Weatherdock AG Page 1 www.easyAIS.com AIS Aid to Navigation (AtoN) – Type3 User Guide V1 English Weatherdock AG Page 2 www.easyAIS.com 1 References • General Warning All marine automatic identification system (AIS) units utilize a satellite based system such as the global positioning satellite (GPS) network or the global navigation satellite system (GLONASS) network to determine position. The accuracy of these networks is variable and is affected by factors such as the antenna positioning, how many satellites are used to determine a position and how long satellite information has been received for. Therefore it is desirable wherever possible to verify both your vessels AIS derived position data and other vessels AIS derived position data with visual or radar based observations. The easyAtoN software is intended for use as an installation and configuration tool. The application is not a navigation tool and should not be used as such. • Safety Warnings This equipment must be installed in accordance with the instructions provided in this manual. Failure to do so will seriously affect its performance and reliability. It is strongly recommended that a trained technician installs and configures this product. This equipment is intended as an aid to navigation and is not a replacement for proper navigational judgement. Information provided by the equipment must not be relied upon as accurate. User decisions based upon information provided by the equipment are done so entirely at the users own risk. The accuracy of a GNSS position fix is variable and affected by factors such as the antenna positioning, how many satellites are used to determine a position and for how long satellite information has been received. Please keep away from the VHF antenna, which is connected to the easyAtoN, when the device is powered on and is transmitting. The recommended distance is 20 cm and more, to avoid higher RF exposure to the human body. • Warnings and Precautions If you use the easyAtoN for marking an aquaculture plant, it is the sole responsibility of the owner/operator of the easyAtoN to enter the correct position of the AtoN in the WGS84 coordinates. If the coordinates (LAT/LON) are wrong, the transmissions of the easyAtoN may cause dangerous situations or damages to other ships. Even if the coordinates are entered correctly, it might be possible that a ship damages the plant, because not all vessels carry AIS stations and therefore are not able to receive the aquaculture AtoN. It is a violation of the rules of the Federal Communications Commission to input an MMSI that has not been properly assigned to the end user, or to otherwise input any inaccurate data in this device. This device must be programmed with the data corresponding to the AtoN on which it will be installed. Programming must be carried out by a Weatherdock dealer. The included instructions contain information on how to verify the correct programming. • Product category This product is categorized as ‘exposed’ in accordance to IEC 62320-2:2017. • Revision Level Stand 1.0, Author: MK, 03/2020 • Restrictions Weatherdock AG Page 3 www.easyAIS.com There are no known restrictions for the usage of the easyTRX3 in EU countries. Weatherdock AG Page 4 www.easyAIS.com 2 Index of Abbreviations Abbreviations CPA Closest point of approach LAN Local area network NMEA National Marine Electronics Association SSID Service set identifier device VHF Very High Frequency VSWR voltage standing wave ratio WiFi wireless fidelity -connect to a network by radio GNSS global navigation satellite system MMSI Maritime mobile service identity HDOP horizontal dilution of precision 3 Pictures/Sketches Overview Figure 1 - scope of delivery ..................................................................................................................................... 6 Figure 2 - AIS general overview ............................................................................................................................... 8 Figure 3 - AtoN supported messages .................................................................................................................... 10 Figure 4 - easyAtoN - connectors and plugs .......................................................................................................... 11 Figure 5 - easyAtoN drilling mask .......................................................................................................................... 12 Figure 6 - power and interface connectors ........................................................................................................... 14 Figure 7 - AtoN type of marks ............................................................................................................................... 15 Figure 8 - programming software ......................................................................................................................... 16 Figure 9 - technical data ........................................................................................................................................ 18 Weatherdock AG Page 5 www.easyAIS.com Table of Contents 1 References ........................................................................................................................................... 2 2 Index of Abbreviations ........................................................................................................................ 4 3 Pictures/Sketches Overview ................................................................................................................ 4 4 Scope of delivery ................................................................................................................................. 6 5 Introduction ......................................................................................................................................... 7 5.1 General Information about AIS ................................…
