ZUZ-VSPHOENIXSELECTRONIC DART SYSTEM

HONG International Corp.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: May 09, 2012
Application Purpose: Original Equipment
Date of Application: May 09, 2012
Equipment Note: ELECTRONIC DART SYSTEM
Frequency Range: 13.56000000 - 13.56000000
Company: HONG International Corp.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Cover Letter(s)

FCC, Request for non-disclosure Date: April 27, 2012 Page 1 of 1 HONG International Corp. #306 JNK Digital Tower, Digitalro-26gil, Guro-dong, Guro-gu, Seoul, Republic of Korea Subject: Request for confidentiality FCC ID: ZUZ-VSPHOENIXS Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby request confidential treatment of information accompanying this application as outlined below: ☑ Block Diagrams ☑ Operational Description ☑ Schematic Diagrams the above materials contain trade secrets and pr oprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. <City> Seoul-si <Name and signature of applicant> Choong-Jae, Lee / Assistant Manager HONG International Corp. Tel : 82-2-3667-3986 Fax : 82-2-3667-3987 E-mail : [email protected]

Cover Letter(s)

HONG International Corp. #306 JNK Digital Tower, Digitalro-26gil, Guro-dong, Guro-gu, Seoul, Republic of Korea April27, 2012 Subject: DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: ZUZ-VSPHOENIXS, would like to declare that the composite portion categorized as computer peripheral hasbeen authorized under the Declaration of Conformity procedures. Test Laboratory : Korea Standard Quality Laboratories #102, Jangduk Dong, Hwasung City, Kyunggi Do, South Korea Regards, Signature: Name/Title: Tony Ohm / Assistant Manager Company Name:HONG International Corp. Address: #306 JNK Digital Tower, Digitalro-26gil, Guro-dong, Guro-gu, Seoul, Republic of Korea TEL: 82-2-3667-3986 FAX: 82-2-3667-3987 Email: [email protected]

ID Label/Location Info

FCC ID : ZUZ-VSPHOENIXS IC : 9811A-VSPHOENIXS M/N : VSPHOENIXS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received. including interference that may cause undesired operations. Made in Korea. 1. Label Location & Label Drawing

Internal Photos

Parts List/Tune Up Info

TRF No.: EN 60335-2-82 F Attachments 3 : List of Critical Components Component (Part no.) Manufacturer(Brand) Mode(Type) Rating or Characteristics Tested by Plug I-Sheng Manufacturing ( SongGang) Factory SP-022 250 V~, 16 A CE Cord I-Sheng Manufacturing ( SongGang) Factory - 60227 IEC 53 (H05VV-F), 3G0.75 ㎟ CE Appliance couplers (Connector) I-Sheng Manufacturing ( SongGang) Factory IS-14 250 V~, 10 A CE Noise Filter Set Applianc e couplers (Applianc e Inlet) Dong il Technology Ltd DAC-4 250 V~, 10 A CE Noise Filter Dong il Technology Ltd IH-1022-H 250 V~, 10 A CE Current fuse Holder Schurter AG FPG 1 250 V~, 10 A CE Current Fuse Suzhou Littelfuse OVS.LTD 312 250 V~, 5 A CE Rocker Switch (Power) Ningbo Yinxian Lihe Switch Factory RL2 250 V~, 16 A CE Micro-Switch (Control_6EA) Qingdao Daesung Electronics Co., Ltd VP333A-0D 250 V~, 5 A CE TFT-LCD (Top) LG Display Co., Ltd LM230WF3 12d.c., 0.475 A CE SMPS (TFT-LCD_Top) Yantai Sam Hwa Polymers Co., Ltd. SAD04212-UV- 36 100-240 V~, 50/60 ㎐, 1.0 A (O/P : 12 Vd.c., 3 A) CE TFT-LCD (Bottom) LG Display Co., Ltd LM230WF3 12d.c., 0.475 A CE 직류전원장치 (TFT- LCD_Bottom) Yantai Sam Hwa Polymers Co., Ltd. SAD04212-UV- 36 100-240 V~, 50/60 ㎐, 1.0 A (O/P : 12 Vd.c., 3 A) CE SMPS Part(NES-50-24) TRF No.: EN 60335-2-82 PCB SHUNDE JUNDA ELECTRONIC CO LTD JD-D V-0 CE Current Fuse (FS1) Suzhou Walter Electronic Co., Ltd FSD 3.15A 250 V~, 3.15 A CE X-Capacitor (C1) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.47 ㎌, X2 CE Line Filter(LF1) Mean Well LF-133-R1 15 mH, Class B CE X-Capacitor (C2) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.1 ㎌, X2 CE Y-Capacitor (C3, C4) PT.Samcon SD 250 V~, 2 200 ㎊, Y1 CE Y-Capacitor (C30) PT.Samcon SD 250 V~, 4 700 ㎊, Y1 CE Transformer (S/W, T1) Mean Well TF-1013 Class B CE Y-Capacitor (C31) PT.Samcon SD 250 V~, 1 000 ㎊, Y1 CE Photocouper (U2, U3) SHARP PC123 Viso : 5 000 Vrms CE SMPS Part (NES-75-12) PCB SHUNDE JUNDA ELECTRONIC CO LTD JD-D V-0 CE Current Fuse (FS1) Suzhou Walter Electronic Co., Ltd FSD 3.15A 250 V~, 4 A CE X-Capacitor (C1) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.47 ㎌, X2 CE Line Filter(LF1) Mean Well LF-132-R1 15 mH, Class B CE X- Capacitor (C2) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.1 ㎌, X2 CE Y- Capacitor (C3, C4) PT.Samcon SD 250 V~, 4 700 ㎊, Y1 CE TRF No.: EN 60335-2-82 Y-Capacitor (C23) PT.Samcon SD 250 V~, 1s00 ㎊, Y1 CE Y- Capacitor (C30) PT.Samcon SD 250 V~, 220 ㎊, Y1 CE Transformer (S/W, T1) Mean Well TF-1302 Class B CE Y- Capacitor (C31) PT.Samcon SD 250 V~, 1 000 ㎊, Y1 CE Photocupler (U2, U3) SHARP PC123 Viso : 5 000 Vrms CE SMPS (Mainboard) Sea Sonic Electronics Co., Ltd SS-350ES 100-240 V~, 50/60 ㎐, 350 W CE Speaker (Built-in Amp) Guangzhou Yingxin Electronic Limited Pan Yu Manufacture Base S2-600B 220-240 V~, 50/60 ㎐, 22 W CE Enclosure (Front) LG Chemical - PP, HB - Enclosure - - Wood -

Test Report

Report Number : KSQ-FCC120405 FCC ID : ZUZ-VSPHOENIXS, IC : 9811A-VSPHOENIXS Page 1 /24 1. Applicant Name: HONG International Corp. Address: #306 JNK Digital Tower, Digitalro-26gil, Guro-dong, Guro-gu, Seoul, Republic of Korea FCC ID: ZUZ-VSPHOENIXS IC: 9811A-VSPHOENIXS 2. Products Name: Electronic Dart System Model/Type: -VSPHOENIXS / Electronic Dart System Manufacturer: HONG International Corp. 3. Test Standard: 47 CFR FCC Part 15 Subpart C RSS-210 Issue 8, RSS-Gen Issue 3 4. Test Method: ANSI C63.4-2009 5. Test Result: Positive 6.Dates of Test: March 10, 2012 to May 05, 2012 7. Date of Issue: May 07, 2012 8. Test Laboratory: Korea Standard Quality Laboratories FCC Designation Number : KR0024 IC OATS Number : 9053A Tested by Approved by Soon Ho, Kim SungBum, Hong Test Engineer: Compliance Engineer: This report may not be reproduced without the full written consent of Korea Standard Quality Laboratories. Korea Standard Quality Laboratories TEST REPORT Part 15 Subpart C 15.225 Report Number : KSQ-FCC120405 FCC ID : ZUZ-VSPHOENIXS, IC : 9811A-VSPHOENIXS Page 2 /24 CONTENTS Page 1. VERIFICATION OF COMPLIANCE..............................................................................................................................................................5 2. GENERAL INFORMATION..............................................................................................................................................................6 . 2.1 PRODUCT DESCRIPTION..................................................................................................................................................................................6 2.2 MODEL DIFFERENCES: ....................................................................................................................................................................................6 2.3 RELATED SUBMITTAL(S) /GRANT(S)...........................................................................................................................................................6 2.4 PURPOSE OF THE TEST .................................................................................................................................................................................6 2.5 TEST METHODOLOGY.......................................................................................................................................................................................6 3. SYSTEM TEST CONFIGURATION...............................................................................................................................................7 3.1 JUSTIFICATION ....................................................................................................................................................................................................7 3.2 PERIPHERAL EQUIPMENT................................................................................................................................................................................7 3.3 MODE OF OPERATION DURING THE TEST...........................................................................................................................................7 3.4 CABLE DESCRIPTION FOR THE EUT ........................................................................................................................................................7 3.5 EQUIPMENT MODIFICATIONS .....................................................................................................................................................................7 3.6 CONFIGURATION OF TEST SYSTEM ........................................................................................................................................................8 3.7 ANTENNA REQUIREMENT .............................................................................................................................................................................8 4. PRELIMINARY TEST..........................................................................................................................................................................8 4.1 ACPOWER LINE CONDUCTED EMISSIONS TESTS..............................................................................................................................8 4.2 RADIATED EMISSIONS TESTS .....................................................................................................................................................................8 5. FINAL RESULT OF MEASURMENT............................................................................................................................................9 5.1 CONDUCTED EMISSION TEST.......................................................................................................................................................................9 5.2 Emission Test ....................................................................................................................................................................................................11 5.2.1 Radiated Emissions ............................................................................................................................................................................11 5.2.1.1 Regulation.............................................................................................................................................................................................11 5.2.1.2 Measurement Procedure .............................................................................................................................................................11 5.2.1.3 Calculation of the field strength limits below 30 MHz...............................................................................................12 5.2.1.4 Test Results ...................................................................…
