ZNFC800GCellular/PCS GSM/WCDMA/EDGE Phone with WLAN and Bluetooth

User Guide LG-C800G www.lg.com E N G L I S H Congratulations on your purchase of the advanced and compact LG-C800G phone by LG, designed to operate with the latest digital mobile communication technology. Some of the contents in this manual may differ from your phone depending on the software of the phone or your service provider. • This handset is not recommended for the visually impaired because of its touch-screen keypad. • Copyright ©2011 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners. • Google™, Google Maps™, Gmail™, YouTube™, Google Talk™ and Android Market™ are trademarks of Google, Inc. Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules and ICES-003 Class B digital apparatus requirements for Industry Canada. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.39inches (1.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.39inches(1.0cm) must be maintained from the user's body. For example, this device must be maintained from the user's body with an appropriatebelt-clip accessory. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. 48 Utilisation comme appareil portatif Ce téléphone a été testé en vue d'une utilisation type comme appareil portatif, avec une distance de 1 cm (0.39 pouces) entre l'arrière de l'appareil et le corps de l'utilisateur. Pour satisfaire aux exigences de la FCC en matière d'exposition aux radiofréquences, on doit maintenir une distance d'au moins 1 cm (0.39 pouces) entre le corps de l'utilisateur et l'arrière du téléphone. Les pinces de ceinture, les étuis et autres accessoires semblables d'autres marques et contenant des composantes métalliques ne doivent pas être utilisés. Les accessoires portatifs qui empêchent le maintien d'une distance de 1 cm (0.39 pouces) entre le corps de l'utilisateur et l'arrière du téléphone et qui n'ont pas été testés en vue d'une utilisation type comme accessoires portatifs peuvent ne pas satisfaire aux limites d'exposition aux radiofréquences stipulées par la FCC et, par conséquent, ne doivent pas être utilisés. Co FC Cet son Par Co et a num d’ I So aux (1) acc pro pré et s acc reç cau ind Sécurité 49 e Conformité aux normes FCC Part 15 Class B Cet appareil et ses accessoires sont conformes aux normes FCC Part 15 Class B de la Federal Communications Commission et aux exigences pour appareils numériques ICES-003 Class B d’ Industrie Canada. Son fonctionnement est sujet aux deux conditions suivantes : (1) Cet appareil et ses accessoires ne doivent pas provoquer de brouillage préjudiciable, et (2) cet appareil et ses accessoires doivent accepter toutes les interférences reçues, y compris celles pouvant causer un fonctionnement indésirable. LG-C800G | User Guide To turn on the phone, press and hold the Power/Lock Key for three seconds. To turn off the phone, press the Power/Lock Key for three seconds and touch Power off. Then touch OK to confirm. Home Key Return to the Home screen from any screen. Menu Key Check what options are available. Earpiece Back Key Return to the previous screen. Genius Key Power/Lock Key Switch your phone on/off by pressing and holding this key. It also locks and unlocks the screen. Proximity Sensor NOTE: Proximity Sensor When receiving and making calls, the proximity sensor automatically turns the backlight off and locks the touch keypad by sensing when the phone is near your ear. This extends battery life and prevents the touch keypad from activating unintentionally during calls. WARNING: Placing a heavy object on the phone or sitting on it can damage its LCD and touch screen functions. Do not cover the LCD‘s proximity sensor with protective film. This may cause the sensor to malfunction. Getting to know your phone Slide Open View Text Msg Space : Press to enter a space between words. Sym : Press to open the Symbol menu. Del : Deletes digits and letters. LG-C800G | User Guide Back Cover Volume Keys • On the Home screen: Controls the ringer volume. • During a call: Controls your earpiece volume. • When playing a song: Controls volume continuously. Battery microSD Card Slot. Back-facing Camera Lens Flash Power/Lock Key Charger/ USB Port Speaker Microphone Earphone Jack Installing the SIM card and bat…

Text truncated - open the document above for the full version.

          !"# Date: September 19#1 Federal Communications Commission Authorization and Evaluation Division 7435 Oakl and Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ZNFC800G Equipment Class:%&%  '  (  )  To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act,  MobileComm hereby requests confidentiality and treatment of certain informat ion accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for * days after the grant as outlined in Public Notice DA 04-1705. This provision will give  MobileComm temporary confidentiality of commercially sensitive i nformation prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: %+,'-./+'0'+,/12-'22' 3) 4 - 5  1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure %+,' 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos ./+'0'+, 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Christopher Johnson Senior Manager LG Electronics MobileComm US A LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G External Photos EUT Type: Portable Handset Page 1 of 5 © 2011 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G External Photos EUT Type: Portable Handset Page 2 of 5 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G External Photos EUT Type: Portable Handset Page 3 of 5 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G External Photos EUT Type: Portable Handset Page 4 of 5 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G External Photos EUT Type: Portable Handset Page 5 of 5 © 2011 PCTEST Engineering Laboratory Inc.

Model No: C800G FCC ID : ZNFC800G S/N : Made in Korea LG Electronics MobileComm U.S.A Inc. LGE

LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 1 of 15 © 2011 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 2 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 3 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 4 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 5 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 6 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 7 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 8 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 9 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 10 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 11 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 12 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 13 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 14 of 15 © 2011 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFC800G Model: C800G Internal Photos EUT Type: Portable Handset Page 15 of 15 © 2011 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Technical Report SN: Test Dates: DUT Type / Apparatus / Device: 0Y1109191668.ZNF 09/23/11 - 09/30/11 Portable Handset Page 1 of 44 © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 Applicant Name: Date of Testing: LG Electronics MobileComm U.S.A., Inc. 09/23/11 - 09/30/11 10101 Old Grove Road, Test Site/Location: San Diego, CA 92131 PCTEST Lab, Columbia, MD, USA USA Technical Report Serial No.: 0Y1109191668.ZNF FCC ID: IC CERTIFICATION NO.: ZNFC800G 2703C-C800G APPLICANT: LG ELECTRONICS MOBILECOMM U.S.A., INC. DUT Type / Apparatus / Device: Portable Handset Application Type: Certification FCC Rule Part(s): IC Specification(s): Applicable Standard(s): Radio Equipment Type: FCC Model(s): IC Model(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [June 2001] RSS-102 Issue 4; Health Canada Safety Code 6 IEC 62209-1, IEC 62209-2, IEEE 1528-2003 Cellular Communications Apparatus C800G, LG-C800G, C800g, LG-C800g, LGC800G, LGC800g C800G, LG-C800G, C800g, LG-C800g, LGC800G, LGC800g Test Device Serial No.: Pre-Production [S/N: 108KPWQ072105, 108KPFX072107] 1 gm Head (W/kg) 1 gm Body-Worn (W/kg) 1 gm Hotspot (W/kg) GSM/GPRS/EDGE 850824.20 - 848.80 MHz32.940.420.991.19 WCDMA/HSPA 850826.40 - 846.60 MHz22.890.290.870.87 GSM/GPRS/EDGE 19001850.20 - 1909.80 MHz30.220.150.280.42 WCDMA/HSPA 19001852.4 - 1907.6 MHz23.000.450.860.86 2.4 GHz WLAN2412 - 2462 MHz16.310.610.310.31 Bluetooth2402 - 2480 MHz11.62 Conducted Power [dBm] N/A 1.50 W/kg Simultaneous SAR per KDB 690783 DR01 SAR Band & ModeTx Frequency Note: Powers in the above table represent output powers for the SAR test configurations applicable and may not represent the highest output powers for all capabilities. All models are electrically identical per the manufacturer. This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com SAR COMPLIANCE EVALUATION REPORT FCC CFR §2.1093 / INDUSTRY CANADA RSS-102 Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Technical Report SN: Test Dates: DUT Type / Apparatus / Device: 0Y1109191668.ZNF 09/23/11 - 09/30/11 Portable Handset Page 2 of 44 © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 TABLE OF CONTENTS 1 INTRODUCTION ............................................................................................................................. 3 2 TEST SITE LOCATION ................................................................................................................... 4 3 SAR MEASUREMENT SETUP ....................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM .................................................................................................. 7 5 PROBE CALIBRATION PROCESS ................................................................................................ 8 6 PHANTOM AND EQUIVALENT TISSUES...................................................................................... 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................... 10 8 DEFINITION OF REFERENCE POINTS ...................................................................................... 11 9 TEST CONFIGURATION POSITIONS ......................................................................................... 12 10 FCC AND HEALTH CANADA SAFETY CODE 6 RF EXPOSURE LIMITS .................................. 15 11 FCC 3G MEASUREMENT PROCEDURES .................................................................................. 16 12 SAR TESTING WITH FCC RULE PART 15 TRANSMITTERS .................................................... 20 13 FCC PERSONAL WIRELESS ROUTER CONFIGURATIONS ..................................................... 23 14 SYSTEM VERIFICATION.............................................................................................................. 25 15 SAR DATA SUMMARY ................................................................................................................. 27 16 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS......................................................... 37 17 EQUIPMENT LIST......................................................................................................................... 40 18 MEASUREMENT UNCERTAINTIES ............................................................................................ 41 19 CONCLUSION............................................................................................................................... 42 20 REFERENCES ..........................................................................................................................…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: ZNFC800G FCC Pt. 22/24 GSM/EDGE/WCDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1109191669.ZNF October 03 - 07, 2011 Portable Handset Page 1 of 58 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.4GWCFI 09/15/2011 Applicant Name: Date of Testing: LG Electronics MobileComm U.S.A., Inc. October 03 - 07, 2011 10101 Old Grove Road, Test Site/Location: San Diego, CA 92131 PCTEST Lab., Columbia, MD, USA USA Test Report Serial No.: 0Y1109191669.ZNF FCC ID: ZNFC800G IC CERTIFICATION NO.: 2703C-C800G APPLICANT: LG ELECTRONICS MOBILECOMM U.S.A., INC. Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §22(H), §24(E) IC Specification(s): RSS-132 Issue 2; RSS-133 Issue 5 EUT Type: Portable Handset Model(s): C800G, LG-C800G, C800g, LG-C800g, LGC800G, LGC800g Test Device Serial No.: identical prototype [S/N: 108KPBF072109] Max. Power (W) Max. Power (dBm) GSM850824.2 - 848.8245KGXW1.44531.60 EDGE850824.2 - 848.8246KG7W0.31624.99 GSM19001850.2 - 1909.8248KGXW0.79929.03 EDGE19001850.2 - 1909.8246KG7W0.31925.04 WCDMA850826.4 - 846.64M14F9W0.20523.11 WCDMA19001852.4 - 1907.64M16F9W0.27024.32 ERP/EIRP Mode Tx Frequency (MHz) Emission Designator This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC Part 22 & 24 / IC RSS-132/RSS-133 Reviewed by: FCC ID: ZNFC800G FCC Pt. 22/24 GSM/EDGE/WCDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1109191669.ZNF October 03 - 07, 2011 Portable Handset Page 2 of 58 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.4GWCFI 09/15/2011 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT............................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 DEVICE CAPABILITIES....................................................................................................................... 5 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.4 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 MEASUREMENT PROCEDURE......................................................................................................... 6 3.2 OCCUPIED BANDWIDTH ................................................................................................................... 6 3.3 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.4 CELLULAR - MOBILE FREQUENCY BLOCKS................................................................................... 7 3.5 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.6 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.7 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.8 RADIATED POWER AND RADIATED SPURIOUS EMISSIONS ........................................................ 8 3.9 PEAK-AVERAGE RATIO ..................................................................................................................... 8 3.10 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 EFFECTIVE RADIATED POWER OUTPUT DATA ........................................................................... 12 6.3 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA .................................................... 1…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Test Dates:DUT Type / Apparatus / Device: 09/23/11 - 09/30/11 Portable Handset Page i of vii © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 APPENDIX D: SAR TEST SETUP PHOTOGRAPHS Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Test Dates:DUT Type / Apparatus / Device: 09/23/11 - 09/30/11 Portable Handset Page ii of vii © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 SAR Test Setup Photo 1 – Right Touch SAR Test Setup Photo 2 – Right Tilt Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Test Dates:DUT Type / Apparatus / Device: 09/23/11 - 09/30/11 Portable Handset Page iii of vii © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 SAR Test Setup Photo 3 – Left Touch SAR Test Setup Photo 4 – Left Tilt Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Test Dates:DUT Type / Apparatus / Device: 09/23/11 - 09/30/11 Portable Handset Page iv of vii © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 SAR Test Setup Photo 5 – Back at 1.0 cm SAR Test Setup Photo 6 – Front at 1.0 cm Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Test Dates:DUT Type / Apparatus / Device: 09/23/11 - 09/30/11 Portable Handset Page v of vii © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 SAR Test Setup Photo 7 – Top at 1.0 cm SAR Test Setup Photo 8 – Bottom at 1.0 cm Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Test Dates:DUT Type / Apparatus / Device: 09/23/11 - 09/30/11 Portable Handset Page vi of vii © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 SAR Test Setup Photo 9 –Right at 1.0 cm SAR Test Setup Photo 10 - Left at 1.0 cm Reviewed by: FCC ID: ZNFC800G IC Cert No.: 2703C-C800G SAR COMPLIANCE REPORT INDUSTRY CANADA TECHNICAL REPORT (RSS-102) Quality Manager Test Dates:DUT Type / Apparatus / Device: 09/23/11 - 09/30/11 Portable Handset Page vii of vii © 2011 PCTEST Engineering Laboratory, Inc. REV 9.4M 09/08/2011 SAR Test Setup Photo 11 – Body Worn Back at 1.0 cm Note: Headset Cable is connected to the device during Body Worn SAR assessment, as seen above.

LG ELECTRONICS MOBILECOMM U.S.A., INC. FCC ID: ZNFC800G Model: C800G Test Set-Up Photos EUT Type: Portable Handset Page 1 of 2 © 2011 PCTEST Engineering Laboratory Inc. TEST SETUP PHOTOGRAPHS LG ELECTRONICS MOBILECOMM U.S.A., INC. FCC ID: ZNFC800G Model: C800G Test Set-Up Photos EUT Type: Portable Handset Page 2 of 2 © 2011 PCTEST Engineering Laboratory Inc.
