MBM67454401 (1.0)Printed in Vietnam Consumer Information on SAR (Specific Absorption Rate) This model device meets the government’s requirements for exposure to radio waves. Your wireless device is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to Radio Frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions specified by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. Although SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. Because the device is designed to operate at multiple power levels to use only the power required to reach the network, in general, the closer you are to a wireless base station antenna, the lower the power output. Before a device model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the governmentadopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. While there may be differences between SAR levels of various devices and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model device with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this model device is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID ZNFV600V. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements. Body-worn operation This device was tested for typical use with the back of the device kept 0.39 inches (1.0 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.39 inches (1.0 cm) must be maintained between the user’s body and the back of the device. Any belt-clips, holsters, and similar accessories containing metallic components may not be used. Avoid the use of accessories that cannot maintain 0.39 inches (1.0 cm) distance between the user’s body and the back of the device and have not been tested for compliance with FCC RF exposure limits. Part15.19 statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Part15.21 statement Changes or modifications that are not expressly approved by the manufacturer for compliance could void the user’s authority to operate the equipment. Part15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Trademarks • Bluetooth ® is a registered trademark of Bluetooth SIG, Inc. worldwide. • Wi-Fi ® and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. • Copyright ©2020 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. Open Source Software Notice Information To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to [email protected]. This offer is valid for a period of three years after our last shipment of this product. This offer is valid to anyone in receipt of this information. Regulatory information (FCC ID number, etc.) For regulatory details, go to Settings > System > Regulatory & safety. ENGLISH Consumer Information on SAR (Specific Absorption R…

Text truncated - open the document above for the full version.

Date : Jan 30, 2020 PCTEST Engineering Laboratory, Inc. 7185 Oakland Mills Road Columbia, MD 21046 USA To whom it may concern: I, th e undersigned, hereby authorize DT&C C o.Ltd. to act o n our behalf in a ll manners relating to application for equipment authorization for FCC ID : ZNFV600V, including signing of al l documents relating to these matters. Any and al l acts carried out by DT&C Co.Ltd. on our behalf shall have the same effect as acts of our own. In authorizing DT&C Co.Ltd. as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e)upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)use certification only to indicate the products are certified as being in conformity with specified standards; g)endeavor to ensure that no certificate or report nor any part thereof is used in a m isleading manner; h)ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Kyu ng-Su Han Director LG Electronics USA, Inc.

Date: Jan. 30, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: ZNFV600V Equipment Class: NII-Unlicensed National Information Infrastructure TX To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA, Inc. hereby requests confidentiality and confidential treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: The Applicant understa nds that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Kyung-Su Han Director LG Electronics USA, Inc. LG Electronics USA, Inc. 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Descriptions 3 Schematics, Tune-up procedure, Parts List SHORT-TERM 1 External Photos 2 Internal Photos 3 Test-Setup Photos 4 User’s Manual

FCC ID: ZNFV600V IC : 2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page1 / 7 View 1 FCC ID: ZNFV600V IC : 2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page2 / 7 View 2 FCC ID: ZNFV600V IC : 2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page3 / 7 View 3 FCC ID: ZNFV600V IC : 2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page4 / 7 <Dual Display> View 1 FCC ID: ZNFV600V IC : 2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page5 / 7 <Dual Display> View 2 FCC ID: ZNFV600V IC : 2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page6 / 7 <Dual Display> View 3 FCC ID: ZNFV600V IC : 2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page7 / 7 <Dual Display> View 4

LGE Internal Use Only Description of E-Label for ZNFV600V ※FCC ID is applied by E-Label on the device Settings Menu Step1Select “Setting” Step 2Select“System” Step 3Select “Regulatory& safety” ※FCC ID is applied on the packaging Label FCC ID: ZNFV600V ※Instruction of E-Label on the User Manual United States of America FCC ID: ZNFV600V

FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page1 / 20 View 1 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page2 / 20 View 2 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page3 / 20 View 3 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page4 / 20 View 4 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page5 / 20 View 5

FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page10 / 20 View 10 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page11 / 20 View 11 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page12 / 20 View 12 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page13 / 20 View 13

FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page14 / 20 View 14 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page15 / 20 View 15 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page16 / 20 View 16 FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page17 / 20 View 17 <Antenna> <Antenna>

FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page18 / 20 View 18 <Antenna> <Antenna> FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page19 / 20 View 19 <Antenna> FCC ID: ZNFV600V IC :2703C-V600V Copyright Ⓒ 2020, DT&C Co., Ltd. Page20 / 20 View 20 <Antenna> <Antenna>

Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 /113 Test Report Version Test Report No. Date Description Tested By Reviewed by DRRFCC2001-0004 Jan. 30, 2020 Initial issue BumJun Park HakMin Kim Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 /113 Table of Contents 1. DESCRIPTION OF DEVICE ......................................................................................................................................................................... 4 1.1 General Information ............................................................................................................................................................................. 4 1.2 Power Reduction for SAR .................................................................................................................................................................... 5 1.3 Nominal and Maximum Output Power Specifications .......................................................................................................................... 5 1.4 DUT Antenna Locati ons ....................................................................................................................................................................... 5 1.5 Simultaneous Transmission Capabilities ............................................................................................................................................. 5 1.6 Miscellaneous SAR Test Considerations ............................................................................................................................................. 6 1.7 Guidance Applied ................................................................................................................................................................................ 6 1.8 Device Serial Numbers ........................................................................................................................................................................ 6 2. INTROCUCTION .......................................................................................................................................................................................... 7 3. DOSIMETRIC ASSESSMENT ...................................................................................................................................................................... 8 3.1 Measurement Proc edure ..................................................................................................................................................................... 8 4. DEFINITION OF REFERENCE POINTS ..................................................................................................................................................... 10 4.1 Ear Reference Point .......................................................................................................................................................................... 10 4.2 Handset Reference Points ................................................................................................................................................................. 10 5. TEST CONFIGURATION POSITIONS FOR HANDSETS ........................................................................................................................... 11 5.1 Device Holder .................................................................................................................................................................................... 1 1 5.2 Positioning for Cheek/Touch .............................................................................................................................................................. 11 5.3 Positioning for Ear / 15 ° Tilt .............................................................................................................................................................. 11 5.4 Body-Worn Accessory Configurations................................................................................................................................................ 12 5.5 Extremity Exposure Configurations .................................................................................................................................................... 12 5.6 Phablet Configurations ...................................................................................................................................................................... 12 6. RF EXPOSURE LIMITS .............................................................................................................................................................................. 13 7. FCC MEASUREMENT PROCEDURES ...................................................................................................................................................... 14 7.1 Measured and Reported SAR ............................................................................................................................................................ 14 7.2 SAR Testing with 802.11 Transmitters ............................................................................................................................................... 14 7.2.1 General Device Setup .................................................................................................................................................................. 14 7.2.2 U-NII and U-NII-2A ....................................................................................................................................................................... 14 7.2.3 U-NII-2C and U-NII-3 ...........................................................................................................…

Text truncated - open the document above for the full version.

Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 59 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 60 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 61 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 62 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 63 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 64 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 65 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 66 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 67 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 68 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 69 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 70 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 71 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 72 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 73 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 74 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 75 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 76 /113

Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 77 /113 APPENDIX B. – Dipole Calibration Data Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 78 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 79 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 80 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 81 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 82 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 83 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 84 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 85 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 86 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 87 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 88 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 89 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 90 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 91 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 92 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 93 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 94 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 95 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 96 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 97 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 98 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 99 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 100 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 101 /113 Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 102 /113 APPENDIX C. – SAR Tissue Specifications Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 103 /113 The brain and muscle mixtures consist of a viscous gel using hydrox-ethylcellulose (HEC) gelling agent and saline solution (see Table C.1). Preservation with a bactericide is added and visual inspection is made to make sure air bubbles are not trapped during the mixing process. The mixture is calibrated to obtain proper dielectric constant (permittivity) and conductivity of the desired tissue. The mixture characterizations used for the brain and muscle tissue simulating liquids are according to the data by C. Gabriel and G. Harts grove. Table C.1 Composition of the Tissue Equivalent Matter Ingredients (% by weight) Frequency (MHz) 2450 5200 ~ 5800 Tissue Type Head Body Head Body Water 71.88 73.40 65.52 80.00 Salt (NaCl) 0.160 0.060 - - Sugar - - - - HEC - - - - Bactericide - - - - Triton X-100 19.97 - 17.24 - DGBE 7.990 26.54 - - Diethylene glycol hexyl ether - - 17.24 - Polysorbate (Tween) 80 - - 20.00 Target for Dielectric Constant 39.2 52.7 - - Target for Conductivity (S/m) 1.80 1.95 - - Figure C.1 Simulated Tissue Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 104 /113 APPENDIX D. – SAR SYSTEM VALIDATION Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V TRF-RF-601(03)161101 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 105 /113 SAR System Validation Per FCC KDB 865664 D02v01r02, SAR system validation status should be documented to confirm measurement accuracy. The SAR systems (including SAR probes, system components and software versions) used for this device were validated against its performance specifications prior to the SAR measurements. Reference dipoles were used with the required tissue- equiv…

Text truncated - open the document above for the full version.

Report No.: DRRFCC2001-0004 FCC ID: ZNFV600V Date of issue: Jan. 30, 2020 Copyright Ⓒ 2020, DT&C Co., Ltd. SAR Plots  Verification Plots  SAR Test Plots DT&C Co., Ltd. DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:726 Communication System: UID 0, CW (0); Frequency: 2450 MHz; Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.846 S/m; ε r = 40.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: Probe: EX3DV4 - SN3933; ConvF(7.84, 7.84, 7.84); Calibrated: 9/27/2019 Electronics: DAE4 Sn1391 Sensor-Surface: 2mm (Mechanical Surface Detection) Phantom: SAM with CRP_2016_07_22_middle; Type: QD000P40CD; Serial: TP:1786 Measurement SW: DASY52, Version 52.10 (3); SEMCAD X Version 14.6.13 (7474) Test Date: 2020-01-09; Ambient Temp: 20.8; Tissue Temp: 20.9 2450 MHz System Head Verification (100 mW) Area Scan (6x8x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = 0.01 dB Peak SAR (extrapolated) = 11.12 W/kg SAR(1 g) = 5.27 W/kg; SAR(10 g) = 2.37 W/kg 0 dB = 8.16 W/kg DT&C Co., Ltd. DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:726 Communication System: UID 0, CW (0); Frequency: 2450 MHz; Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.918 S/m; ε r = 51.08; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: Probe: EX3DV4 - SN3933; ConvF(7.75, 7.75, 7.75); Calibrated: 9/27/2019 Electronics: DAE4 Sn1391 Sensor-Surface: 2mm (Mechanical Surface Detection) Phantom: SAM with CRP_2013_10_08_right; Type: QD000P40CD; Serial: TP:1785 Measurement SW: DASY52, Version 52.10 (3); SEMCAD X Version 14.6.13 (7474) Test Date: 2020-01-09; Ambient Temp: 20.8; Tissue Temp: 21.0 2450 MHz System Body Verification (100 mW) Area Scan (6x8x1): Measurement grid: dx=12mm, dy=12mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Power Drift = 0.07 dB Peak SAR (extrapolated) = 11.32 W/kg SAR(1 g) = 5. 33 W/kg; SAR(10 g) = 2.44 W/kg 0 dB = 8.36 W/kg DT&C Co., Ltd. DUT: Dipole 5000 MHz; Type: D5GHzV2; Serial: D5GHzV2 - SN:1103 Communication System: UID 0, CW (0); Frequency: 5300 MHz; Duty Cycle: 1:1 Medium parameters used: f = 5300 MHz; σ = 4.867 S/m; ε r = 35.029; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: Probe: EX3DV4 - SN7337; ConvF(5.61, 5.61, 5.61); Calibrated: 11/27/2019 Electronics: DAE4 Sn1394 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Phantom: SAM-twin middle_2013_09_24; Type: QD000P40CD; Serial: 1782 Measurement SW: DASY52, Version 52.10 (3); SEMCAD X Version 14.6.13 (7474) Test Date: 2020-01-08; Ambient Temp…
