LG-P875 User Guide All screen shots in this guide are simulated. Actual displays and the color of the phone may vary. Some of the contents in this manual may differ from your phone depending on the software of the phone or your service provider. www.lg.com P/NO: MFL00000000 (1.0) 1. WHAT THIS WARRANTY COVERS : LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and conditions: 1. The limited warranty for the product extends for TWELVE (12) MONTHS beginning on the date of purchase of the product with valid proof of purchase, or absent valid proof of purchase, FIFTEEN (15) MONTHS from date of manufacture as determined by the unit’s manufacture date code. 2. The limited warranty extends only to the original purchaser of the product and is not assignable or transferable to any subsequent purchaser/end user. 3. This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the U.S, including Alaska, Hawaii, U.S. Territories and Canada. 4. The external housing and cosmetic parts shall be free of defects at the time of shipment and, therefore, shall not be covered under these limited warranty terms. 5. Upon request from LG, the consumer must provide information to reasonably prove the date of purchase. 6. The customer shall bear the cost of shipping the product to the Customer Service Department of LG. LG shall bear the cost of shipping the product back to the consumer after the completion of service under this limited warranty. 2. WHAT THIS WARRANTY DOES NOT COVER : 1. Defects or damages resulting from use of the product in other than its normal and customary manner. 2. Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair, misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused by shipping, blown fuses, spills of food or liquid. 3. Breakage or damage to antennas unless caused directly by defects in material or workmanship. 4. That the Customer Service Department at LG was not notified by consumer of the alleged defect or malfunction of the product during the applicable limited warranty period. 5. Products which have had the serial number removed or made illegible. 6. This limited warranty is in lieu of all other warranties, express or implied either in fact or by operations of law, statutory or otherwise, including, but not limited to any implied warranty of marketability or fitness for a particular use. 7. Damage resulting from use of non-LG approved accessories. 8. All plastic surfaces and all other externally exposed parts that are scratched or damaged due to normal customer use. LIMITED WARRANTY STATEMENT 9. 10 11 3. W LG re co d r e ad a p a L G 4. S N T I N M T I N U A A U EX IM T t in r buse, cts sed ctly ted or s, d r a parts mer 9. Products operated outside published maximum ratings. 10. Products used or obtained in a rental program. 11. Consumables (such as fuses). 3. WHAT LG WILL DO: LG will, at its sole discretion, either repair, replace or refund the purchase price of any unit that does not conform to this limited warranty. LG may choose at its discretion to use functionally equivalent reconditioned, refurbished or new units or parts or any units. In addition, LG will not re-install or back-up any data, applications or software that you have added to your phone. It is therefore recommended that you back-up any such data or information prior to sending the unit to LG to avoid the permanent loss of such information. 4. STATE LAW RIGHTS : No other ex warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of limitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 5. HOW TO GET WARRANTY SERVICE : To obtain warranty service, please call or fax to the following telephone numbers from anywhere in the continental United States: Tel. 1-800-793-8896 or Fax. 1-800-448-4026 Or visit www.lg.com. Correspondence may also be mailed to: LG Electronics MobileComm U.S.A., Inc. 201 James Record Road Huntsville, AL 35824 DO NOT RETURN YOUR PRODUCT TO THE ABOVE ADDRESS. Please call or write for the location of the LG authorized service center nearest you and for the procedures for obtaining warranty claims. Table of Contents Important Notice ..............................7 Your Phone ......................................12 Getting Started ...............................14 Installing the SIM card and battery ..14 Charging your phone .........................15 Inserting a microSD card...................15 Removing the microSD card..............16 Formatting the microSD card ............17 Switching between and exiting applications .......................................17 Your Home screen .........................18 Touch screen tips ..............................18 Proximity sensor ................................18 Lock your phone ................................19 Quick Switch to Silent Mode ............19 Home screen panels..........................20 Customizing your Home screen.........20 Customi…

Text truncated - open the document above for the full version.

25 Android keyboard - Numbers and Symbols Entry Alt Key - Tap to enter additional symbols. The keyboard will change to alternate characters. Letters Key - Tap to change input to letters entry. Settings Key - Touch and hold to set various Android keyboard settings. Space Key - Tap to enter a space. Enter Key - Tap to move the cursor to the next line. Delete Key - Tap to delete characters to the left of the cursor. LG keyboard - Letters Entry Shift Key - Tap once to capitalize the next letter you type. Double-tap for all caps. Number and Symbols/Settings Key - Tap to change input to number and symbol entry. Touch and hold to set various LG keyboard settings. Handwriting/Voice to Text Key - Tap to enter text by handwriting. Touch and hold to enter text by voice. Enter Key - Tap to move the cursor to the next line. Delete Key - Tap to delete characters to the left of the cursor. Your Home screen 26 LG keyboard - Numbers and Symbols Entry Alt Key - Tap to enter additional symbols. The keyboard will change to alternate characters. Letters/Settings Key - Tap to change input to letters entry. Touch and hold to set various LG keyboard settings. Handwriting/Voice to Text Key - Tap to enter text by handwriting. Touch and hold to enter text by voice. Space Key - Tap to enter a space. Enter Key - Tap to move the cursor to the next line. Delete Key - Tap to delete characters to the left of the cursor. 123 Mode This mode allows you to enter numbers in a text message (a telephone number, for example) more quickly. Tap the keys corresponding to the required digits before manually switching back to the appropriate text entry mode by tapping on the LG Keyboard or on the Android keyboard. Entering Accented Letters The on-screen keyboard allows you to enter special characters (e.g., “á”). To input the accent, press and hold the desired key (press the “a” key for example). After the accented character appears, slide your finger over it and lift it off it to enter it. Your Home screen 27 The first time you open a Google application on your phone, you will be required to sign in with your existing Google account. If you do not have a Google account, you will be prompted to create one. Creating your Google account 1 From the Home screen, tap the Apps Key . 2 Tap Settings > General tab > Accounts & sync > ADD ACCOUNT > Google > New. 3 Tap a text field to open the keyboard and enter your name. Then tap Done. 4 Enter your username and tap Done. Your phone will communicate with Google servers and check for username availability. 5 Enter and re-enter your password. Then follow the instructions and enter the required and optional information about the account. Wait while the server creates your account. Signing into your Google account 1 From the Home screen, tap the Apps Key . 2 Ta p Settings > General tab > Accounts & sync > ADD ACCOUNT > Google > Existing. 3 Enter your email and password and tap Done. 4 Read the disclaimer about signing in and checkmark if you want to keep updated with news and offers from Google Play. Then, tap OK. 5 After signing in, you can use Gmail™ and take advantage of Google services on your phone. 6 Once you have set up your Google account, your phone will be automatically synchronized with your Google account on the web. (Depending on your synchronization settings.) After signing in, your phone will sync with your Google services, such as Gmail TM , Contacts, Google Calendar, and Picasa photo albums. You can also use Google Maps TM , download applications from Play Store™, back up your Google Account Setup 28 settings to Google servers, and take advantage of other Google services on your phone. IMPORTANT • Some applications, such as Calendar, work only with the first Google Account you add. If you plan to use more than one Google Account with your phone, be sure to sign into the one you want to use with such applications first. When you sign in, your contacts, Gmail messages, Calendar events, and other information from these applications and services on the web are synchronized with your phone. If you don’t sign into a Google Account during setup, you will be prompted to sign in or to create a Google Account the first time you start an application that requires one, such as Gmail or Play Store™. • If you have an enterprise account through your company or other organization, your IT department may have special instructions on how to sign into that account. Google Account Setup 29 Making a call 1 From the Home screen, tap the Phone Key to open the keypad. 2 Enter the number on the keypad. To delete a digit, tap the Clear Key . 3 Tap the Call Key to make a call. 4 To end a call, tap the End Key . n TIP To enter “+” to make international calls, touch and hold . Calling your contacts 1 From the Home screen, tap the Apps Key and then tap Contacts to open your contacts. 2 Scroll through the contact list or tap the Search contacts field and enter the first letter(s) of the contact you want to call. You can also tap the letters at the right side of the screen. 3 In the list that is displayed, tap the contact you want to call. You can also tap the letters at the right side of the screen. 4 In the Contact Info screen, tap the phone number you wish to call. Answering and rejecting a call When the screen is locked When your phone rings, swipe the Answer icon in any direction to answer the incoming call. Swipe the Decline icon in any direction to reject an incoming call. When the screen is unlocked When your phone rings, tap the Answer Key . Tap Decline Key to reject an incoming call. n NOTE Tap or swipe the Quick msg Key if you want to send a message to the caller. If the caller is unknown, the Quick msg Key is not available. Adjusting the in-call volume To adjust the in-call volume during a call, use the Volume Keys on the left side of the phone. Calls 30 Making a second call 1 During your initial call, tap the Menu Key and select Add call. 2 Dial the number or search your contacts. 3 Tap the Call Ke…

Text truncated - open the document above for the full version.

          !"# Date: Feb. 01#3 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ZNFP875 Equipment Class:%&' () ) *+  *  To Whom It May Co ncern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act MobileComm hereby requests confidentiality and treatment of certain informati on accompanying this applicati on. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for , days after the grant as outlined in Public Notice DA 04-1705. This provision will give  MobileComm temporary confidentiality of commercially sensitive information prior to product release. The request ed Permanent and Temporary Confidential exhibits are listed as follows: '-.+%/0-+1+-.023%+33+ 45 6  %e )  1 Block Diagram 2 Operational Descriptions '-.+ 3 Schematics 4 External Photos 5 Internal Photos 6 Test-Setup Photos /0-+1+-. 7 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jacob Cho Director On behalf of LG Electronics MobileComm U.S.A, Inc. LG Electronics MobileComm U.S.A 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 7 EXTERNAL PHOTOGRAPHS FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 7 ■ EXTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 7 ■ EXTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 7 ■ EXTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 7 ■ EXTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 7 ■ EXTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 7 ■ EXTERNAL PHOTO

FCC ID label form LG-P875 ZNFP875

FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 17 INTERNAL PHOTOGRAPHS FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 17 ■ INTERNAL PHOTO BT / WiFi FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １１ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １２ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １３ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １４ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １５ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １６ of 17 ■ INTERNAL PHOTO FCC ID: ZNFP875 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １７ of 17 ■ INTERNAL PHOTO

FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1301FR27-1 Date of Issue: March 06, 2013 EUT Type: Cellular/PCS GSM/GPRS/EDGE Phone with Bluetooth/WLAN/NFC FCC ID: ZNFP875 Page 2 of 75 Version TEST REPORT NO. DATE DESCRIPTION HCTR1301FR27 March 04, 2013 - First Approval Report HCTR1301FR27-1 March 06, 2013 - Updated Information of Outside Frequency Band on Page.16 FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1301FR27-1 Date of Issue: March 06, 2013 EUT Type: Cellular/PCS GSM/GPRS/EDGE Phone with Bluetooth/WLAN/NFC FCC ID: ZNFP875 Page 3 of 75 Table of Contents 1.GENERAL INFORMATION ....................................................................................................................... 4 2.EUT DESCRIPTION .................................................................................................................................. 4 3.TEST METHODOLOGY ............................................................................................................................ 5 3.1EUT CONFIGURATION ............................................................................................................. 5 3.2EUT EXERCISE ......................................................................................................................... 5 3.3GENERAL TEST PROCEDURES ............................................................................................. 5 3.4DESCRIPTION OF TEST MODES ............................................................................................ 5 4.INSTRUMENT CALIBRATION .................................................................................................................. 6 5.FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1FACILITIES ................................................................................................................................ 6 5.2EQUIPMENT .............................................................................................................................. 6 6.ANTENNA REQUIREMENTS.................................................................................................................... 6 7.SUMMARY OF TEST RESULTS ............................................................................................................... 7 8.FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1PEAK POWER ........................................................................................................................... 8 8.2BAND EDGES .......................................................................................................................... 15 8.3FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 23 8.4NUMBER OF HOPPING FREQUENCY .................................................................................. 32 8.5TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 36 8.6SPURIOUS EMISSIONS .......................................................................................................... 43 8.6.1CONDUCTED SPURIOUS EMISSIONS .......................................................................... 43 8.6.2RADIATED SPURIOUS EMISSIONS .............................................................................. 60 8.6.3RADIATED RESTRICTED BAND EDGES ...................................................................... 68 8.7POWERLINE CONDUCTED EMISSIONS ............................................................................... 70 9.LIST OF TEST EQUIPMENT ................................................................................................................... 75 FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1301FR27-1 Date of Issue: March 06, 2013 EUT Type: Cellular/PCS GSM/GPRS/EDGE Phone with Bluetooth/WLAN/NFC FCC ID: ZNFP875 Page 4 of 75 1. GENERAL INFORMATION Applicant: LG Electronics MobileComm U.S.A., Inc. Address: 1000 Sylvan Avenue, Englewood Cliffs NJ 07632 FCC ID: ZNFP875 EUT Type: Cellular/PCS GSM/GPRS/EDGE Phone with Bluetooth/WLAN/NFC Model name(s): LG-P875 Additional Model name(s): P875, LGP875 Date(s) of Tests: January 19, 2013 ~ March 01, 2013 Place of Tests: HCT Co., Ltd. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION EUT Type Cellular/PCS GSM/GPRS/EDGE Phone with Bluetooth/WLAN/NFC FCC Model Name LG-P875 Additional FCC Model Name P875, LGP875 Power Supply DC 3.7 V Battery type Li-ion Battery(Standard) Frequency Range 2402 MHz - 2480 MHz (Bluetooth) Transmit Power 9.89 dBm (9.75 mW) BT Operating Mode Normal, EDR, AFH Modulation Type GFSK(Normal), π/4DQPSK and 8DPSK(EDR) Modulation Technique FHSS Number of Channels 79Channels, Minimum 20 Channels(AFH) Antenna Specification Manufacturer: acetechnology A Antenna type: PIFA Antenna Peak Gain : -4.06 dBi 15.247 Requirements for Bluetooth transmitter ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudo-randomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occup…
