ZPZ0711MGSOLOMacKay Guardian Solo

MacKay Guardian™ Solo Operation and Maintenance Guide MacKay Document Number: C11-0934 August 2011, Version 1.1 (draft) Approved for release by: Director Engineering: Greg Chauvin Customer Service: Daniel Benoit Document Quality Control: Leanne Redding OFFICE USE ONLY MacKay Guardian™ Solo Operation and Maintenance Guide MacKay Document Number: C11-0934 August 2011, Version 1.1 (Draft) Prepared for Limited Release / PTCRB Certification. Head Office United States United Kingdom J.J. MacKay Canada Limited MacKay Meters, Inc. MacKay Meters (UK) Limited c/o J.J. MacKay Canada Limited P.O. Box 338 P.O. Box 338 Unit 8 1342 Abercrombie Road 1342 Abercrombie Road Eldon Way New Glasgow, Nova Scotia New Glasgow, Nova Scotia Paddock Wood, Kent B2H 5E3 Canada B2H 5E3 Canada TN12 6BE England Tel: (902) 752-5124 Tel: (888) 462-2529 Tel: 01892–837737 Fax: (902) 752-5955 Fax: (902) 752-5955 Fax: 01892–837736 Visit our website at www.jjmackay.com Copyright © (2011) J.J. MacKay Canada Limited. All rights reserved. MacKay Guardian™ Solo Operation and Maintenance Guide For meter application software version n.n and higher MacKay Document Number: C11-0934 Version 1.1 (draft) J.J. MacKay Canada Limited reserves the right to modify this document without prior notice. The information contained herein includes information which is confidential and proprietary to J.J. MacKay Canada Limited. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written consent of J.J. MacKay Canada Limited. If however, your only means of access is electronic, permission to print one copy is hereby granted. Instructions in this document do not purport to cover all details or variations in equipment or software, nor to provide for every possible contingency to be met during installation, operation, and maintenance. If further information is desired, or if particular problems arise that are not covered sufficiently for the purchaser’s purpose, the matter should be referred to J.J. MacKay Canada Limited. J.J. MacKay Canada Limited may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document. Except as expressly provided in any written license agreement from J.J. MacKay Canada Limited, the furnishing of this document does not give you any license to these patents, trademarks, copyrights, or other intellectual property. MacKay Meters is a registered trade name of J.J. MacKay Canada Limited. The MacKay logo, MacKay Guardian and SmartChute are either trademarks or registered trademarks of J.J. MacKay Canada Limited in Canada and other countries. Windows and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. PRESAT is a registered trademark of Preventative Maintenance Corp. LPS is a registered trademark of Holt Lloyd Corporation. ProGold is a trademark of Caig Laboratories, Inc. All other trademarks are the property of their respective owners. FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. Any change or modification to the product not expressly approved by J.J. MacKay Canada Limited could void the user's authority to operate the device. This equipment complies with FCC radiation exposure limits set forth in an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the equipment and the user’s body. Industry Canada Statement: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of the device Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: 1) l'appareil ne doit pas produire de brouillage, et 2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This device has been designed to comply with safety requirements for exposure to radio waves (SAR) in accordance with RSS-102. This device should be installed and operated with minimum distance 20cm between the equipment and your body. Cet artifice a été conçu pour se plier à la sécurité les exigences pour l'exposition aux ondes radioélectriques (SAR) dans conformité avec RSS-102. Cet artifice devrait être installé et fait marcher avec la distance minimale 20 centimètres entre l'équipement et votre corps. MacKay Guardian™ Solo Operation and Maintenance Guide, v. 1.1 i Revision History Version Description of Changes Initials Date of Change 1.0 Initial Version (Draft) GEC June 2011 1.1 FCC & Industry Canada Statements added GEC Aug 15 2011 Take Note MacKay has attempted to update pictures/screen shots to the most current revision, where there is a possibility that some confusion could result in describing a particular item/function/procedure. To identify noteworthy changes/additions to the document, where possible/practical a yellow text box, as shown below, will appear next to the section that has been changed. NEW! MacKay Guardian™ Solo Operation and Maintenance Guide, v.1.1 ii Table of Contents 1. Introduction .................................................................................................................................................1 1.1 List of Terms...............................................................................................................................................2 2. …

Text truncated - open the document above for the full version.

J.J. MacKay Canada Limited 1342 Abercrombie Road P.O. Box 338 New Glasgow, Nova Scotia Canada B2H 5E3 Tel: (902) 752-5124 Fax: (902) 752-5955 August 15, 2011 Telecommunication Certification Body RFI Global Services Ltd Pavilion A, Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom To whom it may concern This is to certify that J.J. MacKay Canada Limited, the parent company of U.S. subsidiary Company MacKay Meters Inc., authorizes RFI Global Services Limited to act on our behalf for the application of the FCC ID: ZPZ0711MGSOLO to RFI Global Services Ltd. Telecommunication Certification Body. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Yours Sincerely Greg Chauvin, CET Director of Engineering

J.J. MacKay Canada Limited 1342 Abercrombie Road P.O. Box 338 New Glasgow, Nova Scotia Canada B2H 5E3 Tel: (902) 752-5124 Fax: (902) 752-5955 September 2, 2011 TelecommunicationCertification Body RFI Global Services Ltd. Pavilion A, Ashwood Park Basingstoke, Hampshire RG23 8BG United Kingdom Subject: Confidentiality Request; Certification Application FCC ID: ZPZ0711MGSOLO Pursuant to sections 0.457 and 0.459 of CFR 47 J.J. MacKay Canada Limited, the parent Company of US subsidiary Company, MacKay Meters, Inc., requests that the following information, provided to support the FCC application for the Equipment MacKay Guardian Solo, FCC ID: ZPZ0711MGSOLO, be held permanently confidential: • Schematics • Bill Of Materials • Operational Descriptions • Block Diagrams The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. This information should not be available for public disclosure for an indefinite period of time. Furthermore, pursuant to Public Notice DA 04-1705 in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, we request the following exhibits be withheld from public viewing for a short limited time up to the date of 03 March 2012, due to sensitive business information: • User Guide • Internal Photos • External Photos • Test Setup Photos Yours sincerely, Greg Chauvin, CET Director Engineering

MacKay Guardian™ Solo – External Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 1 MacKay Guardian™ Solo – External Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 2 MacKay Guardian™ Solo – External Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 3 MacKay Guardian™ Solo – External Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 4 MacKay Guardian™ Solo – External Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 5 MacKay Guardian™ Solo – External Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 6

MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 1 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 2 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 3 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 4 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 5 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 6 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 7 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 8 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 9 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 10 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 11 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 12 MacKay Guardian™ Solo – Internal Photos – FCC ID ZPZ0711MGSOLO J.J. MacKay Canada Limited - CONFIDENTIAL 13

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Connected Development LLC, Mackay Meter To: 47CFR15.109 and RSS-GEN Issue 3 Test Report Serial No: RFI-EMC-RP81979JD07A V2.0 Version 2.0 supersedes all previous versions This test report is issued under the authority of Chris Guy, Head of Global Approvals: Checked By: Nicholas Jones Signature: Date of Issue: 09 September 2011 This report is issued in portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DATE: 09 SEPTEMBER 2011 Page 2 of 22 RFI Global Services Ltd. This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DATE: 09 SEPTEMBER 2011 RFI Global Services Ltd. Page 3 of 22 TABLE OF CONTENTS 1. Customer Details .............................................................................................................. 5 2. Summary of Testing ......................................................................................................... 6 3. Equipment under Test (EUT) ........................................................................................... 7 4. Support Equipment ........................................................................................................... 8 5. Monitoring Performance .................................................................................................. 9 6. Measurement Uncertainty .............................................................................................. 10 7. Measurements, Examinations and Derived Results .................................................... 11 8. Photographs of EUT ....................................................................................................... 14 9. Graphical Test Results ................................................................................................... 16 10. Test Configuration Drawing ......................................................................................... 21 TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DATE: 09 SEPTEMBER 2011 Page 4 of 22 RFI Global Services Ltd. This page has been intentionally left blank. TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DATE: 09 SEPTEMBER 2011 RFI Global Services Ltd. Page 5 of 22 1. CUSTOMER DETAILS Company Name: Connected Development LLC Address: 5020 Weston Parkway Suite 215 Cary, NC 27513 United States TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DATE: 09 SEPTEMBER 2011 Page 6 of 22 RFI Global Services Ltd. 2. SUMMARY OF TESTING 2.1. Test Specification Reference: 47CFR15.109 Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart B (Radio Frequency Devices) – Section 15.109. Reference: RSS-GEN Issue 3 December 2010 Title: General Requirements and Information for the Certification of Radio Apparatus Site Registration: FCC: 209735 Industry Canada: 3245B-2 2.2. Summary of Test Results FCC Reference IC Reference Measurement Type Applicability Result 15.109 RSS-Gen 4.10 RSS-Gen 6.1 Radiated Emissions (Enclosure) Y KEY: = Complied = Did not comply 2.3. Location of Testing All the measurements described in this report were performed at the premises of RFI Global Services Ltd, Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire RG24 8AH. 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above, nor from the requirements defined in the basic standards called up within it. TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DATE: 09 SEPTEMBER 2011 RFI Global Services Ltd. Page 7 of 22 3. EQUIPMENT UNDER TEST (EUT) 3.1. Description of EUT The EUT was a remote GSM Parking Meter. 3.2. Identification of Equipment under Test (EUT) ID# Description Brand Name Model No Serial No IMEI E1 Enclosure Mackay Meter 22GD4000000 9000001 352421040133521 3.3. Port Identification Port Description Type P1 Enclosure - 3.4. Operating Modes Mode Reference Definition Idle The EUT was in a stand-alone state scanning for a network Radio characteristics GSM Bands supported: Rated Output Power (dBm) Transmit Frequency range (MHz) ARFCN Transmit Frequency (MHz) Receive Frequency range (MHz) ARFCN Receive Frequency (MHz) GSM 850 33 824 – 849 190 836.6 869 – 894 190 881.6 PCS 1900 30 1850 – 1910 660 1879.8 1930 – 1990 660 1959.8 Supported Technologies e.g. Circuit Switched Voice/Data, Packet Switched Data GPRS/ EDGE Packet switched data 3.5. Configuration and Peripherals Description: Please refer to the Test Configuration and Photograph section for schematic drawing(s) and/or photograph(s) of the test configuration(s) employed in the course of testing. 3.6. Modifications NOTE: No modifications were made during the course of testing 3.7. Additional Information Related to Testing Equipment Category: GSM mobile Intended Operating Environment: Commercial / industrial Cycle Time: < 1 second Power Supply Requirement(s): Internal Batteries / Solar Cell Weight: 8.3 kg Dimensions: 300 x 180 x 180 mm Antenna Type Integral FCC ID: ZPZ0711MGSOLO IC Number: 9753A-MGSOLO TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DATE: 09 SEPTEMBER 2011 Page 8 of 22 RFI Global Services Ltd. 4. SUPPORT EQUIPMENT 4.1. Identification of Support Equipment NOTE: No support equipment or interconnecting cables were required for this test. TEST REPORT SERIAL NO: RFI-EMC-RP81979JD07A V2.0 VERSION: 2.0 ISSUE DA…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Mackay Guardian Solo MGSOLO FCC ID: ZPZ0711MGSOLO IC Certification Number: 9753A-MGSOLO To: FCC Parts 15.209 and 15.215; Industry Canada RSS Gen 4.6 and 4.9 Test Report Serial No: RFI-RPT-RP81979JD05A Version 3.0 supersedes all previous versions This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: Checked By: Ian Watch Signature: pp Date of Issue: 09 September 2011 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP81979JD05A VERSION NO. 3.0 ISSUE DATE: 09 SEPTEMBER 2011 Page 2 of 14 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP81979JD05A VERSION NO. 3.0 ISSUE DATE: 09 SEPTEMBER 2011 RFI Global Services Ltd Page 3 of 14 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 5 2.4. Deviations from the Test Specification 5 3. Equipment Under Test (EUT) ....................................................................................................... 6 3.1. Identification of Equipment Under Test (EUT) 6 3.2. Description of EUT 6 3.3. Modifications Incorporated in the EUT 6 3.4. Additional Information Related to Testing 6 3.5. Support Equipment 6 4. Operation and Monitoring of the EUT during Testing ............................................................... 7 4.1. Operating Modes 7 4.2. Configuration and Peripherals 7 5. Measurements, Examinations and Derived Results .................................................................. 8 5.1. General Comments 8 5.2. Test Results 9 5.2.1. Transmitter Radiated Emissions (Fundamental) 9 5.2.2. Transmitter Radiated Spurious Emissions 10 5.2.3. Transmitter 20 dB Bandwidth 12 6. Measurement Uncertainty .......................................................................................................... 13 Appendix 1. Test Equipment Used ................................................................................................ 14 TEST REPORT SERIAL NO: RFI-RPT-RP81979JD05A VERSION NO. 3.0 ISSUE DATE: 09 SEPTEMBER 2011 Page 4 of 14 RFI Global Services Ltd 1. Customer Information Company Name: Connected Development LLC Address: 5020 Weston Parkway Suite 215 Cary NC 27513 United States TEST REPORT SERIAL NO: RFI-RPT-RP81979JD05A VERSION NO. 3.0 ISSUE DATE: 09 SEPTEMBER 2011 RFI Global Services Ltd Page 5 of 14 2. Summary of Testing 2.1. General Information Specification Reference: FCC 47CFR15.209 and 47CFR15.215 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2010: Part 15 Subpart C (Intentional Radiators) - Sections 209 and 15.215 Specification Reference: Industry Canada RSS-Gen Issue 3 December 2010 Specification Title: General Requirements and Information for the Certification of Radio Apparatus Specification Reference: Industry Canada RSS-210 Issue 8 December 2010 Specification Title: Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment. Site Registration: FCC: 209735; Industry Canada: 3245B-2 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 21 July 2011 to 28 July 2011 2.2. Summary of Test Results FCC Reference (47CFR) IC Reference Measurement Result Part 15.209 RSS-Gen 4.9/7.2.5 Transmitter Radiated Emissions (Fundamental) Part 15.209 RSS-Gen 4.9/7.2.5 Transmitter Radiated Emissions Part 15.215(c) RSS-Gen 4.6.1/4.6.3 Transmitter 20 dB Bandwidth Key to Results = Complied = Did not comply 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP81979JD05A VERSION NO. 3.0 ISSUE DATE: 09 SEPTEMBER 2011 Page 6 of 14 RFI Global Services Ltd 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: Mackay Guardian Solo Model Number: MGSOLO Serial Number: 9000001 Hardware Version Number: 001 Software Version Number: 001 FCC ID: ZPZ0711MGSOLO IC Certification Number: 9753A-MGSOLO 3.2. Description of EUT The equipment under test was a parking meter fitted with an RFID module. 3.3. Modifications Incorporated in the EUT No modifications were applied to the EUT during testing. 3.4. Additional Information Related to Testing Tested Technology: RFID Power Supply Requirement: Nominal 4.5 VDC Type of Unit: Transceiver Channel Spacing: Single channel Transmit Frequency 114 kHz 3.5. Support Equipment No support equipment was used to exercise the EUT during testing. TEST REPORT SERIAL NO: RFI-RPT-RP81979JD05A VERSION NO. 3.0 ISSUE DATE: 09 SEPTEMBER 2011 RFI Global Services Ltd Page 7 of 14 4. Operation and Monitoring of the EUT during Testing 4.1. Operating Modes The EUT was tested in the following operating mode(s): • Constantly transmitting at full power with a modulated carrier in test mode. 4…

Text truncated - open the document above for the full version.
