ZM2-N701NetPad

TRULY Netpad Tablet PC N701 Series Manual Suitable for the following models: N701 N701E N701G N701EG N701T N701W N701TG N701WG Netpad N701 Series Manual Guide to safe and effective use For safe and effective use, please read carefully the following information before use.  When using the files in the T-Flash card, do not pull out the card so as to avoid damage to the memory card or the machine.  When using the headset, please make sure the headset volume is within the acceptable range to avoid damage to your hearing.  Always pay full attention during driving. Checking navigation system screen during driving may lead to serious traffic accident. In order to avoid accident, please pull over the car before operating the GPS system. The map data inside the GPS system may be different from actual road conditions, so it can only be used as a reference. Please use the system in compliance with actual traffic rules. The Company will not be held responsible for any traffic accident or other accident caused by the use of the system.  Do not let the machine and its accessories come into contact with liquid or moisture environment.  Do not place the machine in the environment with too high or too low temperature.  Do not place the machine aside the flame or lighted cigar or cigarette.  Do not paint or varnish the machine.  Do not drop or throw the machine.  Do not place the machine at where the temperature may exceed 60°C such as on the car dashboard, window sill or behind the glass exposed to direct sunlight etc.  Do not attempt to disassemble the machine, and do not repair the machine and accessories without authorization.  The charging voltage of the machine is 5.0V. Please confirm before use.  Do not use any charger not specified by the manufacturer of the machine, otherwise there will be potential danger.  Use only a damp or anti-static cloth to clean the machine. Do not use dry cloth or cloth with static to wipe the machine. - 1-  As the components such as LCD are breakable parts, please take good care and do not let the machine under impact or strong compression.  Do not let children play with the machine or its accessories. Children are likely to cause injury to themselves or others, and may inadvertently damage the machine or its accessories.  Do not freely uninstall the application in the system so as to avoid that the machine or part of the feature is not functional.  The adapter of this product should not be subjected to water splashing or water droplets, and items filled with liquid such as vase should not be placed on the adapter. - 2- Content - 3- 1. Before use............................................................ -4- 1.1 The appearance and various parts.......................................... -4- 1.2 Before use ..................................................................... -5- 1.2.1 Buttons .................................................................. -5- 1.2.2 Batteries ................................................................... -5- 1.2.3 MICRO SD card .......................................................... -5- 1.2.4 SIM or USIM card ....................................................... -5- 2. Main interface operation and setting ............................................. -7- 2.1 Main interface ............................................................... -8- 2.2 Task bar and task bar icon ...................................................... -9- 2.3 Setting ........................................................................ -10- 2.3.1 Wi-Fi connection ......................................................... -10- 2.3.2 3G network connection................................................... -12- 2.3.3 Sound and display ......................................................... -17- 2.3.4 Location and security ................................................... -18- 2.3.5 Application ............................................................... -18- 2.3.6 Account and synchronization .............................................. -19- 2.3.7 SD card and system memory ............................................. -20- 2.3.8 Language and keyboard ................................................ -20- 2.3.9 Date and events ............................................................ -20- 2.4.0 About the mobile multimedia .......................................... -21- 3. Electronic Market .................................................................. -22- 3.1 Login and use of the Electronic Market ................................. -22- 4. Browser ........................................................................... -25- 5. GPS and MAPS .................................................................. -26- 5.1 MAPS ........................................................................... -26- 5.2 GPS maps ..................................................................... -27- Appendix I: Technical Data ...................................................... -28- Appendix II: Technical Data ...................................................... -29- 1.2.5 Connecting the computers ............................................. -6- 10 1112 13 5 3 1 2 4 6 7 8 9 14 1.1 The appearance and various parts Figure 1.1 Appearance 1.Before use 1, 2: Speaker 3: Back button 4: Headphone jack 5: MENU button 6: Main interface button 7: On/Off button 8: HDMI port 9: MICRO SD card 10: Power charging port 11: USIM/SIM card port (suitable for models with 3G function) 12: USB port 13: Reset button 14: MIC - 4- 1.2Before use 1.2.1 Buttons On/Off button: in the shutdown mode, short press this button to perform power on operation; in the power on mode, short press this button to let the machine be in the sleep mode; long press this button to enter the mode switch dialogue interface, where you can select shutdown option to shut off the machine. Menu button: press this button to a pop-up menu of the program in the current interface. Back but…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Truly Industrial(Shanwei) Ltd. 2011.06.08 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ Truly Industrial(Shanwei) Ltd._________hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): NetPad N701WG We affirm that between SIEMIC and __ Truly Industrial(Shanwei) Ltd.___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title Yu hongshu / Engineer Contact information / address : 0660-3380901 [email protected] Truly Industrial Area, Shanwei City, Guangdong Province, People’s Republic of China.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 Truly Industrial(Shanwei) Ltd. 2011/6/8 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID:ZM2-N701 We hereby request confidential treatment of information accompanying this application as outlined below: - Black diagram - Operational Description - SCH - Part List - Tune up The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title Yu hongshu / Engineer Contact information / address : 0660-3380901 [email protected] Truly Industrial Area, Shanwei City, Guangdong Province, People’s Republic of China.

SIZE：60*18MM This device complies with part 15 of the FCC Rules Operation is subject to the following two conditions ; (1) This device may not cause harmful interference, and (2) Thisdevice must accept any interence received , Including interference that may cause undesired operation. FCC ID: ZM2-N701

Label location

0.5cm 0.5cm WWAN Antenna (RX/TX) GPS Antenna (RX) 2.7cm 13cm 5.5cm 6.3cm 0.8cm 1.6cm 3cm 12.9cm 10.5cm WLAN Antenna (RX/TX) HSPA Module WIFI Module

TRULY INDUSTRIAL (SHANWEI) LTD NETPAD Model: N701WG Aug 3rd 2011 Report No.: 1105013(FCC-SAR) Rev1.2 (This report supersedes 1105013(FCC-SAR) Rev1.1) This Test Report is Issued Under the Authority of: David Zhang Compliance Engineer Leslie Bai Director of Certification Modifications made to the product : None This test report may be reproduced in full only. All Test Data Presented in this report is only applicable to presented Test sample. Title: RF Test Report of Truly Industrial (Shanwei) Ltd Model : N701WG To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS-102 Issue 4 and Safety Code 6 Serial# 1105013(FCC-SAR) Rev1.2 Issue Date Aug 3rd 2011 Page 2 of 109 www.siemic.com Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China , Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom , SAR Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom , SAR Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety , SAR Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety, SAR Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC (RCB 208) RF , Telecom HongKong OFTA (US002) RF , Telecom Title: RF Test Report of Truly Industrial (Shanwei) Ltd Model : N701WG To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS-102 Issue 4 and Safety Code 6 Serial# 1105013(FCC-SAR) Rev1.2 Issue Date Aug 3rd 2011 Page 3 of 109 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Truly Industrial (Shanwei) Ltd Model : N701WG To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS-102 Issue 4 and Safety Code 6 Serial# 1105013(FCC-SAR) Rev1.2 Issue Date Aug 3rd 2011 Page 4 of 109 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION...............................................................................................................6 2 TECHNICAL DETAILS.....................................................................................................................................................7 3 INTRODUCTION..............................................................................................................................................................8 4 SAR MEASUREMENT SETUP.........................................................................................................................................9 5 ANSI/IEEE C95.1 – 1999 RF EXPOSURE LIMIT.............................................................................................................19 6 SYSTEM AND LIQUID VALIDATION..............................................................................................................................20 7 TYPE A MEASUREMENT UNCERTAINTY.....................................................................................................................27 8 OUTPUT POWER VERIFICATION..................................................................................................................................29 9 SAR TEST RESULTS....................................................................................................................................................33 ANNEX A. TEST INSTRUMENT & METHOD...........................................................................................................................61 ANNEX B EUT AND TEST SETUP PHOTOGRAPHS..............................................................................................................63 ANNEX C CALIBRATION REPORTS.....................................................................................................................................66 Title: RF Test Report of Truly Industrial (Shanwei) Ltd Model : N701WG To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS-102 Issue 4 and Safety Code 6 Serial# 1105013(FCC-SAR) Rev1.2 Issue Date Aug 3rd 2011 Page 5 of 109 www.siemic.com This page has been left blank intentionally. Title: RF Test Report of Truly Industrial (Shanwei) Ltd Model : N701WG To C95.1, IEEE 1528, OET Bulletin 65 Supplement C & RSS-102 Issue 4 and Safety Code 6 Serial# 1105013(FCC-SAR) Rev1.2 Issue Date Aug 3rd 2011 Page 6 of 109 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programmed was to demonstrate compliance of the Truly Industrial (Shanwei) Ltd Model: N701WG against the current Stipulated Standards. The NETPAD have demonstrated compliance with the C95.1 , IEEE 1528, OET Bulletin 65 Supplement C and Safety Code 6. The test has demonstrated that this unit complies with stipulated standards. EUT Information EUT Description : NETPAD Test Sample type : Product unit Model No : N701WG Serial No : N/A HW version : 2.1-update1 SW version : 2.6.29 Version number : 110303 Antenna Gain : 824 – 894 MHz : 0.5 dBi 1850-2170MHz : 0.8 dBi 2412-2480MHz : 0.8 dBi Input Power : 5VDC, 2A Maximum Conducted Output Power to Antenna GPRS1900(Power Class 1) : 28.28 dBm EGPRS1900(Power Class E2) : 25.08 dBm WCDMA Band V(Power Class 3) : 22.37 dBm HSDPA Band…

Text truncated - open the document above for the full version.

TRULYINDUSTRIAL(SHANWEI)LTD NETPAD Model:N701WG May31st2011 ReportNo.:1105013(FCC_PCE) (ThisreportsupersedesNONE) ThisTestReportisIssuedUndertheAuthorityof: DavidZhang ComplianceEngineer LeslieBai DirectorofCertification Modificationsmadetotheproduct:None Thistestreportmaybereproducedinfullonly. AllTestDataPresentedinthisreportisonlyapplicabletopresentedTestsample. Title:RF Test Report ofTrulyIndustrial(Shanwei)Ltd Model :N701WG ToFCC22(H):2010& FCC24(E):2010 & Serial#1105013(FCC_PCE) Issue DateMay31st2011 Page2 of103 www.siemic.com Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US andAsia, is one of the leading independent testing and certification facilities providingcustomers withone-stop shop servicesfor Compliance Testing and Global Certifications. In addition totestingandcertification, SIEMICprovides initial design reviews andcompliance managementthrough out a project. Our extensive experience withChina, Asia Pacific, North America, European, and internationalcompliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for theglobal markets. Accreditations for Conformity Assessment Country/RegionAccreditation BodyScope USAFCC, A2LAEMC , RF/Wireless, Telecom CanadaIC, A2LA,NISTEMC,RF/Wireless, Telecom TaiwanBSMI , NCC , NISTEMC, RF, Telecom , Safety Hong KongOFTA , NISTRF/Wireless,Telecom AustraliaNATA, NISTEMC, RF, Telecom , Safety KoreaKCC/RRA, NISTEMI, EMS, RF , Telecom, Safety JapanVCCI, JATE, TELEC,RFTEMI,RF/Wireless, Telecom MexicoNOM, COFETEL,CanietySafety,EMC , RF/Wireless, Telecom EuropeA2LA, NISTEMC, RF, Telecom , Safety Accreditations for Product Certifications CountryAccreditation BodyScope USAFCCTCB, NISTEMC , RF , Telecom CanadaICFCB, NISTEMC , RF , Telecom SingaporeiDA, NISTEMC , RF , Telecom EUNB, NISTEMC,RF,Safety,Telecom Title:RF Test Report ofTrulyIndustrial(Shanwei)Ltd Model :N701WG ToFCC22(H):2010& FCC24(E):2010 & Serial#1105013(FCC_PCE) Issue DateMay31st2011 Page3 of103 www.siemic.com This page has been left blank intentionally. Title:RF Test Report ofTrulyIndustrial(Shanwei)Ltd Model :N701WG ToFCC22(H):2010& FCC24(E):2010 & Serial#1105013(FCC_PCE) Issue DateMay31st2011 Page4 of103 www.siemic.com CONTENTS 1EXECUTIVE SUMMARY &EUT INFORMATION............................................................................................................6 2TECHNICAL DETAILS..................................................................................................................................................7 3MODIFICATION...........................................................................................................................................................8 4TEST SUMMARY.........................................................................................................................................................9 5MEASUREMENTS, EXAMINATION AND DERIVED RESULTS.....................................................................................10 ANNEX A. TEST INSTRUMENT & METHOD.........................................................................................................................78 ANNEX B EUT AND TEST SETUP PHOTOGRAPHS...........................................................................................................82 ANNEX C. TEST SETUPAND SUPPORTING EQUIPMENT................................................................................................... 82 ANNEX DUSER MANUAL, BLOCK DIAGRAM,CIRCUIT DIAGRAM..................................................................................85 Title:RF Test Report ofTrulyIndustrial(Shanwei)Ltd Model :N701WG ToFCC22(H):2010& FCC24(E):2010 & Serial#1105013(FCC_PCE) Issue DateMay31st2011 Page5 of103 www.siemic.com This page has been left blank intentionally. Title:RF Test Report ofTrulyIndustrial(Shanwei)Ltd Model :N701WG ToFCC22(H):2010& FCC24(E):2010 & Serial#1105013(FCC_PCE) Issue DateMay31st2011 Page6 of103 www.siemic.com 1Executive Summary & EUT information The purpose of this testprogrammedwas to demonstrate compliance of theTrulyIndustrial(Shanwei)LtdModel: N701WGagainst the current Stipulated Standards.TheNetpadhave demonstrated compliance with theFCC 22(H):2010, FCC24(E):2010. The test has demonstrated that this unit complies with stipulated standards. EUT Information EUT Description : Netpad Model No : N701WG Serial No : N/A HW version: 2.1-update1 SW version: 2.6.29 Version number: 110303 Input Power : 5VDC, 2A Antenna Gain : 824– 894 MHz : 0.5 dBi 1850-2170MHz : 0.8 dBi 2412-2480MHz :0.8 dBi Maximum Conducted Output Power to Antenna GPRS1900(Class 1): 28.28 dBm EGPRS1900(Class E2): 25.08 dBm WCDMA Band V(Class 3): 22.37dBm HSDPA Band V(Class 3): 22.06 dBm HSUPA Band V(Class 3): 22.16 dBm WCDMA Band II(Class 3): 22.42 dBm HSDPA Band II(Class 3): 21.41 dBm HSUPA Band II(Class 3): 21.67 dBm Maximum Radiated ERP/EIRP GPRS1900 (Class 1): 0.81 W (29.08dBm)/ EIRP EGPRS1900 (Class E2): 0.39 W(25.88dBm)/ EIRP WCDMA Band V(Class 3): 0.19 W (22.87dBm) / ERP HSDPA Band V(Class 3): 0.18 W (22.56 dBm) /ERP HSUPA Band V(Class 3): 0.18 W (22.66 dBm)/ERP WCDMABand II(Class 3): 0.21W (23.22dBm)/ EIRP HSDPA Band II(Class 3): 0.17 W (22.21 dBm)/EIRP HSUPA Band II(Class 3): 0.18 W (22.47 dBm)/EIRP Classification Per Stipulated Test Standard : MobileDevice/ PCE Title:RF Test Report ofTrulyIndustrial(Shanwei)Ltd Model :N701WG ToFCC22(H):2010& FCC24(E):2010 & Serial#1105013(FCC_PCE) Issue DateMay31st2011 Page7 of103 www.siemic.com 2TECHNICAL DETAILS Purpose Compliance testing ofNetpadmodelN701WGwith stipulated standard Applicant / Client TrulyIndustrial(Shanwei)Ltd Manufacturer TrulyIndustrial(Shanwei)Ltd TrulyIndustrialArea,ShanweiCity GuangdongProvince,PRC Laboratory performing the testsSIEMIC Laboratories Test report reference number1105013(FCC_PCE) Date EUT receivedApr 10th 2011 Standard applied See Page9 Dates of test (from– to)Apr 10th-May 31st 2011 No of Units:1 Equip…

Text truncated - open the document above for the full version.

Radiated Emission Front View (30MHz-1GHz) Radiated EmissionRear View (30Mhz-1GHz) Radiated EmissionFrontView (>1GHz) Radiated EmissionRearView (>1GHz)
