ZPI-PCR100PointSafe RF

Table of Contents PointSafe Diagram & Overview Registering your PointSafe Quick Start Guide User Guide - PointSafe & PointSafe RF Installation Guide FAQ’s FCC & IC Notice Table of Contents Page 3 PointSafe Diagram Page 4 PointSafe Diagram & Overview Page 5 Registering PointSafe Page 6 Quick Start Guide Page 7 PointSafe Users Guide Programming the PointSafe - Set Clock Page 8-9 Using the PointSafe - Access Key - Deleting PIN - Review Access History Page 10 PointSafe RF Users Guide Enrolling PointSafe RF (GE/UTC Security systems only) Programming the PointSafe RF - Set Clock Page 11-12 Using the PointSafe RF - Access Key & Disabling Alarm - Return Key & Enable Alarm - Deleting PIN - Review Access History 7 RF Transmitter (PointSafe RF only) LCD Display LED Lights Serial Number Key Container –Key “leash” Thumb Turn Knob (releases Key Container) Keypad Mounting Bracket PointSafe Overview The PointSafe provides a secure electronic method for storing a key(s), eliminating the need for employee or vendor keys, accidental lockouts and costly change of locks due to lost, unreturned or stolen keys. The PointSafe also records each access increasing employee and vendor accountability. Each employee or vendor who you have authorized for access is assigned a unique PIN number. To gain access they simply enter their PIN number into the PointSafe keypad, turn the thumb lever and remove the key container. The access key should be attached to the removable key container with a “key leash” (included with the PointSafe). After removing the key and unlocking the door the employee or vendor simply reinserts the key container back into the PointSafe. Each access is recorded by PIN, date and time. The last 90 days of access history can be viewed on the PointSafe display by date or by PIN. The PointSafe comes pre-programmed with 9,000 unique PIN’s. There are three “PIN permission” levels: a) Administrative PIN a. Only PIN that enables programming of PointSafe, PIN deletion, view history b) Manager PIN a. Allows access, deletion of employee and vendor PIN, view access history c) Employee PIN a. Access only d) Vendor PIN a. Access only There are 5 simple steps required to begin using the PointSafe: 1) Install the PointSafe at the desired access point 2) Register the PointSafe at www.pointcentral.com 3) Set the PointSafe clock 4) Obtain PIN codes at www.pointcentral.com 5) Assign PIN codes to authorized employees and/or vendors Registering your PointSafe You will receive a sealed envelope containing a Registration code and an Administration code in your PointSafe shipment. If this envelope has been opened without your knowledge please call the following number (insert tech support number) The PointSafe comes pre-programmed with a 7 digit Registration Code. The Registration Code and the Administration code are required to Register your PointSafe which is done via the PointCentral website. The ADMINISTRATOR can be you or whomever you authorize as the ADMINISTRATOR. The ADMINISTRATOR will be responsible for future setup and programming of the PointSafe. The ADMINISTRATOR needs to register your PointSafe online the first time it is used. This will activate your 6-digit ADMINISTRATOR User Code. 1. Your pre-programmed 7-digit PointSafe Registration Code is located in the tamper-proof envelope included with your PointSafe. To register your PointSafe with your pre- programmed 7-digit Registration Code, simply log onto the Web at www.pointcentral.com. 2. Key your PointSafe Registration Code ____ (here)______ to register your device online. Complete registration by providing all customer information requested. 3. This will activate your 6-digit ADMINISTRATOR User Code that belongs to this device. **Write this ADMINISTRATOR code down and store in a secure place for future referrals. Subsequent setup and administration of additional PointSafe users and their user codes will always require this ADMINISTRATOR User Code. To avoid resetting the entire PointSafe system, retain this ADMINISTRATOR code in a secure, permanent location. 4. Now that you have activated your 6-digit ADMINISTRATOR User Code, you are able to view PIN codes online and print them as needed. Store these codes in a secure location for future referrals. If you subscribe to the PointCodes service option (during or after PointSafe on- line registration) you will be able assign and store all PIN code and information on-line using the PointCodes application. Logging on to www.PointCentral.com and entering your user name and password provides access to the PointCodes application. Quick Start Guide Before getting started please check to ensure that you have the following items: PointSafe Registration Envelope Note: This envelope was sealed at the factory. If this envelope is not sealed and was opened by someone other than you or your authorized installer please call the following customer support number (insert tech support number) PointSafe mounting template Mounting hardware (included with exception of hardware for brick mount location) Quick Start Instructions Step 1 – Select desired location for mounting the PointSafe Step 2 - Mount the PointSafe per the enclosed mounting instructions Step 3 - Open the sealed “registration envelope” Step 4 - Log onto the following site: www.PointCentral.com Step 5 - Click on the “Registration” tab on the lower left hand corner of the home page Step 6 – Obtain PIN codes: Log onto www.PointCentral.com Note: If you subscribed to PointCodes service plan Step 7 – Program PointSafe clock Step 8 – Provide PIN codes to employees (remember to document and securely store) PointCodes web service (complete instructions once software has been completed) User Guide - PointSafe Programming the PointSafe Set Clock a. Press * key on PointSafe keypad b. Enter “administrative PIN” (obtained during registration process) c. Screen will display Access? press the > until “setup?” is displayed press “OK” d. Press the > button until “Set Time” is displaye…

Text truncated - open the document above for the full version.

~ l~ PointCentral 1665LibertyStreetSouth Salem,OR97302 Authorityto Act as Agent Date:6/14/11 ---- AmericanCertificationBody,Inc. 6731WhittierAvenue SuiteClIO McLean,VA 22101 To WhomIt MayConcern: Rob HendricksonIis authorizedto act on our behalf,untilotherwisenotified,for applications to AmericanCertificationBody,Inc. (ACB). We certifythat we are not subjectto denialof federalbenefits,that includesFCCbenefits,pursuantto Section5301of the Anti-DrugAbuseAct of 1988,21D.S.C.862.Further,no party,as definedin 47 CFR1.2002(b). to the applicationis subjectto denialof federalbenefits,that includesFCCbenefits. Thankyou, AgencyAgreementExpirationDate:__-,,5~/=-3~1/,-,1C!:2,-__ By: Stan Earnshaw -------- (Printname) /<...J(Signature) Title:_VPSales& Marketing,_ On behalfof:PointCentral ------- (CompanyName) Telephone:503-367-7083_ 1 _ If a group"entity"is designatedas the authorizedagent,the letterof authorizationmustidentifythoseindividualswithin the groupwhoare authorizedto take actionon the application;or alternativelya statementmustbe providedindicating that as the authorizedagent,any individualwithinthe group"entity"is authorizedto act on behalfof the applicantI granteeand take actionon the application.See b1li1S:,'iai1JlsJ,,~.. gtl\ /O<:iclikdbilllnnsifT)Scar.chgc,;ulll.'agcsiin"s\\iICh=I'&id= 333 J(, . 2 _ \1ustbe s;giiec~bycontactgi \lei1 YOlo ?ppl icanton. ~-!V:: L·:C(~site. 0(' i):the c1uliuJi'iz;.::~~~1g:cnt:r 211 ~:,\)rupcia1.c <.luthcrIzedr.gl~ntL~t':I:;r[~(1Sb~;~;·1Iy·oV~(~ed.Letterssbouklb·;.:; ph:Cf;dOi1 app!·o~):·intetci~teI"11e;:~~~,

PointCentral LLC FCC ID: ZPI-PCR100 Certification Test Report 2011-07-18 Contents 1. Introduction ................................................................................................................................................................. 3 2. Statement of Compliance ............................................................................................................................................ 3 2.1. FCC Part 2 §2.907 ................................................................................................................................................ 3 2.2. FCC Part 2 §2.911 ................................................................................................................................................ 3 2.3. FCC Part 2 §2.913 ................................................................................................................................................ 3 2.4. FCC Part 2 §2.915 ................................................................................................................................................ 3 2.5. FCC Part 2 §2.925 ................................................................................................................................................ 4 2.6. FCC Part 2 §2.943, 2.945 .................................................................................................................................... 4 2.7. FCC Part 2 §2.947 ................................................................................................................................................ 4 2.8. FCC Part 2 §2.948 ................................................................................................................................................ 4 2.9. FCC Part 2 §2.1033 .............................................................................................................................................. 5 3. Discussion of Laboratory Measurements and Rules Compliance ............................................................................... 6 3.1. FCC Part 15 §15.231(a)(1) .................................................................................................................................. 6 3.2. FCC Part 15 §15.231(a)(2) .................................................................................................................................. 6 3.3. FCC Part 15 §15.231(a)(3) .................................................................................................................................. 6 3.4. FCC Part 15 §15.231(a)(4) .................................................................................................................................. 6 3.5. FCC Part 15 §15.231(a)(5) .................................................................................................................................. 6 3.6. FCC Part 15 §15.231(b) ....................................................................................................................................... 6 3.6.1. Raw Field Strength Limits ............................................................................................................................ 6 3.6.2. Duty Cycle Correction Factor and Resulting Limits ..................................................................................... 7 3.6.3. Measured Radiated Field Strength Data ....................................................................................................... 7 3.7. FCC Part 15 §15.231(c) ....................................................................................................................................... 7 1.Introduction Model PC-R100 is a small battery-powered transceiver keypad for use in a wireless alert system. Certification is requested under FCC Rules, Part 15, Subpart C, Paragraph 15.231. 2.Statement of Compliance Specific sections of FCC Rules Part 2 that require information or listing are given below. 2.1.FCC Part 2 §2.907 This is an application for certification of original equipment 2.2.FCC Part 2 §2.911 a)This application has been filed electronically using form 731. b)All required information has been supplied in this application and its attachments. c)This applicant has signed the application electronically. d)The technical test data has been signed by the agency performing the testing. e)Signature supplied in appropriate block on form 731. f)Processing fee has been paid by credit card. g)Signatures have been supplied electronically. 2.3.FCC Part 2 §2.913 a)This application has been filed electronically. b)Appropriate fees have been filed electronically. c)Equipment samples shall be supplied as requested. 2.4.FCC Part 2 §2.915 We are requesting a grant of certification. This application shows compliance with the technical standards. 2.5.FCC Part 2 §2.925 A label shall be affixed to each piece of equipment, showing the FCC identifier. The label shall read “FCC ID: ZPI- PCR100”. See exhibit “Label.pdf” for photographs showing the label and location on the device. External and internal photos are provided in exhibits “External Photos.pdf” and “Internal Photos.pdf”. 2.6.FCC Part 2 §2.943, 2.945 Sample production equipment shall be submitted to the FCC upon request. 2.7.FCC Part 2 §2.947 a)Measurement procedure follows ANSI C63.4 version 2009 b)A description of utilized test equipment is contained in attached “Radiated Data.pdf”. 2.8.FCC Part 2 §2.948 Radiated measurements were taken at the following FCC-approved facility: Compliance Certification Services 47173 Benicia Street, Fremont, CA 94538, USA Tel: 1-510-771-1000 Fax: 1-510-661-0888 Contact: Thu Chan [email protected], See exhibit “Test Setup Photo.pdf” for a photo of the test site. 2.9.FCC Part 2 §2.1033 a. Form 731 has been filed electronically. b. The technical report, along with its exhibits, contains the information as follows: 1. Full name and mailing address of the manufacturer of t…

Text truncated - open the document above for the full version.

ENGINEERING EVALUATION DATA 1. TEST AND MEASUREMENT EQUIPMENT The following test and measurement equipment was utilized for the tests documented in this report: DescriptionManufacturerModelAssetCal DateCal Due Spectrum Analyzer, 26.5 GHzAgilent / HPE4440AC0117901/19/1101/19/12 Antenna, Bilog, 2 GHzSunol SciencesJB1C0101107/12/1007/12/11 Spectrum Analyzer, 26.5 GHzAgilent / HPE4440AC0117608/10/1008/10/11 Antenna, Bilog, 2 GHzSunol SciencesJB1C0117107/12/1007/12/11 Preamplifier, 1300 MHzAgilent / HP8447DC0055801/27/1101/27/12 Antenna, Horn, 18 GHzEMCO3115C0087206/30/1106/30/12 Preamplifier, 26.5 GHzAgilent / HP8449BC0074907/14/1007/14/11 TEST EQUIPMENT LIST 2. RADIATED EMISSION TEST RESULTS 2.1. TX RADIATED SPURIOUS EMISSION LIMITS FCC §15.231 (b) IC A1.1.2 In addition to the provisions of § 15.205, the field strength of emissions from Intentional radiators operated under this section shall not exceed the following: Fundamental Field Strength of Field Strength of Frequency Fundamental Frequency Spurious Emissions (MHz) (microvolts/meter) (microvolts/meter) ______________________________________________________________ 40.66 - 40.70 2,250 225 70 - 130 1,250 125 130 - 174 1,250 to 3,7501 125 to 3751 174 - 260 3,750 375 260 - 470 3,750 to 12,5001 375 to 1,2501 Above 470 12,500 1,250 _______________________________________________________________ 1 Linear interpolation §15.205 (a) Except as shown in paragraph (d) of this section, only spurious emissions are permitted in any of the frequency bands listed below: MHz MHz MHz GHz 0.090 - 0.110 1 0.495 - 0.505 2.1735 - 2.1905 4.125 - 4.128 4.17725 - 4.17775 4.20725 - 4.20775 6.215 - 6.218 6.26775 - 6.26825 6.31175 - 6.31225 8.291 - 8.294 8.362 - 8.366 8.37625 - 8.38675 8.41425 - 8.41475 12.29 - 12.293 12.51975 - 12.52025 12.57675 - 12.57725 13.36 – 13.41 16.42 - 16.423 16.69475 - 16.69525 16.80425 - 16.80475 25.5 - 25.67 37.5 - 38.25 73 - 74.6 74.8 - 75.2 108 - 121.94 123 - 138 149.9 - 150.05 156.52475 - 156.52525 156.7 - 156.9 162.0125 - 167.17 167.72 - 173.2 240 - 285 322 - 335.4 399.9 - 410 608 - 614 960 - 1240 1300 - 1427 1435 - 1626.5 1645.5 - 1646.5 1660 - 1710 1718.8 - 1722.2 2200 - 2300 2310 - 2390 2483.5 - 2500 2655 - 2900 3260 - 3267 3332 - 3339 3345.8 - 3358 3600 - 4400 4.5 - 5.15 5.35 - 5.46 7.25 - 7.75 8.025 - 8.5 9.0 - 9.2 9.3 - 9.5 10.6 - 12.7 13.25 - 13.4 14.47 - 14.5 15.35 - 16.2 17.7 - 21.4 22.01 - 23.12 23.6 - 24.0 31.2 - 31.8 36.43 - 36.5 ( 2 ) 1 Until February 1, 1999, this restricted band shall be 0.490-0.510 MHz. 2 Above 38.6 §15.205 (b) Except as provided in paragraphs (d) and (e), the field strength of emissions appearing within these frequency bands shall not exceed the limits shown in Section 15.209. At frequencies equal to or less than 1000 MHz, compliance with the limits in Section 15.209 shall be demonstrated using measurement instrumentation employing a CISPR quasi peak detector. Above 1000 MHz, compliance with the emission limits in Section 15.209 shall be demonstrated based on the average value of the measured emissions. The provisions in Section 15.35 apply to these measurements. §15.209 (a) Except as provided elsewhere in this Subpart, the emissions from an intentional radiator shall not exceed the field strength levels specified in the following table: Frequency Field Strength Measurement Distance (MHz) (microvolts/meter) (meters) ______________________________________________________________ 30 88 100 ** 3 88 216 150 ** 3 216 960 200 ** 3 Above 960 500 3 _______________________________________________________________ ** Except as provided in paragraph (g), fundamental emissions from intentional radiators operating under this Section shall not be located in the frequency bands 54 72 MHz, 76 88 MHz, 174 216 MHz or 470 806 MHz. However, operation within these frequency bands is permitted under other sections of this Part, e.g., Sections 15.231 and 15.241. §15.209 (b) In the emission table above, the tighter limit applies at the band edges. TEST PROCEDURE The EUT is placed on a non-conducting table 80 cm above the ground plane. The antenna to EUT distance is 3 meters. The EUT is configured in accordance with ANSI C63.4. The EUT is set to transmit in a continuous mode. For measurements below 1 GHz the resolution bandwidth is set to 100 kHz for peak detection measurements or 120 kHz for quasi-peak detection measurements. Peak detection is used unless otherwise noted as quasi-peak. For measurements above 1 GHz the resolution bandwidth is set to 1 MHz, then the video bandwidth is set to 1 MHz for peak measurements and 10 Hz for average measurements. The frequency range of interest is monitored at a fixed antenna height and EUT azimuth. The EUT is rotated through 360 degrees to maximize emissions received. The antenna is scanned from 1 to 4 meters above the ground plane to further maximize the emission. Measurements are made with the antenna polarized in both the vertical and the horizontal positions. RESULTS No non-compliance noted: FUNDAMENTAL EMISSIONS (Z-POSITION) HARMONICS AND TX SPURIOUS EMISSION (30 – 1000 MHz) HARMONICS AND TX SPURIOUS EMISSIONS ABOVE 1GHz 2.2. RX RADIATED SPURIOUS EMISSION LIMITS IC RSS-Gen Issue 2, section 7.2.3.2 All spurious emissions shall comply with the limits shown below: Limits for radiated disturbance of Class B ITE at measuring distance of 3 m Frequency range (MHz) Quasi-peak limits (dBμV/m) 30 to 88 40 88 to 216 43.5 216 to 960 46 Above 960 MHz 54 Note: The lower limit shall apply at the transition frequency. TEST PROCEDURE The EUT is placed on a non-conducting table 80 cm above the ground plane. The antenna to EUT distance is 3 meters. The EUT is configured in accordance with ANSI C63.4. The EUT is set to receive in a continuous mode. For measurements below 1 GHz the resolution bandwidth is set to 100 kHz for peak detection measurements or 120 kHz for quasi-peak detection measurements. Peak detection is used unless otherwise noted as quasi-peak. For measurements above 1 GHz the resol…

Text truncated - open the document above for the full version.

RADIATED EMISSIONS ABOVE 30 MHz (FRONT) RADIATED EMISSIONS ABOVE 30 MHz (BACK)
