rule Part Requirements headline Test result 7.1 § 15.203 Antenna requirement Pass Fail N.t.* 7.2 § 15.207 Conducted Limits Pass Fail N.t. 2 7.3 §95.3367 76 – 81 GHz Band Radar Service radiated power limits Pass Fail N.t.* 7.4 §95.3379 Radiated emission limits, general requirements Pass Fail N.t.* 7.5 §95.3379 Radiated emission limit above 40 GHz Pass Fail N.t.* 7.6 §95.3379 Occupied Bandwidth Pass Fail N.t.* 7.7 §95.3379 Frequency Tolerance Pass Fail N.t.* 7.8 §95.3385 76 – 81 GHz Band Radar Service RF exposure evaluation Pass Fail N.t.* * As far as in this report statements on conformity are made, decision rules according to DIN EN ISO/IEC 17025:2018, 7.8.6 have been applied. For more information see clause 9. The equipment passed all the performed tests ☒ Yes ☐ No Signature Name Mr. Anup Shrestha Mr. Ralf Trepper Designation RF Test engineer Laboratory Manager Date of issue 2024-07-31 2024-07-31 Page 4 of 88 Test report no. 24013198_Rev.01 EUT: QR4000 FCC ID: ZKS-QR4000 FCC Title 47 CFR Part 95 M Date of issue: 2024-08-20 V. 1.24 TÜV NORD Hochfrequenztechnik GmbH & Co. KG LESKANPARK, Gebäude 10, Waltherstr. 49-51, 51069 Köln, Germany Tel.: +49 221 8888950 [email protected] Table of contents 1 Revision History ........................................................................................................................... 6 2 Introduction .................................................................................................................................. 7 3 Administrative Data ...................................................................................................................... 8 3.1 Testing laboratory .................................................................................................................................. 8 3.2 Applicant ́s details .................................................................................................................................. 8 3.3 Manufacturer ́s details ..........................................................…

Text truncated - open the document above for the full version.
