ZNFK120ECellular/PCS GSM and Cellular WCDMA Phone with WLAN and Bluetooth

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Dec 22, 2015
Application Purpose: Original Equipment
Date of Application: Dec 21, 2015
Equipment Note: Cellular/PCS GSM and Cellular WCDMA Phone with WLAN and Bluetooth
Frequency Range: 1850.20000000 - 1909.80000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

www.lg.com MFL69486401 (1.0) ENGLISH USER GUIDE LG-K120E About this user guide Thank you for choosing LG. Please carefully read this user guide before using the device for the first time to ensure safe and proper use. • Always use genuine LG accessories. The supplied items are designed only for this device and may not be compatible with other devices. • This device is not suitable for people who have a visual impairment due to the touchscreen keyboard. • Descriptions are based on the device default settings. • Default apps on the device are subject to updates and support for these apps may be withdrawn without prior notice. If you have any questions about an app provided with the device, please contact a LG Service Centre. For user-installed apps, please contact the relevant service provider. • Modifying the device’s operating system or installing software from unofficial sources may damage the device and lead to data corruption or data loss. Such actions will violate your LG licence agreement and void your warranty. • Some contents and illustrations may differ from your device depending on the region, service provider, software version, or OS version, and are subject to change without prior notice. • Software, audio, wallpaper, images, and other media supplied with your device are licensed for limited use. If you extract and use these materials for commercial or other purposes, you may be infringing copyright laws. As a user, you are fully are entirely responsible for the illegal use of media. • Additional charges may apply for data services, such as messaging, uploading,downloading, auto-syncing and location services. To avoid additional charges, select a data plan suitable to your needs. Contact your service provider to obtain additional details. Instructional notices WARNING Situations that could cause injury to yourself and others, or damage to device or other property. NOTE Notices or additional information. ENGLISH 2 Guidelines for safe and effi cient use ......... 5 Features you will love ................. 15 QuickMemo+ ............................................16 Using Capture+ ............................................................ 16 Viewing the saved memo ....................................... 16 Basics .......................................... 17 Accessories ..............................................18 Device layout ............................................19 Turning Your Device On and Off ..............21 Installing the SIM card and battery .........21 Charging the battery ...............................23 Optimizing battery life .............................24 Inserting the memory card ......................25 Removing the memory card .....................26 Touch screen tips .....................................26 Tap or touch ................................................................... 26 Touch and hold.............................................................. 27 Drag..................................................................................... 27 Swipe or slide ................................................................ 27 Double-tap ...................................................................... 28 Pinch-to-Zoom ............................................................. 28 Google account setup ..............................29 Creating your Google account ............................ 29 Signing into your Google account..................... 29 Locking and unlocking the device ............30 KnockON .......................................................................... 30 Knock Code .................................................................... 30 Changing the screen lock method.................... 31 Smart Lock...................................................................... 31 Home screen ............................................32 Getting to Know the Home Screen ................. 32 Returning to recently-used applications ...... 33 Customizing the Home screen .......................... 34 Notifi cations panel ..................................................... 35 Capturing a screenshot ............................37 On-screen keyboard .................................37 Using the keypad and entering text ................ 37 Entering special characters................................... 38 Transferring data between a PC and the device .......................................................39 Transferring data using USB connection ...... 39 LG Bridge ..................................................40 Features of LG Bridge ............................................. 40 To download the LG Bridge software ............. 40 Apps ............................................ 41 Installing or uninstalling apps ..................42 To open the Play Store app ................................... 42 To open a screen with details about an app 42 To uninstall applications .......................................... 42 Calls ..........................................................43 Making a call .................................................................. 43 Calling your contacts ................................................ 43 Answering and rejecting a call ............................ 43 Making a second call ................................................. 44 Viewing your call logs ............................................... 44 Change your call settings ...................................... 44 Contacts ...................................................45 Searching for a contact ........................................... 45 Adding a new contact .............................................. 45 Table of contents 3 Favourites contacts ................................................... 45 Creating a group .......................................................... 46 Messaging ................................................47 Sending a message .................................................... …

Text truncated - open the document above for the full version.

Cover Letter(s)

!"# Date: December 16#5 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ZNFK120E Equipment Class:%E&% ' ( held to ear To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, MobileComm hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for * days after the grant as outlined in Public Notice DA 04-1705. This provision will give MobileComm temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: %+,'-./+'0'+,/12-'22' 3) 4 - 5 1 Block Diagram 2 Operational Description and KDB Document 3 Parts L ists, Tune-Up Procedure and Antenna Distance %+,' 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos ./+'0'+, 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, LG Electronics MobileComm U.S.A 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Part List s, PCB Layout

External Photos

ID Label/Location Info

FCC ID is applied by E-Label on the device Description of E-Label on the ZNFK120E Instruction of E-Label on the user manual Setting Menu Step 1 Select About Phone Step 2 Select Regulatory and safety FCC ID is applied on packaging Label Note! We, LG Electronics MobileComm USA, state that at the time of purchase, the FCC ID is readily and physically visible to the purchaser on the packaging Label per 2.925(d). So, The FCC ID will be able to survive normal shipping and handling so it is visible for inspection at the time of import. We have programmed the e-label and it is not able to be modified by any third party. Also, SIM Card in is not required to access the FCC ID number. Model No: LG-K120E FCC ID : ZNFK120E S/N : XXXX Made in XXXX IMEI : XXXXXXXXXXXX

Internal Photos

FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 20 INTERNAL PHOTOGRAPHS FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 20 ■ Main Antenna INTERNAL PHOTO Main Antenna FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 20 ■ BT&WLAN Antenna_INTERNAL PHOTO BT / WLAN Antenna FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １１ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １２ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １３ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １４ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １５ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １６ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １７ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １８ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １９ of 20 ■ INTERNAL PHOTO FCC ID: ZNFK120E HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２０ of 20 ■ INTERNAL PHOTO

RF Exposure Info

FCC ID: ZNFK120E Issue Date: 12. 16, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 2 of 115 HCT-A-1512-F003 TEL: +82 31 645 6300 FAX: +82 31 645 6401 Version Rev. DATE DESCRIPTION HCT-A-1512-F003 12. 16, 2015 First Approval Report FCC ID: ZNFK120E Issue Date: 12. 16, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 3 of 115 HCT-A-1512-F003 TEL: +82 31 645 6300 FAX: +82 31 645 6401 Table of Contents 1. Attestation of Test Result of Device Under Test ............................................................................................ ４ 2. Device Under Test Description ..................................................................................................................... ５ 3. INTRODUCTION ...................................................................................................................................... １１ 4. DESCRIPTION OF TEST EQUIPMENT .................................................................................................. １２ 5. SAR MEASUREMENT PROCEDURE ..................................................................................................... １６ 6. DESCRIPTION OF TEST POSITION ....................................................................................................... １８ 7. ANSI/ IEEE C95.1 - 1992 RF EXPOSURE LIMITS .................................................................................. ２１ 8. FCC SAR GENERAL MEASUREMENT PROCEDURES ........................................................................ ２２ 9. Output Power Specifications .................................................................................................................... ２６ 10. SYSTEM VERIFICATION ....................................................................................................................... ３１ 11. SAR TEST DATA SUMMARY ................................................................................................................. ３３ 12. Simultaneous SAR Analysis ................................................................................................................... ３９ 13. SAR Measurement Variability and Uncertainty....................................................................................... ４１ 14. MEASUREMENT UNCERTAINTY ......................................................................................................... ４２ 16. CONCLUSION ........................................................................................................................................ ４４ 17. REFERENCES ....................................................................................................................................... ４５ Attachment 1. – SAR Test Plots.................................................................................................................... ４７ Attachment 2. – Dipole Verification Plots ...................................................................................................... ４８ Attachment 3. – Probe Calibration Data ....................................................................................................... ６５ Attachment 4. – Dipole Calibration Data ...................................................................................................... ８９ Attachment 5. – SAR Tissue Characterization .......................................................................................... １１４ Attachment 6. – SAR SYSTEM VALIDATION ........................................................................................... １１５ FCC ID: ZNFK120E Issue Date: 12. 16, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 4 of 115 HCT-A-1512-F003 TEL: +82 31 645 6300 FAX: +82 31 645 6401 1. Attestation of Test Result of Device Under Test Attestation of SAR test result Trade Name: LG Electronics, MobileComm U.S.A., Inc. FCC ID: ZNFK120E Model: LG-K120E Additional Model Name: K120E, LGK120E EUT Type GSM WCDMA Phone with BT & WLAN Application Type: Certification The Highest Reported SAR (W/Kg) Band Tx. Frequency Equipment Class Reported 1g SAR (W/kg) (MHz) Head Body-Worn Hotspot GSM/GPRS 850 824.2 - 848.8 PCE 0.64 1.15 1.15 GSM/GPRS 1900 1 850.2 -1 909.8 PCE 0.37 0.74 0.74 UMTS 850 826.4 - 846.6 PCE 0.51 0.97 0.97 802.11b 2 412 - 2 462 DTS 0.81 0.11 0.11 Bluetooth 2 402 - 2 480 DSS/DTS 0.13 * Simultaneous SAR per KDB 690783 D01v01r03 1.44 1.28 1.26 Date(s) of Tests: 11/26/2015 ~ 12/09/2015 Note : *1. BT Body-worn SAR value is estimated SAR value that should not be reported standalone SAR on grants of equipment approval. FCC ID: ZNFK120E Issue Date: 12. 16, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 5 of 115 HCT-A-1512-F003 TEL: +82 31 645 6300 FAX: +82 31 645 6401 2. Device Under Test Description 2.1 DUT specification Device Wireless specification overview Band & Mode Operating Mode Tx Frequency GSM/GPRS/EDGE 850 Voice / Data 824.2 – 848.8 MHz GSM/GPRS/EDGE 1900 Voice / Data 1 850.2 – 1 909.8 MHz UMTS 850 Voice / Data 826.4 – 846.6 MHz 2.4 GHz WLAN Data 2 412.0 – 2 462.0 MHz Bluetooth Data 2 402.0 – 2 480.0 MHz Device Description Device Dimension Overall (Length x Width) : 131.9 mm x 66.7 mm Back Cover Normal Battery cover Battery Options Standard Device Serial Numbers Mode Serial Number/IMEI GSM 1900 004402-34-958735-6 GSM 850, UMTS 850, WiFi 004402-34-958729-9 Several samples with identical hardware were used to SAR testing. The manufacturer has confirmed that the devices tested have the same physical, mechanical and thermal characteristics are within operational tolerances expected for production units. 2.2 DUT Wireless mode Wireless Modulation Band Operating Mode Duty Cycle GSM 850 1900 Voice(GMSK) GPRS (GMSK) EGPRS (8PSK) GPRS Multi-Slot Class: Class …

Text truncated - open the document above for the full version.

Test Report

Report No.: HCT-R-1512-F025 Model:LG-K120E F-TP22-03 (Rev.00) FCC ID: ZNFK120E 2/49 Report Revision TEST REPORT NO. DATE DESCRIPTION HCT-R-1512-F025 December 16, 2015 - First Approval Report Report No.: HCT-R-1512-F025 Model:LG-K120E F-TP22-03 (Rev.00) FCC ID: ZNFK120E 3/49 Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 4 2. INTRODUCTION ........................................................................................................................................... 5 2.1. EUT DESCRIPTION ............................................................................................................................ 5 2.2. MEASURING INSTRUMENT CALIBRATION .................................................................................... 5 2.3. TEST FACILITY .................................................................................................................................. 5 3. DESCRIPTION OF TESTS ........................................................................................................................... 6 3.1 ERP/EIRP RADIATED POWER AND RADIATED SPURIOUS EMISSIONS ..................................... 6 3.2 PEAK- TO- AVERAGE RATIO ............................................................................................................ 7 3.3 OCCUPIED BANDWIDTH. .................................................................................................................. 9 3.4 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL. ......................................... 10 3.5 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ....................................... 11 4. LIST OF TEST EQUIPMENT ...................................................................................................................... 12 5. SUMMARY OF TEST RESULTS ................................................................................................................ 13 6. SAMPLE CALCULATION ........................................................................................................................... 14 7. TEST DATA ................................................................................................................................................. 15 7.1 EFFECTIVE RADIATED POWER ..................................................................................................... 15 7.2 EQUIVALENT ISOTROPIC RADIATED POWER ............................................................................. 16 7.3 RADIATED SPURIOUS EMISSIONS ................................................................................................ 17 7.3.1 RADIATED SPURIOUS EMISSIONS (GSM850) .................................................................... 17 7.3.2 RADIATED SPURIOUS EMISSIONS(GSM1900) ................................................................... 18 7.3.3 RADIATED SPURIOUS EMISSIONS (WCDMA850) .............................................................. 19 7.4 PEAK-TO-AVERAGE RATIO ............................................................................................................ 20 7.5 OCCUPIED BANDWIDTH ................................................................................................................. 21 7.6 CONDUCTED SPURIOUS EMISSIONS ........................................................................................... 22 7.6.1 BAND EDGE ............................................................................................................................ 22 7.7 FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ...................................... 23 7.7.1 FREQUENCY STABILITY (GSM850) ..................................................................................... 23 7.7.2 FREQUENCY STABILITY (GSM1900) ................................................................................... 24 7.7.3 FREQUENCY STABILITY (WCDMA850) ............................................................................... 25 8. TEST PLOTS ............................................................................................................................................... 26 Report No.: HCT-R-1512-F025 Model:LG-K120E F-TP22-03 (Rev.00) FCC ID: ZNFK120E 4/49 MEASUREMENT REPORT 1. GENERAL INFORMATION Applicant Name: LG Electronics MobileComm U.S.A., Inc. Address: 1000 Sylvan Avenue, Englewood Cliffs NJ 07632 FCC ID: ZNFK120E Application Type: Certification FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §22, §24, §2 EUT Type: GSM WCDMA Phone with BT & WLAN FCC Model(s): LG-K120E Additional FCC Model(s): K120E, LGK120E Tx Frequency: 824.20 - 848.80 MHz (GSM850) 826.40 - 846.60 MHz (WCDMA850) 1 850.20 - 1 909.80 MHz (GSM1900) Rx Frequency: 869.20 - 893.80 MHz (GSM850) 871.40 - 891.60 MHz (WCDMA850) 1 930.20 - 1 989.80 MHz (GSM1900) Max. RF Output Power: 0.580 W GSM850 (27.64 dBm) / 0.898W GSM1900 (29.53 dBm) 0.081 W WCDMA850 (19.10 dBm) Emission Designator(s): 245 KGXW (GSM850) 249 KGXW (GSM1900) 4M24F9W (WCDMA850) Date(s) of Tests: November 17, 2015 ~ December 10, 2015 Antenna Specification Manufacturer: Antenna type: Peak Gain: Ace Technology PIFA Antenna (Planar Inverted F) GSM850/ WCDMA850 : -4.79 dBi GSM1900 : -0.27 dBi Report No.: HCT-R-1512-F025 Model:LG-K120E F-TP22-03 (Rev.00) FCC ID: ZNFK120E 5/49 2. INTRODUCTION 2.1. EUT DESCRIPTION The LG Electronics MobileComm U.S.A., Inc.LG-K120E GSM WCDMA Phone with BT & WLAN consists of GPRS Class12, GSM850, GSM1900, WCDMA850, HSDPA, HSUPA, DC-HSDPA and HSPA+. 2.2. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. 2.3. TEST FACILITY The Fully-anechoic chamber and…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: ZNFK120E Issue Date: 12. 31, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 1 of 14 HCT-A-1512-F003-1 TEL: +82 31 645 6300 FAX: +82 31 645 6401 Antenna and Device Information FCC ID: ZNFK120E Issue Date: 12. 31, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 2 of 14 HCT-A-1512-F003-1 TEL: +82 31 645 6300 FAX: +82 31 645 6401 Left Right Front FCC ID: ZNFK120E Issue Date: 12. 31, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-d…

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)

[email protected]201-266-2215Fax: 201-816-2003

Technical Contact

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

HCT Co., Ltd.Lee MyoungLim

[email protected]82-31-645-6918Fax: 82-31-645-6401

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
3	24E	1.85 GHz - 1.91 GHz	898.00 mW	249KGXW	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.0 cm separation between the device and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission use conditions is 0.64W/kg, 1.15 W/kg, 1.15 W/kg, and 1.44 W/kg, respectively. This device also contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations.
