ZNFVC100SMART WATCH + CDMA

- 1 - User Manual LG-VC100 Ver. 1.0 2014. 06. 05 - 2 - LIMITED WARRANTY STATEMENT 1. WHAT THIS WARRANTY COVERS: LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and conditions: (1) The limited warranty for the product extends for ONE (1) year beginning on the data of purchase of the product. (2) The limited warranty extends on to the original purchaser of the product and is not assignable or transferable to any subsequent purchaser/end user. (3) This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the U.S., including Alaska, Hawaii, U.S. Territories and Canada. (4) The external housing and cosmetic parts shall not be covered under these limited warranty terms. (5) Upon request from LG, the consumer must provide information to reasonably prove the date of purchase. (6) The customer shall bear the cost of shipping the product to the Customer Service Department of LG. LG shall bear the cost of shipping the product back to the consumer after the completion of service under this limited warranty. 2. WHAT THIS WARRANTY DOES NOT COVER: (1) Defects or damages resulting from use of the product in other than its normal and customary manner. (2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair, misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused by shipping blown fuses spills of food or liquid. (3) Breakage or damage to antennas unless caused directly by defects in material or workmanship. (4) That the Customer Service Department at LG was net notified by consumer of the alleged defect or malfunction of the product during the applicable limited warranty period. (5) Products which have had the serial number removed or made illegible. (6) The limited warranty is in lieu of all other warranties, express or implied either in fact or by operations law, statutory or otherwise, including, but limited to any implied warranty of marketability or fitness for a particular use. (7) Damage resulting from use of non-LG approved accessories. (8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to normal customer use. (9) Products operated outside published maximum ratings. - 3 - (10) Products used or obtained in a rental program. (11) Consumables (such as fuses). 3. STATE LAW RIGHTS: No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, RISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of imitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 4. HOW TO GET WARRANTY SERVICE: To obtain warranty service, please call the following telephone number from anywhere in the continental United States: LG Infocomm Inc. 201 James Record Road Huntsville, AL 35824 Tel. 1-800-793-8896 Fax. 1-800-448-4026 www.lgeservice.com DO NOT RETURN YOUR PRODUCT TO THE ABOVE ADDRESS. Please call or write for the location of the LG Electronics, Inc authorized service center nearest you and for the procedures for obtaining warranty claims. - 4 - SUBJECT The LGVC100 has been designed to operate on the latest digital mobile communication technology, Code Division Multiple Access (CDMA). The LGVC100 support 72poly Audio, etc. This device operates in one of tri band Quad mode - 800Mhz CDMA, 1900Mhz PCS, 1500Mhz GPS. CDMA Standard Designator Description Basic air interface TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000 CDMA Dual-Mode Air Interface 14.4kbps radio link protocol and inter-band operations IS-95 adapted for PCS frequency band CDMA2000 1xRTT Air Interface Network TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124 MAS-BS PCSC-RS Intersystem operations Nom-signaling data comm. Service TIA/EIA/IS-96-B TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801 Speech CODEC Short message service Packet data Position Determination Service (gpsOne) Performance TIA/EIA/IS-97 TIA/EIA/IS-98 ANSI J-STD-018 ANSI J-STD-019 TIA/EIA/IS-125 Cellular base station Cellular mobile station PCS personal station PCS base station Speech CODEC * TSB –74: Protocol between an IS-95A system and ANSI J-STD-008 - 6 - Introduction Highlights Congratulations! Your new mobile device will change your way of communicating and is a compact, lightweight personal communication system with added features for the person on the go. Our advanced digital mobile communication technology allows you to do the followings 1) Main Chipset : QSC6055, Memory(Memory (Flash+RAM 1Gb/512Mb) 2) CMX 5.0 compliant (72 Poly) 3) GPS(gpsOne) Important Information This user’s guide provides important information on the use and operation of the device. Please read all the information carefully prior to using the device for the best performance and to prevent any anticipated damage to or misuse of the device. Any unapproved change or modification will void your warranty. Check Accessories Your wearable device comes with standard accessory of a one-slot desktop charger. Please make sure that this accessory is included. - 7 - Before You Start Safety Instructions WARNING! To red…

Text truncated - open the document above for the full version.

Date: SEP 09, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: ZNFVC100 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.4 57, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram PCB Layout Block Diagram Operation Descriptions Tune-up Procedure Antenna Specification Parts list Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the grant as outlined in Public Notice DA 04-1705. External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely Yours, Jacob Cho Director On behalf of LG Electronics Mobilecomm U.S.A., Inc.

Date: Jan 12, 2013 UL Verification Services Inc. Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc.as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certific ation which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s complianc e with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jacob Cho Director On behalf of LG Electronics MobileComm USA, Inc.

■ FCC ID FCC ID : ZNFVC100 MODEL : LG-VC100 *Note: This device’s FCC ID and location complies with 47 CFR 2.925(d). FCC ID is readily visible to the purchaser at the time of purchase, and be permanently affixed to the product. We, LG Electronics MobileComm USA, state that our device, FCC ID : ZNFVC100, has been printed FCC ID on the rear surface, so the FCC ID is visible to the users as they purchase the product. Rear surface

NVLAP LAB CODE 200065-0 SAR EVALUATION REPORT FCC 47 CFR § 2.1093 IEEE Std 1528-2013 For Smart Watch + CDMA Model: LG-VC100, VC100, LGVC100, LG-VC100P, LGVC100P, VC100P FCC ID: ZNFVC100 Report Number: 14U18513-S1 Issue Date: 9/8/2014 Prepared for LG ELECTRONICS MOBILECOMM U.S.A., INC. 1000 SYLVAN AVE. ENGLEWOOD CLIFFS, NJ 07632 Prepared by UL Verification Services Inc. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 Report No.: 14U18513-S1 Issue Date: 9/8/2014 Page 2 of 18 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. REVISION HISTORY Rev. Issue Date Revisions Revised By -- 9/8/2014 Initial Issue -- Report No.: 14U18513-S1 Issue Date: 9/8/2014 Page 3 of 18 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. Table of Contents 1. Attestation of Test Results ......................................................................................................... 5 2. Test Specification, Methods and Procedures ............................................................................ 6 3. Facilities and Accreditation ........................................................................................................ 6 4. SAR Measurement System & Test Equipment .......................................................................... 7 4.1. SAR Measurement System ........................................................................................................ 7 4.2. Test Equipment .......................................................................................................................... 8 5. Measurement Uncertainty ........................................................................................................... 9 6. Device Under Test (DUT) Information ...................................................................................... 10 6.1. DUT Description ...................................................................................................................... 10 6.2. Wireless Technologies ............................................................................................................. 10 6.3. Nominal and Maximum Output Power ...................................................................................... 10 6.4. Simultaneous Transmission Condition ..................................................................................... 10 7. RF Exposure Conditions (Test Configurations) ...................................................................... 10 7.1. Extremity (Wrist) ...................................................................................................................... 10 7.2. Next-to-Mouth Exposure .......................................................................................................... 10 8. Conducted Output Power Measurements ................................................................................ 11 8.1. CDMA BC0 and BC1 ............................................................................................................... 11 9. Dielectric Property Measurements ........................................................................................... 12 9.1. Tissue Dielectric Parameters ................................................................................................... 12 9.2. Dielectric Property Measurements Results .............................................................................. 13 10. System Check ............................................................................................................................ 14 10.1. Reference Target SAR Values ............................................................................................. 14 10.2. System Check Results ......................................................................................................... 14 11. Measured and Reported (Scaled) SAR Results ....................................................................... 15 11.1. CDMA BC0........................................................................................................................... 15 11.2. CDMA BC1........................................................................................................................... 15 12. SAR Measurement Variability ................................................................................................... 16 12.1. The Highest Measured SAR Configuration in Each Frequency Band ................................... 16 12.2. Repeated Measurement Results .......................................................................................... 16 13. Simultaneous Transmission SAR Analysis ............................................................................. 17 14. Appendixes ................................................................................................................................ 18 14.1. Photos and Antenna Locations ............................................................................................. 18 Report No.: 14U18513-S1 Issue Date: 9/8/2014 Page 4 of 18 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. 14.2. System Performance Check Plots ........................................................................................ 18 14.3. Highest SAR Test Plots ........................................................................................................ 18 14.4. Calibration Certificate for E-Field Probe EX3DV4 - SN 3902 ................................................ 18 14.5. Calibration Certificate for D835V2 - SN 4d142 ..................................................................... 18 14.6. Calibration Certificate for D1900V2 - SN 5d163 ..................…

Text truncated - open the document above for the full version.

Plot No. 1 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/29/2014 20140829 SystemPerformanceCheck-D835V2 SN 4d142 Frequency: 835 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 835 MHz; σ = 1.006 S/m; ε r = 53.342; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(9.86, 9.86, 9.86); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 Body/Pin=100 mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Reference Value = 32.338 V/m; Power Drift = 0.06 dB Fast SAR: SAR(1 g) = 0.899 W/kg; SAR(10 g) = 0.603 W/kg Maximum value of SAR (interpolated) = 1.07 W/kg Body/Pin=100 mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 32.338 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 1.34 W/kg SAR(1 g) = 0.885 W/kg; SAR(10 g) = 0.575 W/kg Maximum value of SAR (measured) = 1.09 W/kg 0 dB = 1.09 W/kg = 0.37 dBW/kg Plot No. 2 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/29/2014 20140829 SystemPerformanceCheck-D835V2 SN 4d142 Frequency: 835 MHz; Duty Cycle: 1:1 Body/Pin=100 mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 1.04 W/kg Plot No. 3 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/29/2014 20140829 SystemPerformanceCheck-D1900V2 SN 5d163 Frequency: 1900 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 1900 MHz; σ = 1.415 S/m; ε r = 38.125; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(8.19, 8.19, 8.19); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: ELI-B v5.0; Type: QDOVA002AA; Serial: TP:1195 Head/Pin=100 mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Reference Value = 60.160 V/m; Power Drift = 0.03 dB Fast SAR: SAR(1 g) = 3.91 W/kg; SAR(10 g) = 2.03 W/kg Maximum value of SAR (interpolated) = 5.15 W/kg Head/Pin=100 mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 60.160 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 7.00 W/kg SAR(1 g) = 3.79 W/kg; SAR(10 g) = 1.98 W/kg Maximum value of SAR (measured) = 5.13 W/kg 0 dB = 5.13 W/kg = 7.10 dBW/kg Plot No. 4 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/29/2014 20140829 SystemPerformanceCheck-D1900V2 SN 5d163 Frequency: 1900 MHz; Duty Cycle: 1:1 Head/Pin=100 mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 5.05 W/kg Plot No. 1 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/29/2014 CDMA2000 BC0 Extremity Frequency: 836.52 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used (interpolated): f = 836.52 MHz; σ = 1.008 S/m; ε r = 53.327; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(9.86, 9.86, 9.86); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection (Locations From Previous Scan Used)), Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 Right Neck/Wrist Worn Extremity SO32 RC3/3 Channel 384/Area Scan (8x8x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.00 W/kg Right Neck/Wrist Worn Extremity SO32 RC3/3 Channel 384/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 33.856 V/m; Power Drift = -0.14 dB Peak SAR (extrapolated) = 1.73 W/kg SAR(1 g) = 0.942 W/kg; SAR(10 g) = 0.540 W/kg Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.23 W/kg 0 dB = 1.23 W/kg = 0.90 dBW/kg Plot No. 2 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/29/2014 CDMA2000 BC0 Next to Mouth Frequency: 836.52 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used (interpolated): f = 836.52 MHz; σ = 0.93 S/m; ε r = 42.444; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn427; Calibrated: 1/21/2014 - Probe: EX3DV4 - SN3902; ConvF(10.04, 10.04, 10.04); Calibrated: 5/19/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: ELI-A v5.0; Type: QDOVA002AA; Serial: TP 1194 Flat/Next-to-Mouth SO55 RC3/3 Channel 384/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.474 W/kg Flat/Next-to-Mouth SO55 RC3/3 Channel 384/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 23.136 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 0.644 W/kg SAR(1 g) = 0.429 W/kg; SAR(10 g) = 0.272 W/kg Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.530 W/kg 0 dB = 0.530 W/kg = -2.76 dBW/kg Plot No. 3 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/27/2014 CDMA2000 BC1 Extremity Frequency: 1880 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 1880 MHz; σ = 1.562 S/m; ε r = 54.707; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a…

Text truncated - open the document above for the full version.

FCC CFR47 PART 22 SUBPART H FCC CFR47 PART 24 SUBPART E CERTIFICATION TEST REPORT FOR SMART WATCH + CDMA MODEL NUMBER: LG-VC100, LGVC100, VC100, LG-VC100P, LGVC100P, VC100P FCC ID: ZNFVC100 REPORT NUMBER: 14U18513-E1 ISSUE DATE: SEPTEMBER 03, 2014 Prepared for LG ELECTRONICS MOBILECOMM U.S.A., INC 1000 SYLVAN AVENUE ENGLEWOOD CLIFFS, NEW JERSEY, 07632, U.S.A Prepared by UL VERIFICATION SERVICES 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 14U18513-E1 DATE: SEPTEMBER 03, 2014 FCC ID: ZNFVC100 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701H 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 9/3/14 Initial issue D. Coronia REPORT NO: 14U18513-E1 DATE: SEPTEMBER 03, 2014 FCC ID: ZNFVC100 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701H 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ............................................................................. 5 2. TEST METHODOLOGY ................................................................................................. 6 3. FACILITIES AND ACCREDITATION ............................................................................. 6 4. CALIBRATION AND UNCERTAINTY ............................................................................ 6 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 6 4.2. SAMPLE CALCULATION ......................................................................................... 6 4.3. MEASUREMENT UNCERTAINTY ........................................................................... 7 5. EQUIPMENT UNDER TEST .......................................................................................... 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. MAXIMUM OUTPUT POWER .................................................................................. 8 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ........................................................... 9 5.4. DESCRIPTION OF TEST SETUP ...........................................................................10 6. TEST AND MEASUREMENT EQUIPMENT ..................................................................13 7. Summary Table ............................................................................................................14 8. CDMA2000 ...................................................................................................................15 8.1.1. 1xRTT ..................................................................................................................15 8.1.2. CDMA2000 OUTPUT POWER RESULT .............................................................16 8.1.3. 1xEV-DO Release 0 .............................................................................................17 8.1.4. 1XEVDO REL 0 OUTPUT POWER RESULT.......................................................18 8.1.5. 1xEV-DO Rev. A ..................................................................................................19 8.1.6. 1xEVDO REV A OUTPUT RESULT .....................................................................20 8.1.7. 1xEV-DO Rev. B ..................................................................................................21 8.1.8. 1xEVDO REV B OUTPUT RESULT .....................................................................22 9. PEAK TO AVERAGE RATIO ........................................................................................23 9.1. CONDUCTED PEAK TO AVERAGE RESULT ........................................................23 10. LIMITS AND CONDUCTED RESULTS .........................................................................25 10.1. OCCUPIED BANDWIDTH .......................................................................................25 10.1.1. OCCUPIED BANDWIDTH RESULTS ...............................................................26 10.1.2. OCCUPIED BANDWIDTH PLOTS ...................................................................27 11. BAND EDGE EMISSIONS ............................................................................................29 11.1. BAND EDGE PLOTS...............................................................................................30 12. OUT OF BAND EMISSIONS .........................................................................................32 REPORT NO: 14U18513-E1 DATE: SEPTEMBER 03, 2014 FCC ID: ZNFVC100 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701H 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 12.1. OUT OF BAND EMISSIONS RESULT ....................................................................33 12.2. OUT OF BAND EMISSIONS PLOTS .......................................................................34 13. FREQUENCY STABILITY .............................................................................................36 13.1. FREQUENCY STABILITY RESULTS ......................................................................37 14. RADIATED TEST RESULTS ........................................................................................39 14.1. RADIATED POWER (ERP & EIRP) .........................................................................39 14.1.1. ERP/EIRP Results ............................................................................................40 14.1.2. ERP/EIRP PLOTS ...........................................................…

Text truncated - open the document above for the full version.

REPORT NO: 14U18513-E1 DATE: SEPTEMBER 03, 2014 FCC ID: ZNFVC100 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701H 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 16. SETUP PHOTOS ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP REPORT NO: 14U18513-E1 DATE: SEPTEMBER 03, 2014 FCC ID: ZNFVC100 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701H 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. RADIATED RF MEASUREMENT SETUP FOR PORTABLE CONFIGURATION REPORT NO: 14U18513-E1 DATE: SEPTEMBER 03, 2014 FCC ID: ZNFVC100 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701H 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification S…
