Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Part 15 Class B Compliance This device and its accessories comply with part 15 of FCC rules and ICES-003 Class B digital apparatus requirements for Industry Canada. Operation is subject to the following two conditions:(1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept cm (0.9 inches) between the user’s body and the back of the phone. To comply with FCC RF exposure requirements, a minimum separation distance of cm (0.9 inches) must be maintained between the user's body and the back of the phone. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain cm (0.9 inches) separation distance between the user's body and the back of the phone, and have not been tested for typical body- worn operations may not comply with FCC RF exposure limits and should be avoided. Conformité aux normes FCC Part 15 Class B Cet appareil et ses accessoires sont conformes aux normes FCC Part 15 Class B de la Federal Communications Commission et aux exigences pour appareils numériques ICES-003 Class B d’Industrie Canada.Son fonctionnement est sujet aux deux conditions suivantes :(1) Cet appareil et ses accessoires ne doivent pas provoquer de brouillage préjudiciable, et (2) cet appareil et ses accessoires doivent accepter toutes les interférences reçues, y compris celles pouvant causer un fonctionnement indésirable. Utilisation comme appareil portatif Ce téléphone a été testé en vue d’une utilisation type comme appareil portatif, avec une distance de cm (0,9 pouces) entre l’arrière de l’appareil et le corps de l’utilisateur. Pour satisfaire aux exigences de la FCC en matière d’exposition aux radiofréquences, une distance d’au moins cm (0,9 pouces) doit être maintenue entre le corps de l’utilisateur et l’arrière du téléphone. Les pinces de ceinture, les étuis et autres accessoires semblables d’autres marques et contenant des composantes métalliques ne doivent pas être utilisés.Les accessoires portatifs empêchant le maintien d’une distance de cm (0,9 pouces) entre le corps de l’utilisateur et l’arrière du téléphone et qui n’ont pas été testés en vue d’une utilisation type comme accessoires portatifs peuvent ne pas satisfaire aux limites d’exposition aux radiofréquences stipulées par la FCC et, par conséquent, ne doivent pas être utilisés. Games Your LG-A270 comes with preloaded games to keep you amused when you have time to spare. Press Menu and select Games. FM radio (Wireless FM) With embedded FM antenna, you can receive FM radio without an external earphone. You can listen to your favourite radio station anytime. Note: In weak FM radio signal area the sensitivity can degrade with wireless and antenna mode. So it is advisable to insert the ear-mic for better and enhanced FM quality. Listening to the radio 1 Press Menu and select FM radio. 2 Select the channel number of the station you would like to listen to. Note: You can listen to the radio via built-in speaker. Press Options, select Listen via and choose Speaker when ear-mic is inserted. 123 mode Type numbers using one keystroke per number. You can also add numbers while remaining in letter modes by pressing and holding the desired key. Contacts You can search for a contact in your Contacts. 1 Press Contacts and choose Search, select Contacts from the Menu screen or press (right soft key) from the standby screen. 2 On the keypad enter the first letter of the contact you want to call. 3 To scroll through the contacts, use the up and down navigation keys. To scroll through their different numbers use the left and right navigation keys. • New contact – You can add phonebook entries by using this menu. • Speed dials – Assign contacts to any keys between 2 and 9. • Copy all – You can copy all entries from the SIM card memory to the Phone memory or from the Phone memory to the SIM card memory. • Delete all – You can delete all entries from the SIM card memory or Phone memory. • Memory status – You can check the memory status for your SIM and phone. • Information › Service dial number – Access the list of service numbers assigned by your service provider securely. › Own number – You can save and check your own numbers on the SIM card. › Business card – You can save and check your business card containing information including your name, mobile phone, home, office and email, and send it in a message. Call history You can check the record of all, missed, dialled, received calls and call durati…
Text truncated - open the document above for the full version.
!"# Date: January 16, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Ro ad, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ZNFA270 Equipment Class:%&% ' ( ) To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, MobileComm hereby requests confidentiality and t reatment of certain information acc ompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for * days after the grant as outlined in Public Notice DA 04-1705. This provision will give MobileComm temporary confidentiality of commercially sensitive i nformation prior to pro duct release. The requested Permanent and Temporary Confidential exhibits are listed as follows: %+,'-./+'0'+,/12-'22' 3) 4 - 5 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure %+,' 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos ./+'0'+, 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Christopher Johnson Senior Manager On behalf of LG Elect ronics MobileComm U.S.A, Inc. LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632
External photos of EUT Front view of EUT Rear view of EUT Top view of EUT Bottom view of EUT
Internal photos of EUT Internal view Top view of main board Top view of main board (Bottom of LCD module) Bottom view of main board Bottom view of main board (Removing Shield) GSM850/1900 Antenna FM Radio receiver Antenna
Report File No. : F690501/RF-SAR001974 Date of Issue : 2012-01-18 Page : 2 / 90 Contents 1. General Information 1.1 Testing Laboratory........................................................................................... 3 1.2 Details of Applicant.......................................................................................... 3 1.3 Version of Report............................................................................................. 3 1.4 Description of EUT(s)....................................................................................... 3 1.5 Operation description........................................................................................ 4 1.6 Evaluation procedures....................................................................................... 4 1.7 The SAR Measurement System............................................................................ 5 1.8 System Components.......................................................................................... 7 1.9 SAR System Verification.................................................................................... 8 1.10 Tissue Simulant Fluid for the Frequency Band.......................................................... 11 1.11 Test Standards and Limits.................................................................................. 12 1.12 Justification for Extended SAR Dipole Calibrations................................................... 14 2. Instruments List.................................................................................... 15 3. Summary of Results................................................................................ 16 3.1 FCC Power Measurement Procedures..................................................................... 16 3.2 RF Conducted Power ....................................................................................... 16 3.3 SAR Data Summary.......................................................................................... 17 APPENDIX A. DASY4 SAR Report B. Uncertainty Analysis C. Calibration certificate Report File No. : F690501/RF-SAR001974 Date of Issue : 2012-01-18 Page : 3 / 90 1. General Information 1.1 Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, 435-040, Korea Telephone : 82-31-428-5700 FAX : 82-31-427-2371 Homepage : www.kr.sgs.com/ee 1.2 Details of Manufacturer Manufacturer : LG Electronics MobileComm U.S.A., Inc. Address : 10101 Old Grove Road, San Diego, CA 92131 Contact Person : Sang-myung Lee Telephone : 82-2-2033-1222 E-mail : [email protected] 1.3 Version of Report Version Number Date Revision 00 2012-01-18 Initial issue 1.4 Description of EUT(s) EUT Type : Cellular/PCS GSM Phone Model : LG-A270 Serial Number : 112KPWQ110009 Mode of Operation : GSM850, PCS1900 Duty Cycle : 8(GSM) Body worn Accessory : Ear Headset Tx Frequency Range : 824.2 ~ 848.8 (GSM850) 1850.2 ~ 1909.8 (PCS1900) Battery Type : 3.7 V d.c. (Lithum-ion Battery) Report File No. : F690501/RF-SAR001974 Date of Issue : 2012-01-18 Page : 4 / 90 1.5 Operation Configuration The device in GSM mode was controlled by using a Communication tester (CMU 200). Communication between the device and the tester was established by air link. And the client provided a special driver and test program which can control the frequency and power of the WLAN module. Measurements were performed at the lowest, middle and highest channels of the operating band. The EUT was set to maximum power level during all tests and at the beginning of each test the battery was fully charged. The DASY4 system measures power drift during SAR testing by comparing e-field in the same location at the beginning and at the end of measurement. Based on the RF Power and antenna separation distance, stand-alone BT SAR and simultaneous SAR evaluation are not required. 1.6 EVALUATION PROCEDURES - Power Reference Measurement Procedures The Power Reference Measurement and Power Drift Measurements are for monitoring the power drift of the device under test in the batch process. The Minimum distance of probe sensors to surface determines the closest measurement point to phantom surface. The minimum distance of probe sensors to surface is 4 . This distance cannot be smaller than the Distance of sensor calibration points to probe tip as defined in the probe properties (for example, 2.7 for an ET3DV6 probe type). - The entire evaluation of the spatial peak values is performed within the Post-processing engine (SEMCAD). The system always gives the maximum values for the 1 g and 10 g cubes. The algorithm to find the cube with highest averaged SAR is divided into the following stages: 1. The extraction of the measured data (grid and values) from the Zoom Scan. 2. The calculation of the SAR value at every measurement point based on all stored data (A/D values and measurement parameters) 3. The generation of a high-resolution mesh within the measured volume 4. The interpolation of all measured values from the measurement grid to the high-resolution grid 5. The extrapolation of the entire 3-D field distribution to the phantom surface over the distance from sensor to surface 6. The calculation of the averaged SAR within masses of 1 g and 10 g. The probe is calibrated at the center of the dipole sensors that is located 1 to 2.7 away from the probe tip. During measurements, the probe stops shortly above the phantom surface, depending on the probe and the surface detecting system. Both distances are included as parameters in the probe configuration file. The software always knows exactly how far away the measured point is from the surface. As the probe cannot directly measure at the surface, the values between the deepest measured point and the surface must be extrapolated. The Report File No. : F690501/RF-SAR001974 Date of Issue : 2012-01-18 Page : 5 / 90 angle between the probe axis and the surface normal line is less than 30 degree. In the Area S…
Text truncated - open the document above for the full version.
Report Number: F690501/RF-RTL005266 Page: 2 of 29 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee INDEX TABLE OF CONTENTS Page 1. General Information ---------------------------------------------------------------------------------------3 2. RF radiated output power & spurious radiated emission ----------------------------------------7 3. Conducted Output Power ------------------------------------------------------------------------------- 13 4. Occupied Bandwidth 99 % ------------------------------------------------------------------------------14 5. Spurious Emissions At Antenna Terminal----------------------------------------------------------- 19 6. Band Edge --------------------------------------------------------------------------------------------------24 7. Frequency Stability --------------------------------------------------------------------------------------- 27 Report Number: F690501/RF-RTL005266 Page: 3 of 29 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1. General information 1.1. Testing laboratory SGS Korea Co., Ltd.(Gunpo Laboratory) - 705, Dongchun-Dong Sooji-Gu, Yongin-Shi, Kyungki-Do, South Korea. - Wireless Div. 2FL, 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea 435-040 www.kr.sgs.com/ee Telephone : +82 +31 428 5700 FAX : +82 +31 427 2371 1.2. Details of applicant Applicant : LG Electronics mobileComm U.S.A.,Inc. Address : 10101 Old Grove Road, San Diego, CA 92131 Contact Person : Lee, Sang-Myung Phone No. : +82 +2 2033 1222 1.3. Description of EUT Kind of Product Cellular/PCS GSM Phone Model Name LG-A270(Add :A270, LGA270) Serial Number N/A Power Supply DC 3.7 V (Li-Ion Battery) Rated Power GSM850 : 33.2 dBm GSM1900 : 30.7 dBm Frequency Range GSM850: 824.2 ㎒ ~ 848.8 ㎒ GSM1900: 1 850.2 ㎒ ~ 1 909.8 ㎒ Emission Designator 246KGXW (GSM850), 247KGXW (GSM1900) Report Number: F690501/RF-RTL005266 Page: 4 of 29 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1.4. Description of test mode Band Frequency (MHz) Voice GSM (dBm) GSM 850 824.2 33.1 836.6 33.1 848.8 33.2 GSM 1900 1 850.2 30.2 1 880.0 30.5 1 909.8 30.6 Report Number: F690501/RF-RTL005266 Page: 5 of 29 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1.5. Test equipment list Equipment Manufacturer Model S/N Cal Due. Signal Generator R&S SMBV100A 255384 Jul. 20, 2012 Signal Generator R&S SMR40 100272 Jul. 15, 2012 Spectrum Analyzer R&S FSV30 100768 Mar. 31, 2012 Mobile Test Unit R&S CMU200 106190 May. 30, 2012 Directional Coupler KRYTAR 152613 122661 May. 16, 2012 High Pass Filter Wainwright WHK3.0/18G-10SS 344 Jul. 07, 2012 Band Reject Filter Wainwright WRCG824/849-814/85 960/10SS 7 Apr. 01, 2012 DC power Supply Agilent U8002A MY50060028 Apr. 01, 2012 Preamplifier H.P. 8447F 2944A03909 Jul. 04, 2012 Preamplifier R&S SCU 18 10117 Mar. 23, 2012 Preamplifier SCHWARZBECK MESSELEKTRONIK JS44-18004000-35-8P1546891 Jul. 04, 2012 Test Receiver R&S ESU26 100109 Feb. 21, 2012 Bilog Antenna SCHWARZBECK MESSELEKTRONIK VULB9163 396 Apr. 27, 2013 Horn Antenna R&S HF 906 100326 Oct. 08, 2012 Horn Antenna SCHWARZBECK MESSELEKTRONIK BBHA 9170 BBHA9170431 Mar. 17, 2012 Dipole Antenna SCHWARZBECK MESSELEKTRONIK VHA 9103/UHA 9105 9103-2817 9105-2514 May. 14, 2013 Antenna Master INN-CO MM4000 N.C.R. N.C.R. Turn Table INN-CO DS 1200 S N.C.R. N.C.R. Anechoic Chamber SY Corporation L × W × H (9.6 m × 6.4 m × 6.6 m) N.C.R. N.C.R. Report Number: F690501/RF-RTL005266 Page: 6 of 29 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040 Tel. +82 31 428 5700 / Fax. +82 31 427 2371 www.kr.sgs.com/ee 1.6. Summary of test results The EUT has been tested according to the following specifications: APPLIED STANDARD : FCC Part 22, 24 Section in FCC part Test Item Result §2.1046 §22.913(a) §24.232(b) RF Radiated Output Power Complied §2.1053 §22.917(a) §24.238(a) Spurious Radiated Emission Complied §2.1046(a) Conducted Output Power Complied §2.1049(h) (i) Occupied Bandwidth Complied §2.1051 §22.917(a) §24.238(a) Spurious Emission at Antenna Terminal Complied §2.1055 §22.355 §24.235 Frequency Stability Complied §22.917(a) §24.238(a) Band Edge Complied 1.7. Test report revision Revision Report number Description 0 F690501/RF-RTL005266 Initial Report Number: F690501/RF-RTL005266 Page: 7 of 29 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Korea Co., Ltd. (Gunpo Laboratory) 18-34, Sanbon-dong, Gunpo-si, Gyeonggi-do, Korea, 435-040…
Text truncated - open the document above for the full version.
EUT Photo Figure 1 DUT Photo Figure 2 DUT Photo EUT Photo Figure 3 DUT Photo Test Setup Photographs Right Ear Cheek Right Ear Tilt Left Ear Cheek Left Ear Tilt Body_Front (1.5 cm) Body_Back (1.5 cm)
Test setup photos of EUT Photo of Radiated output power & Spurious Emission Test
6660-B Dobbin Road · Columbia, Maryland · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 2 | 24E | 1.85 GHz - 1.91 GHz | 420.00 mW | 247KGXW | 2.5 ppm |

Bluetooth Earbuds
Equipment Class
DTS - Digital Transmission System
Bluetooth Earbud (Cradle)
Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
Bluetooth Earbud
Equipment Class
DTS - Digital Transmission System
Portable Handset
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Portable Handset
Equipment Class
NII - Unlicensed National Information Infrastructure TX
