ZNFK200QMPortable Handset

ENGLISH www.lg.com USER GUIDE Copyright ©2020 LG Electronics Inc. All rights reserved. MFL71777401 (1.0) LM-K200QM 1 About this user guide Thank you for choosing this LG product. Please carefully read this user guide before using the device for the first time to ensure safe and proper use. • Always use genuine LG accessories. The supplied items are designed only for this device and may not be compatible with other devices. • Descriptions are based on the device default settings. • Default apps on the device are subject to updates, and support for these apps may be withdrawn without prior notice. If you have any questions about an app provided with the device, please contact the LG Authorized Service Center. For user-installed apps, please contact the relevant service provider. • Modifying the device’s operating system or installing software from unofficial sources may damage the device and lead to data corruption or data loss. Such actions will violate your LG license agreement and void your warranty. • Some content and illustrations may differ from your device, depending on the area, service provider, software version, or OS version, and are subject to change without prior notice. • Software, audio, wallpaper, images, and other media supplied with your device are licensed for limited use. If you extract and use these materials for commercial or other purposes, you may be infringing copyright laws. As a user, you are fully responsible for the illegal use of media. • Additional charges may incur for data services, such as messaging, uploading, downloading, auto-syncing and location services. To avoid additional charges, select a data plan suitable to your needs. Contact your service provider to obtain additional details. • Failure to follow the instructions in this guide and improper use may damage the device. 2 Instructional notices WARNING: Situations that could cause injury to the user and third parties. CAUTION: Situations that may cause minor injury or damage to the device. NOTE: Notices or additional information. 3Table of contents Table of contents 01 Custom-designed Features 6 Google Assistant 02 Basic Functions 9 Product components and accessories 10 Parts overview 12 Turning the power on or off 13 Installing the SIM c ard and memory card 15 Removing the memory card 15 Char ging the battery 17 T ouch screen 19 Home scr een 24 Scr een lock 25 T aking screenshots 25 Copy and P aste 25 D o not disturb 03 Useful Apps 27 Installing and uninstalling apps 28 App Shortcuts 29 Phone 33 Messages 34 Camera 37 Photos 39 Chrome 40 Google apps 42 Contacts 44 Clock 45 Calculator 4Table of contents 04 Settings 47 Settings 47 Net work & internet 52 Connected devices 54 Apps & notifications 55 Battery 55 Display 56 Sound 57 Storage 58 Privacy 58 Location 59 Security 59 Accounts 60 Accessibility 62 Digital W ellbeing & parental controls 62 Google 63 System 65 About phone 05 Appendix 67 LG Language Settings 67 L G Bridge 68 Phone software update 70 Anti-Theft Guide 71 Open Source Software Notice Information 71 R egulatory information (FCC ID number, etc.) 72 Trademarks 73 Laser Safety Statement 75 FAQ 06 For Your Safety 07 LIMITED WARRANTY USA Custom-designed Features 01 Custom-designed Features6 Google Assistant Google Assistant overview You can launch or use desired apps with your voice. • To use this feature, first connect to the network and sign in to your Google Account. • This feature may not work properly or voice recognition accuracy may decrease in areas where Wi-Fi or mobile network signal strength is weak. • This function may be not supported, or the supported languages may differ depending on the service area. Launching Google Assistant 1 Press the Google Assistant key on the left side of the device. OR Touch and hold from the Home screen to launch Google Assistant. 2 Follow the on-screen instructions and say “Ok Google”. • The device saves your voice data for recognition. 3 Tap Save. Launching Google Assistant with your voice 1 Say “Ok Google” when the screen is turned on. 2 Say a command or question when Google assistant pop-up appears on the screen. Custom-designed Features7 Launching Google Assistant from the Home screen 1 Press the Google Assistant key on the left side of the device. OR Touch and hold on the Home screen. 2 Say a command or question when Google assistant pop-up appears on the screen. • Voice recognition accuracy may decrease if you speak with an unclear voice or in a noisy place. When you use the voice recognition feature, increase its accuracy by speaking with a clear voice in a quiet place. Basic Functions 02 Basic Functions9 Product components and accessories The following items are included with your device. • Device • USB cable • Charger • Important Information Booklet • Ejection pin • The items supplied with the device and any available accessories may vary depending on the area and service provider. • Do not use unapproved USB cables or chargers with your device. The LG limited warranty does not cover damage caused by the use of third party accessories. • Some of the device parts are made of tempered glass. If you drop your device on a hard surface or subject it to severe impact, the tempered glass may be damaged. If this happens, stop using your device immediately and contact the LG Authorized Service Center. • If any of these basic items are missing, contact the dealer from which you purchased your device. • To purchase additional basic items, contact the LG Authorized Service Center. • To purchase optional items, contact the LG Authorized Service Center for available dealers. • Some items in the product box are subject to change without notice. • The appearance and specifications of your device are subject to change without notice. • Device specifications may vary depending on the area or service provider. • Be sure to use authentic accessories provided by LG Electronics. Using third-party accessories may damage the device or cause malfunctions. Basic Funct…

Text truncated - open the document above for the full version.

Date: November 11, 2020 PCTEST TCB/CB Div. of PCTEST Engineering Lab., Inc. 7185 Oakland Mills Rd, Columbia, MD 21046 U.S.A SUBJECT: LG Electronics USA, Inc. FCC ID: ZNFK200QM LTE MPR for FCC SAR testing To whom it may concern: We, LG Electronics USA, Inc. hereby confirm that MPR specified in 3GPP will be permanently implemented in ZNFK200QM so that the powers found in this application will not be found to exceed the levels indicated. Additionally, A-MPR (Additional MPR) was disabled for all SAR samples for SAR testing purposes. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, LG Electronics USA, Inc. 111 Sylvan Avenue, North Building Englewood Cliffs, NJ 07632 Dae-Woong Kim Director On behalf of LG Electronics USA, Inc.

Date: November 11, 2020 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG Electronics USA, Inc. FCC ID:ZNFK200QM Part 20.19 Certification To whom it may concern: We, LG Electronics USA, Inc., hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, LG Electronics USA, Inc. 1 11 Sylvan Avenue , North Building Englewood Cliffs, NJ 07632 Dae-Woong Kim Director On behalf of LG Electronics USA, Inc.

LG Electronics USA, Inc. 111 Sylvan Avenue, North Building Englewood Cliffs, NJ 07632 Date: January 1, 2020 PCTEST Lab. 7185 Oakland Mills Road, Columbia, MD 21046 USA To whom it may concern: I, the undersigned, hereby authorize PCTEST Lab. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by PCTEST lab. on our behalf shall have the same effect as acts of our own. In authorizing PCTEST Lab. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Dae Woong Kim Director On behalf of LG Electronics USA, Inc.

Date: November 11, 2020 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ZNFK200QM Equipment Class: PCE: PCS Licensed Transmitter held to ear To whom it may concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA, Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Part Lists and Tune-Up Procedure 4 Schematics SHORT-TERM 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User’s Manual This applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the grant for this application. Sincerely, LG Electronics USA, Inc. 111 Sylvan Avenue, North Building Englewood Cliffs, NJ 07632 Dae-Woong Kim Director On behalf of LG Electronics USA, Inc.

LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM External Photos EUT Type: Portable Handset Page 1 of 5 © 2020 PCTEST V 9.0 02/01/2019 E X T E R N A L P H O T O G R A P H S LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM External Photos EUT Type: Portable Handset Page 2 of 5 © 2020 PCTEST V 9.0 02/01/2019 LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM External Photos EUT Type: Portable Handset Page 3 of 5 © 2020 PCTEST V 9.0 02/01/2019 LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM External Photos EUT Type: Portable Handset Page 4 of 5 © 2020 PCTEST V 9.0 02/01/2019 LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM External Photos EUT Type: Portable Handset Page 5 of 5 © 2020 PCTEST V 9.0 02/01/2019

Description of E-Label on the ZNFK200QM 1. FCC ID is applied by E-label on device. [Step2] [Step3] FCC ID [Step1] Description of E-Label on the ZNFK200QM 1. FCC ID is applied on packaging. FCC ID : ZNFK200QM 2. Instruction of E-label on the user manual

LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM Internal Photos EUT Type: Portable Handset Page 1 of 6 © 2020 PCTEST V 9.0 02/01/2019 I N T E R N A L P H O T O G R A P H S LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM Internal Photos EUT Type: Portable Handset Page 2 of 6 © 2020 PCTEST V 9.0 02/01/2019 LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM Internal Photos EUT Type: Portable Handset Page 3 of 6 © 2020 PCTEST V 9.0 02/01/2019 LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM Internal Photos EUT Type: Portable Handset Page 4 of 6 © 2020 PCTEST V 9.0 02/01/2019 LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM Internal Photos EUT Type: Portable Handset Page 5 of 6 © 2020 PCTEST V 9.0 02/01/2019 LG Electronics USA, Inc. FCC ID: ZNFK200QM Model: LM-K200QM Internal Photos EUT Type: Portable Handset Page 6 of 6 © 2020 PCTEST V 9.0 02/01/2019

FCC ID: ZNFK200QM SAR EVALUATION REPORT Approved by: Quality Manager Document S/N: Test Dates: DUT Type: Page 1 of 89 1M2009230153-01-R1.ZNF 09/30/20 - 10/24/20 Portable Handset © 2020 PCTEST REV 21.4 M 09/11/2019 © 2020 PCTEST All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. Applicant Name: Date of Testing: LG Electronics U.S.A., Inc. 09/30/20 - 10/24/20 111 Sylvan Avenue, North Building Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Document Serial No.: 1M2009230153-01-R1.ZNF F C C I D : ZNFK200QM A P P L I C A N T : LG ELECT RO NI CS U. S.A., INC. DUT Type: Portable Handset Application Type: Certification FCC Rule Part(s): CFR §2.1093 Model: LM-K200QM Additional Model(s): LMK200QM, K200QM Note: This revised Test Report (S/N: 1M2009230153-01-R1.ZNF) supersedes and replaces the previously issued test report on the same subject device for the same type of testing as indicated. Please discard or destroy the previously issued test report(s) and dispose of it accordingly. This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in Section 1.7 of this report; for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. The SAR Tick is an initiative of the Mobile & Wireless Forum (MWF). While a product may be considered eligible, use of the SAR Tick logo requires an agreement with the MWF. Further details can be obtained by emailing: [email protected]. 1g Head (W/kg) 1g Body- Worn (W/kg) 1g Hotspot (W/kg) 10g Phablet (W/kg) PCE Cell. CDMA/EVDO 824.70 - 848.31 MHz 0.42 0.58 0.56 N/A PCE PCS CDMA/EVDO 1851.25 - 1908.75 MHz 0.23 1.11 1.15 3.18 PCE GSM/GPRS/EDGE 850 824.20 - 848.80 MHz 0.33 0.40 0.40 N/A PCE GSM/GPRS/EDGE 1900 1850.20 - 1909.80 MHz 0.14 0.50 1.20 N/A PCE UMTS 850 826.40 - 846.60 MHz 0.42 0.65 0.65 N/A PCE UMTS 1750 1712.4 - 1752.6 MHz 0.20 1.07 0.86 2.62 PCE UMTS 1900 1852.4 - 1907.6 MHz 0.24 1.22 1.30 2.96 PCE LTE Band 12 699.7 - 715.3 MHz 0.35 0.61 0.61 N/A PCE LTE Band 17 706.5 - 713.5 MHz N/A N/A N/A N/A PCE LTE Band 13 779.5 - 784.5 MHz 0.37 0.78 0.81 N/A PCE LTE Band 5 (Cell) 824.7 - 848.3 MHz 0.44 0.59 0.59 N/A PCE LTE Band 66 (AWS) 1710.7 - 1779.3 MHz 0.21 1.06 1.03 2.76 PCE LTE Band 4 (AWS) 1710.7 - 1754.3 MHz N/A N/A N/A N/A PCE LTE Band 25 (PCS) 1850.7 - 1914.3 MHz 0.24 1.12 1.23 3.18 PCE LTE Band 2 (PCS) 1850.7 - 1909.3 MHz N/A N/A N/A N/A PCE LTE Band 7 2502.5 - 2567.5 MHz 0.40 1.00 1.15 2.86 DTS 2.4 GHz WLAN 2412 - 2462 MHz 0.55 0.21 0.21 N/A DSS/DTS Bluetooth 2402 - 2480 MHz < 0.1 < 0.1 < 0.1 N/A 0.99 1.43 1.50 3.18 Equipment Class SAR Simultaneous SAR per KDB 690783 D01v01r03: Band & Mode Tx Frequency PCTEST 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctest.com SAR EVALUATION REPORT FCC ID: ZNFK200QM SAR EVALUATION REPORT Approved by: Quality Manager Document S/N: Test Dates: DUT Type: Page 2 of 89 1M2009230153-01-R1.ZNF 09/30/20 - 10/24/20 Portable Handset © 2020 PCTEST REV 21.4 M 09/11/2019 © 2020 PCTEST All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from PCTEST. If you have any questions about this international copyright or have an enquiry about obtaining additional rights to this report or assembly of contents thereof, please contact [email protected]. T A B L E O F C O N T E N T S 1 DEVICE UNDER TEST ................................................................................................................................ 3 2 LTE INFORMATION ..................................................................................................................................... 9 3 INTRODUCTION ........................................................................................................................................ 10 4 DOSIMETRIC ASSESSMENT ................................................................................................................... 11 5 DEFINITION OF REFERENCE POINTS ................................................................................................... 12 6 TEST CONFIGURATION POSITIONS ...................................................................................................... 13 7 RF EXPOSURE LIMITS ............................................................................................................................. 17 8 FCC MEASUREMENT PROCEDURES ..................................................................................................... 18 9 RF CONDUCTED POWERS ...................................................................................................................... 24 10 SYSTEM VERIFICATION ........................................................................................................................... 55 11 SAR DATA SUMMARY .............................................................................................…

Text truncated - open the document above for the full version.

© 2020 PCTEST A P P E N D I X A : S A R T E S T D A T A A1 PCTEST DUT: ZNFK200QM; Type: Portable Handset; Serial: 00269 Communication System: UID 0, CDMA; Frequency: 836.52 MHz; Duty Cycle: 1:1 Medium: 835 Head Medium parameters used (interpolated): f = 836.52 MHz; σ = 0.944 S/m; ε r = 41.694; ρ = 1000 kg/m 3 Phantom section: Right Section Test Date: 10/13/2020; Ambient Temp: 23.3°C; Tissue Temp: 22.4°C Probe: EX3DV4 - SN3589; ConvF(8.58, 8.58, 8.58) @ 836.52 MHz; Calibrated: 1/21/2020 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1558; Calibrated: 1/13/2020 Phantom: Twin-SAM V5.0 (30); Type: QD 000 P40 CD; Serial: 1647 Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Mode: Cell. CDMA, Right Head, Cheek, Mid.ch Area Scan (9x14x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (6x6x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 21.47 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 0.554 W/kg SAR(1 g) = 0.419 W/kg Smallest distance from peaks to all points 3 dB below = 24.9 mm Ratio of SAR at M2 to SAR at M1 = 76.5% 0 dB = 0.505 W/kg = -2.97 dBW/kg A2 PCTEST DUT: ZNFK200QM; Type: Portable Handset; Serial: 00251 Communication System: UID 0, PCS CDMA; Frequency: 1880 MHz; Duty Cycle: 1:1 Medium: 1900 Head Medium parameters used: f = 1880 MHz; σ = 1.392 S/m; ε r = 39.758; ρ = 1000 kg/m 3 Phantom section: Left Section Test Date: 10/19/2020; Ambient Temp: 20.7°C; Tissue Temp: 22.8°C Probe: EX3DV4 - SN7406; ConvF(7.96, 7.96, 7.96) @ 1880 MHz; Calibrated: 6/23/2020 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1583; Calibrated: 5/14/2020 Phantom: Twin-SAM V8.0; Type: QD 000 P41 Ax; Serial: 1966 Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Mode: PCS EVDO Rev A, Left Head, Cheek, Mid.ch Area Scan (9x13x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.11 V/m; Power Drift = 0.16 dB Peak SAR (extrapolated) = 0.345 W/kg SAR(1 g) = 0.223 W/kg Smallest distance from peaks to all points 3 dB below = 15.3 mm Ratio of SAR at M2 to SAR at M1 = 65.9% 0 dB = 0.297 W/kg = -5.27 dBW/kg A3 PCTEST DUT: ZNFK200QM; Type: Portable Handset; Serial: 00244 Communication System: UID 0, GSM GPRS; 4 Tx slots; Frequency: 836.6 MHz; Duty Cycle: 1:2.076 Medium: 835 Head Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.944 S/m; ε r = 41.694; ρ = 1000 kg/m 3 Phantom section: Right Section Test Date: 10/13/2020; Ambient Temp: 23.3°C; Tissue Temp: 22.4°C Probe: EX3DV4 - SN3589; ConvF(8.58, 8.58, 8.58) @ 836.6 MHz; Calibrated: 1/21/2020 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1558; Calibrated: 1/13/2020 Phantom: Twin-SAM V5.0 (30); Type: QD 000 P40 CD; Serial: 1647 Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Mode: GPRS 850, Right Head, Cheek, Mid.ch, 4 Tx slots Area Scan (9x13x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 18.67 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 0.417 W/kg SAR(1 g) = 0.316 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid Ratio of SAR at M2 to SAR at M1 = 76.4% 0 dB = 0.380 W/kg = -4.20 dBW/kg A4 PCTEST DUT: ZNFK200QM; Type: Portable Handset; Serial: 00244 Communication System: UID 0, GSM GPRS; 4 Tx slots; Frequency: 1880 MHz; Duty Cycle: 1:2.076 Medium: 1900 Head Medium parameters used: f = 1880 MHz; σ = 1.392 S/m; ε r = 39.758; ρ = 1000 kg/m 3 Phantom section: Left Section Test Date: 10/19/2020; Ambient Temp: 20.7°C; Tissue Temp: 22.8°C Probe: EX3DV4 - SN7406; ConvF(7.96, 7.96, 7.96) @ 1880 MHz; Calibrated: 6/23/2020 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1583; Calibrated: 5/14/2020 Phantom: Twin-SAM V8.0; Type: QD 000 P41 Ax; Serial: 1966 Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Mode: GPRS 1900, Left Head, Cheek, Mid.ch, 4 Tx slots Area Scan (9x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.782 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 0.182 W/kg SAR(1 g) = 0.120 W/kg Smallest distance from peaks to all points 3 dB below = 13.9 mm Ratio of SAR at M2 to SAR at M1 = 67.6% 0 dB = 0.159 W/kg = -7.99 dBW/kg A5 PCTEST DUT: ZNFK200QM; Type: Portable Handset; Serial: 00269 Communication System: UID 0, UMTS; Frequency: 836.6 MHz; Duty Cycle: 1:1 Medium: 835 Head Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.944 S/m; ε r = 41.694; ρ = 1000 kg/m 3 Phantom section: Right Section Test Date: 10/13/2020; Ambient Temp: 23.3°C; Tissue Temp: 22.4°C Probe: EX3DV4 - SN3589; ConvF(8.58, 8.58, 8.58) @ 836.6 MHz; Calibrated: 1/21/2020 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1558; Calibrated: 1/13/2020 Phantom: Twin-SAM V5.0 (30); Type: QD 000 P40 CD; Serial: 1647 Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Mode: UMTS 850, Right Head, Cheek, Mid.ch Area Scan (9x15x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 21.62 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 0.557 W/kg SAR(1 g) = 0.421 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid Ratio of SAR at M2 to SAR at M1 = 76% 0 dB = 0.510 W/kg = -2.92 dBW/kg A6 PCTEST DUT: ZNFK200QM; Type: Portable Handset; Serial: 00244 Communication System: UID 0, UMTS; Frequency: 1732.4 MHz; Duty Cycle: 1:1 Medium: 1750 Head Medium parameters used (interpolated): f = 1732.4 MHz; σ = 1.332 S/m; ε r = 40.092; ρ = 1000 kg/m 3 Phantom section: Right Section Test Date: 10/14/2020; Ambient Temp: 22.1°C; Tissue Temp: 24.5°C Probe: EX3DV4 - SN7406; ConvF(8.32, 8.32, 8.32) @ 1732.4 MHz; Calibrated: 6/23/2020 Sensor-Surface: 1.4mm (Mechanica…

Text truncated - open the document above for the full version.

Object: Date Issued: Page 3 of 4 D1900V2 – SN: 5d148 02/21/2020 Impedance & Return-Loss Measurement Plot for Head TSL Object: Date Issued: Page 4 of 4 D1900V2 – SN: 5d148 02/21/2020 Impedance & Return-Loss Measurement Plot for Body TSL Object: Date Issued: Page 1 of 4 D1900V2 – SN: 5d149 10/18/2019 Certification of Calibration Object D1900V2 – SN:5d149 Calibration procedure(s) Procedure for Calibration Extension for SAR Dipoles. Extended Calibration date: October 18, 2019 Description: SAR Validation Dipole at 1900 MHz. Calibration Equipment used: Note: CBT (Calibrated Before Testing). Prior to testing, the measurement paths containing a cable, amplifier, attenuator, coupler or filter were connected to a calibrated source (i.e. a signal generator) to determine the losses of the measurement path. Measurement Uncertainty = ±23% (k=2) Name Function Signature Calibrated By: Brodie Halbfoster Team Lead Engineer Approved By: Kaitlin O’Keefe Senior Technical Manager Manufacturer Model Description Cal Date Cal Interval Cal Due Serial Number Control Company 4040Therm./Clock/Humidity Monitor 6/29/2019 Biennial 6/29/2021 192291470 Control Company 4352Ultra Long Stem Thermometer 8/2/2018 Biennial 8/2/2020 181334684 Amplifier Research 15S1G6 Amplifier CBTN/A CBT433971 Narda 4772-3 Attenuator (3dB) CBTN/A CBT9406 Keysight Technologies 85033E Standard Mechanical Calibration Kit (DC to 9GHz, 3.5mm) 7/2/2019 Annual 7/2/2020 MY53401181 Rohde & Schwarz ZNLE6 Vector Network Analyzer 10/11/2019 Annual 10/11/2020 101307 Mini-Circuits BW-N20W5+ DC to 18 GHz Precision Fixed 20 dB Attenuator CBTN/A CBTN/A SPEAG DAKS-3.5 Portable Dielectric Assessment Kit 8/13/2019 Annual 8/13/2020 1041 Anritsu MA2411B Pulse Power Sensor 8/14/2019 Annual 8/14/2020 1315051 Anritsu MA2411B Pulse Power Sensor 8/8/2019 Annual 8/8/2020 1339008 Anritsu ML2495A Power Meter 11/20/2018 Annual 11/20/2019 1039008 Agilent N5182A MXG Vector Signal Generator 8/19/2019 Annual 8/19/2020 MY47420837 Seekonk NC-100 Torque Wrench 5/9/2018 Biennial 5/9/2020 22217 Mini-Circuits NLP-2950+ Low Pass Filter DC to 2700 MHz CBTN/A CBTN/A MiniCircuits ZHDC-16-63-S+Bidirectional Coupler CBTN/ACBTN/A MiniCircuits VLF-6000+ Low Pass Filter CBTN/ACBTN/A SPEAG EX3DV4 SAR Probe 2/19/2019 Annual 2/19/2020 3914 SPEAG EX3DV4 SAR Probe 5/16/2019 Annual 5/16/2020 7406 SPEAG DAE4 Dasy Data Acquisition Electronics 5/8/2019 Annual 5/8/2020 859 SPEAG DAE4 Dasy Data Acquisition Electronics 2/14/2019 Annual 2/14/2020 1272 PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctest.com Object: Date Issued: Page 2 of 4 D1900V2 – SN: 5d149 10/18/2019 DIPOLE CALIBRATION EXTENSION Per KDB 865664 D01, calibration intervals of up to three years may be considered for reference dipoles when it is demonstrated that the SAR target, impedance and return loss of a dipole have remained stable according to the following requirements: 1. The measured SAR does not deviate more than 10% from the target on the calibration certificate. 2. The return-loss does not deviate more than 20% from the previous measurement and meets the required 20dB minimum return-loss requirement. 3. The measurement of real or imaginary parts of impedance does not deviate more than 5Ω from the previous measurement. The following dipole was checked to pass the above 3 requirements to have 2-year calibration period from the calibration date: Calibration Date Extension Date Certificate Electrical Delay (ns) Certificate SAR Target Head (1g) W/kg @ 20.0 dBm Measured Head SAR (1g) W/kg @ 20.0 dBm Deviation 1g (%) Certificate SAR Target Head (10g) W/kg @ 20.0 dBm Measured Head SAR (10g) W/kg @ 20.0 dBm Deviation 10g (%) Certificate Impedance Head (Ohm) Real Measured Impedance Head (Ohm) Real Difference (Ohm) Real Certificate Impedance Head (Ohm) Imaginary Measured Impedance Head (Ohm) Imaginary Difference (Ohm) Imaginary Certificate Return Loss Head (dB) Measured Return Loss Head (dB) Deviation (%) PASS/FAIL 10/23/201810/18/20191.1933.934.247.89%2.052.186.34%52.951.81.16.36.40.1-23.4-23.8-1.80%Pass Calibration Date Extension Date Certificate Electrical Delay (ns) Certificate SAR Target Body (1g) W/kg @ 20.0 dBm Measured Body SAR (1g) W/kg @ 20.0 dBm Deviation 1g (%) Certificate SAR Target Body (10g) W/kg @ 20.0 dBm Measured Body SAR (10g) W/kg @ 20.0 dBm Deviation 10g (%) Certificate Im…
