ZNFKS1301Portable Handset with Multi-band GSM/EDGE, WCDMA, WLAN, RFID and BT

MBMXXXXXXXX KS1301_LGL23 ii Preface Thank you for buying the "LGLxx" (simply called the "product" from here on). Before using the product, be sure to read the "Basic Manual" (this manual) or "Full Instruction Manual" (Japanese only) to ensure correct use. After you have finished reading this manual, be sure to store it in a safe place so that you can retrieve it whenever needed. If you lose the "Basic Manual" (this manual), contact an au shop or Customer Service Center. About Operating Instructions ■■"Basic■Manual"■(this■manual) Handles only basic operations for main features. For detailed descriptions of various functions, refer to the "Instruction Manual" application that can be used on your product or "Full Instruction Manual" (Japanese only) on au website: http://www.au.kddi.com/torisetsu/index.html • All company names and product names in this manual are either trade marks or registered trade marks. ■■"Instruction■Manual"■Application■(Japanese■only) You can use the "Instruction Manual" application on this product to check detailed operational procedures. Certain functions can be directly activated from the application screens on which their operations are described. ■● Steps a Home■screen■u■"Apps"■u■"Security/Support"■u■■ "取扱説明書■(Instruction■Manual)" • When using the application for the first time, you must download and install it following the on-screen instructions. ■■Downloading■Instruction■Manual You can download "Basic Manual" (this manual), "Setting Guide" and "Full Instruction Manual" (Japanese only) from au website. http://www.au.kddi.com/torisetsu/index.html 1 Safety Precautions Before you start using this product, be sure to read the "Safety Precautions" to ensure correct use. Before you assume that the product is malfunctioning, be sure to read "Troubleshooting" in this manual and check for possible remedies. Check for possible remedies in the following au Customer Support site of au website. http://cs.kddi.com/support/komatta/kosho/index.html When Using This Product • Communication is not possible even inside the service area in places where the signal does not reach (e.g. tunnels and basements). Also, communication is sometimes not possible in poor reception areas. Communication is sometimes interrupted if you move into a poor reception areas during communications. • Since this product uses radio waves, the possibility of communication intercepts by third parties cannot be eliminated. (Though LTE/CDMA/GSM system has highly secure confidential communication features.) • The product is compatible with the international roaming service. Each network service described in this manual varies depending on the area and service content. • Since this product is a radio station under the Radio Law, you may be asked to temporarily submit the product for inspection in accordance with the Radio Law. • When the au Micro IC Card (LTE) is inserted in your cell phone, the IMEI information of the cell phone is automatically sent to KDDI CORPORATION for maintenance and monitoring operational status of your cell phone. • If you are using the product overseas, please check the relevant laws and regulations of the country/region that you visit. 2 Cell■phone■etiquette! • Take care not to inconvenience people around you when you use the product in a public place. • When the product is used by a child, guardians should thoroughly read the "Basic Manual" (this manual) and teach the child how to use it. • Do not talk on the phone loudly. • Ask for permission of other people before taking pictures of them with this cell phone. • The same to PC, depending on the application you install, the operation of your product may get unstable, or your location information and other personal information registered in the product may get revealed and abused via Internet. Make sure to confirm the source and the operation conditions of the application you use. Take■care■of■people■around■you! • Turn the product off in crowded trains or other crowded places, since there may be people with a cardiac pacemaker nearby. • When a medical institution has laid down designated areas where use of the product is prohibited or is not allowed to be brought in, abide by the instructions of that medical institution. Use■of■the■product■is■not■allowed■in■the■ following■places! • Do not use a cell phone while driving a car or riding a motorbike or bicycle. It may cause a traffic accident. Use of a cell phone while driving a car or motorbike is prohibited by law. Use of a cell phone while riding a bicycle may be punishable by some regulations. • Do not use the product while you are aboard an airplane. Use of electric devices transmitting radio waves in airplane is prohibited by law. Some airline companies, however, allow their passengers to use cell phones. For details, contact the airline company you use. 3 List of Packaged Items Before you start using the product, make sure that you have all the following packaged with the product. ●Main unit（Including the rear cover） ●Desktop holder（LGLxxPUA） • Provided with the detachable phone guide ●設定ガイド (Setting Guide) (Japanese) ●取扱説明書 (Instruction Manual) (Japanese) ●保証書 (Warranty) (Japanese only) The following items are not included in the package. ●Earphones ●microUSB cable ●AC adapter ●microSD memory card • Purchase a specified charger (sold separately). • Reproduction of the content of this manual in part or in whole is prohibited. • The content of this manual is subject to change without notice. • Every effort has been made in the preparation of this manual. Should you notice any unclear points, omissions, etc., feel free to contact us. • Wrong page order or missing pages will be replaced. • Illustrations of cell phones in this manual are only for reference. They may look different from the actual product. 4 Contents Preface .................................................................................ii About Operating Instructions ................................................i…

Text truncated - open the document above for the full version.

31 Safety ■ Precautions ■■Precautions■on■charging The supplied and optional accessories are not waterproof. Be sure to check the following points before and after charging. • Never charge the battery if the main unit is wet. Doing so might cause electric shock or short circuit resulting in fire or a fault. • Check that the main unit is not wet. If you are charging the battery just after the product gets wet, drain water well and wipe remaining water off with a clean dry cloth before connecting it to the specified charging equipment (sold separately) or the desktop holder. • Do not touch the specified charging equipment (sold separately) or desktop holder with wet hands. Doing so might cause electric shock. • Do not splash water over the specified charging equipment (sold separately) and desktop holder when using them. Do not use them near water such as in a bathroom, shower room, kitchen or washroom. Doing so might cause fire, electric shock or a fault. Do not bring them into a bathroom, etc. even when you are not charging with them. Notes on Using Bluetooth ® / Wireless LAN Functions • The Bluetooth ® function and the wireless LAN function of this product conforms to the domestic standards of Japan, FCC standards, and EC directives, and has been certified. • The 2.4 GHz band used by wireless LAN and Bluetooth ® devices is shared by various other devices. For this reason, the communication speed and connectable range may be decreased, or disconnection may occur, due to interference by other devices. • Do not use this product in places where electromagnetic waves are generated or near electric products, AV and OA equipment, or other magnetized devices. • Subjecting this product to magnetic or electrical noise might increase noise and prevent it from performing communications. (This product is particularly susceptible to noise when it used near a microwave oven.) • Using this product near a TV, radio or similar appliance might cause reception interference and disrupt TV images. • Searching might not be successful if there are multiple wireless LAN access points near to the product or the same channel is being used. • The wireless LAN function cannot be used in airplane. Be sure to turn off the power even in a Wi-Fi compliant airplane. Some airline companies, however, allow their passengers to use cell phones. For details, contact the airline company you use. • The communication speed and connectable range vary depending on the distance between communication devices, obstacles and the Bluetooth ® devices used. 32 Safety ■ Precautions 2.4■GHz■Frequency■Band■Precautions The frequencies used by the Bluetooth ® and/or wireless LAN function of this product are in the 2.4 GHz band. In this frequency band, other similar wireless stations, in-plant wireless stations for mobile unit identification that require a license for use, such as factory production lines, specific small power wireless stations that do not require licenses, amateur wireless stations (collectively called "other wireless stations" from here on) are operated in addition to home electrical appliances such as microwave ovens, devices for industrial, scientific and medical devices. 1. Before using the product, make sure that "other wireless stations" are not in operation nearby. 2. In the event that instances of radio wave interference have occurred between this product and "other wireless stations", immediately either relocate this product or stop operation of the device (stop emission of radio waves). 3. If you are unclear on any points or are troubled by anything, contact an au shop or Customer Service Center. Bluetooth ® and wireless LAN functions of this product use frequencies in the 2.4 GHz band. • Bluetooth ® function: 2.4FH1 This product uses the 2.4 GHz band. FH-SS is used as the modulation scheme. The interference distance is about 10 m or less. • Wireless LAN function: 2.4DS/OF4 This product uses the 2.4 GHz band. DS-SS and OFDM are used as the modulation schemes. The interference distance is about 40 m or less. • Bandwidth to use: Full band This means that full band can be used, and that bands of mobile unit identification devices can be avoided. • Available channels differ depending on the country. • For use in airplane, check with the airline company in advance. ■ ■■ ■ 33 Safety ■ Precautions • Connections between this product and all other Bluetooth ® and wireless LAN devices have not been confirmed. Therefore, connections with all Bluetooth ® and wireless LAN devices are not guaranteed. • This product supports security features for wireless communications that are compliant with the Bluetooth ® and wireless LAN standard specifications, but the security may not be sufficient depending on the usage environment and configuration. Be careful when making data communication using Bluetooth ® or wireless LAN function. • Wireless LAN has the advantage that it can be freely connected anywhere within the radio wave range, as it uses radio waves for exchanging information. At the same time, there is a risk that a malicious third party may obtain unauthorized access if security settings have not been configured. You are recommended to configure security settings before using wireless LAN at your decision and responsibility. • The Company assumes no responsibility for leakage of data or information that may occur during Bluetooth ® / wireless LAN communication. • Since Bluetooth ® and wireless LAN functions use the same frequency band, using the both functions at the same may cause radio wave interference resulting in decreased communication speed or disconnection from the network. If connection fails, stop using either of the Bluetooth ® and wireless LAN functions. Notes on Packet Communication Charge • Since constant Internet connection is possible with this product, packet communication may be performed automatically by some applications, resulting in high packet communication charges. Therefore, subscription to a packet comm…

Text truncated - open the document above for the full version.

61 Applications Starting an Application a Home■screen■u■"Apps" b Tap■an■icon The tapped application starts. Icons stored in a folder can be displayed by tapping on the folder. Main Applications The■preinstalled■applications■are■shown■as■below. IconApplicationOverview Friends Note"Friends Note" can manage Native Address Book of your phone and multiple social networking services in just one application. auスマートパス (au Smart Pass) You can enjoy as many applications as you want from among over 500 apps by ¥390 (including tax) per month! Also coupons, presents, photo storage and security apps are available. Please enjoy your safety and comfortable smartphone life! au MarketYou can install Android-based applications offered with au Smart Pass service. LISMO PlayerPlays music or checks information on the music using the LISMO Player. Moreover, try listening it and purchase the investigated music. au Wi-Fi 接続ツール (au Wi-Fi connection tool) Connects to a Wi-Fi network easily in an area where au Wi-Fi SPOT is available. Also, you can set Wi-Fi ® easily with a wireless LAN (Wi-Fi ® ) access point on which “Simple connection” is available. リモートサポート (Remote Support) Call for technical supports on the phone operations by sharing the screen that you are watching with au operators. 3LM SecurityLock the product's operations remotely in case of loss of your product. FacebookAccess Facebook. GREE MARKETThis application allows you to browse games and other content provided by GREE. You do not need a GREE account in order to use this application. 62 Applications Using au Disaster Countermeasure Application au災害対策■(au■Disaster■Countermeasure)■application■ enables■you■to■use■Disaster■Message■Board,■Emergency■ Rapid■Mail■(Earthquake■Early■Warnings,■Disaster■and■ Evacuation■Information,■tsunami■warnings),■and■Disaster■ Voice■Messaging■Service. a Home■screen■u■"Apps"■u■"Security/Support"■u■ "au災害対策■(au■Disaster■Countermeasure)" au disaster countermeasure menu is displayed. Using■Disaster■Message■Board Disaster Message Board is a service that enables people to register their safety information from disaster areas via LTE NET when large-scale disaster such as earthquake with intensity of over 6 lower occurs. Registered safety information can be confirmed from au phones, other company's phones, and PCs. For details, refer to "災害用伝言板サービス (Disaster Message Board service)" on au website. a "au災害対策■(au■Disaster■Countermeasure)"■u■■ "災害用伝言板■(Disaster■Message■Board)" Follow the on-screen instructions to register and confirm. • An e-mail address (@ezweb.ne.jp) is required to register safety information. Set up e-mail address beforehand. For details on settings of an e-mail address, refer to "Setting Guide". • While wireless LAN (Wi-Fi ® ) is connected, deleting and changing the settings of safety information e-mail is not available. 63 Applications Using■Emergency■Rapid■Mail The Emergency Rapid Mail is a service that distributes Earthquake Early Warning and tsunami warnings provided by Japan Meteorological Agency, or Disaster and Evacuation Information provided by national/local governments to all au cell phones in specified areas simultaneously. The "受信設定 (receiving setting)" for Emergency Rapid Mail (Earthquake Early Warning or Disaster and Evacuation Information) is set to "受信する (receive)" at the time of purchase. The "受信設定 (receiving setting)" for tsunami warnings can be set on the "災害・避難情報(Disaster and Evacuation Information)". When you receive Earthquake Early Warning, ensure your safety and take proper action according to the situation around you. When you receive tsunami warnings, leave sea coast immediately and evacuate to safe places such as hills and substantial tall buildings. a "au災害対策■(au■Disaster■Countermeasure)"■u■■ "緊急速報メール■(Emergency■Rapid■Mail)" Inbox is displayed. Select a mail to view detailed information. 削除■(Delete) Delete a received mail. 設定■ (Setting) 受信設定■ (Receive■ option■ setting) 緊急地震速報■(Earthquake■Early■ Warning): Set if receive Earthquake Early Warning. 災害・避難情報■(Disaster■and■ Evacuation■Information): Set if receive Disaster and Evacuation Information and tsunami warnings. 設定■ (Setting) 通知設定■ (Notification■ settings) 音量■(Volume): Set ringtone volume when receiving a mail. バイブ■(Vibrator): Set if enable vibrator when receiving a mail. マナー時の鳴動■(Linkage■to■manner■ mode): Set if make a notification by manner mode (sets Sound profile to "Vibrate only" or "Silent") while manner mode is on. 受信音／■ バイブ確認■ (Confirm■ ringtone■/ vibrator) 緊急地震速報■(Earthquake■Early■ Warning): Confirm ringtone/vibrator for Earthquake Early Warning. 災害・避難情報■(Disaster■and■ Evacuation■Information): Confirm ringtone/vibrator for Disaster and Evacuation Information and tsunami warnings. • Reception of Emergency Rapid Mail is notified by a special warning tone. The warning tone cannot be changed. • Earthquake Early Warning is sent to areas where strong quakes (over 4 degrees) are expected when earthquakes whose maximum intensity is predicted of 5 lower or more degrees. • Immediately after an earthquake occurs, quakes (P waves and initial tremors) near the epicenter are detected and position, scale, and expected strength are automatically calculated and notification is sent as soon as possible within a few seconds to tens of seconds before the strong quakes (S waves and major tremors) caused by the earthquake start. • Earthquake Early Warning may not arrive before strong tremors in areas near the epicenter. 64 Applications • Tsunami warning notifies tsunami warnings (major tsunami, tsunami) provided by Japan Meteorological Agency to area including the target sea coasts. • Disaster and Evacuation Information is a service that distributes bulletins concerning residents' safety including evacuation advisories, evacuation orders and other warnings issued by the national and local governments. • This service is available only in Japan (it cannot be used overseas). • No information fee or communication charge is required for receiving Emerge…

Text truncated - open the document above for the full version.

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: October 28, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakl and Mills Road, Columbia, MD 21046 RE: Requ est of Confide ntiality for FCC ID: ZNFKS1301 Equipment Class: JBP: Part 1 5 Class B Computing Device Peripheral To Whom It May Concer n: Pursu ant to Sections 0.457 and 0.459 of t he Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics MobileComm USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade se crets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics MobileComm USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jacob Cho Director On behalf of LG Electronics MobileComm U.S.A, Inc. LG Electronics MobileComm U.S.A 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 7 EXTERNAL PHOTOGRAPHS FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 7 ■ EXTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 7 ■ EXTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 7 ■ EXTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 7 ■ EXTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 7 ■ EXTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 7 ■ EXTERNAL PHOTO

※ KS1301 FCC ID Label Form LG Electronics KS1301 FCC ID: ZNFKS1301 Top Bottom Top * FCC ID is printed on the bottom of device The FCC ID shown will be readily visible at the time of purchase because it's printed on the bottom of the device.

FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 INTERNAL PHOTOGRAPHS FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ Main Antenna INTERNAL PHOTO Main Antenna FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ BT&WLAN Antenna_INTERNAL PHOTO BT / WiFi Antenna FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO FCC ID: ZNFKS1301 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page of 24 ■ INTERNAL PHOTO

FCC ID: ZNFKS1301 Report No.: HCTE1310FE06 Date: October 23, 2013 HCT CO., LTD. 74, SEOICHEON-RO, 578BEON-GIL, MAJANG-MYEON, ICHEON-SI, GYEONGGI-DO, KOREA TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr Page 2 of 19 DOCUMENT HISTORY The revision history for this document is shown in table. Version Date Description HCTE1310FE06 October 23, 2013 Initial Release FCC ID: ZNFKS1301 Report No.: HCTE1310FE06 Date: October 23, 2013 HCT CO., LTD. 74, SEOICHEON-RO, 578BEON-GIL, MAJANG-MYEON, ICHEON-SI, GYEONGGI-DO, KOREA TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr Page 3 of 19 TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION ....................................................................................................... 4 1.1 Product Description ................................................................................................................. 4 1.2 Related Submittal(s) / Grant(s)................................................................................................ 4 1.3 Tested System Details.............................................................................................................. 5 1.4 Cable Description .................................................................................................................... 6 1.5 Noise Suppression Parts on Cable. (I/O cable) ....................................................................... 6 1.6 Test Methodology .................................................................................................................... 7 1.7 Test Facility ............................................................................................................................. 7 1.8 Frequency Range of Radiated Measurements ......................................................................... 7 2. SYSTEM TEST CONFIGURATION ........................................................................................... 8 2.1 Configuration of Test System .................................................................................................. 8 3. PRELIMINARY TEST ................................................................................................................. 9 3.1 Conducted Emission Test ........................................................................................................ 9 3. 2 Radiated Emission Test .......................................................................................................... 9 4. CONDUCTED AND RADIATED EMISSION TEST SUMMARY ......................................... 10 4.1 Conducted Emission Test ...................................................................................................... 10 4.2 Radiated Emission Test ......................................................................................................... 11 5. FIELD STRENGTH CALCULATION ...................................................................................... 17 6. TEST EQUIPMENT ................................................................................................................... 18 7. CONCLUSION .......................................................................................................................... 19 ATTACHMENT: TEST SETUP PHOTOGRAPHS FCC ID: ZNFKS1301 Report No.: HCTE1310FE06 Date: October 23, 2013 HCT CO., LTD. 74, SEOICHEON-RO, 578BEON-GIL, MAJANG-MYEON, ICHEON-SI, GYEONGGI-DO, KOREA TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr Page 4 of 19 1. GENERAL INFORMATION 1.1 Product Description Equipment Under Test is EUT type: Cellular/PCS GSM/ GPRS/EDGE, Cellular WCDMA/ HSDPA/HSUPA Phone with Bluetooth/WLAN/NFC, Model: KS1301 manufactured by LG Electronics MobileComm U.S.A., Inc. Its basic purpose is used for communications. Model Name KS1301 FCC ID ZNFKS1301 EUT Type Cellular/PCS GSM/ GPRS/EDGE, Cellular WCDMA /HSDPA/HSUPA Phone with Bluetooth/WLAN/NFC TX Frequency 824.20 ㎒ to 848.80 ㎒ (GSM 850) 1 850.20 ㎒ to 1 909.80 ㎒ (GSM 1 900) 826.40 ㎒ to 846.60 ㎒ (WCDMA 850) RX Frequency 869.20 ㎒ to 893.80 ㎒ (GSM 850) 1 930.20 ㎒ to …
