MFLXXXXXXXX (1.0) Copyright ©2020 LG Electronics Inc. All rights reserved. www.lg.com ENGLISH USER GUIDE LM-K420HM 1 About this user guide Thank you for choosing this LG product. Please carefully read this user guide before using the device for the first time to ensure safe and proper use. • Always use genuine LG accessories. The supplied items are designed only for this device and may not be compatible with other devices. • Descriptions are based on the device default settings. • Default apps on the device are subject to updates, and support for these apps may be withdrawn without prior notice. If you have any questions about an app provided with the device, please contact an LG Service Centre. For user-installed apps, please contact the relevant service provider. • Modifying the device’s operating system or installing software from unofficial sources may damage the device and lead to data corruption or data loss. Such actions will violate your LG licence agreement and void your warranty. • Some content and illustrations may differ from your device, depending on the area, service provider, software version, or OS version, and are subject to change without prior notice. • Software, audio, wallpaper, images, and other media supplied with your device are licenced for limited use. If you extract and use these materials for commercial or other purposes, you may be infringing copyright laws. As a user, you are fully responsible for the illegal use of media. • Additional charges may incur for data services, such as messaging, uploading, downloading, auto-syncing and location services. To avoid additional charges, select a data plan suitable to your needs. Contact your service provider to obtain additional details. • This user guide is written in major languages for each country. Depending on the language used, content may partly differ. ENGLISH 2About this user guide Instructional notices WARNING: Situations that could cause injury to the user and third parties. CAUTION: Situations that may cause minor injury or damage to the device. NOTE: Notices or additional information. 3 Table of contents 01 Custom-designed Features 16 Camera features 20 Audio recording features 20 Google Assistant 22 Finger print recognition 26 Multi- tasking feature 02 Basic Functions 30 Product components and accessories 31 P arts overview 35 Turning the power on or off 36 Installing the SIM c ard 38 Inserting the memory card 39 R emoving the memory card 39 Battery 42 T ouch screen 45 Home screen 54 Scr een lock 57 Memory card encryption 58 Taking screenshots 59 Content sharing 61 D o not disturb 6 Guidelines for safe and efficient use 4Table of contents 03 Useful Apps 63 Installing and uninstalling apps 65 App Shor tcuts 66 Phone 70 Messaging 71 Camera 82 Gallery 87 Contacts 89 QuickMemo+ 92 Clock 93 Calculator 94 Music 95 ThinQ 95 FM Radio 96 Audio Recorder 96 Game Launcher 97 Smart Doctor 97 LG Mobile Switch 98 App trash 98 RemoteCall Service 98 Cell Broadcast 99 Google apps 04 Settings 103 Settings 103 Network & internet 110 Connected devices 112 Sound 113 Notifications 114 Display 115 Wallpaper & theme 115 Lock scr een & security 117 Privacy 118 Location 118 Extensions 120 Apps 120 Battery 121 Storage 121 Accounts 121 Digital W ellbeing & parental controls 122 Google 122 System 126 Accessibility 5Table of contents 05 Appendix 129 LG Language Settings 129 LG Bridge 130 Phone software update 132 Anti- Theft Guide 133 Open Source Software Notice Information 133 Regulatory information (Regulation ID number, E-labeling, etc.) 134 Trademarks 135 Laser safety statement 135 DECLARATION OF CONFORMITY 136 Contact o ffice for compliance of this product 136 Wi-Fi (WLAN) 137 More information 141 FAQ 6 Guidelines for safe and efficient use Please read these simple guidelines. Not following these guidelines may be dangerous or illegal. Should a fault occur, a software tool is built into your device that will gather a fault log. This tool gathers only data specific to the fault, such as signal strength, cell ID position in sudden call drop and applications loaded. The log is used only to help determine the cause of the fault. These logs are encrypted and can only be accessed by an authorised LG Repair centre should you need to return your device for repair. Exposure to radio frequency energy Radio wave exposure and Specific Absorption Rate (SAR) information. This device has been designed to comply with applicable safety requirements for exposure to radio waves. These requirements are based on scientific guidelines that include safety margins designed to assure the safety of all persons, regardless of age and health. • The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. Tests for SAR are conducted using standardised methods with the device transmitting at its highest certified power level in all used frequency bands. • While there may be differences between the SAR levels of various LG device models, they are all designed to meet the relevant guidelines for exposure to radio waves. • The SAR limit recommended by the International Commission on Non-Ionizing Radiation Protection (ICNIRP) is 2 W/kg averaged over 10 g of tissue. • The highest SAR value for this model tested for use at the ear is X.XXX W/kg (10 g) and when worn on the body is X.XXX W/kg (10 g). • This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 5 mm away from the body. When a carry case, belt clip or holder is used for body-worn operation, it should not contain metal and should position the product at least 5 mm away from your body. In order to transmit data files or messages, this device requires a quality connection to the network. In some cases, transmission of data files or messages may be delayed until such a connection is available. Ensure the above separation distance instructions are followed until the transmission is comple…

Text truncated - open the document above for the full version.

MFLXXXXXXXX (1.0) Copyright ©2020 LG Electronics Inc. All rights reserved. www.lg.com ENGLISH USER GUIDE LM-K420HMW 1 About this user guide Thank you for choosing this LG product. Please carefully read this user guide before using the device for the first time to ensure safe and proper use. • Always use genuine LG accessories. The supplied items are designed only for this device and may not be compatible with other devices. • Descriptions are based on the device default settings. • Default apps on the device are subject to updates, and support for these apps may be withdrawn without prior notice. If you have any questions about an app provided with the device, please contact an LG Service Centre. For user-installed apps, please contact the relevant service provider. • Modifying the device’s operating system or installing software from unofficial sources may damage the device and lead to data corruption or data loss. Such actions will violate your LG licence agreement and void your warranty. • Some content and illustrations may differ from your device, depending on the area, service provider, software version, or OS version, and are subject to change without prior notice. • Software, audio, wallpaper, images, and other media supplied with your device are licenced for limited use. If you extract and use these materials for commercial or other purposes, you may be infringing copyright laws. As a user, you are fully responsible for the illegal use of media. • Additional charges may incur for data services, such as messaging, uploading, downloading, auto-syncing and location services. To avoid additional charges, select a data plan suitable to your needs. Contact your service provider to obtain additional details. • This user guide is written in major languages for each country. Depending on the language used, content may partly differ. ENGLISH 2About this user guide Instructional notices WARNING: Situations that could cause injury to the user and third parties. CAUTION: Situations that may cause minor injury or damage to the device. NOTE: Notices or additional information. 3 Table of contents 01 Custom-designed Features 16 Camera features 20 Audio recording features 20 Google Assistant 22 Finger print recognition 26 Multi- tasking feature 02 Basic Functions 30 Product components and accessories 31 P arts overview 35 Turning the power on or off 36 Installing the SIM c ard 38 Inserting the memory card 39 R emoving the memory card 39 Battery 42 T ouch screen 45 Home screen 54 Scr een lock 57 Memory card encryption 58 Taking screenshots 59 Content sharing 61 D o not disturb 6 Guidelines for safe and efficient use 4Table of contents 03 Useful Apps 63 Installing and uninstalling apps 65 App Shor tcuts 66 Phone 70 Messaging 71 Camera 82 Gallery 87 Contacts 89 QuickMemo+ 92 Clock 93 Calculator 94 Music 95 ThinQ 95 FM Radio 96 Audio Recorder 96 Game Launcher 97 Smart Doctor 97 LG Mobile Switch 98 App trash 98 RemoteCall Service 98 Cell Broadcast 99 Google apps 04 Settings 103 Settings 103 Network & internet 110 Connected devices 112 Sound 113 Notifications 114 Display 115 Wallpaper & theme 115 Lock scr een & security 117 Privacy 118 Location 118 Extensions 120 Apps 120 Battery 121 Storage 121 Accounts 121 Digital W ellbeing & parental controls 122 Google 122 System 126 Accessibility 5Table of contents 05 Appendix 129 LG Language Settings 129 LG Bridge 130 Phone software update 132 Anti- Theft Guide 133 Open Source Software Notice Information 133 Regulatory information (Regulation ID number, E-labeling, etc.) 134 Trademarks 135 Laser safety statement 135 DECLARATION OF CONFORMITY 136 Contact o ffice for compliance of this product 136 Wi-Fi (WLAN) 137 More information 141 FAQ 6 Guidelines for safe and efficient use Please read these simple guidelines. Not following these guidelines may be dangerous or illegal. Should a fault occur, a software tool is built into your device that will gather a fault log. This tool gathers only data specific to the fault, such as signal strength, cell ID position in sudden call drop and applications loaded. The log is used only to help determine the cause of the fault. These logs are encrypted and can only be accessed by an authorised LG Repair centre should you need to return your device for repair. Exposure to radio frequency energy Radio wave exposure and Specific Absorption Rate (SAR) information. This device has been designed to comply with applicable safety requirements for exposure to radio waves. These requirements are based on scientific guidelines that include safety margins designed to assure the safety of all persons, regardless of age and health. • The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. Tests for SAR are conducted using standardised methods with the device transmitting at its highest certified power level in all used frequency bands. • While there may be differences between the SAR levels of various LG device models, they are all designed to meet the relevant guidelines for exposure to radio waves. • The SAR limit recommended by the International Commission on Non-Ionizing Radiation Protection (ICNIRP) is 2 W/kg averaged over 10 g of tissue. • The highest SAR value for this model tested for use at the ear is X.XXX W/kg (10 g) and when worn on the body is X.XXX W/kg (10 g). • This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 5 mm away from the body. When a carry case, belt clip or holder is used for body-worn operation, it should not contain metal and should position the product at least 5 mm away from your body. In order to transmit data files or messages, this device requires a quality connection to the network. In some cases, transmission of data files or messages may be delayed until such a connection is available. Ensure the above separation distance instructions are followed until the transmission is compl…

Text truncated - open the document above for the full version.

LG Electronics USA, Inc. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (ZNFK420HMW). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics Operational Description Parts List Tune Up Block Diagram, Schematics Operational Description Parts List Tune Up The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name External Photos, Internal Photos, Test Setup Photos, Manual External Photos, Internal Photos, Test Setup Photos, Manual Planned Release Date STC: Date of Grant + 180 days Sincerely, ____ Contact Person: Kyung-Su Han E-mail: [email protected]

LG Electronics USA, Inc. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for: ZNFK420HMW To Whom It May Concern: We, the undersigned, hereby authorize Jim Huang at SGS-CSTC Standards Technical Services Ltd on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by SGS-CSTC Standards Technical Services Ltd on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ____ Contact Person: Kyung-Su Han E-mail: [email protected]

Amendment Letter TIMCO Engineering, Inc. This is to request report update for FCC ID: ZNFK420HMW The Major change filed under this application and the relevant report numbers are as below: Original report number New report number Revise content ZR/2020/6001505 ZR/2020/6001505-01 1.Modify data conversion error of antenna height in radiated emission. 2. Update equipment list in section 5. 3. Updated Support Units, Test facility and Test Location in section 1.1, 1.2, and 1.3 ZR/2020/6001501 ZR/2020/6001501-01 1.Add test site Information in section 2, 3.2 and 3.3 2. Update equipment list in section 5. 3. Updated the report NO. of appendix B in header with “-01” 4. Added antenna height and angle for ‘Field Strength of Spurious Radiation’ in appendix B ZR/2020/6001502 ZR/2020/6001502-01 1.Add test site Information in section 1, 1.2 and 1.3 2.Modify data conversion error of antenna height in radiated spurious emission and Radiated band- edge. 3.Update equipment list in section 4. ZR/2020/6001503 ZR/2020/6001503-01 1.Add test site Information in section 1, 1.2 and 1.3 2.Modify data conversion error of antenna height in radiated spurious emission and Radiated band- edge. 3.Update equipment list in section 4. ZR/2020/6001504 ZR/2020/6001504-01 1.Add test site Information in section 1, 1.2 and 1.3 2.Modify data conversion error of antenna height in radiated spurious emission and Radiated band- edge. 3.Update equipment list in section 4. Sincerely, (signature) (printed name) Simon Ling

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 External Photos FCC ID: ZNFK420HMW SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5

Description of E-Label on the LM-K420HM 1. FCC ID is applied by E-label on device. [Step1] [Step2] [Step3] FCC ID E-Label display Step 1 Select Settings Step 2 Select System Step 3 Select Regulatory & safety Description of E-Label on the LM-K420HM 2. FCC ID is applied on packaging. FCC ID : ZNFK420HMW 3. Instruction of E-label on the user manual

Description of E-Label on the LM-K420HMW 1. FCC ID is applied by E-label on device. [Step1] [Step2] [Step3] FCC ID E-Label display Step 1 Select Settings Step 2 Select System Step 3 Select Regulatory & safety Description of E-Label on the LM-K420HMW 2. FCC ID is applied on packaging. FCC ID : ZNFK420HMW 3. Instruction of E-label on the user manual

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 Internal Photos FCC ID: ZNFK420HMW SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/6001505 Appendix A Detailed System Check Results 1. System Performance Check System Performance Check 750 MHz Head System Performance Check 835 MHz Head System Performance Check 1750 MHz Head System Performance Check 1900 MHz Head System Performance Check 2450 MHz Head System Performance Check 2600 MHz Head Date: 2020-07-04 Test Laboratory: SGS-SAR Lab System Performance Check 750 MHz Head DUT: D750V3; Type: D750V3; Serial: 1160 Communication System: UID 0, CW (0); Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL750;Medium parameters used: f = 750 MHz; σ = 0.871 S/m; ε r = 43.551; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.34, 9.34, 9.34); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Body/d=15mm, Pin=250mW/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.58 W/kg Body/d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 50.48 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 3.44 W/kg SAR(1 g) = 2.13 W/kg; SAR(10 g) = 1.39 W/kg Maximum value of SAR (measured) = 2.92 W/kg 0 dB = 2.92 W/kg = 4.65 dBW/kg Date: 2020-07-08 Test Laboratory: SGS-SAR Lab System Performance Check 835 MHz Head DUT: D835V2; Type: D835V2; Serial: 4d105 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL835;Medium parameters used: f = 835 MHz; σ = 0.927 S/m; ε r = 42.883; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Body/d=15mm, Pin=250mW/Area Scan (6x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.90 W/kg Body/d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 51.17 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 3.62 W/kg SAR(1 g) = 2.4 W/kg; SAR(10 g) = 1.57 W/kg Maximum value of SAR (measured) = 3.06 W/kg 0 dB = 3.06 W/kg = 4.86 dBW/kg Date: 2020-07-13 Test Laboratory: SGS-SAR Lab System Performance Check 1750 MHz Head DUT: D1750V2; Type: D1750V2; Serial: 1149 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL1750;Medium parameters used: f = 1750 MHz; σ = 1.325 S/m; ε r = 40.439; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(7.81, 7.81, 7.81); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Body/d=10mm, Pin=250mW/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 13.8 W/kg Body/d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 85.92 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 17.1 W/kg SAR(1 g) = 9.22 W/kg; SAR(10 g) = 4.9 W/kg Maximum value of SAR (measured) = 14.2 W/kg 0 dB = 14.2 W/kg = 11.52 dBW/kg Date: 2020-07-18 Test Laboratory: SGS-SAR Lab System Performance Check 1900 MHz Head DUT: D1900V2; Type: D1900V2; Serial: 5d028 Communication System: UID 0, CW (0); Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL1900;Medium parameters used: f = 1900 MHz; σ = 1.394 S/m; ε r = 40.341; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(7.61, 7.61, 7.61); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Body/d=10mm, Pin=250mW/Area Scan (8x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 9.72 W/kg Body/d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 88.89 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 19.1 W/kg SAR(1 g) = 10. W/kg; SAR(10 g) = 5.33 W/kg Maximum value of SAR (measured) = 11.6 W/kg 0 dB = 11.6 W/kg = 10.64 dBW/kg Date: 2020-07-21 Test Laboratory: SGS-SAR Lab System Performance Check 250MHz Head DUT: D250V2; Type: D250V2; Serial: 733 Communication System: UID 0, CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL2450;Medium parameters used: f = 2450 MHz; σ = 1.824 S/m; ε r = 39.15; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(7.06, 7.06, 7.06); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1428; Calibrated: 2020-03-03 Phantom: SAM 2; Type: SAM; Serial: 1913  DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Body/d=10mm, Pin=250mW/Area Scan (9x15x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 19.8 W/kg Body/d=10mm, Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 89.71 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 23.6 W/kg SAR(1 g) = 11.8 W/kg; SAR(10 g) = 5.53 W/kg Maximum value of SAR (measured) = 19.4 W/kg 0 dB = 19.4 W/kg = 12.88 dBW/kg Date: 2020-07-24 Test Laboratory: SGS-SAR Lab System Performance Check 2600MHz Head DUT: D2600V2; Type: D2600V2; Serial: 1125 Communication System: UID 0, CW (0); Frequency: 2600 MHz;Duty Cycle: 1:1 Medium: HSL2600;Medium parameters used: f = 2600 MHz; σ = 1.977 S/m; ε r = 38.589; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(6.88, 6.88, 6.88); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detectio…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/6001505 Appendix B Detailed Test Results 1. GSM GSM850 for Head & Body GSM1900 for Head & Body 2. WCDMA WCDMA Band II for Head & Body WCDMA Band IV for Head & Body WCDMA Band V for Head & Body 3.LTE LTE Band 2 for Head & Body LTE Band 4 for Head & Body LTE Band 5 for Head & Body LTE Band 7 for Head & Body LTE Band 12 for Head & Body LTE Band 13 for Head & Body LTE Band 17 for Head & Body LTE Band 66 for Head & Body 4.WIFI WIFI 2.4G for Head & Body 5.Bluetooth Bluetooth for Head & Body Date: 2020-07-08 Test Laboratory: SGS-SAR Lab LM-K420HMW GSM 850 GSM 4 TS 190CH Right cheek DUT: LM-K420HMW; Type: Mobile handset; Serial: 356589110055771 C ommunication System: UID 0, GSM Only Communication System (0); Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium: HSL835;Medium parameters used: f = 837 MHz; σ = 0.929 S/m; ε r = 42.874; ρ = 1000 kg/m 3 Phantom section: Right Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Configuration/Head/Area Scan (8x14x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.154 W/kg Configuration/Head/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 2.635 V/m; Power Drift = 0.19 dB Peak SAR (extrapolated) = 0.170 W/kg SAR(1 g) = 0.131 W/kg; SAR(10 g) = 0.098 W/kg Maximum value of SAR (measured) = 0.153 W/kg 0 dB = 0.153 W/kg = -8.15 dBW/kg Date: 2020-07-08 Test Laboratory: SGS-SAR Lab LM-K420HMW GSM850 GSM 190CH Back side 10mm DUT: LM-K420HMW; Type: Mobile handset; Serial: 3565871 10025992 Communication System: UID 0, GSM 850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium: HSL835;Medium parameters used: f = 837 MHz; σ = 0.929 S/m; ε r = 42.874; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Configuration/Body/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.345 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.13 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 0.549 W/kg SAR(1 g) = 0.321 W/kg; SAR(10 g) = 0.196 W/kg Maximum value of SAR (measured) = 0.340 W/kg 0 dB = 0.340 W/kg = -4.69 dBW/kg Date: 2020-07-08 Test Laboratory: SGS-SAR Lab LM-K420HMW GSM850 GPRS 4TS 190CH Back side 10mm DUT: LM-K420HMW; Type: Mobile handset; Serial: 3565871 10025992 Communication System: UID 0, GSM 850 4TS; Frequency: 836.6 MHz;Duty Cycle: 1:2.075 Medium: HSL835;Medium parameters used: f = 837 MHz; σ = 0.929 S/m; ε r = 42.874; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Configuration/Body/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.550 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 19.59 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 0.897 W/kg SAR(1 g) = 0.504 W/kg; SAR(10 g) = 0.305 W/kg Maximum value of SAR (measured) = 0.530 W/kg 0 dB = 0.530 W/kg = -2.76 dBW/kg Date: 2020-07-18 Test Laboratory: SGS-SAR Lab LM-K420HMW GSM 1900 GSM 661CH Left cheek DUT: LM-K420HMW; Type: Mobile handset; Serial: 3565871 10055771 Communication System: UID 0, GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium: HSL1900;Medium parameters used: f = 1880 MHz; σ = 1.385 S/m; ε r = 40.374; ρ = 1000 kg/m 3 Phantom section: Left Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(7.61, 7.61, 7.61); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Configuration/Head/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.158 W/kg Configuration/Head/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.483 V/m; Power Drift = -0.16 dB Peak SAR (extrapolated) = 0.206 W/kg SAR(1 g) = 0.130 W/kg; SAR(10 g) = 0.081 W/kg Maximum value of SAR (measured) = 0.164 W/kg 0 dB = 0.164 W/kg = -7.85 dBW/kg Date: 2020-07-18 Test Laboratory: SGS-SAR Lab LM-K420HMW GSM1900 GSM 661CH Back side 10mm DUT: LM-K420HMW; Type: Mobile handset; Serial: 356587110025992 Communication System: UID 0, GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium: HSL1900;Medium parameters used: f = 1880 MHz; σ = 1.385 S/m; ε r = 40.374; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(7.61, 7.61, 7.61); Calibrated: 2020-05-09 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2019-09-18 Phantom: SAM 3; Type: SAM; Serial: 1912 DASY52 52.8.8(1222); SEMCAD X 14.6.13(7474) Configuration/Body/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.452 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.368 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 0.621 W/kg SAR(1 g) = 0.359 W/kg; SAR(10 g) = 0.206 W/kg Maximum value of SAR (measured) = 0.492 W/kg 0 dB = 0.492 W/kg = -3.08 dBW/kg Date: 2020-07-18 Test Laboratory: SGS-SAR Lab LM-K420HMW GSM1900 GPRS 4TS 661CH Back side 10mm DUT: …

Text truncated - open the document above for the full version.

SGS-CSTCStandardsTechnicalServicesCo.,Ltd.Xi’an Branch ReportNo.:ZR/2020/6001501 Page: 1 of 67 AppendixB GSM850&1900 SGS-CSTCStandardsTechnicalServicesCo.,Ltd.Xi’an Branch ReportNo.:ZR/2020/6001501 Page: 2 of 67 CONTENT Page 1.EFFECTIVE(ISOTROPIC)RADIATEDPOWEROUTPUTDATA.................................................................................4 1.1.TestResult...............................................................................................................................................4 2.PEAK-TO-AVERAGERATIO..............................................................…
