ZNFK510EMWMulti-band GSM/WCDMA/LTE phone with Bluetooth, Wlan, NFC mobile phone

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Mar 17, 2020
Application Purpose: Original Equipment
Date of Application: Mar 16, 2020
Equipment Note: Multi-band GSM/WCDMA/LTE phone with Bluetooth, Wlan, NFC mobile phone
Frequency Range: 2402.00000000 - 2480.00000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

MFLXXXXXXXX (1.0) Copyright ©2020 LG Electronics Inc. All rights reserved. www.lg.com ENGLISH USER GUIDE LM-K510EMW 1 About this user guide Thank you for choosing this LG product. Please carefully read this user guide before using the device for the first time to ensure safe and proper use. • Always use genuine LG accessories. The supplied items are designed only for this device and may not be compatible with other devices. • Descriptions are based on the device default settings. • Default apps on the device are subject to updates, and support for these apps may be withdrawn without prior notice. If you have any questions about an app provided with the device, please contact an LG Service Centre. For user-installed apps, please contact the relevant service provider. • Modifying the device’s operating system or installing software from unofficial sources may damage the device and lead to data corruption or data loss. Such actions will violate your LG licence agreement and void your warranty. • Some content and illustrations may differ from your device, depending on the area, service provider, software version, or OS version, and are subject to change without prior notice. • Software, audio, wallpaper, images, and other media supplied with your device are licenced for limited use. If you extract and use these materials for commercial or other purposes, you may be infringing copyright laws. As a user, you are fully responsible for the illegal use of media. • Additional charges may incur for data services, such as messaging, uploading, downloading, auto-syncing and location services. To avoid additional charges, select a data plan suitable to your needs. Contact your service provider to obtain additional details. • This user guide is written in major languages for each country. Depending on the language used, content may partly differ. ENGLISH 2About this user guide Instructional notices WARNING: Situations that could cause injury to the user and third parties. CAUTION: Situations that may cause minor injury or damage to the device. NOTE: Notices or additional information. 3 Table of contents 01 Custom-designed Features 16 Camera features 19 Gallery featur es 22 Sound quality and ef fects features 22 Google Assistant 24 Fingerprint recognition 27 Multi-tasking featur e 02 Basic Functions 29 Product components and accessories 30 Parts overview 33 Turning the pow er on or off 34 Installing the SIM card 37 Inserting the memory card 38 Removing the memory card 38 Batt ery 40 Touch scr een 44 Home screen 54 Screen lock 59 Memory c ard encryption 60 Taking screenshots 60 Entering text 65 Content sharing 03 Useful Apps 68 Installing and uninstalling apps 69 App trash 70 App Short cuts 71 Phone 75 Messaging 76 Camera 86 Gallery 90 Contacts 92 QuickMemo+ 94 Clock 96 Music 97 Calcul ator 97 ThinQ 97 Game Launcher 98 Audio Rec order 5 Guidelines for safe and efficient use 4Table of contents 99 Update centre 99 Smart Doctor 99 LG Mobile Switch 100 App trash 100 SmartWorld 101 RemoteCall Service 101 Cell Broadcast 102 Google apps 04 Settings 106 Settings 106 Network & internet 113 Connected de vices 116 Sound 117 Display 118 Lock screen & security 120 Extensions 122 Digital Wellbeing & par ental controls 122 Apps & notifications 122 Battery 123 Storage 123 Ac counts 124 Google 124 Syst em 127 Ac cessibility 05 Appendix 131 Language Settings 131 LG Bridge 132 Phone sof tware update 134 Anti-Theft Guide 135 Open Source Software Notice Information 135 Regulatory information (Regulation ID number, E-labeling, etc.) 136 Trademarks 137 DECLARATION OF CONFORMITY 137 Contact of fice for compliance of this product 138 More information 142 FAQ 5 Guidelines for safe and efficient use Please read these simple guidelines. Not following these guidelines may be dangerous or illegal. Should a fault occur, a software tool is built into your device that will gather a fault log. This tool gathers only data specific to the fault, such as signal strength, cell ID position in sudden call drop and applications loaded. The log is used only to help determine the cause of the fault. These logs are encrypted and can only be accessed by an authorised LG Repair centre should you need to return your device for repair. Exposure to radio frequency energy Radio wave exposure and Specific Absorption Rate (SAR) information. This device has been designed to comply with applicable safety requirements for exposure to radio waves. These requirements are based on scientific guidelines that include safety margins designed to assure the safety of all persons, regardless of age and health. • The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. Tests for SAR are conducted using standardised methods with the device transmitting at its highest certified power level in all used frequency bands. • While there may be differences between the SAR levels of various LG device models, they are all designed to meet the relevant guidelines for exposure to radio waves. • The SAR limit recommended by the International Commission on Non-Ionizing Radiation Protection (ICNIRP) is 2 W/kg averaged over 10 g of tissue. • The highest SAR value for this model tested for use at the ear is 0.501 W/kg (10 g) and when worn on the body is 1.335 W/kg (10 g). 6Guidelines for safe and efficient use • This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 5 mm away from the body. When a carry case, belt clip or holder is used for body-worn operation, it should not contain metal and should position the product at least 5 mm away from your body. In order to transmit data files or messages, this device requires a quality connection to the network. In some cases, transmission of data files or messages may be delayed until such a connection is available. Ensure the above separation distance instructions are followed until the transmission is completed. …

Text truncated - open the document above for the full version.

Cover Letter(s)

022818 – 11 Authority to Act as Agent Date: Jan.06.2020 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: _______ CTTL, Telecommunication Technology Labs, CAICT_______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____12 months___ By: __________________________ _____ Kyung-Su Han____ (Signature 1 ) (Print name) Title: _____ Director _____________ On behalf of: ____ LG Electronics USA, Inc __ (Company Name) Telephone: __+82-2-6946-1675________________ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 022818 – 11 Request for Confidentiality Date: _ Jan.06.2020_____ Subject: Confidentiality Request for: ______ZNFK510EMW Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 9.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☐ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term ☐ Permanent * 2 Internal Photos ☐ Short Term ☐ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☐ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term ☐ Permanent * 3 User’s Manual LG Electronics USA, Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___ 180 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: ________ / Dir ector _____ ____ Kyung-Su Han____ (Signature/Title 4 ) (Print name) 2 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 3 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Cover Letter(s)

Project NameDH35 Base ModelLM-K510BMW, LMK510BMW, K510BMW Variant ModelLM-K510EMW, LMK510EMW, K510EMW HW VersionRev.1.0 Issue Date CHANGE NOTE LM-K510EMW, LMK510EMW, K510EMW These model names are only written differences, are the same model, there is no difference LGE Internal Use Only Product Change Description 1. Base Model information -Model name: LMK510BMW -FCC ID: ZNFK510HM -Supported Band : ZNFK510EMW GSM850/900/1800/1900, WCDMA FDD B1/B2/B4/B5/B8, LTE B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B28/B38/B40/B66， 2.4 GHz Wi-Fi, 2.4GHz BT -Capability: Hotspot/VoIP, GPRS/EDGE Class12, Wi-Fi 2.4 GHz(b/g/n), BT 5.0, Wi-Fi Direct support -Nominal Target Power: GSM850/900: 33dBm, GSM1800/1900 : 30dBm, WCDMA B1/B5/B8:24dBmWCDMA B2/B4: 23.5dBm LTE B1/B3/B5/B8/B12/B13/B17/B28: 24dBm LTE B2/B4/B66 : 23.5dBm LTE B7/B38/B40: 23dBm 2. Variant Model information -Model name: LMK510EMW -FCC ID: -Supported Band : GSM850/900/1800/1900, WCDMA FDD B1/B2/B5/B8, LTE B1/B3/B7/B8/B20/B28/B38， 2.4 GHz Wi-Fi, 2.4GHz BT -Capability: Hotspot/VoIP, GPRS/EDGE Class12, Wi-Fi 2.4 GHz(b/g/n), BT 5.0 , Wi-Fi Direct support -Nominal Target Power: GSM850/900: 33dBm, GSM1800/1900 : 30dBm, WCDMA B1/B5/B8:24dBmWCDMA B2: 23.5dBm LTE B1/B3/B8/B20/B28: 24dBm LTE B7/B38 : 23dBm 3. Details HW difference -Remove Band4(66)/12(17)/40,DNI the related component without PCB change; -Band20 Tx& PRxuses Band13 HW path and DRxuses Band8 DRxHW path -Band8 DRxuses Band12 DRxHW path -Add NFC SW difference -FM not support -NFC support *Please find the change details on next page. LGE Internal Use Only Change Note Remove1(remove Band4/66) Remove Band4/66 related component( DNI component marked green without PCB change); LGE Internal Use Only Change Note Remove2(remove Band40) Remove Band40 related component( DNI component marked green without PCB change); LGE Internal Use Only Change Note Remove3(remove Band12/17) duplexer Band12/17 transmit Remove Band12/17 duplexer related component ( DNI component marked green without PCB change); Remove Band12 transmit related component (DNI component marked green without PCB change). LGE Internal Use Only Change Note Add1(add NFC) Add NFC related circuit (DNI except shielding in other sku) LGE Internal Use Only Change Note Change2(Band8/20 diversity change ) Band8 diversity path changed from green to yellow; Use diversity path marked green as Band20 diversity path. Use Band12/13/17 diversity path as Band8 diversity path. Use Band8 diversity path as Band20 diversity path. LGE Internal Use Only Change Note Change3(Use Band13 as Band20 RF path) Component marked green used as Band20 primary path. Use Band13 primary path as Band20 primary path. LGE Internal Use Only Change Note Change4(Use Band13 PA output path as Band20 PA output path ) Use Band13 PA(power amplifier ) output path as Band20 PA(power amplifier ) output path(marked green)

Cover Letter(s)

Date: Mar. 16, 20 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request permission to use GSM/UMTS/LTE/Wi-Fi/BT test results from model LM-K510BMW in our applications for model LM-K510EMW FCC ID: ZNFK510EMW To whom it may concern: We request permission to partially use GSM/UMTS/LTE/Wi-Fi /BT test results from model LM-K510BMW (FCC ID: ZNFK510HM) in our applications for model LM- K510EMW (FCC ID: ZNFK510EMW). You can find details next page: For the above, we performed full test for SAR and NFC, and partially re-used the test results of LM-K510BMW for other parts, shown as below. For details, please refer to the relevant test reports. Item Test done on the new model GSM Part GSM mobile phone FCC certification part22/24 testing on PCS1900 Radiated Output Power and Emission Limit UMTS Part UMTS mobile phone FCC certification part22 testing on WCDMA Band V Radiated Output Power and Emission Limit LTE Part LTE mobile phone FCC certification part22/27 testing on LTE Band 7 Radiated Output Power and Emission Limit BT Part BT LE with EDR FCC certification part15C testing Spot check on Output Power WiFi Part WiFi 802.11b/g/n 2.4G FCC certification part15C testing Spot check on Output Power Sincerely yours, Zi Xiaogang

External Photos

FCCID: ZNFK510EMW BL-T49_ALT BL-T49_ALT MCS-V02WR MCS-V02WR EAB64468444 DC15WB-G

ID Label/Location Info

FCC ID is applied by E-Label on the device Description of E-Label on the ZNFK510EMW Instruction of E-Label on the user manual Setting Menu Settings Step 1 System Step 2 Regulatory & Safety FCC ID is applied on packaging Label FCC ID : ZNFK510EMW

Internal Photos

FCCID:ZNFK510EMW

RF Exposure Info

©Copyright. All rights reserved by CTTL. SAR TEST REPORT No. I20Z60047-SEM02 For LG Electronics USA,Inc. Multi-band GSM/WCDMA/LTE phone with Bluetooth, Wlan, NFC mobile phone Model name: LM-K510EMW, LMK510EMW, K510EMW With FCC ID: ZNFK510EMW Issued Date: 2020-3-17 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL, Telecommunication Technology Labs, CAICT No. 51, Xueyuan Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 2 of 141 REPORT HISTORY Report Number Revision Issue Date Description I20Z60047-SEM02 Rev.0 2020-3-15 Initial creation of test report I20Z60047-SEM02 Rev.1 2020-3-17 Update the information on section 2 of test report. Update the information on section 4.1 of test report. Update the information on section 14 of test report. No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 3 of 141 TABLE OF CONTENT 1 TEST LABORATORY .................................................................................................................... 5 1.1 TESTING LOCATION ........................................................................................................................................ 5 1.2 TESTING ENVIRONMENT ................................................................................................................................. 5 1.3 PROJECT DATA ............................................................................................................................................... 5 1.4 SIGNATURE ..................................................................................................................................................... 5 2 STATEMENT OF COMPLIANCE .................................................................................................. 6 3 CLIENT INFORMATION ................................................................................................................ 7 3.1 APPLICANT INFORMATION .............................................................................................................................. 7 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 7 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................. 8 4.1 ABOUT EUT ................................................................................................................................................... 8 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................................... 8 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................................ 8 5 TEST METHODOLOGY ................................................................................................................ 9 5.1 APPLICABLE LIMIT REGULATIONS .................................................................................................................. 9 5.2 APPLICABLE MEASUREMENT STANDARDS ...................................................................................................... 9 6 SPECIFIC ABSORPTION RATE (SAR) ...................................................................................... 10 6.1 INTRODUCTION ............................................................................................................................................. 10 6.2 SAR DEFINITION .......................................................................................................................................... 10 7 TISSUE SIMULATING LIQUIDS ................................................................................................. 11 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 11 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 11 8 SYSTEM VERIFICATION ............................................................................................................ 14 8.1 SYSTEM SETUP ............................................................................................................................................. 14 8.2 SYSTEM VERIFICATION ................................................................................................................................. 15 9 MEASUREMENT PROCEDURES .............................................................................................. 16 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 16 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 18 9.3 WCDMA MEASUREMENT PROCEDURES FOR SAR ...................................................................................... 19 9.4 SAR MEASUREMENT FOR LTE ..................................................................................................................... 20 9.5 BLUETOOTH & WI-FI MEASUREMENT PROCEDURES FOR SAR .................................................................... 22 9.6 POWER DRIFT ............................................................................................................................................... 22 10 AREA SCAN BASED 1-G SAR .............................…

Text truncated - open the document above for the full version.

RF Exposure Info

No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 96 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 97 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 98 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 99 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 100 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 101 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 102 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 103 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 104 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 105 of 141

RF Exposure Info

No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 106 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 107 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 108 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 109 of 141 ANNEX H Dipole Calibration Certificate 835 MHz Dipole Calibration Certificate No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 110 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 111 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 112 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 113 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 114 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 115 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 116 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 117 of 141 1900 MHz Dipole Calibration Certificate No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 118 of 141

RF Exposure Info

No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 119 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 120 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 121 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 122 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 123 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 124 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 125 of 141 2450 MHz Dipole Calibration Certificate No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 126 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 127 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 128 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 129 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 130 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 131 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 132 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 133 of 141 2600 MHz Dipole Calibration Certificate No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 134 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 135 of 141

RF Exposure Info

No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 136 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 137 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 138 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 139 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 140 of 141 No.I20Z60047-SEM02 ©Copyright. All rights reserved by CTTL. Page 141 of 141 ANNEX I Accreditation Certificate

Test Report

©Copyright.AllrightsreservedbyCTTL. FCCPART15C TESTREPORT No.I20Z60047-IOT03 for LGElectronicsUSA,Inc. Multi-bandGSM/WCDMA/LTEphonewithBluetooth,Wlan,NFC mobilephone ModelName:LM-K510EMW,LMK510EMW,K510EMW FCCID:ZNFK510EMW IssuedDate:2020-3-13 Note: Thetestresultsinthistestreportrelateonlytothedevicesspecifiedinthisreport.Thisreportshallnotbe reproducedexceptinfullwithoutthewrittenapprovalofCTTL. Thereportmustnotbeusedbytheclienttoclaimproductcertification,approval,orendorsementbyNVLAP,NIST, oranyagencyoftheU.S.Government. TestLaboratory: CTTL,TelecommunicationTechnologyLabs,CAICT No.52,HuayuanNorthRoad,HaidianDistrict,Beijing,P.R.China100191. Tel:+86(0)10-62304633-2512,Fax:+86(0)10-62304633-2504 Email:[email protected],website:www.chinattl.com No.I20Z60047-IOT03 ©Copyright.AllrightsreservedbyCTTL. Page2of92 . REPORTHISTORY ReportNumberRevisionDescriptionIssueDate I20Z60047-IOT03Rev.01stedition2020-3-13 No.I20Z60047-IOT03 ©Copyright.AllrightsreservedbyCTTL. Page3of92 . CONTENTS 1.TESTLABORATORY................................................................................................................................5 1.1.INTRODUCTION&ACCREDITATION..........................................................................................................5 1.2.TESTINGLOCATION.................................................................................................................................5 1.3.TESTINGENVIRONMENT..........................................................................................................................6 1.4.PROJECTDATA.........................................................................................................................................6 1.5.SIGNATURE..............................................................................................................................................6 2.CLIENTINFORMATION.........................................................................................................................7 2.1.APPLICANTINFORMATION.......................................................................................................................7 2.2.MANUFACTURERINFORMATION..............................................................................................................7 3.EQUIPMENTUNDERTEST(EUT)ANDANCILLARYEQUIPMENT(AE)...................................8 3.1.ABOUTEUT............................................................................................................................................8 3.2.INTERNALIDENTIFICATIONOFEUT........................................................................................................8 3.3.INTERNALIDENTIFICATIONOFAE...........................................................................................................8 3.4.NORMALACCESSORYSETTING................................................................................................................9 3.5.GENERALDESCRIPTION...........................................................................................................................9 4.REFERENCEDOCUMENTS..................................................................................................................10 4.1.DOCUMENTSSUPPLIEDBYAPPLICANT..................................................................................................10 4.2.REFERENCEDOCUMENTSFORTESTING.................................................................................................10 5.TESTRESULTS.........................................................................................................................................11 5.1.SUMMARYOFTESTRESULTS.................................................................................................................11 5.2.STATEMENTS..........................................................................................................................................11 5.3.EXPLANATIONOFRE-USEOFTESTDATA...............................................................................................11 6.TESTFACILITIESUTILIZED...............................................................................................................12 7.MEASUREMENTUNCERTAINTY.......................................................................................................13 7.1.PEAKOUTPUTPOWER-CONDUCTED...................................................................................................13 7.2.FREQUENCYBANDEDGES-CONDUCTED.............................................................................................13 7.3.FREQUENCYBANDEDGES-RADIATED................................................................................................13 7.4.TRANSMITTERSPURIOUSEMISSION-CONDUCTED...............................................................................13 7.5.TRANSMITTERSPURIOUSEMISSION-RADIATED..................................................................................13 7.6.TIMEOFOCCUPANCY(DWELLTIME)....................................................................................................13 7.7.20DBBANDWIDTH................................................................................................................................14 7.8.CARRIERFREQUENCYSEPARATION......................................................................................................14 7.9.ACPOWERLINECONDUCTEDEMISSION...............................................................................................14 ANNEXA:DETAILEDTEST…

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)

[email protected]201-266-2215Fax: 201-816-2003

Technical Contact

CTTL-Terminals Test Lab of China Academy of TelecXue Zhen

[email protected]86-10-62304633

No. 52, Huayuan Bei Road, Haidian District, · Beijing · China

Test Firm

Telecommunication Technology Labs, CAICTYaqin Shen

[email protected]8610-62304633Fax: 8610-62300586

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	5.10 mW

Confidentiality

Long Term

Grant Notes

Power output listed is conducted. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device also contains BLE, NFC, WLAN 2.4GHz and GSM/WCDMA/LTE transmitters.
