ZQ3-SPS-USZONMining Safety Proximity Transmitter

Strata Proximity Systems LLC

Click to zoom

Application Details

Equipment Class: DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant: Jan 17, 2012
Application Purpose: Original Equipment
Date of Application: Jan 16, 2012
Equipment Note: Mining Safety Proximity Transmitter
Frequency Range: 0.07300000 - 0.07300000
Company: Strata Proximity Systems LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Strata Proximity Systems Underground Silent Zone Generator Users Manual v1.0 2011 Strata Proximity Systems, LLC 1769 Jeff Road Huntsville, AL 35806 1.800.691.6601 Confidential Patent #’s 7,420,471 5,939,986 and 6,810,353 Patent Pending Page 2 of 6 Strata Proximity Systems Underground Silent Zone Generator Users Manual v1.0 Confidential and Proprietary December 12, 2011 Table of Contents 1 Overview .............................................................................................................................3 1.1 Theory of Operation ......................................................................................................3 1.2 Frequency of Operation ................................................................................................3 1.3 Label Information..........................................................................................................3 1.4 FCC Information ............................................................................................................4 2 Operation ............................................................................................................................5 2.1 Installation Information ................................................................................................5 2.1.1 Interoperability Warning ........................................................................................5 2.2 Charging ........................................................................................................................5 2.3 Alerts ............................................................................................................................5 2.4 Maintenance .................................................................................................................6 3 Warranty .............................................................................................................................6 4 Revision History ...................................................................................................................6 4.1 Version 1.0 – December 12, 2011..................................................................................6 Confidential Patent #’s 7,420,471 5,939,986 and 6,810,353 Patent Pending Page 3 of 6 Strata Proximity Systems Underground Silent Zone Generator Users Manual v1.0 Confidential and Proprietary December 12, 2011 1 Overview The Underground Silent Zone Generator is part of a complete HazardAvert™ Proximity Detection System from Strata Proximity Systems which provides warnings to both individuals and to machinery to alert them that the individual has entered too close to an operating piece of equipment and is in a dangerous situation. The Underground Silent Zone Generator is mounted on a vehicle or piece of machinery and is connected by an interface cable to an Underground controller. The Underground Silent Zone Generator is mounted on the vehicle or machinery in an area near where the operator would normally be while operating the machinery. 1.1 Theory of Operation The function of the Underground Silent Zone Generator is:  To transmit a 73 kHz “Silent Zone” field around a small portion of the vehicle or piece of machinery in which the operator is allowed to work or enter as part of his normal activities. The Underground Silent Zone Generator is connected to a HazardAvert™ Underground Controller which generates a 73 kHz signal for creating a Silent Zone around the area of a machine where the operator is located. This 73 kHz signal is connected to the Silent Zone Generator via a wire bundle. Inside the Underground Silent Zone Generator is a wire/ferrite radiator element to which the 73 kHz signal is connected. The 73 kHz signal passing through this wire/ferrite radiator element generates a “Silent Zone” electromagnetic field which encompasses only the small area of the machine in which the operator can be during operation. The operator is required to wear a Personal Alarm Device (PAD) which is another component of the HazardAvert™ system which detects and responds to the presence of 73 kHz fields. As long as the operator is within this “Silent Zone” his PAD will know he is within a defined area and not alarm. If the operator exits this Silent Zone area, his PAD will function to alert him and other machines equipped with the HazardAvert™ system of his proximity to dangerous conditions due to his distance from machine or vehicle hazards. 1.2 Frequency of Operation The Underground Silent Zone Generator will transmit on a frequency of 73 kHz. 1.3 Label Information The Underground Silent Zone Generator label is located on the face of the unit. A picture of the Strata label is below: Confidential Patent #’s 7,420,471 5,939,986 and 6,810,353 Patent Pending Page 4 of 6 Strata Proximity Systems Underground Silent Zone Generator Users Manual v1.0 Confidential and Proprietary December 12, 2011 The Strata label defines the model and serial number of the Underground Silent Zone Generator also MSHA and Commonwealth of Pennsylvania information. 1.3.1.1 MSHA Blasting Distance MSHA has published Program Policy Letter P11-V-07 concening Two Way Communications and Blasting Circuits. SPS magnetic field generators produce a magnetic field that at 100 kHz or .1000 MHz does not achieve the Critical H Field until 1.42 m with a blasting cap having a pickup area of 10 sq. meters. SPS magnetic field generators are safe to 1.42 m from the blasting caps. SPS does recommend a minimum distance of 25’ as a precaution. 1.3.1.2 Pennsylvania Blasting Distance At this date, Pennsylvania has not made a recommendation or statement concerning surface systems. 1.4 FCC Information The FCC ID for the Underground Silent Zone Generator is ZQ3-SPS-USZON. When configured by Strata for underground use, the device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference. (2) This…

Text truncated - open the document above for the full version.

External Photos

Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 Internal & External Photos for FCC Certification Underground Silent Zone Generator – Page 1 of 7 Model: SA221200-1 FCC ID: ZQ3-SPS-USZON Underground Silent Zone Generator – External Photo In Housing Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 Internal & External Photos for FCC Certification Underground Silent Zone Generator – Page 2 of 7 Model: SA221200-1 FCC ID: ZQ3-SPS-USZON Underground Silent Zone Generator – Photo Internal Wire / Ferrite Radiator With Housing Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 Internal & External Photos for FCC Certification Underground Silent Zone Generator – Page 3 of 7 Model: SA221200-1 FCC ID: ZQ3-SPS-USZON Underground Silent Zone Generator – Internal Photo Wire / Ferrite Radiator Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 Internal & External Photos for FCC Certification Underground Silent Zone Generator – Page 4 of 7 Model: SA221200-1 FCC ID: ZQ3-SPS-USZON Underground Silent Zone Generator – External Photo With Controller in Explosion Proof Housing Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 Internal & External Photos for FCC Certification Underground Silent Zone Generator – Page 5 of 7 Model: SA221200-1 FCC ID: ZQ3-SPS-USZON Underground Silent Zone Generator – External Photo With Controller Board in Explosion Proof Housing Housing Open Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 Internal & External Photos for FCC Certification Underground Silent Zone Generator – Page 6 of 7 Model: SA221200-1 FCC ID: ZQ3-SPS-USZON Underground Silent Zone Generator Controller Board – Top View Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 Internal & External Photos for FCC Certification Underground Silent Zone Generator – Page 7 of 7 Model: SA221200-1 FCC ID: ZQ3-SPS-USZON Underground Silent Zone Generator Controller Board – Bottom View

ID Label/Location Info

Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 FCC Label: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Strata Proximity Systems Model: SA221200-1FCC ID: ZQ3-SPS-USZON Strata Proximity Systems LLC 1769 Jeff Road Huntsville, AL 35806 256-830-2008 FCC Label Location: The label is of weatherproof silver polyester as are all of our present labels for harsh environment use. It is laser printer printed and is self stick and supplied on a sheet of 8. It is applied by manufacturing personnel by peeling from the sheet of 8 and pressing on the Surface Proximit y Module at the same the module ident ification label is applied.

Internal Photos

Test Report

Certificates and reports shall not be reproduced except in full, without the written permission of Washington Laboratories, Limited. FCC Certification Test Report For the Strata Proximity Systems Underground Silent Zone Generator Model SA221200-001 FCC ID: ZQ3-SPS-USZON WLL JOB# 12037 November 29, 2011 Prepared for: Strata Proximity Systems 1769 Jeff Road Huntsville, AL 35806 Prepared By: Washington Laboratories, Ltd. 7560 Lindbergh Drive Gaithersburg, Maryland 20879 Testing Certificate AT-1448 Strata Proximity Systems Underground Silent Zone Generator FCC Certification Test Report November, 2011 WLL Report #12037-01 ii © 2011 Washington Laboratories, Ltd FCC Certification Test Report for the Strata Proximity Systems Underground Silent Zone Generator Model SA221200-001 FCC ID: ZQ3-SPS-USZON November 29, 2011 WLL JOB# 12037 Prepared by: Steven Dovell Compliance Engineer Reviewed by: Michael F. Violette President Strata Proximity Systems Underground Silent Zone Generator FCC Certification Test Report November, 2011 WLL Report #12037-01 iii © 2011 Washington Laboratories, Ltd Abstract This report has been prepared on behalf of Strata Proximity Systems to support the attached Application for Equipment Authorization. The test report and application are submitted for a Transmitter under Part 15.209 (10/2009) of the FCC Rules and Regulations. This Certification Test Report documents the test configuration and test results for the Strata Proximity Systems Underground Silent Zone Generator. Testing was performed on an Open Area Test Site (OATS) of Washington Laboratories, Ltd, 7560 Lindbergh Drive, Gaithersburg, MD 20879. Site description and site attenuation data have been placed on file with the FCC's Sampling and Measurements Branch at the FCC laboratory in Columbia, MD. The Industry Canada OATS numbers are 3035A-1 and 3035A-2 for Washington Laboratories, Ltd. Site 1 and Site 2, respectively. Washington Laboratories, Ltd. has been accepted by the FCC and approved by ACLASS under Certificate AT-1448 as an independent FCC test laboratory. The Strata Proximity Systems Underground Silent Zone Generator complies with the limits for a Transmitter device under FCC Part 15.209. Revision History Description of Change Date Rev 0 Initial Release November 29, 2011 Strata Proximity Systems Underground Silent Zone Generator FCC Certification Test Report November, 2011 WLL Report #12037-01 iv © 2011 Washington Laboratories, Ltd Table of Contents Abstract ............................................................................................................................... ii 1 Introduction ..............................................................................................................1 1.1 Compliance Statement ........................................................................................ 1 1.2 Test Scope ........................................................................................................... 1 1.3 Contract Information ........................................................................................... 1 1.4 Test Dates ........................................................................................................... 1 1.5 Test and Support Personnel ................................................................................ 1 1.6 Abbreviations ...................................................................................................... 2 2 Equipment Under Test .............................................................................................3 2.1 EUT Identification & Description ...................................................................... 3 2.2 Test Configuration .............................................................................................. 4 2.3 Equipment Configuration.................................................................................... 4 2.4 Testing Algorithm ............................................................................................... 5 2.5 Test Location ...................................................................................................... 5 2.6 Measurements ..................................................................................................... 5 2.6.1 References ....................................................................................................... 5 2.7 Measurement Uncertainty ................................................................................... 5 3 Test Equipment ........................................................................................................7 4 Test Results ..............................................................................................................8 4.1 Occupied Bandwidth: (FCC Part §2.1049) ......................................................... 8 Radiated Spurious Emissions: (FCC Part §15.209) ........................................................ 9 4.1.1 Test Procedure ................................................................................................ 9 List of Tables Table 1. Device Summary ................................................................................................... 3 Table 2: Equipment Configuration ..................................................................................... 4 Table 2: Expanded Uncertainty List ................................................................................... 6 Table 3: Test Equipment List .............................................................................................. 7 Table 4. Radiated Emissions Limits ................................................................................... 9 Table 5. Radiated Emissions Test Data < 30MHz ............................................................ 10 Table 6. Radiated Emissions Test Data > 30MHz ............................................................ 11 List of Figures Figure 1: Test Configuration ....…

Text truncated - open the document above for the full version.

Test Report

Response to ATCB Comments ZQ3-SPS-USZON 1 Washington Laboratories, Ltd. 7560 LINDBERGH DRIVE GAITHERSBURG, MD 20879 (301) 216 - 1500 FAX # (301) 216 - 1590 January 16, 2012 Mr. Richard Fabina American Telecommunications Certification Body Inc. 6731 Whittier Ave McLean, VA 22101 RE: Comments of January 11, 2012 APPLICATION: ATCB011650; ZQ3-SPS-USZON for Strata Proximity Systems Dear Mr. Fabina: Below are the comments that you have provided regarding the application for certification referenced above. Our responses to those comments are in bold italic. Many responses refer you to additional exhibit(s) which has been uploaded to the application folder at the ATCB website. Thank you for your attention. Please feel free to contact us for any additional information that you may require. Regards, James Ritter EMC Compliance Engineer WLL Project: 12037 1) Please either provide AC line conducted emissions tests with this device being powered by the AC power lines or provide justification on why these tests are not required. Section 15.207( c) of the FCC Rules states “Devices that include, or make provisions for, the use of battery chargers which permit operating while charging, AC adapters or battery eliminators or that connect to the AC power lines indirectly, obtaining their power through another device which is connected to the AC power lines, shall be tested to demonstrate compliance with the conducted limits.” Section 2.2 of the submitted test report shows the EUT being powered from support equipment which is being powered by the AC mains network. R. The manufacturer has advised us that this equipment is for mining operations and will not be connected directly or indirectly to the public mains, only independent powered equipment such as vehicle batteries. The setup referred to in Section 2.2 of the test report showing the device connected to a lab DC power supply was used only for lab testing purposes and does not reflect the actual final field power installation configuration.

Test Setup Photos
