ZNFP705GCellular/ PCS GSM/ WCDMA Phone with WLAN and Bluetooth

• Some of the contents of this manual may not apply to your phone. This depends on your phone’s software and your service provider. • This handset is not recommended for the visually impaired because of its touch screen keyboard. • Copyright ©2011 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners. • Google™, Google Maps™, Gmail™, Google Talk™ and Android Market™ are trademarks of Google, Inc. This guide helps you get started using your phone. If you need more information, please visit www.lg.com. LG-P705g User Guide English Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules and ICES-003 Class B digital apparatus requirements for Industry Canada. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device was tested for typical use with the back of the phone kept 0.39 inches (1 cm) from the body. To comply with FCC/IC RF exposure requirements, a minimum separation distance of 0.39 inches (1 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters, and similar accessories containing metallic components may not be used. Avoid the use of accessories that cannot maintain 0.39 inches (1 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC/IC RF exposure limits. 37 To t urn on your phone, press and hold the Power key for 3 seconds. To t urn off the phone, press and hold the Power key for 3 seconds, then touch Power off a nd OK. Menu key Check what options are available. Home key Return to home from any screen. Back key Return to the previous screen. Speaker/Receiver Power/Lock key Switch your phone on/off by pressing and holding this key. Turn off and lock the screen. Proximity sensor Getting to know your phone Stereo earphone connector Power/Lock key 38 Volume keys On t he home screen: control ringer volume. • D uring a call: control your In-Call volume. • W hen playing a track: control volume continuously. SIM card slot microSD memory card slot Camera lens Charger, micro USB cable connector Battery Back cover Getting to know your phone 39 NOTE: Proximity sensor When receiving and making calls, the proximity sensor automatically turns the backlight off and locks the touch keypad by sensing when the phone is near your ear. This extends battery life and prevents the touch keypad from activating unintentionally during calls. WARNING Placing a heavy object on the phone or sitting on it can damage its LCD and touch screen functions. Do not cover the protective film on the LCD’s proximity sensor. This may cause the sensor to malfunction. 40 Installing the SIM card and battery 1 To r emove the back cover, hold the phone in y our hand firmly. With the other hand, firmly press your thumb on the back cover. Now lift off the battery cover. 2 Slide the SIM card into the SIM card slot. Make sure the gold contact area on the card is facing downwards. Getting to know your phone 41 3 Insert the battery by aligning the gold contacts on the phone and the battery. 4 Replace the back cover of the phone. Charging your phone Insert the charger, then plug it into an electrical outlet. Your LG-P705g must be charged before you see . NOTE: The battery must be fully charged initially to improve battery lifetime. 42 Installing the memory card To s tore multimedia files, such as images captured using the built-in camera, you must insert a memory card into your phone. NOTE: The LG-P705g supports memory cards up to 32 GB. To insert a memory card: 1 Turn the phone off before inserting or removing a memory card. Remove the back cover. Getting to know your phone 43 2 Insert the memory card into the slot. Make sure the gold contact area is facing downwards. WARNING Do not insert or remove the memory card when the phone is on. Doing so may damage the memory card as well as your phone, and the data stored on the memory card may be corrupted. 44 Formatting the memory card Your memory card may already be formatted. If it isn’t, you must format it before you can use it. NOTE: All files on the card are deleted when you format the card. 1 In t he Home screen, touch the Applications t ab t o open the applications menu. 2 Scroll to and touch Settings > SD card & Phone storage > Mass storage only. 3 Touch Unmount SD card a nd touch OK to c onfirm. 4 Touch Era…

Text truncated - open the document above for the full version.

PCTEST TCB 6660-B Dobbin Road Maryland, Columbia 21045 U.S.A SUBJECT:LGElectronicsMobileCommU.S. A FCCID: ZNFP705G Model:LG-P705g Date: March 16, 2012 Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Christopher Johnson Senior Manager On behalf of LG Electronics MobileComm U.S.A, Inc. Gentle men: We, LG Electronics MobileComm USA hereby confirm that below devices are electrically identical to the <Model: LG-P705g, FCC ID: ZNFP705G>. •Additional model: P705g, P705G, LGP705g,LGP705G, LG-P705G, P708g, LGP708g, LG-P708g, P708G, LGP708G, LG-P708G This letter confirms that there have been no changes or modifications to the models being added except for the following: 1. Model name & Color changed

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: March 13, 2012 Federal Communicatio ns Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confide ntiality for FCC ID: ZNFP705G Equipment Class: JBP: Part 15 Class B Comp uting Devic e Peripheral To Whom It May Co ncern: Pursuant to Section s 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics MobileComm USA hereby requests confidentiality and treatment of certain information accompanying this applica tion. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics MobileComm USA temporary confidentiality of commercially sensitive information prior to product release. Th e requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Christopher Johnson Senoir Manager On behalf of LG Electronics MobileComm U.S.A, Inc.

LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G External Photos EUT Type: Portable Handset Page 1 of 4 © 2012 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G External Photos EUT Type: Portable Handset Page 2 of 4 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G External Photos EUT Type: Portable Handset Page 3 of 4 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G External Photos EUT Type: Portable Handset Page 4 of 4 © 2012 PCTEST Engineering Laboratory Inc.

Model No: LG-P705g FCC ID : ZNFP705G S/N : Made in Korea LG Electronics MobileComm USA, Inc. LGE

LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 1 of 9 © 2012 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 2 of 9 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 3 of 9 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 4 of 9 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 5 of 9 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 6 of 9 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 7 of 9 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 8 of 9 © 2012 PCTEST Engineering Laboratory Inc. LG Electronics MobileComm U.S.A., Inc. FCC ID: ZNFP705G Model: LG-P705G Internal Photos EUT Type: Portable Handset Page 9 of 9 © 2012 PCTEST Engineering Laboratory Inc.

FCC ID: ZNFP705G, IC: 2703C-P705G Report No.: HCTE1203FE05 Date: March 12, 2012 HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYOUNGKI-DO, 467-811, REPUBLIC OF KOREA TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr Page 2 of 17 TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION ....................................................................................................... 3 1.1 Product Description ................................................................................................................. 3 1.2 Related Submittal(s) / Grant(s)................................................................................................ 3 1.3 Tested System Details.............................................................................................................. 4 1.4 Cable Description .................................................................................................................... 5 1.5 Noise Suppression Parts on Cable. (I/O cable) ....................................................................... 5 1.6 Test Methodology .................................................................................................................... 6 1.7 Test Facility ............................................................................................................................. 6 1.8 Frequency Range of Radiated Measurements ......................................................................... 6 2. SYSTEM TEST CONFIGURATION........................................................................................... 7 2.1 Configuration of Test System .................................................................................................. 7 3. PRELIMINARY TEST ................................................................................................................. 8 3.1 Conducted Emission Test ........................................................................................................ 8 3. 2 Radiated Emission Test .......................................................................................................... 8 4. CONDUCTED AND RADIATED EMISSION TEST SUMMARY ........................................... 9 4.1 Conducted Emission Test ........................................................................................................ 9 4.2 Radiated Emission Test ......................................................................................................... 10 5. FIELD STRENGTH CALCULATION ...................................................................................... 15 6. TEST EQUIPMENT................................................................................................................... 16 7. CONCLUSION .......................................................................................................................... 17 ATTACHMENT: TEST SETUP PHOTOGRAPHS FCC ID: ZNFP705G, IC: 2703C-P705G Report No.: HCTE1203FE05 Date: March 12, 2012 HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYOUNGKI-DO, 467-811, REPUBLIC OF KOREA TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr Page 3 of 17 1. GENERAL INFORMATION 1.1 Product Description Equipment Under Test is Cellular/PCS GSM/GPRS/EDGE Rx only/WCDMA/HSDPA Phone with Bluetooth and WLAN, Model: LG-P705g manufactured by LG Electronics Mobilecomm U.S.A., Inc. Its basic purpose is used for communications. FCC/IC Model LG-P705g FCC ID ZNFP705G IC 2703C-P705G Additional Model(s) P705g, P705G, LGP705g, LGP705G, LG-P705G, P708g, LGP708g, LG-P708g, P708G, LGP708G, LG-P708G E.U.T Type Cellular/PCS GSM/GPRS/EDGE Rx only/WCDMA /HSDPA Phone with Bluetooth and WLAN TX Frequency 824.20 ㎒ to 848.80 ㎒ (GSM 850) 1 850.20 ㎒ to 1 909.80 ㎒ (GSM 1 900) 826.40 ㎒ to 846.60 ㎒ (WCDMA 850) 1 852.4 ㎒ to 1 907.6 ㎒ (WCDMA 1 900) RX Frequency 869.20 ㎒ to 893.80 ㎒ (GSM 850) 1 930.20 ㎒ to 1 989.80 ㎒ (GSM 1 900) 871.40 ㎒ to 891.60 ㎒ (WCDMA 850) 1 932.4 ㎒ to 1 987.6 ㎒ (WCDMA 1 900) 1.2 Related Submittal(s) / Grant(s) Original submittal only. FCC ID: ZNFP705G, IC: 2703C-P705G Report No.: HCTE1203FE05 Date: March 12, 2012 HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYOUNGKI-DO, 467-811, REPUBLIC OF KOREA TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr Page 4 of 17 1.3 Tested System Details All equipment descriptions used in the tested system (including inserted cards) are: Device Type Manufacturer Model Name FCC ID / DoC Connected To Cellular/PCS GSM/ GPRS/EDGE Rx only/ WCDMA/HSDPA Phone with Bluetooth and WLAN LG LG-P705g ZNFP705G Notebook PC Notebook PC LG X140-02 DoC E.U.T Notebook PC adaptor Notebook PC adaptor DELTA (JIANG SU) ADP-40PH AD - Notebook PC Mouse PRIMAX ELECTRONICS MOARUO DoC Notebook PC Micro SD card (4 GB) SanDisk - - E.U.T USB cable - - - E.U.T Notebook PC Headset - - - E.U.T RJ45 cable - - - Router Notebook PC Router MMCTECH MW-2100R - Notebook PC Router adaptor Dee Van Electronics(Shenz hen)Co., Ltd. DSA-0101F-05KA1 - Router FCC ID: ZNFP705G, IC: 2703C-P705G Report No.: HCTE1203FE05 Date: March 12, 2012 HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYOUNGKI-DO, 467-811, REPUBLIC OF KOREA TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr Page 5 of 17 1.4 Cable Description Product Name Port Power Cord Shielded (Y/N) I/O Cable Shielded (Y/N) Length (m) Micro USB Y Y (P,D)1.2 Cellular/PCS GSM/ GPRS/EDGE Rx only/ WCDMA/HSDPA Phone with Bluetooth and WLAN Headset jack - N (D)1.2 RJ 45 - N (D)1.5 Notebook PC USB (Mouse) - Y (D)1.8 * The marked "(D)" means the data cable and "(P)" means the power cable. 1.5 Noise Suppression Parts on Cable. (I/O cable) Product Name Port Ferrite Bead (Y/N) Location Metal Hood (Y/N) Location Micro USB N N/A Y Both End Cellular/PCS GSM/ GPRS/EDGE Rx only/ WCDMA/HSDPA Phone with Bluetooth and WLAN Headset jack N N/A Y E.U.T End RJ 45 N N/A N Both End Notebook PC USB (Mouse) - - Y Notebook PC End FCC ID: ZNFP705G, IC: 2703C-P705G Report No.: HCTE1203FE05 …
