Please read the Important Safety Information for the proper use of this product. After reading, store this User Manual in an easily accessible place for all users. NOTE: Please read all information carefully prior to using the headset in order to enjoy the best performance and prevent damage to the product. Rev 1.0 US www.lg.com Copyright © 2020 LG Electronics Inc. All rights reserved. Copyright © 2020 LG Electronics Inc. Todos los derechos reservados. USER MANUAL / MANUAL DEL USUARIO Bluetooth® LG Stereo Headset Auricular Estéreo Bluetooth® LG HBS-FN6 / HBS-FN5W / HBS-FN4 Lea la Información importante de seguridad para poder utilizar este producto cor- rectamente. Después de leerla, guarde este Manual del Usuario en un lugar al que todos los usuarios puedan acceder fácilmente. NOTA: Lea toda la información detenidamente antes de utilizar los auriculares para obtener el mejor rendimiento y evitar daños en el producto. Make sure authentic LG Electronics components are used. Using a non-authentic component may damage the product and thus void the warranty. Utilice solo componentes genuinos de LG Electronics. Si utiliza un componente que no es genuino, se podría dañar el producto y, por lo tanto, anular la garantía. ! CAUTION / PRECAUCIÓN The complete manual is available for download from the LG Electronics website. El manual completo está disponible para descargar desde el sitio web de LG Electronics. www.lg.com > Support > Manuals & Documents > Browse by Product > Mobile Devices > LG Bluetooth Devices NOTE / NOTA *The appearance and specifications of the actual product may differ depending on the model. *La apariencia y las especificaciones del producto real pueden variar dependiendo del modelo. NOTE: Actual product design may differ from images shown in manual. *A mid-sized ear gel is attached to the earbud by default. NOTA: El diseño real del producto puede ser distinto de las imágenes que aparecen en este manual. *De forma predeterminada, el audífono tiene colocado un adaptador de gel para la oreja de tamaño mediano. NOTE / NOTA: HBS-FN4 does not have a UV-C LED and mood light. / Los HBS-FN4 no tienen un LED UV-C ni luz ambiental. Product Description / Descripción del producto Charging Case / Estuche de Carga Earbuds / Audífono Charging terminals / Terminales de carga Microphone / Micrófono Microphone / Micrófono Touchpad / Panel táctilTouchpad / Panel táctil Charging terminals / Terminales de carga UV-C LED / LED UV-C Pairing / Battery check button / Botón Emparejamiento / Comprobación de batería Charging indicator lamp / Luz indicadora de carga Charging port / Puerto de carga NOTE: When the charging case lid is closed, charging case battery status is displayed. If the charging case has no remaining charge, there will be no display and it cannot function. We recommend you keep the charging case charged at all times as the earbuds are not able to be turned on and turned off independently. NOTA: Cuando la tapa del estuche de carga está cerrada, se visualiza el estado de la batería del estuche de carga. Si el estuche de carga no tiene carga restante, no se visualizará nada y no podrá funcionar. Le recomendamos mantener el estuche de carga cargado en todo momento, ya que los audífonos no pueden encenderse y apagarse de forma independiente. Battery Status Estado de la batería If the earbuds are mounted in the charging case while plugged in, the UVnano process will commence for ten minutes. Once this process is complete, the charging case’s battery status will be displayed. Si los audífonos se montan en el estuche de carga mientras este está conectado, el proceso de sanitización UVnano comenzará por diez minutos. Una vez completado este proceso, el estado de la batería del estuche de carga será visualizado. How to pair Instrucciones para vincular el dispositivo -( -( #MVFUPPUI 0/ 12 ~39 inch, ~1m -( -( -(
)#4'/ #MVFUPPUI 3 -( -( -(
)#4'/ NOTE / NOTA: To connect with another device, perform the above procedure again. / Para conectar con otro dispositivo, realice nuevamente el procedimiento de arriba. Activate Bluetooth on your phone or device. Active Bluetooth en su teléfono o dispositivo. While the earbud is mounted in the charging case, open the charging case lid and press the pairing button for 3 to 5 seconds until the blue indicator lamp blinks. Con el audífono montado en el estuche de carga, abra la tapa del estuche de carga y pulse el botón de emparejamiento de 3 a 5 segundos hasta que la luz indicadora azul parpadee. When the Fast Pair connection pop-up appears on the top area of the mobile phone screen, tap it to connect. (It only supports Android™ 5.0 or higher.) Cuando aparezca el emergente de conexión emparejado rápido en el área superior de la pantalla del teléfono móvil, tóquelo para conectar. (Solo es compatible con Android 5.0 o superiores.) If the pop-up does not appear, select [HBS-FN6] from the Bluetooth menu on the mobile phone and connect it (for users of iOS or Android 5.0 or lower versions). Si el emergente no aparece, seleccione [HBS-FN6] desde el menú Bluetooth del teléfono móvil y conéctelo (para usuarios de iOS o Android 5.0 o versiones inferiores). How to wear earbuds Cómo llevar los audífonos 2 1 3 NOTE / NOTA: The earbuds and the charging case are charged at the same time. / Los audífonos y el estuche de carga son cargados al mismo tiempo. NOTE / NOTA: The wireless charger is not provided. HBS-FN4 does not support wireless charging. / El cargador inalámbrico no está incluido. El modelo HBS-FN4 no soporta la carga inalámbrica. NOTE / NOTA: You can change the operation mode through the touch pad settings in the app. / Puede cambiar el modo de operación desde los ajustes del panel táctil en la aplicación. Separate the earbuds from the charging case and adjust them so that they fit comfortably in your ears. When you wear the earbuds, you will hear a wearing detection alarm. Saque los audífonos del estuche de carga y colóquelos de manera que se ajusten cómodamente…

Text truncated - open the document above for the full version.

LG Electronics USA, Inc. Date: May 11, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: New Family Listing Declaration Please review the attached exhibits supporting our request for applying New Family Listing to the FCC ID: ZNFHBSFN6 for Company Name: LG Electronics USA, Inc. Product Description: Bluetooth Earbud Base model: HBS-FN6 Additional model(s): HBS-FN5W, HBS-FN5U, HBS-FN4 The only difference between the base model HBS-FN6 and the additional model(s) HBS-FN5W, HBS-FN5U, HBS-FN4 is as follows: Model Name Differences HBS-FN6 Basic Model (Wireless Charging / UV-C LED function: O) HBS-FN5W The models are identical to basic model but the use function is different. (Wireless Charging / UV-C LED function: X) HBS-FN5U The models are identical to basic model but the use function is different. (Wired Charging / UV-C LED function: O) HBS-FN4 The models are identical to basic model but the use function is different. (Wired Charging / UV-C LED function: X) * UVnano charging case has a built-in UV-C LED, which kills 99.9% of bacteria while charging Should you have any questions, please contact us. Sincerely, Name: Kyung-Su, Han Title: Director, Standards & Compliance

Letter of Authorization Company : LG Electronics USA, Inc. Address : 1000 Sylvan Ave. Englewood Cliffs, New Jersey, 07632, United States Product Name : Bluetooth Earbud Model Number : HBS-FN6 FCC Identifier : ZNFHBSFN6 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Kyung-Su, Han Date: May 11, 2020 Title: Director, Standards & Compliance Signature of applicant:

LG Electronics USA, Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 11, 2020 Subject; Request for Confidentiality FCC ID: ZNFHBSFN6 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Kyung-Su, Han Title: Director, Standards & Compliance

Page 1 of 18 -. Charging case Page 2 of 18 Page 3 of 18 Page 4 of 18 Page 5 of 18 Page 6 of 18 Page 7 of 18 -. Bluetooth Earbud LEFT Page 8 of 18 Page 9 of 18 Page 10 of 18 Page 11 of 18 Page 12 of 18 Page 13 of 18 -. Bluetooth Earbud RIGHT Page 14 of 18 Page 15 of 18 Page 16 of 18 Page 17 of 18 Page 18 of 18

MADE IN VIETNAM BY LG EPA Est.95742-VNM-1;92827-IL-1 FCC ID: ZNFHBSFN6 IC: 2703C-HBSFN6 MODEL : HBS-FN6 S/N: YMMB8xxx000000 제조사/제조국: 엘지전자(주)/베트남 이어버드 : R-R-LGE-HBS-FN6 정격 : 5.0V=500mA A/S : 1544-7777 MODEL : HBS-TFN6 S/N: YMMB8xxx000000 MADE IN VIETNAM BY LG CNC ID: XX-XXXXX XXXXX-XX-XXXXX IFT: xxxx XXXXX-XX-XXXXX MODEL : HBS-FN6 S/N: YMMB8xxx000000 Font : LG 스마트체2.0 R MADE IN VIETNAM BY LG S/N: YMMB8xxx000000 MODEL : HBS-FN6

Page 1 of 56 -. Bluetooth Earbud LEFT Page 2 of 56 Page 3 of 56 Page 4 of 56 Page 5 of 56 Page 6 of 56 Page 7 of 56 Page 8 of 56 Page 9 of 56 Page 10 of 56 Page 11 of 56 Page 12 of 56 Page 13 of 56 FPCB Antenna Page 14 of 56 Page 15 of 56 -. Bluetooth Earbud RIGHT

Page 16 of 56 Page 17 of 56 Page 18 of 56 Page 19 of 56 Page 20 of 56 Page 21 of 56 Page 22 of 56 Page 23 of 56 Page 24 of 56 Page 25 of 56 Page 26 of 56 Page 27 of 56 FPCB Antenna Page 28 of 56

Page 29 of 56 Basic Model: HBS-FN6 Page 30 of 56 Page 31 of 56 Page 32 of 56 Page 33 of 56 Page 34 of 56 Page 35 of 56 Coil Antenna Page 36 of 56 Page 37 of 56 Multiple Model: HBS-FN5W Page 38 of 56 Page 39 of 56 Page 40 of 56 Page 41 of 56 Page 42 of 56 Page 43 of 56 Page 44 of 56

Page 45 of 56 Multiple Model: HBS-FN5U Page 46 of 56 Page 47 of 56 Page 48 of 56 Page 49 of 56 Page 50 of 56 Page 51 of 56 Multiple Model: HBS-FN4 Page 52 of 56 Page 53 of 56 Page 54 of 56 Page 55 of 56 Page 56 of 56

Page 1 of 86 Report No. OT-204-RWD-058 EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) FCC SAR Test Report Report No. : OT-204-RWD-058 AGR. No. : A203A-350 Applicant : LG ELECTRONICS INC Address : 60-39, Gasan-Dong, Gumchon-Gu, Seoul, 153-801, Korea DUT Type : Bluetooth Earbud FCC ID : ZNFHBSFN6 Brand : LG Model No. : HBS-FN6 Additional Model No. : HBS-FN5W, HBS-FN5U, HBS-FN4 FCC Rule Part(s) : CFR §2.1093 Sample Received Date : 2020-03-30 Date of Testing : 2020-04-23 ~ 2020-04-24 Issue Date : 2020-04-27 This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distribute in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of ONETECH Corp. or testing done by ONETECH Corp. In connection with distribution or use of the product described in this report must be approved by ONETECH Corp. in writing. Tested By : No Gyun Im / Manager Approved By : Jung Wook Kim / Technical Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Page 2 of 86 Report No. OT-204-RWD-058 EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision history Report No. Reason for Change Date Issued OT-204-RWD-058 Initial release 2020-04-27 Page 3 of 86 Report No. OT-204-RWD-058 EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) TABLE OF CONTENTS 1. Summary of Maximum SAR Value ............................................................................ 4 2. Device Under Test ..................................................................................................... 4 3. INTRODUCTION ...................................................................................................... 6 4. DOSIMETRIC ASSESSMENT .................................................................................. 8 5. TEST CONFIGURATION POSITIONS ...................................................................... 9 6. RF EXPOSURE LIMITS .......................................................................................... 10 7. FCC MEASUREMENT PROCEDURES .................................................................. 11 8. RF CONDUCTED POWERS .................................................................................. 12 9. SYSTEM VERIFICATION ....................................................................................... 14 10. SAR TEST DATA SUMMARY .................................................................................. 16 11. EQUIPMENT LIST .................................................................................................. 18 12. MEASUREMENT UNCERTAINTIES ....................................................................... 19 13. CONCLUSION ........................................................................................................ 20 14. REFERENCES ....................................................................................................... 21 APPENDIX A: SYSTEM VERIFICATION ................................................................................... 23 APPENDIX B: SAR TEST DATA ................................................................................................ 26 APPENDIX C: PROBE & DIPOLE ANTENNA CALIBRATION ................................................... 31 APPENDIX D: SAR TISSUE SPECIFICATIONS ........................................................................ 62 APPENDIX E: SAR SYSTEM VALIDATION ............................................................................... 78 APPENDIX F: DUT ANTENNA DIAGRAM & SAR TEST SETUP PHOTOGRAPHS .................. 79 Page 4 of 86 Report No. OT-204-RWD-058 EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. Summary of Maximum SAR Value Equipment Class Band & Mode Tx Frequency SAR 1 g Head (W/kg) 1 g Body (W/kg) 10g Hands (W/kg) DSS Bluetooth 2 402 ~ 2 480 MHz < 0.10 0.47 0.15 Simultaneous SAR per KDB 690783 D01v01r03: N/A N/A N/A This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general…
