ZRYAM3Activity Monitor

EN Wireless Activity and Sleep Tracker Quick Start Guide WELCOME Welcome to your iHealth Wireless Activity and Sleep Tracker, a device that tracks your daily activity and sleep. This Tracker, along with the free iHealth MyVitals app, can keep you motivated and help you stay on track to a more active and healthier lifestyle. Box Contents Wearing the Tracker Wear your tracker on your wrist or waist during the day to track your daily activity, and wear it on your wrist at night to track your sleep. Charging the Battery Your iHealth Wireless Activity and Sleep Tracker contains a built-in rechargeable battery. Plug one end of the charging cable into the USB port on the back of the Tracker, and the other into your computer’s USB port, and charge for approximately two hours before first use. A battery level indicator will appear in the Tracker’s display area. A fully charged battery will typically last 5–7 days. Download App Download the “iHealth MyVitals” app from the App Store. Your compatible iOS device should be version 5.0 or later. Create User and Cloud Account After downloading the app, register and set up your user account following the on-screen instructions. Upon setting up your user account, you will also have access to a free, secure iHealth Cloud account. Go to www.ihealthlabs.com, then click “Sign In” to access your cloud account from PC or Mac. Bluetooth Connection Your iHealth Wireless Activity and Sleep Tracker uses Bluetooth 4.0 technology. Turn on Bluetooth on your iOS device, open the app, and follow the onscreen instructions for first-time connection. Subsequently, the Tracker will automatically connect to your mobile device each time you open the app. If your Tracker’s battery is drained, charge the battery fully, then open your app to reestablish the Bluetooth connection before using it again. A reminder message— “Launch the app to start”— will appear on the Tracker display. Data Syncing Your activity and sleep stats are sent to your mobile app automatically when you open the app. Your Tracker can save up to 14 days’ worth of stats between syncing. Daily syncing is recommended. Activity Tracking Your iHealth Wireless Activity and Sleep Tracker is always tracking. View your steps, calories, and distance stats by pressing the button on the tracker. Activity stats reset at midnight to zero. Sleep Tracking To start tracking your sleep, press and hold the button on the Tracker for 2 seconds until you see “sleep” on the Tracker display. When you are awake, press and hold the same button for 2 seconds to end sleep tracking and resume activity tracking. Sleep stats will appear on your app after syncing. Silent Alarms When you set a silent alarm from the iHealth MyVitals app, your Tracker will vibrate gently on your wrist to either wake you up or remind you to be more active. Airplane Mode Turn on the “airplane” mode to disable Bluetooth connection while in flight (app->device setting). Press and hold the button on the Tracker for 2 seconds to disable airplane mode and resume activity tracking. IMPORTANT INFORMATION REQUIRED BY THE FCC This device complies with Part 15 of the FCC Rules. Its operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by iHealth Lab Inc. would void the user’s authority to operate the product. NOTE: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1 Tracker2 Colored wrist bands and matching waist clips 1 USB cable for charging —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Visit www.ihealthlabs.com for additional product information. For Customer Service, please call 1(855) 816-7705. WELCOME Welcome to your iHealth Wireless Activity and Sleep Tracker, a device that tracks your daily activity and sleep. This Tracker, along with the free iHealth MyVitals app, can keep you motivated and help you stay on track to a more active and healthier lifestyle. Box Contents Wearing the Tracker Wear your tracker on your wrist or waist during the day to track your daily activity, and wear it on your wrist at night to track your sleep. Charging the Battery Your iHealth Wireless Activity and Sleep Tracker contains a built-in rechargeable battery. Plug one end of the charging cable into the USB port on the back of the Tracker, and the other into your computer’s USB port, and charge for approximately two hours before first use. A battery level indicator will appear in the Tracker’s display area. A fully charged battery will typically last 5–7 days. Download App Download the “iHealth MyVitals” app from the App Store. Your compatible iOS device should be version 5.0 or later. Create User and Cloud Account After downloading the app, register and set up your user account following the on-screen instructions. Upon setting up your user account, you will also have access to a free, secure iHealth Cloud account. Go to www…

Text truncated - open the document above for the full version.

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Request for Confidentiality Date: 2013-3-7 ____ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ _____Andon Health Co.,Ltd_____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Project Manager_ ____ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. Subject: Confidentiality Request for: _____FCC IKD:ZRYAM3

SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix A Page: 1 of 4 Page 1 of 4 AM3 External Photos Application No.: SHEM1302000239ME Applicant: Andon Health Co., Ltd Address of Applicant: No. 3 JinPing Street, YaAn Road, Nankai District, Tianjin 300190, China Equipment Under Test (EUT): Product Name: Activity Monitor Brand Name: iHealth Model No.: AM3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix A Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS..........................................................................................................2 2 EXTERNAL PHOTOS........................................................................................3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix A Page: 3 of 4 Page 3 of 4 2 External Photos Front View Top View SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix A Page: 4 of 4 Page 4 of 4 Rear View End

SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix B Page: 1 of 4 Page 1 of 4 AM3 Internal Photos Application No.: SHEM1302000239ME Applicant: Andon Health Co., Ltd Address of Applicant: No. 3 JinPing Street, YaAn Road, Nankai District, Tianjin 300190, China Equipment Under Test (EUT): Product Name: Activity Monitor Brand Name: iHealth Model No.: AM3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix B Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS..........................................................................................................2 2 INTERNAL PHOTOS.........................................................................................3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix B Page: 3 of 4 Page 3 of 4 2 Internal Photos SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix B Page: 4 of 4 Page 4 of 4 End

SGS-CSTC Standards Technical Services（ （（ （Shanghai） ）） ） Co., Ltd. No. 588 West Jindu Road, Songjiang District, Shanghai, China Telephone: +86 (0) 21 61915666 Fax: +86 (0) 21 61915678 [email protected] Report No.: SHEM130200023906 Page 1 of 11 Tony Wu E&E Section Manager SGS-CSTC (Shanghai) Co., Ltd. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only FCC MPE REPORT Application No.: SHEM1302000239ME Applicant: Andon Health Co., Ltd Equipment Under Test (EUT): NOTE: The following sample(s) submitted was/were identified on behalf of the client as Product Name: Activity Monitor Brand Name: iHealth Model: AM3 Added Model: N/A FCC ID: ZRYAM3 Standards: 47 CFR Part 1.1307(2011) 47 CFR Part 2.1093 (2011) KDB447498 D01 Date of Receipt: Feb.22, 2013 Date of Test: Feb.27, 2013 Date of Issue: Mar.15, 2013 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services（ （（ （Shanghai） ）） ） Co., Ltd. Report No.: SHEM130200023906 Page: 2 of 11 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only Version Revision Record Version Chapter Date Modifier Remark 00 / Mar.15, 2013 / Original Authorized for issue by: Zenger Zhang Engineer Print Name Amy Wang Clerk Print Name Keny Xu Reviewer Print Name SGS-CSTC Standards Technical Services（ （（ （Shanghai） ）） ） Co., Ltd. Report No.: SHEM130200023906 Page: 3 of 11 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only 2 Contents Page 1 COVER PAGE .............................................................................................................. 1 VERSION.............................................................................................................................................1 VERSION.............................................................................................................................................2 2 CONTENTS....…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 588 W est Jindu Road,Songjiang District,Shanghai,China Telephone: +86 (0) 21 6191 5666 Fax: +86 (0) 21 6191 5678 [email protected] Report No.: SHEM130200023901 Page 1 of 41 Tony Wu E&E Section Manager SGS-CSTC (Shanghai) Co., Ltd. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only FCC Part 15C TEST REPORT Application No. : SHEM1302000239ME Applicant: Andon Health Co., Ltd FCC ID: ZRYAM3 Equipment Under Test (EUT): NOTE: The following sample(s) submitted was/were identified on behalf of the client as Product Name: Activity Monitor Brand Name: iHealth Model: AM3 Added Model: N/A Standards: FCC PART 15 Subpart C: 2011 Date of Receipt: Feb.22, 2013 Date of Test: Feb.27, 2013 to Mar.07, 2013 Date of Issue: Mar.15, 2013 Test Result : PASS * *In the configuration tested, the EUT detailed in this report complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM130200023901 Page: 2 of 41 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only Version Revision Record Version Chapter Date Modifier Remark 00 / Mar.15, 2013 / Original Authorized for issue by: Engineer Zenger Zhang Print Name Clerk Amy Wang Print Name Reviewer Keny Xu Print Name SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM130200023901 Page: 3 of 41 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement FCC Part 15, Subpart C Section 15.203/15.247 (c) --- PASS AC Power Line Conducted Emission FCC Part 15, Subpart C Section 15.207 ANSI C63.10 (2009) Section 6.2 PASS Minimum 6dB Bandwidth FCC Part 15, Subpart C Section 15.247 (a)(2) ANSI C63.10 (2009) Section 6.9 PASS Conducted Peak Output Power FCC Part 15, Subpart C Section 15.247 (b)(3) ANSI C63.10 (2009) Section 6.10 PASS Power Spectrum…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix C Page: 1 of 4 Page 1 of 4 AM3 Test Setup Photos Application No.: SHEM1302000239ME Applicant: Andon Health Co., Ltd Address of Applicant: No. 3 JinPing Street, YaAn Road, Nankai District, Tianjin 300190, China Equipment Under Test (EUT): Product Name: Activity Monitor Brand Name: iHealth Model No.: AM3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix C Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS..........................................................................................................2 2 TEST PHOTOS...................................................................................................3 2.1 RADIATED EMISSION TEST SETUP.........................................................................3 2.2 CONDUCTED EMISSIONS ON MAINS TERMINALS TEST SETUP...............................4 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix C Page: 3 of 4 Page 3 of 4 2 Test Photos 2.1 Radiated Emission Test Setup 30MHz to 1GHz Above 1GHz SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1302000239ME －Appendix C Page: 4 of 4 Page 4 of 4 2.2 Conducted Emissions on Mains Terminals Test Setup End
