ZNFL85CCellular/PCS CDMA Phone with WLAN and Bluetooth

User Manual L85C Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 0.79 inches (2cm ) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79 inches (2cm ) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain 0.79 inch (2cm ) separation distance between the user’s body and t he b ack of the phone, and have not been tested for typical body-worn operations may not comply with FCC RF exposure limits and should be avoided. FCC Part 15.19 statement This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that cause undesired operation. FCC Part 15.21 statement Changes or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. FCC Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules . These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be d etermined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Getting Started View of Phone 1. PWR/Lock Switch: Lets you power the phone on or off. 2. Antenna: Retractable antenna provides optimum reception for 800 MHz & 1900 MHz frequencies. 3. Headset Jack: Provides connection for an optional headset. 4. Volume Control Keys: Adjust the Ring Volume in the Main Menu or the Voice Volume during a call. The keys also scroll through mouths in the Calendar or pages in the MiniBrowser. 5. Menu: Show menus that is associated with a current activity 6. Home: Returns to the main home screen 7. Back: Lets you clear an entry or back-up in the menu. 8. Search: Brings up the search function Installing and Removing the Battery To install the battery, insert the bottom of the battery into the opening on the back of the phone. Then, push the battery down until the latch clicks. To remove the battery, press down on the latch and remove the battery from the phone. Turning Your Phone On and Off To turn your phone on, push the PWR/Lock Switch (near the antenna) until a logo shows on the display. Your phone performs a short self-test before letting you know it is operational. If your phone does not turn on, make sure the battery is installed correctly and is adequately charged or has external power (via the AC Adapter, Cigarette Lighter Adapter or Hands-Free Car Kit). To turn your phone off, push the PWR/Lock Switch until a pop-up message shows, then choose the menu “Power Off” and “OK”. Main Menu When your phone acquires Service, the Greeting (a banner of text), the current time and date and the Main Menu are displayed. If you are in authorized digital cellular provider’s service area, you are ready to send and receive calls. Power Save Mode When the phone is in an area without service for 15 minutes, it stops searching for service and enters into the power Save Mode. When your phone activates this feature, Power Save is displayed on your screen. The phone automatically checks for service periodically or you can check manually by pressing any key. Entering Characters Using the Keypad To enter a letter, punctuation or number when creating Contacts or Scheduler entries, press the corresponding key on the screen keyboard. By default, the first letter of a word is capitalized and following letters are lowercase. Characters in the following layout: 1) Letters 2) Numbers If you make a mistake, press to erase a character. To clear the entire entry, press and hold .7 Press to switch the layout from Letters to Numbers. Press to switch the layout from Numbers to Letters. Display Icons Display icons are the symbols your phone uses to communicate important information. They are as follows: ICON DESCRIPTION Alarm Battery Antenna No service In use Voice Privacy TTY Using Your Phone Placing a Call When the phone is on, Signal strength icon on the display shows that whether you are in a Service Area or not. The area may include an authorized PCS CDMA provider’s service area. 1. At Home Screen or Menu Screen. 2. Touch Phone 3. At Phone Screen, Enter digits. 4. Touch Send key. 5. Dialing 6. If you want call end, press MENU key and Touch Call End or press Power PWR/Lock key on top of phone Roaming With Your Phone Your Phone is you can use it to make and receive calls in many places. Calling Experience When you use your phone on other PCS CDMA networks, your calling experience and call quality will be quite similar to what you experience when making calls within the Network. Although certain calling features may not be available, your phone calls are still private and secure. Correcting Dialing Mistakes To delete one digit at a time, press . To delete all digits, press and hold . Rediali…

Text truncated - open the document above for the full version.

Date: August 17 2011 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LGElectronicsMobileCommUSA Date: August 17, 2011 SUBJECT:LGElectronicsMobileCommU.S.A FCC ID: ZNFL85C Part 20.19 Certification To Whom It May Concern: The following are the model designations and their associated key features for this FCC ID, according to requirement in the TCB Guidance issued on June 20, 2008. FCC ID: ZNFL85C Air Interfaces: CDMA Wireless Technologies: EVDO Bands: CDMA835/PCS1900 Bluetooth/WiFi Should you have any questions or comments concerning the above Key Features: Bluetooth/WiFi MP3 player, Camera A-GPS Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Christopher Johnson Senior Manager LG Electronics USA

Date: August 17, 2011 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: LG Electronics Mobilecomm U.S.A FCC ID: ZNFL85C Part 20.19 Certification Gentlemen: We, LG Electronics MobileComm USA, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Christopher Johnson Senior Manager LG Electronics USA LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

          !"# Date: August 17#1 Federal Communications Commission Authorization and Evaluation Division 7435 Oakl and Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ZNFL85C Equipment Class:%&%  '  (  )  To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act,  MobileComm hereby requests confide ntiality and treatment of certain informatio n accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for * days after the grant as outlined in Public Notice DA 04-1705. This provision will give  MobileComm temporary confidentiality of comme rcially sensitive information prio r to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: %+,'-./+'0'+,/12-'22' 3) 4 - 5  1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure %+,' 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos ./+'0'+, 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Christopher Johnson Senior Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG MobileComm FCC ID: ZNFL85C Model: L85C External Photos EUT Type: Portable Handset Page 1 of 4 © 2011 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG MobileComm FCC ID: ZNFL85C Model: L85C External Photos EUT Type: Portable Handset Page 2 of 4 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C External Photos EUT Type: Portable Handset Page 3 of 4 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C External Photos EUT Type: Portable Handset Page 4 of 4 © 2011 PCTEST Engineering Laboratory Inc.

Model No: L85C FCC ID : ZNFL85C S/N : Made in Korea LG Electronics MobileComm U.S.A Inc. LGE

LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 1 of 11 © 2011 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 2 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 3 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 4 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 5 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 6 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 7 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 8 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 9 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 10 of 11 © 2011 PCTEST Engineering Laboratory Inc. LG MobileComm FCC ID: ZNFL85C Model: L85C Internal Photos EUT Type: Portable Handset Page 11 of 11 © 2011 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC ID: ZNFL85C SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1108221459.ZNF 08/22/11 - 08/31/11 Portable Handset Page 1 of 35 © 2011 PCTEST Engineering Laboratory, Inc. REV 9.3M 08/28/2011 Applicant Name: Date of Testing: LG Electronics MobileComm U.S.A., Inc. 08/22/11 - 08/31/11 10101 Old Grove Road, Test Site/Location: San Diego, CA 92131 PCTEST Lab, Columbia, MD, USA USA Test Report Serial No.: 0Y1108221459.ZNF FCC ID: ZNFL85C APPLICANT: LG ELECTRONICS MOBILECOMM U.S.A., INC. EUT Type: Portable Handset Application Type: Certification FCC Rule Part(s): Model(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [June 2001] L85C, LGL85C, LG-L85C Test Device Serial No.: Pre-Production [S/N: SAR #1] 1 gm Head (W/kg) 1 gm Body-Worn (W/kg) Cell. CDMA/EvDO824.70 - 848.31 MHz24.580.720.93 PCS CDMA1851.25 - 1908.75 MHz24.230.980.37 2.4 GHz WLAN2412 - 2462 MHz15.340.590.05 Bluetooth2402 - 2480 MHz10.70 SAR Band & ModeTx Frequency Conducted Power [dBm] All models are confirmed to be electrically identical per the manufacturer. This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com SAR COMPLIANCE EVALUATION REPORT Reviewed by: FCC ID: ZNFL85C SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1108221459.ZNF 08/22/11 - 08/31/11 Portable Handset Page 2 of 35 © 2011 PCTEST Engineering Laboratory, Inc. REV 9.3M 08/28/2011 TABLE OF CONTENTS 1 INTRODUCTION ............................................................................................................................. 3 2 TEST SITE LOCATION ................................................................................................................... 4 3 SAR MEASUREMENT SETUP ....................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM .................................................................................................. 7 5 PROBE CALIBRATION PROCESS ................................................................................................ 8 6 PHANTOM AND EQUIVALENT TISSUES...................................................................................... 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................... 10 8 DEFINITION OF REFERENCE POINTS ...................................................................................... 11 9 TEST CONFIGURATION POSITIONS ......................................................................................... 12 10 FCC RF EXPOSURE LIMITS........................................................................................................ 15 11 FCC 3G MEASUREMENT PROCEDURES .................................................................................. 16 12 SAR TESTING WITH IEEE 802.11 TRANSMITTERS .................................................................. 19 13 SYSTEM VERIFICATION.............................................................................................................. 22 14 SAR DATA SUMMARY ................................................................................................................. 24 15 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS......................................................... 29 16 EQUIPMENT LIST......................................................................................................................... 31 17 MEASUREMENT UNCERTAINTIES ............................................................................................ 32 18 CONCLUSION............................................................................................................................... 33 19 REFERENCES .............................................................................................................................. 34 Reviewed by: FCC ID: ZNFL85C SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1108221459.ZNF 08/22/11 - 08/31/11 Portable Handset Page 3 of 35 © 2011 PCTEST Engineering Laboratory, Inc. REV 9.3M 08/28/2011 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices. [1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz [3] and Health Canada RF Exposure Guidelines Safety Code 6 [24]. The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measu…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: ZNFL85C FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1108221456.ZNF 08/30/2011 Portable Handset Page 1 of 37 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.3CFI 10/26/2010 Applicant Name: Date of Testing: LG Electronics MobileComm U.S.A., Inc. 08/30/2011 10101 Old Grove Road, Test Site/Location: San Diego, CA 92131 PCTEST Lab., Columbia, MD, USA USA Test Report Serial No.: 0Y1108221456.ZNF FCC ID: ZNFL85C APPLICANT: LG ELECTRONICS MOBILECOMM U.S.A., INC. Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §22(H), §24(E) IC Specification(s): RSS-132 Issue 2; RSS-133 Issue 5 EUT Type: Portable Handset Model(s): L85C, LGL85C, LG-L85C Tx Frequency Range: 824.70 - 848.31MHz (Cell. CDMA) / 1851.25 - 1908.75MHz (PCS CDMA) Max. RF Output Power: 0.204 W ERP Cell. CDMA (23.09 dBm), 0.54 W EIRP PCS CDMA (27.32 dBm) Emission Designator(s): 1M27F9W (CDMA) / 1M27F9W (PCS) MEID: identical prototype [MEID: 268435460901444000] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com MEASUREMENT REPORT FCC Part 22 & 24 / IC RSS-132/RSS-133 Reviewed by: FCC ID: ZNFL85C FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1108221456.ZNF 08/30/2011 Portable Handset Page 2 of 37 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.3CFI 10/26/2010 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT...........................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.3 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 MEASUREMENT PROCEDURE......................................................................................................... 6 3.2 OCCUPIED BANDWIDTH ................................................................................................................... 6 3.3 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.4 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 7 3.5 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.6 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.7 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.8 RADIATED POWER AND RADIATED SPURIOUS EMISSIONS ........................................................ 8 3.9 PEAK-AVERAGE RATIO ..................................................................................................................... 8 3.10 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 EFFECTIVE RADIATED POWER OUTPUT DATA ........................................................................... 12 6.3 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA .................................................... 13 6.4 CELLULAR CDMA RADIATED MEASUREMENTS........................................................................... 14 6.5 PCS CDMA RADIATED MEASUREMENTS...................................................................................... 17 6.6 CELLULAR CDMA FREQUENCY STABI…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: ZNFL85C HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0Y1108221460.ZNF 8/29/2011 Cellular/PCS CDMA/EVDO Phone with BT and WLAN Page 1 of 76 © 2011 PCTEST Engineering Laboratory, Inc. REV 8.4C 08/10/10 Applicant Name: Date of Testing: LG Electronics MobileComm U.S.A., Inc. 8/29/2011 10101 Old Grove Road, Test Site/Location: San Diego, CA 92131 PCTEST Lab, Columbia, MD, USA USA Test Report Serial No.: 0Y1108221460.ZNF FCC ID: ZNFL85C APPLICANT: LG ELECTRONICS MOBILECOMM U.S.A., INC. Application Type: Certification FCC Rule Part(s): § 20.19(b) HAC Standard: ANSI C63.19-2007 §6.3(v), §7.3(v); EUT Type: Cellular/PCS CDMA/EVDO Phone with BT and WLAN Model(s): L85C, LGL85C, LG-L85C Tx Frequency: 824.70 - 848.31 MHz (Cellular CDMA) 1851.25 - 1908.75 MHz (PCS CDMA) Test Device Serial No.: Pre-Production Sample [S/N: HAC RFE] C63.19-2007 HAC Category: M4 (RF EMISSIONS CATEGORY) This wireless portable device has been shown to be hearing-aid compatible under the above rated category, specified in ANSI/IEEE Std. C63.19-2007 and had been tested in accordance with the specified measurement procedures. Hearing-Aid Compatibility is based on the assumption that all production units will be designed electrically identical to the device tested in this report. Test results reported herein relate only to the item(s) tested and are for North American Bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com HEARING AID COMPATIBILITY Reviewed by: FCC ID: ZNFL85C HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0Y1108221460.ZNF 8/29/2011 Cellular/PCS CDMA/EVDO Phone with BT and WLAN Page 2 of 76 © 2011 PCTEST Engineering Laboratory, Inc. REV 8.4C 08/10/10 TABLE OF CONTENTS 1. INTRODUCTION ............................................................................................................................. 3 2. TEST SITE LOCATION ................................................................................................................... 4 3. EUT DESCRIPTION ........................................................................................................................ 5 4. ANSI/IEEE C63.19 PERFORMANCE CATEGORIES..................................................................... 6 5. SYSTEM SPECIFICATIONS...........................................................................................................7 6. TEST PROCEDURE ..................................................................................................................... 13 7. SYSTEM CHECK .......................................................................................................................... 15 8. MODULATION FACTOR...............................................................................................................18 9. FCC 3G MEASUREMENTS .......................................................................................................... 20 10. OVERALL MEASUREMENT SUMMARY ..................................................................................... 21 11. EQUIPMENT LIST......................................................................................................................... 24 12. MEASUREMENT UNCERTAINTY ................................................................................................ 25 13. TEST DATA ................................................................................................................................... 26 14. CALIBRATION CERTIFICATES.................................................................................................... 35 15. CONCLUSION............................................................................................................................... 71 16. REFERENCES .............................................................................................................................. 72 17. TEST PHOTOGRAPHS ................................................................................................................74 Reviewed by: FCC ID: ZNFL85C HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0Y1108221460.ZNF 8/29/2011 Cellular/PCS CDMA/EVDO Phone with BT and WLAN Page 3 of 76 © 2011 PCTEST Engineering Laboratory, Inc. REV 8.4C 08/10/10 1. INTRODUCTION On July 10, 2003, the Federal Communications Commission (FCC) adopted new rules requiring wireless manufacturers and service providers to provide digital wireless phones that are compatible with hearing aids. The FCC has modified the exemption for wireless phones under the Hearing Aid Compatibility Act of 1998 (HAC Act) in WT Docket 01-309 RM-8658 1 to extend the benefits of wireless telecommunications to individuals with hearing disabilities. These benefits encompass business, social and emergency communications, which increase the value of the wireless network for everyone. An estimated more than 10% of the population in the United States show signs of hearing impairment and of that fraction, almost 80% use hearing aids. Approximately 500 million people worldwide suffer from hearing loss. Compatibility Tests Involved: The standard calls for wireless communications devices to be measured for: ƒ RF Electric-field emissions ƒ RF Magnetic-field emissions ƒ T-coil mode, magnetic-signal strength in the audio band ƒ …

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: ZNFL85C HAC (T-COIL) TEST REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1108221461.ZNF August 30 - 31, 2011 Cell/PCS CDMA/EvDO Phone with Bluetooth and WLAN Page 1 of 38 © 2011 PCTEST Engineering Laboratory, Inc. REV 6.4C 04/05/10 Applicant Name: Date of Testing: LG Electronics MobileComm U.S.A., Inc. August 30 - 31, 2011 10101 Old Grove Road, Test Site/Location: San Diego, CA 92131 PCTEST Lab, C…
